Superscope PSD410 User manual

User Manual
© Copyright 2010, Superscope Technologies, Inc.
PSD410
Music Practice and Digital Recording System
PREVIOUS
OVERDUB
PUNCH
IN/OUT
PUSH
ENTER
BEAT
LMIC RMIC
32
FUNCTION ADJUST
1
NEXT
PLAY/PAUSE
REC REVIEW
STOP
REC
POWER
TAPMETROTONETUNER
TEMPO
/ KEY
LOOP
INPUT
SELECT
TRACK
SELECT EDITCANCELMENU RECORD FORMAT

- 2 - Superscope PSD410 User Manual
Superscope PSD410 User Manual
The lightning flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
■Important Safety
Instructions
READ BEFORE OPERATING EQUIPMENT
This product was designed and manufactured to meet strict quality
and safety standards. There are, however, some installation and
operation precautions which you should be particularly aware of.
1. Read instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with dry cloth.
6. Do not use this apparatus near water.
7. To ventilate the unit, do not install it in a rack or bookshelf, and
note the following: Do not insert objects beneath the unit. Do not
block ventilation slots at the top of the unit. Do not place anything
about 1 meter above the top panel. Make a space of about 8“ (20
cm) around the unit.
8. Do not install near nay heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
Additional Safety Information!
• This product should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
• Apparatus shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the
apparatus.
• When the switch is in the OFF position, the apparatus isn’t
completely switched-off from the MAINS.
WARNINGS
Do not expose the equipment to rain or moisture.
Do not remove the cover from the equipment.
No naked flame sources, such as lighted candles, should be placed on the
equipment.
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Set the unit up on an even surface away from direct sunlight, high
temperatures, high humidity, and excessive vibration.
Do not place heavy items on the unit.
Do not use high voltage power sources. This can overload the unit and cause a
fire.
Do not handle the plug with wet hands. This can cause electric shock.
Do not let metal objects fall inside the unit.
Do not let liquids get into the unit.
Do not spray insecticides onto or into the unit.
Do not attempt to repair this unit by yourself.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR EVITER LES CHOC ELECTRIQUES, INTRODUIRE LA
LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE
DE LA PRISE ET POUSSER JUSQUíAU FOND.
NOTE TO CATV SYSTEM INSTALLER:
This reminder is provided to call the CATV (Cable-TV) system installer’s
attention to Section 820-40 of the NEC which provides guidelines for
proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close to
the point of cable entry as practical.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by tuning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numÈrique de la Classe B conforme à la norme NMB-003
du Canada.
SD Logo is a trademark. microSD Logo is a trademark.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION

