Sunjoy S-DN012-T User manual

IMPORTANT
1. When installing and assembling your bar, it is recommended that 2 or more adults are involved.
2. This product should be placed on flat, horizontal ground.
3. Ensure enough clearance around the product.
4. Do not leave the bar assembled when there is a risk of high wind, as damage may occur to the structure.
5. This package contains small items and plastic bags that should be kept away from children.
6. Ensure that all connectors & poles are firmly secured in position fully. It is important to do so before use so as
to avoid collapsing or damage to the item, which could result in injury.
7. WARNING: Keep flame and heat sources away from the bar fabric. The fabric may burn if it is exposed to
prolonged contact with a source of heat.
8. WARNING: Please take down the bar during strong wind. The manufacturer or retailer is not liable for any
loss of the product or other items due to the failure to take down the bar during strong wind.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Assembly Instructions: Aspen Sling Bar
Item# S-DN012-T

No. Description Qty
A Top Arc Tube 2
B Plastic Screw 2
C Top Horizontal Pipe 2
D Upper Round Tube 1
E Upper Arc Tube 2
F Table Top 1
G Front Coaming 1
H Side Coaming 1 1
I Side Coaming 2 1
J Connector 4
K Clapboard 2
L Canopy 1
No. Description Qty
AA Bolt M6*15 10
BB Flat washer M6 23
CC Bolt M6*25 5
DD Bolt M6*40 4
EE Nut 4
FF Wrench 1
GG Hex key 1
Step 1:Connect Connector (J) , Side Coaming 1 (H) and Front Coaming (G) with Bolt (AA) and Flat Washer
(
BB
)
. Connect Connector
(
J
)
, Side Coamin
g
2
(
I
)
and Front Coamin
g
(
G
)
in the same wa
y
.
Parts List
Hardware List

Step 2: Insert Clapboard (K) into the connector of Side Coaming 1 (H) and Side Coaming 2 (I) according to
arrow direction.
Step 3: Put the Table Top (F) on the assembled frame according to arrow direction, connecting Table Top
(F), Side Coaming 1 (H), Side Coaming 2 (I) and Front Coaming (G) with Bolt (CC) and Flat Washer (BB)

Step 4: Put Upper Arc Tube (E) on the Table Top (F) according to arrow direction. And connecting Upper
Arc Tube (E) and the Table Top (F) with Bolt (DD), Flat Washer (BB) and Nut (EE).
Step 5: Connecting the connector of Upper Arc Tube (E) and Upper Round Tube (D) with Bolt (AA) and Flat
Washer (BB)

Step 6: Aligning the plastic’s tooth of Top Arc Tube (A) to the plastic’s tooth of Upper Arc Tube ( E), then
connecting the plastic parts with plastic screw (B).
Step 7: Insert the Top Horizontal Pipe (C) into the Canopy (L) according to arrow direction.

WARNINGS
1. Assembly Instructions must be followed.
2. Warranty does not cover damage due to extreme weather conditions.
CUSTOMER SERVICE
Sunjoy Industries warrants to the original purchaser that this item is free from defects in workmanship and
materials of your item provided the item was factory-sealed at the time of purchase and is maintained with care
and used only for personal, residential purposes. The item is warranted to be free from defects in material or
workmanship for a period of 6 months. Should any manufacturing defect arise within this warranty period, Sunjoy
Industries will repair or replace (at our option) any defective merchandise upon proof of purchase; however,
transportation and delivery costs, as well as labor and material charges to remove or replace parts, remain the
responsibility of the purchaser. A purchaser of an "open box," previously-returned, or "clearance" item, as well as
original purchasers outside of the warranty period, may obtain replacement parts from Sunjoy Industries for
products in current production, at nominal cost.
If you are within the return policy that most stores have, you do have the option of returning this item back to the
store which you bought it from for an exchange of the same item, or a refund of the purchase.
Step 8: Insert the Top Horizontal Pipe (C) into Top Arc Tube (A) , then spread out the Canopy (L) .

If you are within or beyond the return policy that most stores have, and need tech. assistance or replacement
parts, please call Sunjoy Industries at 1(866) 578-6569 from 8:30 am to 4:30 pm eastern standard time or write
e-mails to [e-mail] or visit www.sunjoydirect.com to place your order or fax your parts
replacement order form together with the purchase receipt to 1 [phone] for assistance.
Made in China
