superbrightleds DDAL-SW3B60W-3NPT5-AM50S Series User manual

Field-Selectable Wattage and CCT LED
Dusk-to-Dawn Area Light
User Manual
Important: Read all instructions prior to installation. DDAL-SW3B60W-x3NPT5-AM50S
Parts Included
Specications
Photocell Operation
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
- area light
- pole mount bracket
- access plate (for wall installation)
- hardware kit
DDAL-SW3B60W-SL3NPT5-AM50S
Model DDAL-SW3B60W-x3NPT5-AM50S
Environmental Rating IP65
Operating Temperature -40°–122° F (-40°–50° C)
• Product should be installed by a certied electrician in
accordance with applicable national, state, and local
building and electrical codes.
• To reduce the risk of electric shock, ensure that the main
power source and circuit breakers are switched o󰀨 before
performing any installation or wiring procedures.
• Avoid looking directly into the lamp when illuminated.
• Ensure all mounts are securely attached and will support
the weight of the xture. Failure to properly support
the xture may result in damage or injury, for which the
manufacturer does not assume responsibility.
Safety and Notes
CCT and Wattage Selection
Included photocell sensor switches light on when ambient
light goes below 16 lx, and o󰀨 when ambient light goes back
above 24 lx.
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
Remove cover to access switches and select
desired wattage and CCT. Wattage and CCT
can be selected before or after installation.
CCT and wattage selector switches
switch cover plugs
Rev Date: V1 09/29/2020

WIFI-CON
User Manual
Important: Read all instructions prior to installation.
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Pole Mount Installation
1. Remove supply power.
2. Make all electrical connections.
3. Loosely attach pole mount bracket to light.
4. Slide light over pole (max diameter 1.75” OD) and tighten mount bracket.
Note: Overtightening bracket may result in damage to pole.
5. Restore supply power.
6. Adjust wattage and CCT to desired value.
Wall Mount Installation
1. Remove supply power.
2. Measure mounting ange and drill three pilot holes.
3. Partially thread the bottom two lag screws in place.
4. Place light over to lower lag screws and install third lag screw, then tighten all lag screws.
5. Make all electrical connections. Wire should pass through bottom or rear access plate knockout
using an appropriate strain relief (not included).
Note: Knockouts are 1/2” trade size.
6. Attach access plate to light.
7. Restore supply power.
8. Adjust wattage and CCT to desired value.
Toggle switch
Plug
Plug
Toggle switch
86
Drill bit: 10mm
Wall Mount Hardware
Pole Mount Hardware
MM
10#
Toggle switch
Plug
Plug
Toggle switch
86
Drill bit: 10mm
Wall Mount Hardware
Pole Mount Hardware
MM
10#
Toggle switch
Plug
Plug
Toggle switch
86
Drill bit: 10mm
Wall Mount Hardware
Pole Mount Hardware
MM
10#
0.24in
6.10mm
3.36in
85.34mm
.47in
11.99mm
1.60in
40.64mm
Field-Selectable Wattage and CCT LED
Dusk-to-Dawn Area Light
DDAL-SW3B60W-x3NPT5-AM50S
Rev Date: V1 09/29/2020