Superscope PSD410 User Manual - 3 -
Contents
■Table of Contents
■Important Safety Instructions ..................... 2
■Table of Contents ......................................... 3
■Supplied Accessories .................................... 6
Infrared (IR) Remote .................................................. 6
AAA Batteries ........................................................... 6
AC Adapter ............................................................... 6
Micro SD Card ...........................................................6
Mini SD Card Adapter ............................................... 6
SD Card Adapter ....................................................... 6
USB Cable ................................................................. 6
AC Power Cord ......................................................... 6
RCA Patch Cables ......................................................6
■Introduction .................................................. 7
General Features ....................................................... 7
Recording Features .................................................... 7
Music Practice Features ............................................. 7
Package Contents .....................................................7
■Preparations Before Use .............................. 8
AC Adapter Safety ...................................................8
Remote Controller Battery Installation ....................... 9
■Top Panel ....................................................... 10
POWER .................................................... 10
FUNCTION CONTROL Buttons ............................. 10
A. TRACK SELECT ..................................................... 10
B. INPUT SELECT ....................................................... 10
C. LOOP .................................................................... 11
D. TEMPO/KEY ..........................................................11
E. TUNER ...................................................................11
F. TONE ..................................................................... 11
G. METRO ................................................................. 11
H. TAP ....................................................................... 11
BEAT Indicator ..................................................... 11
FUNCTION ADJUST Knobs ................................... 11
JOG WHEEL / JOYSTICK / ENTER ..........................11
OVERDUB ............................................................12
PUNCH IN / OUT .................................................. 12
CONTROL Buttons (Transport) ............................. 12
A. REC BUTTON ........................................................ 12
B. PREVIOUS & REC REVIEW BUTTON ....................... 12
C. PLAY/PAUSE Button .............................................. 12
D. STOP BUTTON ...................................................... 12
E. NEXT ..................................................................... 12
CONTROL Buttons (Top Right) ............................. 12
A. MENU ...................................................................12
B. CANCEL ................................................................ 12
C. EDIT ...................................................................... 12
D. RECORD FORMAT .................................................12
Internal Speaker ..................................................13
- Internal Mic R & Internal Mic L ................... 13
LCD Color Display ................................................ 13
■Front Panel .................................................... 14
Infrared (IR) Receiver ........................................... 14
IR Signal Indicator ................................................14
MIC / LINE L & R Level Control ............................. 14
Instrument Level Control ..................................... 14
Phantom Power ON/OFF SWITCH ........................ 14
MIC ATT ON/OFF ................................................ 14
RECORD LEVEL MAN / LIM / ALC .........................14
MAN (Manual) .......................................................... 14
LIM (Limiter) .............................................................. 14
ALC (Automatic Level Control) ..................................14
PHONES / SPEAKER LEVEL ................................... 14
PHONES Jack ....................................................... 14
■Right Side Panel ............................................ 15
Left / XLR / “1/4” Input Jack ................................ 15
Right / XLR / “1/4” Input Jack .............................. 15
INST IN Jack ......................................................... 15
AUX LEVEL .......................................................... 15
AUX IN Jacks ....................................................... 15
LINE OUT Jacks .................................................... 15
■Left Side Panel .............................................. 16
DC Input Jack ...................................................... 16
USB Connector .................................................... 16
Mini SD Slot ........................................................16
FOOT PEDAL Jack ................................................ 16
Digital OUT Jack .................................................. 16
Digital IN Jack ......................................................16
■Back Panel ..................................................... 17
Battery Compartment .......................................... 17
■Remote Control ............................................ 18
STANDBY / POWER ......................................... 18
w Alphanumeric Keypad ...........................................18
e FOLDER ................................................................. 18
r SEARCH ................................................................ 18
t CANCEL ................................................................ 18
y TEMPO .................................................................. 18
u ENTER ................................................................... 18
i FINE TUNE ............................................................. 18
o TEMPO RESET ....................................................... 18
a PLAY ................................................................ 18
s STOP ................................................................. 19
d REPEAT.................................................................. 19
f PAUSE .............................................................19
g DRIVE SELECT ....................................................... 19
h MUTE .................................................................... 19
j LOCATION ............................................................ 19
k LOOP ENTER/EXIT ................................................. 19
 FF (Fast Forward) ............................................. 19
 REW (Rewind).................................................. 19

