Sunnydaze Decor AGR-386 User manual

CR540 02/2023
SCAN THIS CODE
WITH YOUR
SMARTPHONE
TO VIEW OUR
ASSEMBLY VIDEO
TRUNK WITH HANDLES
AGR-386
Carefully review assembly and care instructions before using this product. Save this document for future reference.

Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell.
Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with
the date of purchase as well as photos of the merchandise defect, must be provided. Photos are used to determine
the cause of defects and for future quality control. Register your warranty at https://tiny.cc/SunnydazeWarranty
If you have any questions, comments or concerns, feel free to contact us by phone at 833-982-1977, by email:
[e-mail], or via our contact us page at https://tiny.cc/SunnydazeContact
Purchase Date: / / Order/Customer Reference Number:
HELPFUL HINTS
Sunnydaze Decor advises reviewing this manual fully, and assembling the unit soon after purchase.
Check that all parts are accounted for and familiarize yourself with the assembly before beginning.

2-PERSON
ASSEMBLY
RECOMMENDED
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
Save the packing slip.
Page 1 / 10

CR540 02/2023
INTRODUCTION
Instrucciones
Instructions


Read the manual carefully to ensure you fully understand
all use, care, assembly, and safety information.
Read this manual carefully and
follow the assembly instructions
in the order listed. Pay close
attention to assembly drawings.
Regularly clean with a clean
microber cloth to prevent dust
accumulation.
Do not paint the unit.
Do not use abrasive materials or
cleaners to clean the furniture.
Indoor use only.
Do not expose the furniture to
heat or humidity.
When cleaning nearby the
furniture, do not allow contact
with water or cleaners as it may
deteriorate the furniture.
Do not allow metal components
to come in contact with water or
cleaners as it may cause rust and
staining.
Assemble on a soft, at, clean, and
dry surface.
Use a soft, protective barrier when
assembling the furniture.
TIP: Use the box carton as a
protective layer to separate and
protect the parts from scratches and
other damage during assembly.
Do not push or drag furniture as
doing so may damage the unit.
Only move furniture when it is empty.
Always ask for help when moving
furniture.
Avoid Accidents - Do not climb, sit
or stand on the furniture.
Do not allow children to play on or
inside the furniture.
Keep sharp objects away as they
may scratch or damage the unit.
Do not use the furniture as a writing
surface without a padded barrier.
NOTICE:
Manufacturer and seller expressly disclaim any and all liability from personal injury, property damage
or loss, whether direct or indirect, or incidental, resulting from the incorrect attachment, improper use,

Page 2 / 10

CR540 02/2023
  
AWood Dowel 18
BM4.5x28mm Pan Screw 2
CM4x16mm Bolt 4
DConnector 19
ETack 6
FHandle Set 2
GM3x16mm Flat Screw 8
HM4.5x25mm Pan Screw 35
JHinge 2
KM3.5x14mm Pan Screw 12
LLid Support 2
COMPONENTS
(not included)
Phillips Screwdriver
Rubber Mallet
CHOKING HAZARD — This item contains small parts that can
be swallowed. Keep children and pets away during assembly.
WARNING
2-PERSON
ASSEMBLY
RECOMMENDED
  
01 Lid 1
02 Cap Panel 1
03 Side Panel (L/R) 2
04 Back Panel 1
05 Front Panel 1
06 Bottom Support Rail 1
07 Short Trim Board (L/R) 2
08 Long Trim Board (L/R) 2
09 Bottom Panel 1
10 Lid Support Rail 2
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
Save the packing slip.
Page 3 / 10

CR540 02/2023
IMPORTANT: Take care not to over-tighten screws as doing so may crack the wood or strip the screw hole, causing a weak connection and reduced stability.
ASSEMBLY
Carefully review all steps and fully understand assembly before beginning.
STEP 1
03: 2
04: 1
06: 1
A: 18
STEP 2
D: 19
TIP: Install connectors by gently tapping them into
the designated holes using a rubber mallet.
Locate and lay out two Side Panels (03),
Back Panel (04) and Bottom Support Rail (06).
Install Wood Dowels (A) as noted below, and shown in the diagrams above:
Side Panels (03), install six Wood Dowels (A). Repeat with the remaining side panel.
Back Panel (04), install two Wood Dowels (A).
Bottom Support Rail (06), install four Wood Dowels (A).
With the angled edge facing the inside of the panel, install eight Connectors (D) into two Side Panels (03). Then,
install three Connectors (D) into Back Panel (04).
Page 4 / 10

CR540 02/2023
STEP 3
H: 6
STEP 4
09: 1
IMPORTANT:
Ensure components are installed in
the correct direction, as shown in
the diagram.
Ensuring the bottom grooves align, secure two Side Panels (03) to Back Panel (04) using six M4.5x25mm Pan
Screws (H).
Ensuring the angled mounting holes face the bottom, align Bottom Support Rail (06) with the back panel, as shown.
NOTE: The support rail will be secured in Step 6.
Slide Bottom Panel (09) into the grooves, as shown.
Page 5 / 10

