Superchips 1815 Installation manual

Page 1 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Superchips Model 1815 flashpaq Tuner
99-06 Expedition, Navigator, Excursion V8 4.6L/5.4L, V10 6.8L
99-08 Ranger / Mazda B3000 / B4000 V6 3.0L / 4.0L
99-07 F250 / F350 V6 4.2L, V8 4.6L / 5.4L, V10 6.8L
99-08 F150 V6 4.2L, V8 4.6 / 5.4L Trucks
Vehicle Programming Instructions
PLEASE READ THIS ENTIRE INSTRUCTION SHEET BEFORE YOU PROCEED
Thank you for choosing Superchips’ new FLASHPAQ Tuner,
a state-of-the-art, high powered tuning and data acquisition1
tool. We listened to our customers and created this product
from your requests.
The new FLASHPAQ Tuner includes the following features:
Internet Updateable – Supports web updates
Built-In DTC Definitions – No lookup manual needed
Built-In Help Screens – Reduces need for user manual
USB Communications – Connects to any PC2with USB
Custom Application Upgradeable – Download customs
Multiple Tuning Levels – User Selectable Tuning Types
Increased User Options – Allow user more control
Ergonomically Designed Case – Fits well in hand
Large, SoftKey Buttons – Easy operation
Permanently mounted cable – No assembly required
300% Bigger Screen – Includes graphics support
BackLight Screen – Easy to view day or night
Your 1815 FLASHPAQ houses specialized databases that contain optimally calibrated,
individual vehicle application, performance programs which tune BOTH the engine &
transmission. Superchips calibrations include optimization of the entire power band – from idle to
redline! Part throttle, as well as Wide Open Throttle is covered with Superchips FLASHPAQ
Tuning. Superchips calibrations are intended for stock vehicles.
Minimum Octane Requirements:
Super charged vehicles – 91 octane
Performance and Towing V8 – 91 octane
Performance and Towing V6 – 87 octane
The “87 Octane” Tuning Level provides optimal motor tuning while operating with 87 Octane fuel.
(Use of premium fuel is NOT recommended with this tune.)
If your vehicle is a Lightning or super-charged Harley Davidson Edition vehicle, an “HP4”
tuning level is offered in lieu of the “87 Octane” tuning level for use when a 4lb pulley is used to
raise boost pressure. Do not select this tuning level if you have the stock pulley installed.
Doing so will degrade engine performance.
The Superchips 1815 FLASHPAQ also offers users the following (options vary by vehicle):
Raise the Vehicle Top Speed Limiter
Raise the Engine Rev Limiter – Except 05-07’ F250
Selectable Axle Ratio Size (Correction of Speedometer & Shift Points) – Except 05-07’ F250
Selectable Tire Height (Correction of Speedometer & Shift Points)
Selectable automatic transmission Shift Point (per gear)
Selectable automatic transmission Shift Pressure (per gear)
Log onto, www.superchips.com to check for application updates.
1Visit www.superchips.com for availability
2Windows XP, 2000 or higher (MAC, UNIX, LINUX Not supported)
Page 2 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Table of Contents
Warranty and Important Product Information
Cover with Product Information Page 1
Table of contents Page 2
Warranty & Return Policy for Superchips products Page 3
Your Vehicle’s Stock Program Page 4
Important Note Regarding Storage of Your Tuner Page 4
Your Vehicle and Service Centers Page 4
Vehicle Preparation Page 4
FLASHPAQ Overview and Setup
Hardware Overview Page 5
Connecting the tuner to my vehicle Page 6
Opening Screen Overview Page 6
About (Part number, Firmware, Database, Serial Number) Page 7
Setting the Screen Contrast Page 7
Setting the Screen Backlight Page 7
Performance Tuning
Quick Start – Read & Program My Vehicle Now!! Page 8
Quick Start – Program my vehicle with User Options Now!!! Page 9
Return My Vehicle to Factory Stock Now!! Page 10
Menu Layout
FLASHPAQ Setup – Menu Layout Page 11
FLASHPAQ Setup Page 11
Read Vehicle – Menu Layout Page 12
Read Vehicle Page 12
Change Setup – Menu Layout Page 13
Change Setup – Power Level Page 13
Options – Menu Layout Page 14
Options Page 14
View Settings – Menu Layout Page 15
View Settings Page 15
Program Vehicle – Menu Layout Page 16
Program Vehicle Page 16
Advanced Features – Menu Layout Page 17
Diagnostics Page 17
Frequently Asked Questions
Frequently Asked Questions Page 18
Recovery Procedure Page 23

Page 3 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Refund Policy
If for any reason during the first thirty (30) days after your purchase of a new Superchips product (“Product”),
you may return it to the place you bought it for a full refund of the purchase price, credit or a replacement
Product at the dealer’s discretion. This Guarantee does not apply to products purchased from auctions nor
does it apply to Products purchased used. Follow these procedures to get your refund or replacement.