- 4 - Superscope PSD410 User Manual
Contents
 Next ............................................................... 19
 Previous .......................................................... 19
 FINE TUNE RESET .................................................. 19
 KEY RESET ............................................................ 19
 KEY ....................................................................... 19
 MENU ................................................................... 19
 TONE ON/OFF ....................................................... 19
 TUNER ON/OFF ..................................................... 19
 METRO ON/OFF .................................................... 19
 INPUT MIC/LINE/AUX ............................................ 19
 RECORD ................................................................19
 RECORD REVIEW ...................................................19
 MONITOR ............................................................. 19
■LCD Display ................................................... 20
PLAY / STOP Mode .................................................... 20
Ⓐ Icons ..................................................................... 20
 Status Icons ........................................................... 20
w Loop Icons............................................................. 20
e Repeat Icons .......................................................... 20
r Voice Reduction Icons ........................................... 21
y Monitor Icons ....................................................... 21
y Mute Icons ............................................................ 21
u AC/Battery Icons ................................................... 21
PLAY / STOP Mode .................................................... 21
Ⓑ File Information ....................................................21
PLAY / STOP Mode .................................................... 22
Ⓒ Playback Data ....................................................... 22
PLAY / STOP Mode .................................................... 22
Ⓓ Location ............................................................... 22
Indicating Location .................................................... 22
PLAY / STOP Mode .................................................... 22
Ⓔ Balance & Levels ................................................... 22
PLAY / STOP Mode .................................................... 22
Ⓕ VU Meters ............................................................ 22
■Powering On ................................................. 23
Using the AC Adapter ............................................... 23
Using Batteries .......................................................... 23
Battery Life ................................................................ 24
AC Power and Battery Tips ........................................ 24
■Setting Date and Time ................................. 25
■About the Mini SD Card ............................... 26
Inserting a Mini SD Card ...........................................26
Inserting an SD Card with a Large Number of Audio
Files ........................................................................... 26
Inserting an SD Card with a Large Number of Non-
Audio Files ................................................................ 26
Inserting an SD Card Containing Large Audio Files .... 26
Removing the Mini SD Card ...................................... 27
■Setting Up Speakers ..................................... 27
Using Headphones or the Built-In Speaker ................. 27
External Speakers ...................................................... 27
■Setting Up Microphones, Instruments and
Other Sound Sources ....................................... 28
Microphones ............................................................. 28
Balanced Connections ............................................... 28
Unbalanced Connections ..........................................28
External Microphones ............................................... 28
Setting Levels ............................................................ 29
STEREO/PAN Mode ................................................... 30
Pan Setting – L/1 ....................................................... 30
Pan Setting – R/2 ...................................................... 30
Recording a Solo Performance ................................... 31
Internal Built-in Microphones ....................................32
Connecting Musical Instruments ............................... 33
Recording a Microphone and a Musical Instrument at
the Same Time .......................................................... 33
Line Level Sources ..................................................... 35
AUX .......................................................................... 36
Digital Connection .................................................... 38
Computer Connection ............................................... 39
■Working With Files and Folders .................. 40
Selecting Tracks ......................................................... 40
Searching Folders ...................................................... 40
Search a USB Device ..................................................40
Create a Folder .......................................................... 41
Rename ..................................................................... 41
Create a Playlist .........................................................42
■Music Practice ............................................... 43
How to Use the Tuner ............................................... 43
Using the Chromatic Tuner ........................................ 43
Using the Tuning Tone ............................................... 44
Using the Metronome ............................................... 44
Adjusting Accent Beat and Accent Beat Volume ........ 45
Using Tap Tempo ....................................................... 45
Using the [Search] Feature .........................................46
Text Input Method .................................................... 47
■Play ................................................................ 48
Playback Operation ................................................... 48
Playback Modes ........................................................ 49
Repeat Modes ........................................................... 49
A-B Loop (Repeat Playback) ...................................... 50
Set the A Point .......................................................... 50
Set the B Point .......................................................... 50
Adjusting Tempo, Key, and Fine Tune ........................ 51
Tempo ....................................................................... 51
Key ........................................................................... 51
Interval Indication ...................................................... 52
Fine Tune ..................................................................52
Voice Reduction ........................................................ 52