CR540 02/2023
STEP 5
05: 1
H: 6
STEP 7
07: 2
H: 4
STEP 6
B: 2
Assistance is recommended for this step.
Secure Bottom Support Rail (06) to the front
and back panels using two M4.5x28mm
Pan Screws (B).
Ensuring the bottom grooves align, secure
Front Panel (05) using six M4.5x25mm
Pan Screws (H).
Align two Short Trim Boards (07) with the
bottom of the side panels, as shown.
To ensure they remain ush with the
unit while hardware is secured, have an
assistant rmly hold the trim boards in
place. From the inside of the trunk, secure
each trim board using two M4.5x25mm
Pan Screws (H).
Page 6 / 10

CR540 02/2023
STEP 8
08: 2
H: 8
STEP 9
02: 1
C: 4
F: 2
H: 5
Assistance is recommended for this step.
Align two Long Trim Boards (08) with the bottom of the unit, as shown.
Have an assistant rmly hold the trim boards in place to ensure they remain ush with the unit while hardware is
secured. From the inside of the trunk, secure each trim board using four M4.5x25mm Pan Screws (H).
Align the components of Handle Sets (F) with the side panels. Ensuring the handle plates remain straight, secure
each handle set using two M4x16mm Bolts (C).
Align Cap Panel (02) with the dowels on the back panel. Secure the cap panel using ve M4.5x25mm Pan Screws (H).
Page 7 / 10

CR540 02/2023
STEP 10
01: 1
10: 2
H: 6
J: 2
K: 6
STEP 11
K: 6
Ensuring Top (01) is aligned with Cap Panel (02), secure the hinges to the cap panel using six M3.5x14mm Pan
Screws (K) .
Lay Top (01) face-up on a clean, smooth surface.
Align two Hinges (J) with the indents on the top and mostly fasten them using six M3.5x14mm Pan Screws (K).
Turn the top over and align two Lid Support Rails approximately 5 inches (5in, 12.7cm) from each short edge of the
top. Secure each support rail using three M4.5x25mm Flat Screws (H).
Page 8 / 10

CR540 02/2023
Lid
Trunk
STEP 12
G: 8
L: 2
STEP 13
E: 6
For even spacing, carefully measure and install eight Tacks (E) as indicated above.
30 mm
30 mm
40 mm
45 mm
HELPFUL MEASURING HACK
To help ensure tacks are evenly spaced, we developed a hack to make this step easier.
Grab a blank white piece of paper or tracing paper, a writing utensil, a ruler and scissors.
The blocks below are sized to the dimensions noted in the above diagrams.
Place the blank piece of paper over the blocks below. Use a writing utensil to mark the corner of each block.
Use a ruler to connect the dots of each block. Write the size inside the block and cut them out.
Align the cutout with the designated corner (shown above).
Use the sharp end of one of the
tacks to make a small indent at
the inside corner of cutout.
After tack placement has been
marked, install tacks using
a rubber mallet.
Align the metal mounting plate of
Lid Support (L) with the indents
on the underside of the lid and
secure using two M3x16mm
Flat Screws (G).
Align the plastic mounting
bracket, at an angle, with the
indents on the inside of the trunk
and secure using two M3x16mm
Flat Screws (G).
NOTE: There are 3 indents on the
side panels, this is a result of the
manufacturing process so the panels
are interchangeable (can be installed
on the left or right side and still allow for
proper alignment of the lid supports).
Page 9 / 10

CR540 02/2023

SAFETY STATEMENTS & WARNINGS
• Residential use only. Not for commercial or industrial use.
• For indoor use only.
• Ensure fittings are tight before use. Periodically check fitting to ensure they are tight.
• Only use this unit on a flat, level surface.
• Do not sit, stand or climb on the unit.
• Supervise children; never allow children to climb on or play in this unit as doing so may cause serious injury.
• Do not place liquids or hot items directly on the furniture.
• Never use chemical cleaning products or polishes as they may damage the finish.
• Do not exceed the weight capacity of the furniture.
• Never move the unit when items are inside, empty the unit before moving.
• Do not place the unit in direct sunlight.
• Avoid placing unit near heating or cooling vents as forced air is very drying and can damage the unit.
• Do not write on furniture without a padded barrier to protect the surface.
NOTICE:
Manufacturer and seller expressly disclaim any and all liability from personal injury, property damage
or loss, whether direct or indirect, or incidental, resulting from the incorrect attachment, improper use,

Page 10 / 10
If you experience issues with assembly or the product was damaged during shipping,
please contact our customer service team directly through one of the methods mentioned at the top of page 1.
Please have the item number and order information ready to expedite response time.
