A10
2012800
WE HAVE YOU IN MIND, LET US SERVE YOU!
Nous pensons en vous, laissez nous vous aider!
Questions? Issues? / Questions? Problèmes?
CONTACT US / Contactez-nous
[e-mail]
www.sunjoyonline.com

2 / 59
Country of Origin: China
Pais d’origine: Chine
 This product is intended for domestic outdoor use only.
 The product should be placed on flat, horizontal ground.
 Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as fences,
garages, houses, overhanging branches, laundry lines, or electrical wires.
 This gazebo is not to be regarded as part of a building/house structure. The gazebo is to be
anchored onto the ground for added safety. Do not assemble the gazebo onto soil/earth
ground. It is best advisable to have the gazebo built onto a wooden deck or concrete ground
for stability. If it is to be build onto a wooden deck/ground, do ensure that the wooden
deck/ground has a strong foundation. It is advisable to use appropriate floor plugs (not
provided) to anchor the gazebo onto the wooden/concrete ground.
 Some structures may require two or more people to install safely. Check for underground
utilities before digging or driving stakes into the ground.
 During installation, follow all safety warnings provided with your tools, and use safety glasses.
 In case you set up more than one gazebo, keep a minimum distance of 10' (3 m) between the
gazebos.
 Any assembly or maintenance of the product must be carried out by adults only.
 Arrange necessary manpower when assembling or moving the product.
 Some parts may contain sharp edges. Wear protective gloves if necessary.
 Keep children and pets away while setting up the gazebo.
 Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
 Repairing and replacing parts should be done by a qualified technician.
 This gazebo is intended for decorative and sunshade purposes only, and it is not designed to
withstand harsh weather, including high winds, rain, and snow.
 Do not light any fires inside or near the product！
 Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
 firemen allow you to do so.
 Do not hang heavy weights on the roof frame.
 Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
 Retain the original packaging to store the gazebo.
Important Safety Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution! Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped.
Do not attempt to assemble the gazebo if any parts are missing.

3/ 59
Country of Origin: China
Pais d’origine: Chine
Consignes de sécurité importantes
ATTENTION! 





Avertissement!



•
•
•



• 
 
 
 
 

•

•

• 

•
•
•
•
•

•
•

•
•

•
•

•

4 / 59
Country of Origin: China
Pais d’origine: Chine
• Please read and understand this manual before any assembly. Before beginning
assembly of product, make sure all parts are present. Compare parts with packaging
contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position them on the floor in front of you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Read each step carefully before beginning any assembly and make sure you understand each
step. If you are missing a part, please email [e-mail].
•Needed for assembly:（The following tools are not included）
IMPORTANT:
Cordless drill Hammer Screwdriver Ladder 5people

5/ 59
Country of Origin: China
Pais d’origine: Chine
IMPORTANT:
•

•
•

•

•





Utilisez un niveau


Véfifiez avec un équerre


Serrer les boulons Mesurer la distance




   5 personnes

6 / 59
Country of Origin: China
Pais d’origine: Chine
EXPLODED DRAWING/ DESSIN ÉCLATÉ

7 / 59
Country of Origin: China
Pais d’origine: Chine
EXPLODED DRAWING/ DESSIN ÉCLATÉ

8 / 59
Country of Origin: China
Pais d’origine: Chine
Parts List
Label Part Number Description Qty Part Image
01 P00020068001 Post 1 2
02 P00630012701 Screen 1 2
03 P00630012801 Screen 2 1
04 P00630012901 Screen 3 1
05 P00230009501 Shelf 4
06 P00410017201 Storage Door Panel
1 2
08 P00380063901 Storage Side Panel 2
A P00610023401 Base Cover 2
B P00010046201 Post Base 2
C P00020068301 Post 4 2
D P00020068101 Post 2 2
E P00010046301 Screen Base 4

9 / 59
Country of Origin: China
Pais d’origine: Chine
Liste de Pièces
Étiquette Numéro de la Pièce Description Quantité Numéro de la Pièce Diagramme
01 P00020068001 Poteau 1 2
02 P00630012701 Façade 1 2
03 P00630012801 Façade 2 1
04 P00630012901 Façade 3 1
05 P00230009501 Étagère 4
06 P00410017201
Panneau de la
Porte du Coffre de
Stockage 1
2
08 P00380063901 Panneau Latéral du
Coffre de Stockage 2
A P00610023401 Barde de la base 2
B P00010046201 Poteau Base 2
C P00020068301 Poteau 4 2
D P00020068101 Poteau 2 2
E P00010046301 Façade Base 4