1. If you are returning a MicroTuner or Flashpaq, use the MicroTuner or Flashpaq to return your
vehicle to the stock settings for the vehicle. Instructions are included in the user manual.
2. Put the Product back in its original packaging.
3. Make a copy of your sales receipt. The sales receipt must be from the location where you
purchased your Product and must include the name of the business, its address, and the part
number or description of the applicable Superchips Product. Invoices, credit card statements, or
sales receipts from an online payment service company will not be accepted.
4. Return the Product in its original packaging with a copy of the sales receipt to the place of
purchase.
Superchips, Inc.
Limited Warranty
What is Covered? This warranty covers any defects in materials or workmanship in any product sold by
Superchips or its affiliates through its authorized dealers (“Product”). Warranty is valid only for new products
purchased through Authorized Dealers; (Proof of purchase is required for all warranty claims).
How Long Does the Coverage Last? This warranty lasts for one (1) year from the date of purchase.
Coverage terminates if you sell or otherwise transfer ownership of the Product.
What will Superchips Do? Superchips will repair or replace the defective or malfunctioning Product or any
defective or malfunctioning part thereof at no charge. This warranty covers parts and labor only. Superchips
will reimburse you for all reasonable shipping charges within the first thirty (30) days of purchase.
What Does This Warranty Not Cover? This warranty does not cover any problem that is caused by abuse,
misuse, acts of God, or improper installation or repair by non-Superchips personnel. This warranty does not
cover Products purchased used nor does it apply to Products purchased from auctions or entities that are
not Superchips’ authorized dealers. This warranty does not cover damage to your vehicle. Use of the
Product to change the performance characteristics of your vehicle could invalidate the warranty provided by
the vehicle manufacturer. Consult your vehicle warranty before using the Product on your vehicle.
SUPERCHIPS SHALL NOT BE LIABLE TO YOU FOR ANY CONSEQUENTIAL, SPECIAL, OR
INCIDENTAL DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY
NOT APPLY TO YOU.
How Do You Get Service? If something goes wrong with your Product during the warranty period, use the
following procedure to return the Product to Superchips.
1. Call Superchips’ Customer Service at 1-888-227-2447 Monday through Friday from 8:00 am to
5:00 pm EST to request a Return Authorization (“RA”) number.
2. Mark the outside of the shipping package with the RA number. Packages that are not marked
with the RA number will be refused.
3. Make a copy of your sales receipt. The sales receipt must be from the location where you
purchased your Product and must include the name of the business where you purchased the
Product and the address of such business. Invoices, credit card statements, or sales receipts
from an online payment service company will not be accepted.
4. Send the Product, postage paid, the copy of the sales receipt, a brief written description of the
problem, and your contact information to:
Superchips, Inc.
1790 East Airport Blvd
Sanford, FL 32773
Attn: Warranty Claims
We will inspect the Product and either repair it or replace it with a new or rebuilt Product. We reserve the
right to use refurbished parts when making repairs.
Your Rights Under State Law: This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Page 4 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Caution
For V8 engines, the “Performance”, “Towing”, and “HP4” tuning level requires that you
use at least 91 octane fuel. Using a lower octane fuel while the “Performance”, “Towing”,
or “HP4” tuning level is selected for your V8 may cause “pinging” that can be harmful to
your vehicle. This is not covered under your vehicle warranty or Superchips warranty.
Your Vehicle’s STOCK Program
The FLASHPAQ Tuner stores a copy of your vehicle’s original stock computer program.