Superscope PSD410 User Manual - 5 -
Contents
■Editing ........................................................... 54
Export ....................................................................... 54
Creating a File with a New Tempo or Key .................. 54
Changing File Format ................................................ 55
Naming the Exported File ..........................................55
Move a Track ............................................................. 56
Copy a Track ............................................................. 57
Delete a Track ........................................................... 58
Divide a Track ............................................................ 58
Trim In / Out .............................................................. 61
Edit Track Information ............................................... 62
Title/Artist/Album ..................................................... 62
Genre ........................................................................ 63
24>16bit Convert ......................................................63
■Recording with the PSD410 ......................... 64
Basic Recording ......................................................... 64
Recording to External USB Storage ............................ 64
Track Increment ......................................................... 64
The Record Settings Menu ........................................ 65
Fade In / Out ............................................................. 65
Count In .................................................................... 65
Recording File Format ................................................65
Bit size table .............................................................. 66
Pre-Roll Time/ Post-Roll Time ..................................... 66
Auto Track Increment ................................................ 66
One Touch Recording ................................................66
Auto Convert ............................................................ 66
■Overdub ........................................................ 67
Overdubbing for Composition (Layering sections of a
Track) ........................................................................ 67
Overdubbing for Practice (Recording over a Loop) ..... 69
Monitor Source ......................................................... 70
■Punch In/Out ................................................. 71
Punch In/Out with Foot Pedal .................................... 73
■Recording Effects ......................................... 74
Selecting an Input Signal ........................................... 74
① Delay Time ............................................................ 75
󳿭 Decay ................................................................... 75
Playback Balance and Level........................................75
Equalizer Settings ...................................................... 77
Playback Equalizer ..................................................... 77
Frequency ................................................................. 77
Gain .......................................................................... 77
Bandwidth ................................................................ 78
Input Equalizer .......................................................... 78
■System Settings ............................................ 79
Auto Power Off .........................................................79
Backlight Timer ......................................................... 79
Recording Dimmer ....................................................79
Battery Type .............................................................. 79
Foot Pedal ................................................................. 79
Set Time / Date .......................................................... 80
■Appendix ....................................................... 81
Main Menu (1 of 2) ................................................... 81
Main Menu (2 of 2) ................................................... 82
Track Select Mode Transition Diagram ....................... 83
Input Select Mode Transition Diagram ....................... 84
Edit Menu Options .................................................... 85
Key/Tempo Menu......................................................86
Chromatic Tuner Menu .............................................87
Tone Menu................................................................ 87
Metronome Menu .....................................................87
Continuous Recording Time with Battery Operation .. 88
SD Card Record Times ............................................... 88
■Specifications ................................................ 89
General ..................................................................... 89
Audio ........................................................................ 89
Input/Outputs .......................................................... 89
■Trademarks, Copyrights and Disclaimers.... 90
MPEG Layer-3 Licensing ............................................ 90

- 6 - Superscope PSD410 User Manual
Superscope PSD410 User Manual
3
GHI
2
DEF
1
ABC
6
PQR
5
MNO
4
JKL
9
XYZ
8
VW
7
STU
0
SPACE
REPEAT
OFF / 1 / ALL
SDCD
DRIVE SELECT
HDDLOOP
ENTER / EXIT
MUTE
ON / OFF
BA
MENU CANCEL
FINE TUNE +
KEY RESET TEMPO RESET
ENTER
KEY
KEY
#
TEMPO TEMPO
+
FINE TUNE RESET
REMOTE CONTROL RC450PSD
LOCATION
♭
FINE TUNE
RECORD
j
POWER
MIC/LINE/AUX
ON / OFF
ON / OFF
ON / OFF
INPUT
TONE
TUNER
METRO
FOLDERSEARCH
PLAY
STOPNEXT PREVIOUS
PAUSEFFREW
xwfd
rsa
MONTOR REC REVIEW
Infrared (IR) Remote
Micro SD Card
Mini SD Card Adapter
SD Card Adapter
USB Cable RCA Patch Cables
AC Adapter
AC Power Cord
AAA Batteries
■Supplied Accessories
The following items (not pictured) are also in the box:
• Instruction Manual on CD-ROM (PDF format)
• Quick Start Guide (printed))

Superscope PSD410 User Manual - 7 -
Getting Started
■Introduction
Thank you for purchasing the Superscope PSD410 Recording System.
Were you looking for a high-quality, portable recorder? A music practice and transcription tool? If either factor
is important to you, we’re confident you’ll find the PSD410 is an immensely powerful and versatile audio system.
Here are just a few of the PSD410’s features:
General Features
• 3.5-inch liquid crystal color display for easy navigation of all features.
• Record more than 6 hours with eight nickel metal hydride AA batteries (or 4 hours with alkaline batteries).
• USB connection for transferring audio files to and from a computer.
• Stereo internal microphones.
• Stereo XLR combo microphone jacks.
• 48V phantom power.
Recording Features
• Record WAV or MP3 files to SD card or to external USB storage.
• Layer audio with the Overdub feature.
• Re-record portions of audio with the Punch In/Out feature.
• Edit file information or recorded audio (Trim, Divide, etc.).
Music Practice Features
• Change the key of a song without affecting tempo (+/- one octave in half steps or finer increments).
• Change the tempo of a song without affecting musical pitch (-75% to +50%).
• Create new versions of audio files in different keys and tempos.
• Seamlessly loop different sections of audio material for practice or transcription.
• Reduce lead vocals from stereo recordings.
• Rehearse with the built-in metronome.
• Tune your instrument with the 440Hz tone or chromatic tuner.
Package Contents
• One Superscope PSD410 Recorder.
• One AC adapter (DA450PSD).
• One micro SD card (with micro-mini adapter).
• One infrared wireless remote controller (RC450PSD).
• 2-AAA type batteries (for remote control).
• One USB cable.
• One RCA stereo audio system cable.
• One instruction manual on CD-ROM.
• One Quick Start Guide (printed).