10 / 59
Country of Origin: China
Pais d’origine: Chine
F P00070106101 Screen Cover 4
G P00020068201 Post 3 2
J P00010046401 Storage Base 1 2
L P00040129801
Middle
Gutter (Short
Side)
2
M P00040130501
Short Side Left
Gutter (For
Steel Post)
1
N P00040130601
Short Side Right
Gutter (For
Wood Post)
1
P P00050028101 Cross Beam
Connector 2 8
Q P00050028001 Cross Beam
Connector 1 8
R P00040130301
Short Side Left
Gutter (For
Wood Post)
1
S P00040130401
Short Side Right
Gutter (For
Steel Post)
1
T P00040129701 Middle Gutter
(Long Side) 2
U P00040129901
Long Side Left
Gutter (For
Wood Post)
1
V P00040130001
Long Side Right
Gutter (For
Wood Post)
1

11 / 59
Country of Origin: China
Pais d’origine: Chine
F P00070106101 Façade couverture 4
G P00020068201 Poteau 3 2
J P00010046401
Base du
Coffre de
Stockage 1
2
L P00040129801
Canal
Central
(Côté Court)
2
M P00040130501
Canal Gauche Côté
Court (Pour
Poteau en Acier)
1
N P00040130601
Canal Droit Côté
Court (Pour
Poteau en Bois)
1
P P00050028101 Connexion de
la Traverse
2
8
Q P00050028001 Connexion de
la Traverse1 8
R P00040130301
Canal Gauche Côté
Court (Pour
Poteau en Bois)
1
S P00040130401
Canal Droit Côté
Court (Pour
Poteau en Acier)
1
T P00040129701
Canal
Central (Côté
Long)
2
U P00040129901
Canal Gauche
Côté Long (Pour
Poteau en Bois)
1
V P00040130001
Canal Droit Côté
Long (Pour
Poteau en Bois)
1

12 / 59
Country of Origin: China
Pais d’origine: Chine
W P00040130101
Long Side Left
Gutter (For Steel
Post)
1
X P00040130201
Long Side Right
Gutter (For Steel
Post)
1
Y P00220018101 Post Cap 1 2
AA P00220018301 Post Cap 2 2
AB P00500064301 Brace 1 2
AC P00500064401 Brace 2 2
AD P00060218601 Rafter Connector 2
2
AE P00060218501 Rafter Connector 1
2
AF P00060218401 Rafter 4
AG P00060218701 Roof Frame 1
AJ P00060218101 Long Middle Beam 6
AK P00060218201 Short Middle Beam
1 4
AL P00060218301 Short Middle Beam
2 4
AM P005800001 Hook 1

13 / 59
Country of Origin: China
Pais d’origine: Chine
W P00040130101
Canal Gauche
Côté Long (Pour
Poteau en Acier)
1
X P00040130201
Canal Droit Côté
Long (Pour
Poteau en Acier)
1
Y P00220018101 Pommeau du
Poteau 1
2
AA P00220018301 Pommeau du Poteau
2
2
AB P00500064301 Barre de Renfort 1 2
AC P00500064401 Barre de Renfort 2 2
AD P00060218601 Connexion du
Chevron 2 2
AE P00060218501 Connexion du
Chevron1 2
AF P00060218401 chevron 4
AG P00060218701 Cadre de toit 1
AJ P00060218101 Longue Poutre
Centrale 6
AK P00060218201 Courte outre
Centrale 1 4
AL P00060218301 Courte outre
Centrale 2 4
AM P005800001 Crochet 1

14 / 59
Country of Origin: China
Pais d’origine: Chine
AP P00220034602 Fixed Panel 1
AQ P00760012501 Solar Panel 1
AR P00060219101 Upper Small Beam
(Short Side) 4
AS P00060218901 Upper Small Beam
(Long Side) 4
AT P00060219201 Lower Small Beam
(Short Side) 4
AU P00060219001 Lower Small Beam
(Long Side) 4
AV P00060218801 Middle Small Beam
(Long Side) 4
AX P00070106301
Middle Lower
Roof Panel (Long
Side)
2
AY P00070106401 Roof Panel (Left) 4
BA P00070106501 Roof Panel (Right) 4
BB P00070106601 Roof Panel (Left
Middle) 4
BC P00070106701 Roof Panel (Right
Middle) 4
BD P00070106801 Roof Small Panel
(Left) 4
BE P00070106901 Roof Small Panel
(Right) 4