To begin, your vehicle’s computer must contain the manufacturer’s STOCK factory program. If
you have used a programmer from another aftermarket company you must use their product to
return your computer back to STOCK condition before proceeding. If you have an aftermarket
performance-enhancing electronic device installed, it must be removed prior to using the
Superchips FLASHPAQ Tuner.
Your Vehicle and Service Centers
If you need to return your vehicle to a service center, restore the vehicle’s program to its STOCK
program. The service center might reprogram your vehicle with an updated STOCK program
without your knowledge. If your vehicle has not been returned to its STOCK program prior to
service, the Superchips FLASHPAQ Tuner will no longer be able to program your vehicle. Such
a failure is not covered by the Superchips Inc. warranty.
Vehicle Preparation
Before connecting the FLASHPAQ Tuner to your vehicle, make sure that:
•All power-draining accessories are turned off, including radio, lights, cell phones, etc...
The FLASHPAQ Tuner needs full battery voltage to program your vehicle.
•Ensure your vehicle battery is fully charged and not connected to a battery charger.
•Do not leave the FLASHPAQ Tuner connected and unattended for any length of time.
This prevents unnecessary battery drain.
•Do not remove the programming cable during any programming sequence.
Please follow the FLASHPAQ Tuner display screens.
Important Note Regarding Storage of Your FlashPaq Tuner
It is not recommended to store your FlashPaq Tuner in your vehicle in extreme heat, direct
sunlight, or extreme cold (temperatures near or below freezing). These conditions can cause
malfunction or dama
g
e to the FlashPa
q
Tuner not covered b
y
the Su
p
erchi
p
s Inc. warrant
y
.
About Maximum Trailer Weight
The original manufacturer of your vehicle has specified a Maximum Trailer Weight for your
vehicle. It may be found in your vehicle owner’s manual.
This Superchips product is designed to increase your engine power and performance. It
does not change the engine, suspension or drive train characteristics that limit the maximum
trailer weight your vehicle is designed to tow. Towing trailer weights above the maximum
trailer weight specified by the vehicle manufacturer may cause transmission or other
damage.
If you wish to tow greater than the maximum trailer weight for your vehicle, modifications to
your vehicle may need to be made. Consult your performance auto mechanic for the proper
vehicle modifications.
Damage caused by towing weights greater than the maximum trailer weight specified for
your vehicle shall not be the responsibility of Superchips Inc.

Page 5 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
FLASHPAQ Overview and Setup
¾Hardware Overview
The screen text on your particular FLASHPAQ Tuner may differ from the example above.
Graphical Display
Soft Key
Buttons
Note:
screenrelation
Vehicle Cable
USB
Port
for PC
Page 6 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
FLASHPAQ Overview and Setup
¾Connecting the tuner to my vehicle
Diagnostic port
Close-up
The Flashpaq plugs into your vehicle’s The port and cable are
diagnostic port usually underneath the dash setup to only fit on one
below the steering wheel (see white arrow). way. Typically the wider
edge faces the top, as
shown above.
¾Opening Screen Overview
When a Flashpaq is first powered up, the opening screen is displayed
Flashpaq Setup
oAbout
oSet Screen Contrast
oSet Screen Backlight
Performance Tuning
oRead Vehicle
oChange Settings
oView Settings
oProgram Vehicle
Advanced Features
oDiagnostic Codes
oData Logging (visit www.superchips.com for updates)

Page 7 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
FLASHPAQ Overview and Setup
¾About
*** Press DOWN to scroll as needed ***
From the Opening screen
1) Press ENTER – after selection of FLASHPAQ Setup
2) Press ENTER – after selection of About
Screen Displays:
•Product description
•Product part number
•“Operating software” Firmware Version #
Visit www.superchips.com for latest updates
•“Calibration (Tuning File)” Database Version #
Visit www.superchips.com for latest updates
•Product Serial Number
3) Press OK – Returns to the previous screen
4) Press EXIT – Returns to the Opening screen
¾Setting the Screen Contrast
From the Tuner Setup Screen
1) Press ENTER – after selection of Set Contrast
2) Press DOWN/UP & SAVE – adjusts screen contrast to increase
or decrease (text/graphics darkness)
¾Setting the Screen Backlight
From the Tuner Setup Screen
1) Press ENTER – after selection of Set Backlight
2) Press DOWN/UP & SAVE – adjusts screen Backlight to
increase or decrease (screen brightness)
3) Press EXIT – returns to Opening screen
Page 8 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Performance Tuning
¾Quick Start – Read & Program my vehicle NOW!!!