- 8 - Superscope PSD410 User Manual
Getting Started
■Preparations
Before Use
AC Adapter Connection
Connect the power output plug of the adapter to the DC
IN jack of the recorder. Connect the AC Power cord to
the household AC power receptacle.
AC Adapter Safety
Only use the AC adapter that is provided with the
recorder. Use of other adapters may result in damage to
the recorder and invalidate the warranty.
Using Batteries
The recorder is designed for use with 8 “AA” size
Alkaline, Nickel-Cadmium (Ni-Cad) or Nickel-Metal
Hydride (Ni-MH) batteries.
The recorder DOES NOT allow for charging of
rechargeable batteries. If you use rechargeable batteries,
you must use an external battery charger (see battery
charger manufacturer instructions for operation and safe
use).
The battery capacity monitoring is different for alkaline
batteries and Ni-Cad/Ni-MH batteries. Please select
the correct battery type you are using from the System
Settings menu of the recorder.
To operate the recorder with battery power, install
batteries into the recorder as follows:
1. Remove the battery cover from the rear side of the
recorder.
2. Insert the batteries into the battery compartment,
making sure to align the positive ( + ) and negative
( - ) end of each battery according to the polarity
diagram shown inside the compartment.
3. Re-attach the battery cover to the rear side of the
recorder.
Safety Cautions When Handling
Batteries
To avoid leakage, overheating, fire and rupturing, always
follow the points below when using batteries with the
recorder.
• Electrolyte leakage or corrosion may occur if
batteries are kept inside the recorder for prolonged
periods of time. Remove batteries prior to prolonged
storage of the recorder.
• When installing batteries into the recorder, make
sure the batteries are installed with the proper
polarity shown inside the battery compartment of
the recorder.
• Do not attempt to recharge non-rechargeable
batteries.
• Do not install old/exhausted batteries into the
recorder. Dispose of old batteries properly.
• Do not mix the types (Alkaline, Ni-Cad or Ni-MH) or
voltages of batteries.
Remote Controller Notes
The remote controller may not work if the infrared
receiver is exposed to direct sunlight.
The remote controller will not work when there is an
obstacle between the wireless remote controller and the
infrared receiver.
Please be careful when using the remote controller near
other equipment that responds to infrared signals.
Please do not place objects on the remote controller. If
an object resting on the remote continuously depresses a
button, battery power will drain.
The remote controller will work within a range of 5m and
60 degrees right or left of the IR receiver, as indicated by
the following image:

Superscope PSD410 User Manual - 9 -
Getting Started
Remote Controller Battery Installation
Place 2-AAA batteries (included) inside the wireless
remote controller before it is used. Replace batteries by
removing the battery cover as shown:
Always match the polarity of the 2-AAA batteries with
the polarity indication inside the battery compartment.
Close the battery cover as shown:
With improper battery use, batteries may rupture, leak,
and cause corrosion. Please read the following guidelines
carefully:
If the remote controller is not in use for a long period of
time (more than one month), remove the batteries.
Please do not mix old batteries and new batteries
together.
Please match the polarity of the battery (+/ -) with the
polarity indication on the remote controller.
Batteries may have the same shape, but different
voltages. Do not mix different battery types.
If a battery leaks, clean the liquid from the battery
compartment and dispose of the leaking battery
according to the guidelines of your local government.
Please dispose of the used batteries according to the
guidelines of your local government.

