User Manual
Part Number:
User Manual
Part Number:
Opening Fixture
Installation I: Mounting to J-box
LED Wall Pack With Glass Lens LED Wall Pack With Glass Lens
Important: Read all instructions prior to installation. Important: Read all instructions prior to installation.
Specications
Included Parts
Wire Diagram
Warnings
1 - Foam Mounting Gasket
1 - Knockout Plug
3 - Wire Nuts
4 - M7x40mm Phillips Screws
THIS FIXTURE MUST BE WIRED IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE
AND APPLICATION LOCAL CODES OR ORDINANCES. ALL WORK SHOULD BE PERFORMED
BY A QUALIFIED ELECTRICIAN.
Rev Date: V1 01/24/2018Rev Date: V1 01/24/2018
WPDG Series
Intensity 6000 lm 11600 lm
Operating Voltage Range 100~277 VAC
Total Power Consumption 40 Watts 80 Watts
Power Factor >0.90
Ecacy 150 lm/w
Beam Angle 90 degree
Color Temperature 4000 K 5000 K 4000 K 5000 K
CRI >80
Operating Temperature -4~104°F (-20~40 °C)
IP Rating IP65
Fixture Material Aluminum alloy housing, Glass Lens
LED Lifetime 50,000 Hours
Dimmable 0~10V
Fixture Weight 9.67lbs (4.38Kg)
Standards and Certications UL, DLC
Warranty 5 year
Specications WPDG-40K40P WPDG-50K40P WPDG-40K80P WPDG-50K80P
• This product should be installed by a fully
certied electrician in accordance with local
building and electrical codes.
• Due to risk of electric shock, ensure that the
main power source and circuit breakers are
switched o before performing any installation
or wiring procedures.
• Failure to properly support the xture during
installation may cause damage or injury, for
which the manufacturer is not responsible.
Ensure the light bracket is securely mounted
and will support the weight of the xture.
Safety Notes
WPDG Series
Quick connect
Terminal
Slide front cover down
on hinges
Q
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mou
Screws
nt to J-box
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mou
Screws
nt to J-box
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mou
nt to J-box
Quick connect
Terminal
Slide front cover down
on hinges
Q
Drill bit
1/8” bit size
uick connect
Terminal
Quick connect
Terminal Conduit
J-box
Mou
Screws
nt to J-box
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray
Green
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Gray