*** Press DOWN to scroll as needed ***
1) Press ENTER – after selection of Performance Tuning
2) Press ENTER – after selection of Read Vehicle
3) Press ENTER – after selection of Read Stock
4) Press OK – Begin with the Ignition OFF
5) Follow ON SCREEN – Prompts including Vehicle Ignition
ON/OFF/ON requests (DO NOT START VEHICLE!!)
6) Press EXIT – returns you to previous screen
From the Performance Tuning screen
1) Press ENTER – after selection of Change Setup
2) Press ENTER – after selection of Power Level
3) Press SAVE – after selection of the tuning level
4) Press EXIT – returns you to the previous screen
From the Performance Tuning screen
1) Press ENTER – after selection of Program Vehicle
2) Follow ON SCREEN – Prompts including Vehicle Ignition
OFF/ON requests (DO NOT START VEHICLE!!)
Upon completion, remove cable from vehicle
Your vehicle is now programmed with Superchips tuning!
You may now start your vehicle.

Page 9 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Performance Tuning
¾Quick Start – Program my vehicle with User Options NOW!!!
*** Press DOWN to scroll as needed ***
*** Press PLUS/MINUS to adjust options as needed ***
From the Opening screen
1) Press ENTER – after selection of Performance Tuning
2) Press ENTER – after selection of Read Vehicle
3) Press ENTER – after selection of Read Stock
4) Follow ON SCREEN Prompts including any Vehicle Ignition
ON/OFF requests (DO NOT START VEHICLE!!!)
5) Press EXIT – returns you to previous screen
From the Performance Tuning screen
1) Press ENTER – after selection of Change Setup
2) Press ENTER – after selection of Power Level
3) Press SAVE – after selection of the tuning level
Follow ON SCREEN Prompts for octane fuel & option status
1) Press ENTER – after selection of Options
2) Press NEXT/SAVE – adjusts Rev Limiter
You must have Z rated tires to modify the Speed Limiter
3) Press NEXT/SAVE – adjusts Speed Limiter
4) Press SAVE – after adjusting Axle Size
5) Press SAVE – after adjusting Tire height
6) Press SAVE – after adjusting (WOT) shift point 1-2
7) Press SAVE – after adjusting (WOT) shift point 2-3
8) Press SAVE – after adjusting (WOT) shift point 3-4
9) Press SAVE – after adjusting shift pressure 1-2
10) Press SAVE – after adjusting shift pressure 2-3
11) Press SAVE – after adjusting shift pressure 3-4
12) Press EXIT – returns you to previous screen
From the Performance Tuning screen
1) Press ENTER – after selection of Program Vehicle
2) Follow ON SCREEN Prompts including Vehicle Ignition
ON/OFF requests (DO NOT START VEHICLE!!!)
Upon completion, remove cable from vehicle
Your vehicle is now programmed with Superchips and user options!
You may now start your vehicle.
Page 10 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Performance Tuning
¾Return My Vehicle to Factory Stock Now!!!
Please follow the steps below to return your vehicle to factory stock
*** Press DOWN to scroll as needed ***
From the Opening screen
1) Press ENTER – after selection of Performance Tuning
2) Press ENTER – after selection of Change Setup
3) Press ENTER – after selection of Power Level
4) Press SAVE – after selecting the Stock tuning level
5) Press EXIT – returns you to previous screen
From the Performance Tuning screen
1) Press ENTER – after selection of Program Vehicle
2) Follow ON SCREEN Prompts including Vehicle Ignition
ON/OFF requests (DO NOT START VEHICLE!!!)
Upon completion, remove cable from vehicle
Your vehicle’s program is now returned to factory stock.
You may now start your vehicle.