- 10 - Superscope PSD410 User Manual
Controls
■Top Panel
POWER
Slide the POWER switch to the right to turn power ON or
OFF.
FUNCTION CONTROL Buttons
Ⓐ TRACK SELECT Ⓔ TUNER (Chromatic tuner)
Ⓑ INPUT SELECT Ⓕ TONE (Tuning tone)
Ⓒ LOOP (A-B) Ⓖ METRO (Metronome)
Ⓓ TEMPO/ KEY Ⓗ TAP
A. TRACK SELECT
Press to select a track for playback, Edit, Overdub, or
Punch In/Out. Also, use to select a record location. Press
this button a second time to return to the normal screen.
B. INPUT SELECT
Press to select an input for recording or practice. The
Input Select menu also provides options for Pan, Input
Equalizer, and Effect. Press this button a second time to
return to the main screen.

Superscope PSD410 User Manual - 11 -
Controls
C. LOOP
Press to set loop markers and seamlessly loop a section
of audio. Press this button a second time to return to the
main screen.
D. TEMPO/KEY
Press to adjust the Key, Tempo, and Fine Tuning of any
file played on the PSD410. The Tempo/Key menu also
provides options for Voice Reduction, Playback Level,
Playback Balance, and Playback Equalizer. Press this
button a second time to return to the main screen.
E. TUNER
Press to access the chromatic tuner. Press this button a
second time to return to the main screen.
F. TONE
Press to sound the 440Hz tuning tone. The frequency of
this tone is adjustable between 410Hz and 470Hz. Press
this button a second time to return to the main screen.
G. METRO
Press to access the Metronome menu. Press this button a
second time to return to the main screen.
H. TAP
When the metronome menu is selected, press repeatedly
at the desired tempo. Once this button has been pressed
six consecutive times, a new BPM (beats per minute)
setting will be established for the metronome.
BEAT Indicator
LED flashes on and off according to the BPM setting
of the metronome. The LED will flash green for normal
beats and red for accent beats.
FUNCTION ADJUST Knobs
Turn to adjust various parameters. In addition, pushing
the knobs resets certain settings to their default
values. Refer to indication on display for knob/function
relationship.
Ⓐ FUNCTION ADJUST #1 knob
Ⓑ FUNCTION ADJUST #2 knob
Ⓒ FUNCTION ADJUST #3 knob
JOG WHEEL / JOYSTICK / ENTER
Ⓐ JOYSTICK
Ⓑ JOG WHEEL
A. Move the joystick up and down to select items, or
in certain modes, to change screens. Move the joystick
right and left to changes parameters, or in Play mode to
search through a track. In addition, push the joystick to
"ENTER" (select) items or settings.
B. Turn the jog wheel to select various items or
parameters.

- 12 - Superscope PSD410 User Manual
Controls
OVERDUB
When an accompaniment track is selected, press this
button to enter Overdub mode. When overdubbing is
complete, press this button to return to the main screen.
PUNCH IN / OUT
When a track is selected, press to enter Punch In/Out
mode. When you have finished recording your punch-in,
press this button to return to the main screen.
CONTROL Buttons (Transport)
Ⓐ REC
Ⓑ PREVIOUS & REC REVIEW
Ⓒ PLAY/PAUSE
Ⓓ STOP
Ⓔ NEXT
A. REC BUTTON
From Stop mode, press to enter Record Pause mode or
Record mode. The Record LED will flash during Record
Pause mode and remain lit during Record mode. From
Record mode, press to increment a track.
B. PREVIOUS & REC REVIEW BUTTON
During playback, press to return to the beginning of the
track. If playback is within one second of the start point,
press to return to the beginning of the previous track.
In Stop mode, press to return to the beginning of the
previous track. In Record Mode, press to stop recording
and automatically play back the recently recorded file
(Rec Review function).
C. PLAY/PAUSE Button
From Stop mode, press to start or pause playback.
From Record Pause mode, press to begin recording.
From Record mode, press to pause the recording and
increment a track.
D. STOP BUTTON
Press to stop playback or recording.
E. NEXT
Press to advance to the next track.
CONTROL Buttons (Top Right)
Ⓐ MENU
Ⓑ CANCEL
Ⓒ EDIT
Ⓓ RECORD FORMAT
A. MENU
Press to view menu options.
B. CANCEL
Press to cancel settings and delete characters when
editing titles and file information.
C. EDIT
Press to view edit options.
D. RECORD FORMAT
Press to view the Record Settings menu.

