Sunricher SR-2819T Series User manual

RF & WiFi RGBW Controller
Product introduction
SR-2819T with SR-1009FA series
Parameter
Wiring diagram
Product Size
RF RGB(W) remote controller is a wireless color controlling system that consists of a sender
and a receiver or several receivers. By selecting switch status, you can set the system as RGB 3-channel
output, or RGBW 4-channel output. Using Easy RGB(W) remote controller, you can get whatever color you
want; you can choose any color from RGB(W) to adjust so as to mix more than 100 mi l l ion kinds of colors.
With built-in 10 kinds of color changing modes, you can easily switch color changing modes and adjust speed
and brightness. “Function Pause” enables RGBW LED to stay at your favorite color under the situation of color
changing modes, which operation is simple but functional.
Part No. Iuput Voltage Remarks
Current
SR-1009FA 12-36VDC Constant voltage
4x(60-180)W
4x5A
Output
SR-1009EA 12-36VDC Constant voltage
4x(96-288)W4x8A
Remote
Part No. Operation Voltage DIMENSIONS
ø/h (mm)
Operation
Frequency
SR-2819T 4.5VDC 43.8x131.6x24.5
434MHz/868MHz
Receiver
SR-1009FA3 12-36VDC Constant current
4x(4.2-12.6)W
4x350mA
SR-1009FA7 12-36VDC Constant current
4x(8.4-25.2)W4x700mA
43.8
131.6
24.5
Brief introduction of buttons
R G Short press: switch on/off each channel;
Long press: dim up/down each channel
B W
Working status indicator, the sender is in dormant status when the indicator is off. The
sender is under working when the indicator is flashing rapidly. If the indicator continues
flashing at the frequency of 1 second, it indicates that the sender batteries low and
needs to replace new batteries.
S- Speed down when color is changing S+ Speed up when color is changing
B- Brightness down B+ Brightness up
Turn ON/OFF
Touch wheel for selecting R/G/B colors
R G B W
S- S+
W+
B- B+
Z1 Z2
P1 P2 P3 P4
12 3 4Z1 Z2
P1 P2 P3 P4
1 2 34
2 zones
Each button built-in 2 modes
4 buttons for saving 4 colors or modes each zone. If you like a color or mode,
just long press any of the 4 buttons over 2seconds to save it. Short press to get
that saved color or mode.
W+ Short press: RGB mixed white: CW,NW,WW in circle;
Long press : switch OFF RGB channels
1)Receiver Connection Diagram for Single Unit
2) Connection Diagram for Multiple UnitsReceiver
Power Supply
12-36VDC
LN
110V-230VAC
white
SR-1009FA
LED CONTROLLER
1234
Learning Key
white
SR-1009FA
LED CONTROLLER
1234
Learning Key
white
SR-1009FA
LED CONTROLLER
1234
Learning Key
Power Supply
12-36VDC
LN
110V-230VAC
white
SR-1009FA
LED CONTROLLER
1234
Learning Key

Z1
Safety & Warnings
Warranty Agreement
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
1. Do wiring according to connection diagram and install battery into remote control.
2. How to learn&delete ID process?
a. Turn on the remote by .
b. Short press at Learning Key on receiver.
c. Press any zone button(which you desire to control) on remote, for example .
d.Then touch color wheel.
e.Connected LED light will blink to confirm zone designation.
How to reset to factory default: Long Press Learning Key on receiver for over 5 seconds until connected LED light flash off,
to delete the learned ID, the receiver will be reset to factory default. If you want to learn receiver into another zone, please follow
learning ID process operation 2.
Operation
