Sunjoy D-GZ209PST-H User manual

1/ 6
Assembly Instructions
Item# D-GZ209PST-H

2/ 6
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or
install the product. For technical assistance on assembly or replacement parts. Please call
Sunjoy Industries at 1(866) 578-6569 from 8:00 am EST to 8:00 pm PST.
WARNING:
1.When installing and assembling your gazebo, it is recommended that 2 or more adults are
involved.
2.This product is intended for outdoor use only and should be placed on flat, horizontal ground.
3.Ensure enough clearance around the product.
4.Do not use the unit during an electrical storm, as there is a remote chance of getting struck
by lightening.
5.Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury, possibly
even death.
6.Never barbecue under this gazebo or use lanterns that contain naked flames.
7.This package contains small items and plastic bags that should be kept away from children.
8.Ensure that all connectors & poles are firmly secured in position fully. It is important to do so
before use so as to avoid collapsing or damage to the item, which could result in injury.
9.WARNING: Keep all flame and heat sources away from this tent fabric. This tent is made
with fabric that meets CPAI - 84 specifications for flame resistance. It is not fire proof. The
fabric will burn if left in continuous contact with any flame source. The application of any
foreign substance to the tent fabric may render the Flame-resistant properties ineffective.
10. WARNING: Please take down the gazebo during strong wind. The manufacturer or retailer
is not liable for any loss of the product or other items due to the failure to take down the gazebo
during strong wind.
11. Hook maximum weight: 26 lbs.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list. If any part is missing or damaged, do not attempt to assemble the
product.
Estimated Assembly Time: 10 minutes.
No Tools Required for Assembly!

3/ 6
Description
Part
Quantity
Finial
A
1
Top connector
B
1
Short oblique beam
C
4
Connector
D
1
Top Hook
E
1
Middle beam
F
4
Long oblique beam
G
4
Oblique beam
H
4
Beam
I
4
Shelf
J
4
Screen
K
4
Big canopy
L
1
Small canopy
M
1
Parts List

4/ 6
Fig.1:Insert Beam (I) into Screen (K).
Fig.3: Insert Long oblique beam
(G) into the Connect tube (D).
Fig.2: Insert Long oblique beam
(G) into Oblique beam (H).
Fig.4: Insert Oblique beam (H)
into Screen (K).

5/ 6
Fig.8: Put on the Small
canopy (M) on small top.
Hardware Pack
FF
Dia.6x180MM Stake
16 PCS
Fig.5: Insert Middle beam (F) into
Connector (D), then assemble the
Top hook (E) on the connector (D).
Fig.7: Insert Short oblique beam
(C) into Top connector (B).
Fig.6: Insert Middle beam (F) into
Beam (I). Put on the Big canopy
(L) and do not unfold first.
Fig.10: Insert the assembled
small dome into Long oblique
beam (G) by Short oblique beam
(C).
Fig.9: Insert Finial (A) into Top
connector (B).

6/ 6
Fig.11: Expand Big
canopy (L), secure it to
the four corners of the
oblique beam and the
middle beam.
Fig.12:Put Shelf (J) on
Screen (K).
CARE AND MAINTENANCE
This gazebo is intended for decorative and sunshade purposes only, and is not designed to
withstand hard weather, including high winds, rain, and snow. In order to avoid damages,
remove accumulated water on the roof immediately, or disassemble the gazebo. Disassemble
the gazebo in the reverse order of the assembly steps.
Always disassemble the gazebo completely. A partially disassembled gazebo is not stable
enough to resist wind and bad weather, and therefore can be damaged and/or cause damage.
Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts.
Steel components of garden accessories and furniture are treated with rust inhibiting paint.
However, due to the nature of steel, surface oxidation (rusting) will occur if this protective
coating is scratched. This is a natural process. To minimize this condition, it is recommended
that care be taken when assembling and handling the product, in order to prevent the paint
from being scratched.
Surface rust can be removed easily using a very light application of common cooking oil. If
surface oxidation (rusting) occurs and no measures are taken to correct it, the oxidation may
start dripping onto the assembly surface, which may cause damaging stains that may be
difficult to remove.
If the product will not be used for a long period (e.g. winter time), it should be stored in a clean,
dry environment.
Keep the original packaging to store the gazebo.
Important: Please do not return this product to the store. For technical assistance on
assembly or replacement parts. Please call Sunjoy Industries at 1-866-578-6569 from 8:00 am
EST to 8:00 pm PST or fax the replacement part form which is in the box to 1-740-283-3549 or
Email [e-mail] for assistance.
Made in China
2016-04
Fig.13: Secure the gazebo
to the ground by using the
Stakes (FF).