Superscope PSD410 User Manual - 13 -
Controls
Internal Speaker
All PSD410 sounds can be heard through the built-in
monitor speaker.
- Internal Mic R & Internal Mic L
Use the Right and Left internal mics to record without
additional equipment.
LCD Color Display
High-resolution full-color liquid crystal display monitor.
Please refer to LCD Display for an explanation of display
icons.

- 14 - Superscope PSD410 User Manual
Controls
■Front Panel
Infrared (IR) Receiver
The infrared receiver detects signals from the wireless
remote controller.
IR Signal Indicator
This LED flashes red when a signal from the wireless
remote controller is received.
MIC / LINE L & R Level Control
Turn these knobs to adjust the level of the MIC/LINE
inputs.
Instrument Level Control
Turn this knob to adjust the level of the INST input.
Phantom Power ON/OFF SWITCH
Switch on to supply 48V phantom power to microphones
connected to the XLR inputs. Switch off when a
microphone does not need phantom power.
MIC ATT ON/OFF
If input level controls are turned low and microphone or
instrument levels are still too strong, switch on to add
15dB of attenuation.
RECORD LEVEL MAN / LIM / ALC
This switch determines the method for setting record
levels.
MAN (Manual)
Input level is controlled by manual adjustment of the
Mic/Line, INST, or AUX level controls.
LIM (Limiter)
Input level is controlled by manual adjustment of the
Mic/Line, INST, or AUX level controls. A limiter circuit
protects against signal overload.
ALC (Automatic Level Control)
The Mic/Line, INST, or AUX level controls are bypassed
and input level is controlled automatically. A limiter circuit
protects against signal overload.
PHONES / SPEAKER LEVEL
Turn this knob to adjust the level for the built-in speaker
and headphones.
PHONES Jack
Connect stereo headphones here. This input accepts ¼”
headphone plugs.

Superscope PSD410 User Manual - 15 -
Controls
■Right Side Panel
Left / XLR / “1/4” Input Jack
Connect microphones or line level equipment with XLR
or ¼” inch plugs here. Push the Input Select button [2B]
to select the input you wish to use.
Right / XLR / “1/4” Input Jack
Connect microphones or line level equipment with XLR
or ¼” inch plugs here. Push the Input Select button [2B]
to select the input you wish to use.
INST IN Jack
Connect an electric guitar, bass, or keyboard here.
VU Meter Overload If your keyboard or guitar/bass
signals routinely cause the VU meters to display “OVER,”
change INST Input Gain setting to Low.
AUX LEVEL
Turn this knob to adjust the input signal level of the AUX
IN.
AUX IN Jacks
Use these inputs when connecting line level equipment
with RCA outputs, such as CD players or mixing boards.
LINE OUT Jacks
Connect these outputs to the inputs of another audio
device, such as an amplifier, mixing board or alternate
recording device.

- 16 - Superscope PSD410 User Manual
Controls
DC Input Jack
Connect the DA450PSD AC to DC adapter here.
Do not use any adapter other than the DA450PSD.
USB Connector
Connect a USB cable here to transfer data between the
PSD410’s mini SD card and a PC. In USB mode, all other
features will be inactive. The PSD410 will not enter USB
mode during recording or when menu screens are active.
Mini SD Slot
Insert a mini SD card in here. (The PSD410 includes a
micro SD card with a micro-to-mini adapter.)
■Left Side Panel
FOOT PEDAL Jack
Connect an optional foot pedal here to provide Play/
Pause, Record/Pause, or Punch In/Out control. The
Superscope FT200 foot pedal is available at our online
store.
Digital OUT Jack
Connect to the digital input terminal of another audio
product. The PSD410 outputs a signal with a 44.1 kHz
sample rate.
Digital IN Jack
Connect the digital output of another audio product to
this terminal.

Superscope PSD410 User Manual - 17 -
Controls
■Back Panel
Battery Compartment
Insert a Ni-MH rechargeable battery or eight alkaline size
AA batteries here. Please refer to "Using Batteries.”