15 / 59
Country of Origin: China
Pais d’origine: Chine
AP P00220034602 Panneau de Fixation 1
AQ P00760012501 Panneau Solaire 1
AR P00060219101
Poutre
Supérieure Petite
(Côté courte)
4
AS P00060218901
Poutre Supérieure
Petite
(Côté Long)
4
AT P00060219201
Poutre Inférieure
Petite
(Côté courte)
4
AU P00060219001
Poutre Inférieure
Petite
( Côté Long)
4
AV P00060218801
Poutre Centrale
Petite
(Côté Long)
4
AX P00070106301
Panneau Central
Inférieur du Toit
(Côté Long)
2
AY P00070106401 Panneau du Toit
(la gauche)
4
BA P00070106501 Panneau du Toit
(Droit)
4
BB P00070106601
Panneau du
Toit(Milieu
gauche)
4
BC P00070106701 Panneau du Toit
(Milieu Droit) 4
BD P00070106801
Panneau Petit du
Toit (Gauche) 4
BE P00070106901 Panneau Petit du
Toit (Droit) 4

16 / 59
Country of Origin: China
Pais d’origine: Chine
BF P00080037001 Rafter Upper Cover 4
BG P00080037101 Rafter Lower Cover 4
BJ P00090016901 Roof Cap 1
BK P00510038101 Soft Close Hinge 2
BL P00510036101 Storage
Door Handle 2
BM P00210050801 Storage Table Top 1 2
BP P00220020601 Bluetooth
Container 1
BQ P007600005 Bluetooth 1
BR P007600006 Lock 6

17 / 59
Country of Origin: China
Pais d’origine: Chine
BF P00080037001 Bâche du Chevron
Supérieur 4
BG P00080037101 Bâche du Chevron
Inférieur 4
BJ P00090016901 Pommeau du Toit 1
BK P00510038101 Charnière à
amortissement 2
BL P00510036101
Manche de la Porte
du Coffre de
Stockage
2
BM P00210050801
Dessus de
Table du Coffre
de Stockage 1
2
BP P00220020601 Caisse du Bluetooth 1
BQ P007600005 Bluetooth 1
BR P007600006 Verrouillage 6

18 / 59
Country of Origin: China
Pais d’origine: Chine
Hardware Pack
Label Part Number Description Qty Add Part Image
H2 H100040010 Bolt M6*20 8 1
H3 H100010047 Bolt M6*20 260 13
H4 H100010046 Bolt M6*40 42 3
H5 H100010051 Bolt M6*55 8 1
H6 H010030536 Bolt M10*180 4 1
H7 H030050052 Screw ST4.8*25 22 2
H9 H030030022 Screw ST 9.5*60 4 1
H10 H050070014 Washer M10 12 1
H11 H040050026 Hex Nut M10 4 1
HS H070010001 Stake Φ8*180 8 0
HW1 H090010017 Wrench M6 2 0
HW2 H090010015 Wrench M10 1 0
HW3 H090030002 Allen Key M6 1 0
HW5 H090030005 Allen Key M8 1 0
H12 H030030021 Screw ST8*25 8 1
H13 H050080007 Flat Washer M8 8 1
HW4 H090030008 Allen Key M10 1 0

19 / 59
Country of Origin: China
Pais d’origine: Chine
Pack Quincaillerie
Étiquette Numéro de la
Pièce Description Quantité Add Numéro de la Pièce Diagramme
H2 H100040010 Boulon M6*20 8 1
H3 H100010047 Boulon M6*20 260 13
H4 H100010046 Boulon M6*40 42 3
H5 H100010051 Boulon M6*55 8 1
H6 H010030536 4 1
H7 H030050052 Vis ST 4.8*25 22 2
H9 H030030022 Vis ST 9.5*604 1
H10 H050070014 Rondelle
plate M10 12 1
H11 H040050026 Écrou Hexagonal
M10 4 1
HS H070010001 Piquet Φ8*180 8 0
HW1 H090010017 Clé M6 2 0
HW2 H090010015 Clé M10 1 0
HW3 H090030002 Clé Allen M6 1 0
HW5 H090030005 Clé Allen M8 1 0
H12 H030030021 Vis ST8*25 8 1
H13 H050080007 Rondelle plate
M8 8 1
HW4 H090030008 Clé Allen M10 1 0
Boulon M10*180

20 / 59
Country of Origin: China
Pais d’origine: Chine
1