Page 11 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Menu Layout
¾FLASHPAQ Setup – Menu Layout
¾ FLASHPAQ Setup
About: Displays Tuner Firmware Version, Database Version, Serial Number
Visit www.superchips.com for latest updates
Set Screen Contrast: Allows changes to screen text & graphics darkness
Set Screen BackLight: Allows changes to screen brightness level
(Adjustable for extreme viewing situations – direct sunlight, nighttime, low lighting)
FlashPaq
Main Menu
FlashPaq
Setup Performance
Tuning Advanced Features
FlashPaq
Setup
About Set Screen
Contrast Set Screen BackLight
Displays
Firmware #
Database #
Serial #
Adjust
Contrast
0-100%
Adjust
BackLight
0-100%
Page 12 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Menu Layout
¾Read Vehicle – Menu Layout
¾Read Vehicle
Display Vehicle ID: Displays vehicle identification from the connected vehicle
Read Stock Vehicle: Reads the factory stock file(s) from the connected vehicle
FlashPaq
Main Menu
FlashPaq
Setup Performance
Tuning Advanced Features
Performance
Tuning
Read
Vehicle Change Setup View Settings Program Vehicle
Read
Vehicle
Read
Vehicle ID Read Stock
Display
Vehicle ID Read Stock Vehicle

Page 13 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Menu Layout
¾Change Setup – Menu Layout
¾Change Setup – Power Level
Performance: Selects Superchips optimum performance tuning for engine & transmission.
Towing: Selects Superchips optimum towing tuning for engine & transmission
Note: V8 Performance and Towing tuning requires 91 octane fuel or better.
V6 Performance and Towing tuning is optimized for use with 87 octane fuel.
87 Octane (V8 Only): Selects Superchips optimum tuning for V8 engine & transmission when
using 87 octane fuel.
Stock w/ Options: Selects factory stock tuning while allowing user option changes.
Stock: Selects factory stock tuning for engine & transmission.
Change
Setup
Power Level Options
Select
Stock w/
Options
Select
87 Octane
Select
Towing
Select
Performance See Next
Page
Select
Stock
FlashPaq
Main Menu
FlashPaq
Setup Performance
Tuning Advanced Features
Performance
Tuning
Read
Vehicle Change Setup View Settings Program Vehicle
Page 14 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Menu Layout
¾Options – Menu Layout
Options
Shift Pressure
1-2
(WOT)
Shift Point
3-4
(WOT)
Shift Point
2-3
(WOT)
Shift Point
1-2
Shift Pressure
3-4
Shift Pressure
2-3
*General
User Options
Stock,
Superchips,
Stock +/- 5MPH
500 RPM
Stock,
Superchips,
Stock +/- 10MPH
500 RPM
Stock,
Superchips,
Stock +/- 10MPH
500 RPM
Stock,
Superchips,
Increase 2-20PSI
Axle (Gear)
Ratio
Selection
Engine Rev
Limiter
Settings
Tire Height
Selection
Vehicle
Speed
Limiter
Settings
Stock,
3.08, 3.31,
3.55,3.73, 4.10,
4.30,4.56,4.88,
5.13
Stock,
Superchips
Stock,
Superchips
28.00"-40.00"
0.25"increments
¾Options*
Raise the Vehicle Top Speed Limiter
Raise the Engine Rev Limiter – Except 05-07 F250
Selectable Axle Ratio Size (Correction of Speedometer & Shift Points) – Except 05-07’ F250
Selectable Tire Height (Correction of Speedometer & Shift Points)
Selectable automatic transmission Shift Point (per gear)
Selectable automatic transmission Shift Pressure (per gear)
Note: “WOT” – Wide Open Throttle.
WOT Shift Points & Shift Pressures also proportionally affect part throttle operation.
07-08 Ranger trucks support the “Shift Point” option, but only by MPH, not RPM & MPH.
*General User Options: Options Vary by vehicle

Page 15 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Menu Layout
¾View Settings – Menu Layout
¾View Settings
Display Vehicle ID & Tuner Status: Displays stored vehicle ID & tuner programming status
(This feature displays previously read data, no communications with the vehicle occur)
Display Power Level: Displays stored user selection from Change Setup - Power Level.
(This feature is for display only, to make changes see Performance Tuning - Change Setup)
Display Options: Displays current settings user has selected from Change Setup – Options.
(This feature is for display only, to make changes see Performance Tuning - Change Setup)
FlashPaq
Main Menu
FlashPaq
Setup Performance
Tuning Advanced Features
Performance
Tuning
Read
Vehicle Change Setup View Settings Program Vehicle
View
Settings
Power Level Options
FlashPaq
Status
Display
Power Level Display Options
Display
Vehicle ID
Tuner Status
Page 16 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Menu Layout
¾Program Vehicle – Menu Layout
¾Program Vehicle
Program Vehicle: Programs vehicle based on Change Setup – Power Level and Options.
