superbrightleds WPFCD Series User manual

LED Wall Pack
Important: Read all instructions prior to installation.
User Manual
Part Number:
Installation II: Mounting to Wall/Conduit
Dimensional Drawings
Rev Date: V1 03/02/2018Rev Date: V1 03/02/2018
LED Wall Pack
User Manual
Part Number:
5yr
WPFCD Series
WPFCD Series
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mount to J-box
Mount to wall with
3 anchors and 3
screws
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mount to J-box
Mount to wall with
3 anchors and 3
screws
2.34in
59.38mm
6.53in
165.81mm
9.25in
234.82mm
14.02in
356.09mm
10.87in
276.22mm
9.26in
235.33mm
FOAM GASKET
3.30in
83.82mm
3.50in
88.90mm
2.75in
69.85mm
INSIDE DRILL DIAGRAM

User Manual
Part Number:
User Manual
Part Number:
Opening Fixture
Installation I: Mounting to J-box
LED Wall Pack LED Wall Pack
Important: Read all instructions prior to installation. Important: Read all instructions prior to installation.
Specications
Included Parts
Wire Diagram
Warnings
1 - LED Wall Pack Fixture
1 - Foam Mounting Gasket
1 - Stainless Steel Cable Strain Relief
THIS FIXTURE MUST BE WIRED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE
AND APPLICATION LOCAL CODES OR ORDINANCES. ALL WORK SHOULD BE PERFORMED
BY A QUALIFIED ELECTRICIAN.
Rev Date: V1 03/02/2018Rev Date: V1 03/02/2018
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Green
WPFCD Series
• This product should be installed by a fully
certied electrician in accordance with local
building and electrical codes.
• Due to risk of electric shock, ensure that the
main power source and circuit breakers are
switched o󰀨 before performing any installation
or wiring procedures.
• Failure to properly support the xture during
installation may cause damage or injury, for
which the manufacturer is not responsible.
Ensure the light bracket is securely mounted
and will support the weight of the xture.
Safety Notes
WPFCD Series
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mount to J-box
Mount to wall with
3 anchors and 3
screws
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mount to J-box
Mount to wall with
3 anchors and 3
screws
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mount to J-box
Mount to wall with
3 anchors and 3
screws
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mount to J-box
Mount to wall with
3 anchors and 3
screws
Intensity 4800 lm 4800 lm 9600 lm 9600 lm
Operating Voltage Range 100~277 VAC
Total Power Consumption 40 Watts 40 Watts 80 Watts 80 Watts
Current Draw 0.33A 0.33A 0.7A 0.7A
Power Factor >0.90
Beam Angle 155 x 95 degree
Color Temperature 4000K
CRI >80
Operating Temperature -4~113°F (-20~45 °C)
IP Rating IP65
Fexture Material Aluminum / PC
LED Lifetime 50,000 Hours
Dimmable 1-10V
Fixture Weight 6.83 lbs (3.1Kg) 7.5 lbs (3.4Kg)
Standards and Certications UL
Warranty 5 year
Specications WPFCD-40K40P WPFCD-50K40P WPFCD-40K80P WPFCD-50K80P
