superbrightleds ALD Series User manual

LED Parking Lot/Area Light
Important: Read all instructions prior to installation. ALD and ALD2 Series
User Manual
5yr
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V3 05/03/2023
Mounting Options
Safety and Notes
Environmental Specications
Operating Temperature -22°–131° F (-30°–55° C)
IP Rating IP65
Flush Mount (ALD-FM)
Slip-Fitter (ALD-SF)
Yoke Mount (ALD-FB)
Slip-Fitter with Junction Box (ALD-SFS)
• Product should be installed and serviced by a certied electrician
in accordance with applicable national, state, and local building
and electrical codes.
• To reduce the risk of electric shock, ensure that the main power
source and circuit breakers are switched o󰀨 before performing
any installation or wiring procedures.
• Avoid looking directly into lamp when illuminated.
• Ensure all mounts are securely attached and will support the
weight of the xture. Failure to properly support xture may
result in damage or injury, for which the manufacturer does not
assume responsibility.
Specications
ALD-50K10W-C-BRC3-SF
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
Wiring Diagram
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray / Pink
Green
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray / Pink
Green
120–277 / 277–480 VAC Input 1–10 V Dimming

LED Parking Lot/Area Light
Important: Read all instructions prior to installation. ALD and ALD2 Series
User Manual
5yr
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V3 05/03/2023
Slip-Fitter (ALD-SF) Installation
Slip-Fitter with Photocell Junction Box (ALD-SFS) Installation
1. Disassemble mount and run wiring through it.
2. Reassemble mount.
3. Attach mount to light.
4. With supply power o󰀨, connect wiring.
5. Slide mount over pole/post and secure in place.
The maximum pole/post diameter is 2.375 in.
6. Rotate light to desired angle and tighten
adjustment screw.
1. Disassemble mount and run wiring through it.
2. Reassemble mount.
3. Attach mount to light.
4. With supply power o󰀨, connect wiring.
5. Slide mount over pole/post and secure in place.
The maximum pole/post diameter is 2.375 in.
6. Rotate light to desired angle and tighten
adjustment screw.

LED Parking Lot/Area Light
Important: Read all instructions prior to installation. ALD and ALD2 Series
User Manual
5yr
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V3 05/03/2023
Square/Round Mount (ALD-FM) Installation
1. Remove side access plate cover on mount.
2.Run wiring through the ange that attaches to the light.
3.Attach mount to light.
4.Make appropriate mounting and wiring holes in pole/post and
attach mount to pole/post.
5.With supply power o󰀨, use side access to connect wiring.
6.Loosen adjustment bolt to adjust angle. Rotate light to desired
angle and tighten adjustment screw.
7. Re-install side access plate cover.
Yoke Mount (ALD-FB) Installation
1. Use U-bracket mount as a template to make mounting holes
on wall/surface and install hardware.
2.Attach the light to the bracket
3.Mount light to surface.
4.With supply power o󰀨, connect wiring.
5.Once installation is complete, the position locking bolts can
be removed and the center trunnion bolts can be loosened
to adjust the mounting angle of the light. Reinstall the position
locking bolts and retighten center bolt when the desired
angle is achieved.

LED Parking Lot/Area Light
Important: Read all instructions prior to installation. ALD and ALD2 Series
User Manual
5yr
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V3 05/03/2023
Photocell Installation
1. Remove photocell access plate.
2.Attach Photocell receptacle socket.
3.With supply power o󰀨, make all wiring connections according to the diagram.
4.Photocell plugs in and twists to lock.
Note: JL-205C photocell is meant for operation with 120–277 VAC.
JL-207F photocell is meant for operation with 480 VAC.
Photocell
Line
Neutral
Ground
Purple (Dim +)
Green
White
White Red Black
Black
N/C
N/C Gray (Dim -)
Light
Neutral
Ground
Purple (Dim +)
Green
White
BlackLine
N/C
N/C Gray (Dim -)
Light
Photocell
Line
Neutral
Ground
Purple (Dim +)
Green
White
White Red Black
Black
N/C
N/C Gray (Dim -)
Light
Neutral
Ground
Purple (Dim +)
Green
White
BlackLine
N/C
N/C Gray (Dim -)
Light
Default Wiring Diagram Photocell Wiring Diagram
ALD-SFS with Photocell
Receptacle and Sensor
ALD-FM with Photocell
Receptacle and Sensor