(This feature is for live vehicle programming; an active vehicle connection to tuner is required.
Superchips optimum tuning will be installed without modification unless the user changes
settings in Power Level – Options)
FlashPaq
Main Menu
FlashPaq
Setup Performance
Tuning Advanced Features
Program
Vehicle
Performance
Tuning
Read
Vehicle Change Setup View Settings Program Vehicle

Page 17 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Menu Layout
¾Advanced Features – Menu Layout
FlashPaq
Main Menu
FlashPaq
Setup Performance
Tuning Advanced Features
Diagnostic
Codes Data Logging
Read DTCs AdvancedClear DTCs Log by Speed Log by
Distance
Advanced
Features
¾Diagnostics
Display DTC’s: Reads & displays DTC’s (Diagnostic Trouble Codes) from connected vehicle.
(This feature is for live vehicle diagnostics; an active vehicle connection to tuner is required.
Vehicle DTC’s, if present, will be displayed along with a full text description, when available)
Clear DTC’s: Clears current DTC’s (Diagnostic Trouble Codes) from connected vehicle.
(This feature is for live vehicle diagnostics; an active vehicle connection to tuner is required.
Vehicle DTC’s, if present, will be cleared. If DTC’s reoccur, this could indicate a vehicle
malfunction or problem condition)
Data Logging: Visit www.superchips.com for additional updates containing Data Acquisition.
(Please visit us to ensure your product is always up to date with the latest & greatest!)
Page 18 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Frequently Asked Questions
A. Measuring my tire in order to adjust my “Tire Size” setting.
Solution: Measure your “Tire Size” vertically, and place a ruler or a flat level item on the top of
your tire in order to measure accurately. Measure your vehicle’s Tire in inches and round up to
the nearest quarter of an inch. Note: “Tire Size” includes tire and rim.
See the picture below as an example of how to measure your specific vehicle’s tire.
B. Blank Display Screen when plugged into vehicle
Solution: Your diagnostic port may share power with the Cigar Lighter fuse. Please check the
owner manual & replace if bad.
If a blown fuse is not found, check the pin connectors in your vehicle diagnostic connector.
Make sure that none of these pins have been pushed out of the connector body.
(Note: Typically not all pins are present in this connector)
If still no resolution, plug your FLASHPAQ Tuner into another supported vehicle. If the tuner
powers up, your vehicle has something wrong with either the pins/wiring harness or there is
still a blown fuse in that circuit of the vehicle.
If your tuner fails to power up on a second supported vehicle, call Superchips Customer
Service at 407-585-7000 to ask for a Return Authorization (RA) to send the FLASHPAQ Tuner
in for inspection. (See Step C, 4 in this section for details.)
Top of Tire
------------------------------------Tire
S
ize------------------------------------
Ground Level

Page 19 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Frequently Asked Questions
C. FLASHPAQ ‘Tuner Requires an Update’
Solution: Your FLASHPAQ Tuner does not have the calibration files necessary to tune your
vehicle; therefore a database update may be necessary.
1) Write down any screen prompted text, such as
Tuner Requires
an Update...
Please visit www.superchips.com to update your tuner!
2) If you have internet access follow below, if not skip to step 4
3) From any PC running Windows XP, 2000 or higher
a. Connect to the internet
b. Go to www.superchips.com
c. Click ’New Users’ or ‘Existing Users’ (if previously registered)
d. Follow on screen prompts
i. Install software drivers, as prompted
ii. Run the application to update your tuner
iii. Plug in your supplied USB cable to your PC
iv. When prompted by setup plug in the USB cable to Flashpaq
v. Close Internet
vi. Disconnect tuner
vii. Return to vehicle for programming
4) Call Superchips customer service and request a RA #
a. Follow the check list on the last page of this instruction manual
b. Ensure you fill out the form completely on the last page
c. Return ship the tuner to Superchips
D. Vehicle Requires a Factory (Dealer) Update
If your FLASHPAQ Tuner has found your vehicle box code and it is problematic to tune, the
following messages will be displayed:
Vehicle Requires
a Factory Update
Call Superchips!
