superbrightleds PLOL-xW3 Series User manual

LED Low Voltage Landscape Light
Important: Read all instructions prior to installation.
User Manual
Part Number:
LED Low Voltage Landscape Light
PLOL-xW3xx
PLHS-xW3xx
PLGS-xW3xx
PLxx-xW3xx
PLMS-xW3xx
PLOS-xW3xx
Installation Manual
5yr
Rev Date: V1 11/07/2016Rev Date: V1 11/07/2016
Installation Instructions (PLOL-xW3xx)
PLxx-xW3xx
1. Assemble as shown in Fig. 3.
2. Loosen ground with a shovel and/
or soften soil with water. Press stake
into ground. Do not press directly on
 xture while installing. Attach  xture
to power cable (see recommended
accessories). (Fig. 2)

PLxx-xW3xx
User Manual
Part Number:
Installation Instructions
Preparation Instructions
LED Low Voltage Landscape Light
Important: Read all instructions prior to installation.
Rev Date: V1 11/07/2016
Safety and Notes
• Read all of these instructions thoroughly before use. Keep this instruction
manual in a safe place for future reference.
• This light xture is only suitable for a 12~15 Volt AC or DC power supply.
• Use direct burial landscape wire: SBL Product #: WP14-2DB or WP12-2DB
Before beginning assembly of product,
make sure all parts are present.
1. Fixture can be set to multiple heights
using downrods. Select height
desired and assemble as shown in
(Fig. 1). Do not over tighten.
* For Product PLOS-xW3xx, lamp
shade and lamp head are one piece,
and includes only one downrod.
Part Description Quantity
ACap Nut 1
B Lamp Shade 1
CLamp Head 1
DDownrod A 1
EDownrod Connector 2
F Downrod B 1
G Ground Stake 1
Recommended Accessories
SBL Part No. Description Quantity
WWN-2212 Silicone Filled Wire Nut 2 (per xture)
SFT-20 Self Fusing Silicone Tape As required
WP14-2DB Direct Burial Wire As required
WP12-2DB Direct Burial Wire As required
PLOS-xWxx
2. Loosen ground with a shovel and/or soften soil with water. Press
stake into ground. Do not press directly on xture while installing.
Attach xture to power cable (see recommended accessories). (Fig.
2)
3. Unscrew cap nut from lamp head. Install lamp shade, then reinstall
cap nut, do not over tighten. (Fig. 2)
