Super Circuits PC815VF User manual

1. FEATURES:
◎ Sony 1/3” Color Exview™ CCD 750TVL Effio-E 960H.
◎ High Sensitivity、True Color reproduced in day time
◎ Built in 14 Super Bright Large LEDs and 21 wide spread LEDs
Automatically Switch to ON/OFF
◎ IR Range: More than 280 ft
◎ Lens External Adjustment through Trap Door
◎ Cable Management
◎ Multi-Language OSD setup menu
◎ ATR (Dgital Wide Dynamic Range), Motion Detection,
2D Noise Reduction, High Light Compensation, Privacy
◎ Multiple PCBs Design, Reliable Circuitry & Safety
◎ Weather Proof IP-65 Rated
When you connect power to the camera, the IR illuminator will turn on
for a few seconds and then turn off automatically.
P8 P.1
4. OPERATION GUIDE:
Zoom / Focus / OSD adjustment
5. SYSTEM CONNECTION
P.6 P.3
PC815VF
INSTRUCTION MANUAL
PICT ADJUST 
OFF
MIRROR
ON
BRIGHTNESS
0~255
CONTRAST
0~255
SHARPNESS
0~255
HUE
0~255
GAIN
0~255
ATR
ON 
OFF
LUMINAN
CONTRA
LOW
MID
HIGH
MIDLOW
MID
LOW
MIDHIGH
HIGH
MOTION DET
ON 
OFF
DETECT
BLOCK DISP
OFF
ON
MOTION
AREA SEL
TOP
BOTTOM
LEFT
RIGHT
ENABLE 
OFF
ON
1/4
2/4
3/4
4/4
0~127
0~244
0~244
0~474
0~474
2
1
24x16 BLOCK
NEXT 
EXIT

SAVE ALL
PRIVACY
OFF
ON 
AREA SEL
TOP
BOTTOM
LEFT
RIGHT
COLOR
TRANSP
MOSAIC
1/4
0~244
0~244
0~474
0~474
2/4
3/4
4/4
1
2
3
4
5
6
7
8
0.00
0.50
0.75
1.00
OFF
ON
LONG RANGE 280 FEET INFRARED
VIDEO SECURITY CAMERA 12 VDC

2. CAUTIONS:
1、Before attempting to connect this product, please read this
manual completely.
2、Ensure the supply voltage is correct as specified for the
particular variant of camera before operation.
3、Never face the camera toward the sun directly.
4、Do not attempt to service this unit unless you are
authorized to do so. Opening or removing the cover may
expose you to hazards. Refer all servicing to
qualified personnel.
5、Keep a suitable clearance between the unit
and the place where the unit mounted.
6、Do not disassemble the camera.
7、We strongly suggest that the current of the power source
(12 Vdc) be 1.5 ampere or above.
3. SYSTEM COMPONENTS:
Camera ……………...……………….…..…1
Instruction manual……...………….….….…1
Bracket……….………….………….….……1
Coaxial--cable BNC & POWER connector---1
Hexagonal wrench………..………………….1
P.2 P.7
6. SPECIFICATION: 8. ADJUSTMENT: (Through OSD menu)
Total Pixels PAL: 1024 * 596 / NTSC: 1028 * 508
Effective Pixels PAL: 976 * 582 / NTSC: 976 * 494
Sync System Internal Sync
Video Output
1 Vp-p Composite, 75 ohm BNC Connector
Lens
Lens Varifocal 5 ~ 50 mm Auto IRIS, F1.6
Resolution
More than 750 TV Lines ( Horizontal )
Gamma Correction 0.45
Minimum Illumination
0 lux (IR LEDs Activated)
S/N Ratio
More than 68 dB (AGC Off)
Power Source
12 Vdc
Power Consumption
2 W (IR LEDs Activated : 13 W Max)
Ambient -10 ～ 50℃ (14~122F) /30 ～ 90 ﹪RH
Dimensions
127 mm(H) x 156 mm(W) x 354 mm(D)
Weight
Apprx. 4400 g
Backlight Compensation Setting through OSD menu
White Balance Setting through OSD menu
Gain Control Setting through OSD menu
Image Correction Image Reverse/Brightness/Contast/Sharpness/HUE/AGC
Weather proof IP-65
IR LED
14 Pieces of Big LEDs , ※ New 14 LEDs (10Φ Big LED) +
21 LEDs (5Φ LED)
7. INSTALLATION INSTRUCTIONS:
1、Connect the video output of the camera to a color
monitor or other video device through a 75 Ω
coaxial cable with a BNC connector.
2、Connect the regulated power source to the
12 Vcd power-in jack with 2 mm center +, outer plug.
P.4 P.5
DAY / NIGHT
COLOR
B/W 
AUTO 
BRUST
OFF
ON
BRUST
DELAY CNT
DAY→NIGHT
NIGHT→DAY
OFF
ON
0~255
0~255
0~255
NR 
NR MODE
Y LEVEL
C LEVEL
OFF
Y
C
Y/C
0~15
0~15
CAMERA ID
OFF
ON 
SYNC
INT
LL 
PHASE
0~524 (NTSC)
0~624 (PAL)
Spanish
English
LANGUAGE
Japanese
German
French
Russian
Portuguese
CAMERA RESET
BACK 
EXIT  SAVE ALL
(LENS : MANUAL)
WHITE BAL
ATW 
SPEED
0~255
DELAY CNT
0~255
ATW FRAME
x0.50
x1.00
x1.50
x2.00
R-GAIN
0~255
ENVIRONMENT
OUTDOOR
INDOOR
R-GAIN
0~255
PUSH
USER1 
B-GAIN
0~255
USER2 
B-GAIN
0~255
ANTI CR
MANUAL 
LEVEL
0~255
PUSH LOCK
BACK LIGHT
OFF
BLC
HLC
DC
VIDEO
AUTO
OPEN
CLOSE
0~255
LENS
MANUAL
AUTO 
TYPE
MODE
SPEED
SHUTTER/AGC
MANUAL 
MODE
SHUT+AG
SHUTTER
1/60
1/100
1/250
1/50
1/1K
1/2K
1/4K
1/10K
AGC
6.00
12.00
18.00
24.0
30.00
36.0
42.0
44.80
SHUT
SHUT+AUTO IRIS
MODE
AUTO IRIS
BRIGHTNE
0~255
LOW LUMINANCE
MODE
AGC
OFF
BRIGHTNE
x0.25
x0.50
x0.75
x1.0
AUTO 
HIGH
(LENS : AUTO)