Use Code #E-XX (XX=a two digit number)
Record this File
Name: XXXXXXXXXX
Solution: Superchips has found that some stock applications have numerous problems that
have been fixed with an updated stock program available from a dealer for your vehicle. An
update of the stock program in your vehicle is required before your FLASHPAQ Tuner may be
used on your vehicle.
You may call Superchips Customer Service for confirmation that a dealer updated file is
available and instructions about how to have the stock files for your vehicle updated. Write
down both the Code number (#E-XX) and the File Name XXXXXXXXXX and give this to the
Superchips customer service representative.
Page 20 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Frequently Asked Questions
E. Unsupported application
If your particular vehicle or engine type is not currently supported by the FLASHPAQ Tuner,
the following error messages will be displayed:
This application
is unsupported
currently! Call
us if incorrect.
Call Superchips!
Use Code #E-36
Solution: Check year, model and engine to verify the FLASHPAQ Tuner being used is correct
for the application. If not, return it to the dealer from which it was purchased for the correct
FLASHPAQ Tuner. If the vehicle is correct for the FLASHPAQ Tuner being used, call
Superchips Customer Service at 407-585-7000.
F. Non-Stock File Application
If the FLASHPAQ Tuner has checked your file and cannot match it to a stock file the following
messages will be displayed:
Vehicle File is
Not Stock...
Call Superchips!
Use Code #E-43
Solution: This may be because another programmer has been previously used to reprogram
the vehicle. The vehicle computer must be reprogrammed with a valid stock program before
trying to use the Superchips FLASHPAQ Tuner. You may call Superchips Customer Service
for instructions about how to have the stock files for your vehicle updated. Write down both the
Code number (#E-XX) and the File Name XXXXXXXXXX and give this to the Superchips
customer service representative. If you require a Return Authorization (RA) please See Step B,
4 in this section for details.
G. Locked Vin Number
As long as FLASHPAQ Tuner programming is in a vehicle, the tuner is “locked” to that vehicle.
If an attempt is made to use your “locked” FLASHPAQ Tuner on a different vehicle the
following messages will be displayed:
Locked VIN
is mismatched!
Not the Original
Vehicle/Program
Call Superchips!
Use Code #E-37
Solution: Return the original vehicle back to stock before using the FLASHPAQ Tuner on a
different vehicle or purchase another FLASHPAQ Tuner for use on a second vehicle.

Page 21 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Frequently Asked Questions
H. Not original Program ID
If the FLASHPAQ Tuner is “VIN locked” to a vehicle and that vehicle has been updated at the
dealership to a different Box Code (identification number) without first using the FLASHPAQ
Tuner to Return the Vehicle to Stock, the following messages will be displayed:
Not the Original
Program ID
Not the Original
Vehicle/Program
Call Superchips!
Use Code #E-38
Solution: Your FLASHPAQ Tuner can only be unlocked if it is able to return the ‘VIN locked’
vehicle to stock. Since a dealership has replaced Superchips tuning with updated stock tuning,
you will need to call Superchips Customer Service at 407-585-7000 to ask for a Return
Authorization (RA) to send the FLASHPAQ Tuner in for inspection. (See Step B, 4 in this
section for details.)
I. Checksum Error
If the FLASHPAQ Tuner is “VIN locked” to a vehicle and that vehicle has been updated at the
dealership to the same Box Code (identification number) without first using the FLASHPAQ
Tuner to Return the Vehicle to Stock, the following messages will be displayed:
Not the Original
Program Checksum
Not the Original
Vehicle/Program
Call Superchips!
Use Code #E-39
Solution: Your FLASHPAQ Tuner can only be unlocked if it is able to return the ‘VIN locked’
vehicle to stock. Since a dealership has replaced Superchips tuning with stock tuning, you will
need to call Superchips Customer Service at 407-585-7000 to ask for a Return Authorization
(RA) to send the FLASHPAQ Tuner in for inspection. (See Step B, 4 in this section for details.)
J. Upload Error
If the FLASHPAQ Tuner cannot detect the ignition is in the on position the following messages
will be displayed:
Problem with
uploading!
Please retry
Call Superchips!
Use Code #E-XX (XX=a two digit number)
Solution: Make sure Ignition is ON (DO NOT START VEHICLE!). Retry again. It is possible
that your vehicle’s battery charge is low, please check and correct, if necessary.
