superbrightleds PLTT 1BK Series User manual

LED Low Voltage Path Lights
Important: Read all instructions prior to installation.
User Manual
LED Low Voltage Path Lights
User Manual
Rev Date: V2.2 04/12/2019Rev Date: V2.2 04/12/2019
Trouble Shooting
PLTT-x1BK, PLOS-x1BR
PLMB-x1BK, PLOS-x3CU
PLP-x25
Problem Possible Cause Solution
Fixture does
not light
1. There is no power to 12V power
supply.
2. The quick connector does not
make contact with wires.
3. The primary landscape wire is not
connected to 12V power supply.
4. There is a disconnection in prima-
ry landscape wire.
5. Minimum load not exceeded.
1. Check the outlet to 12V power supply and ensure that a breaker or GFCI
circuit has not been tripped.
2. Check the wiring of quick connector that it is screwed tightly, piercing
through wire insulation to make solid contact with wire conductors.
3. Check primary landscape wire connection to 12V power supply.
4. Follow wires from xture to 12V power supply to ensure a continuous run
and/or follow wires between problematic xture and working xture.
5. Ensure that your power supply does not have a minimum load requirement.
Consult the power supply specications or manual.
Light ickers
(one xture)
1. There is a loose connection with
quick connect on primary land-
scape wire.
1. Tighten quick connects, and ensure contacts are piercing through wire
insulation to make solid contact with wire conductors.
Light ickers
(all xtures)
1. There is a loose connection to 12V
power supply.
2. Minimum load not exceeded.
1. Disconnect power to 12V power supply and ensure primary landscape wire
connections are securely fastened and not in contact with other wire.
2. Ensure that your power supply does not have a minimum load requirement.
Consult the power supply specications or manual.
Light is dim 1. Maximum load of 12V power
supply has been exceeded.
2. Recommended distance per land-
scape wire guage exceeded.
1. Check for other lights or other load on same system and/or increase 12V
power supply wattage.
2. Increase primary landscape wire gauge size to recommended guidelines.
* For superbrightleds.com technical help call 866-590-3533
Power Supply
Wattage @ 12 VAC
Max Fixtures
PLTT-x1BK PLOS-x1BR PLMB-x1BK PLOS-x3CU PLP-x25
20 W 8 12 8 3 10
50 W 22 32 22 8 25
100 W 44 64 44 17 50
200 W 88 128 88 35 100
Power Load Guide
* For superbrightleds.com technical help call 866-590-3533 or use our online chat service.

Installation Instructions
LED Low Voltage Path Lights
Important: Read all instructions prior to installation.
Rev Date: V2.2 04/12/2019
SBL Part No. Description
*WWN-2212 Silicone Filled Wire nut
SFT-20 Self Fusing Silicone Tape
WP14-2DB 14 Guage Landscape Wire
WP12-2DB 12 Guage Landscape Wire
Safety and Notes
Parts Included Recommended Accessories
Assembly
1 - Low Voltage Path Light
1 - Mounting Stake
*Note: Cutting quick connects will not void warranty.
Product exchange only.
1. Lay xtures out as they will be installed.
2. Run landscape wire (WP14-2DB or WP12-2DB available at
superbrightleds.com) from 12V supply past each light. Wire must be
within 8” of mounting stake to allow power connections to be made.
3. Use quick connects supplied with each xture to connect each light
to the landscape wire.
4. Using a small shovel and/or water, loosen the ground where xture will be
installed. Press stake into ground.
Note: Do not use a hammer or exert excessive force on the xture while
installing as this may cause damage.
Note: DO NOT force stake using xture as grip. Push from stake only.
5. Turn on 12V supply and ensure all xtures are working. If one or more individual
xtures are not working, check each connection to landscape wire. If none
come on, check connection to the 12V supply. It is recommended to wrap all
connections in electrical or self-fusing tape (available at superbrightleds.com).
6. Bury landscape wire, xture pigtails, and connectors. A depth of 3” is
recommended. Wires and connectors can also be covered by mulch or stone.
Low Voltage
Landscape Wire
Quick Connects
Slot
Power
Supply
Assemble xtures as shown below. Run
power wires through slot in stakes.
PLTT-x1BK PLOS-x1BR PLMB-x1BK PLOS-x3CU
PLTT-x1BK, PLOS-x1BR
PLMB-x1BK, PLOS-x3CU
PLP-x25
PLP-x25
User Manual
• For use with outdoor, low-voltage landscape lighting systems only.
• Do not submerge in water—not for use with submersible or pool/spa equipment.
• Light xture is only compatible with 12-Volt AC or DC power supply. Do not exceed 80% of power supply max output.
• Use appropriate landscape wire. (SBL product numbers WP14-2DB or WP12-2DB)