- 18 - Superscope PSD410 User Manual
Controls
STANDBY / POWER
Press to turn power ON or OFF.
※ During battery operation, this button can
only be used to power the unit off. The AC
adapter must be connected to power the unit
on with the remote control.
w Alphanumeric Keypad
When editing folder names, playlist names, or file
information, use the alphanumeric keypad to enter text.
e FOLDER
Press to select a new folder.
r SEARCH
Press to access the Search function.
t CANCEL
When editing folder names, playlist names, or file
information, use this button to delete a character. Also
used to undo changes to Menu settings.
y TEMPO
Press to increase or decrease playback speed without
affecting pitch.
u ENTER
Press to enter selected menus or confirm setting
changes.
i FINE TUNE
Press to increase or decrease playback pitch without
affecting playback speed. Fine Tune control is adjustable
+/-50 cents (100 cents = 1 semitone).
o TEMPO RESET
Press to reset Tempo control to normal speed.
a PLAY
Press to play the currently selected track.
■Remote Control

Superscope PSD410 User Manual - 19 -
Controls
s STOP
Press to stop playback.
d REPEAT
Press to change repeat mode. Options include: Off, All,
1, (Single, 1), (Single, All), and Single.
f PAUSE
Press to pause playback.
g DRIVE SELECT
On the PSD410, pressing the SD button will return to
the Track Select screen. The HDD and CD buttons are
reserved for the model PSD450 and will have no effect
on the PSD410.
h MUTE
Press to mute the internal speaker and Line Out. This will
not affect the headphones or Digital Out.
j LOCATION
A. LOCATION A – In Loop mode, press to set location A.
B. LOCATION B – In Loop mode, press to set location B.
k LOOP ENTER/EXIT
Press to enter and exit Loop mode.
 FF (Fast Forward)
Press and hold to initiate an audible forward search of
the playing track.
 REW (Rewind)
Press and hold to initiate an audible reverse search of the
playing track.
 Next
Press to advance to the next available track.
 Previous
Press to return to the beginning of the selected track.
Press within the first second of playback to return to the
previous track.
 FINE TUNE RESET
Press to reset Fine Tune control to normal pitch.
 KEY RESET
Press to reset Key control to normal pitch.
 KEY
Press to change the playback key in semitones. Press
‘♭’ to lower the key. Press ‘♯’ to raise the key. Key is
adjustable +/- one octave.
 MENU
Press to view Menu options.
 TONE ON/OFF
Press to sound the 440Hz tuning tone. The frequency of
this tone is adjustable between 410Hz and 470Hz. Press
this button a second time to return to the main screen.
 TUNER ON/OFF
Press to access the chromatic tuner. Press this button a
second time to return to the main screen.
 METRO ON/OFF
Press to turn the metronome ON and to enter the
metronome screen. Press this button a second time to
stop the metronome and return to the main screen.
 INPUT MIC/LINE/AUX
Press to change the Input Source. Options include: Input
MUTE, Internal MIC, External MIC, LINE, INST, Internal
MIC (Lch) + INST, External MIC (Lch) + INST, LINE (Lch) +
INST, AUX, and DIGITAL.
 RECORD
Press to enter Record Pause mode. Press this button a
second time to begin recording. During recording, press
this button to increment tracks.
 RECORD REVIEW
In Record mode, press to stop recording and
automatically play back the recently recorded file.
 MONITOR
Press to toggle the monitor source between Playback
Signal and Recording Signal. When Playback Signal is
selected, the input signals, e.g., External MIC, INST, etc.
will not be heard.

- 20 - Superscope PSD410 User Manual
LCD Display
■LCD Display
PLAY / STOP Mode
Ⓐ
Ⓐ Icons
 Status Icons
Indicates STOP
Indicates PLAY
Indicates PLAYBACK PAUSE
Indicates RECORD
Indicates RECORD PAUSE
w Loop Icons
Indicates “A-B” LOOP Playback is ON
Indicates “A-B” LOOP Playback is OFF
e Repeat Icons
Play back current track once, then stop at start of current track (Single, 1)
Play back and repeat current track (Repeat 1)
Play back all tracks once, then stop at start of the first track (Single, All)