Page 22 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Frequently Asked Questions
K. Ignition ON Error
If the FLASHPAQ Tuner cannot detect that the ignition is in the ON position, the following
messages will be displayed:
Cannot Detect
Ignition On
Please retry
Call Superchips!
Use Code #E-31
Solution: Make sure Ignition key is turned completely forward in the ON position (DO NOT
START VEHICLE!). Check to see if pins are pushed out of the diagnostic connector. It is
possible that your vehicle’s battery charge is low, please check and correct, if necessary.
L. Communications Error
If the FLASHPAQ Tuner looses communications the following messages will be displayed:
Communications
Error!!!
Please retry
Call Superchips!
Use Code #E-XX
Solution: Make sure Ignition is ON (DO NOT START VEHICLE!). Retry again. It is possible
that your vehicle’s battery charge is low, please check and correct, if necessary. If it still fails,
then contact Superchips. The FLASHPAQ Tuner will need to be returned to Superchips.
M. The FLASHPAQ Tuner did not program same number of files as saved
This is normal. The FLASHPAQ Tuner communicates with all the necessary modules on the
vehicle to gain the information needed to correctly operate. It may be necessary to save
additional files that are not programmed to allow for correct tuning.
N. My friend’s truck has the same engine but programs or reads at different speeds.
Each vehicle configuration has been optimized to the fastest and safest method of operation.
Your friend may have different types of vehicle computers in his truck which may require more
or less time to do certain operations.
O. Why do similar vehicle types have different numbers of files?
Even similar vehicles can have different configurations and quantities of computers. The
FLASHPAQ Tuner communicates with all the necessary computer modules in the vehicle to
gain the information needed to operate correctly.
P. My friend’s truck has the same engine but is tuned differently, why?
Each vehicle configuration has been optimized for the best tuning. Your friend’s truck may
have different types of vehicle computers, thus requiring different tuning.

Page 23 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
Recovery Procedure
In the event of a status message during a programming sequence, the FLASHPAQ Tuner will
attempt to recover the vehicle to the original stock program. It is necessary to carefully follow
the screen prompts, possibly requiring multiple “Ignition OFF” and “Ignition ON” sequences, to
correctly return the vehicle to stock settings.
Status Notification
When recovery is completed your vehicle is returned to factory stock. You are now able to
start your vehicle normally. You may now attempt to use the FLASHPAQ Tuner to program
your vehicle again or to program another vehicle (the tuner is now reset and not locked to a
vehicle). Follow the on-screen prompts. In the event that recovery is unsuccessful, or for
any reason the FLASHPAQ Tuner fails to complete its programming cycle, a Status
message will be displayed on the unit. Please make note of the message displayed and
contact Superchips Customer Service.
Page 24 of 24 Form 0159J 1815 03/10/2008 Superchips Inc.
Superchips Inc. 1790 East Airport Blvd., Sanford, FL. 32773 [phone] http://www.Superchips.com
Superchip & Superchips are registered trademarks of Superchips, Inc.
If it is necessary to return your Flashpaq Tuner to Superchips, please take a moment to
copy and fill out this form. The following information will be necessary to process your
request.
Check list:
Complete this form and have it available when you contact Superchips.
Contact Superchips Customer Service @ 407.585.7000 to obtain an RA number.
An RA number must be issued, enter the RA number on the bottom of this form.
Attach a photocopy of your purchase receipt to this form.
Attach this form to the product being returned to Superchips.
Name:______________________________________________
Street Address: _______________________________________
City: _______________________ State: _______ Zip: _________
Home Phone:__________________ Other phone: _______________
Place of purchase: _____________________________________
Date of Purchase: ______________________
Vehicle Year: _____ Vehicle Make: _______
Vehicle Model: ______________________
VIN Number: __________________________
Transmission: Automatic Manual
Tuner model: _____________________
Serial number on back of Flashpaq Tuner: ______________________
E-mail address: _____________________________________________________
RA Number:_________________
Prior to returning any product to Superchips, you must obtain
an RA number; please contact Superchips customer service
at 407.585.7000.
Please attach a photocopy of sales receipt here.
If in "Needs Update"
Mode or there is a Status
Message Please List:
File/Status #1:
File/Status #2:
File/Status #3:
