1 Safety instructions
12 Maintenance...........................................................................44
13 Disposal or waste....................................................................44
14 Appendi A – Flow measurement ranges.....................................45
14.1 Volumetric flow ranges.......................................................45
14.2 Analog output...................................................................46
15 Appendi B - Modbus communication e ample............................47
4 S430

1 Safety instructions
1 Safety instructions
Please check if this instruction manual matches the
product type.
Please observe all notes and instructions indicated in this
manual. It contains essential information that must be observed
before and during installation, operation, and maintenance.
Therefore this instruction manual must be read carefully by the
technician and by the responsible user / qualified personnel.
This instruction manual must be available at the operation site of the
flow sensor at any time. In case of any obscurities or questions
regarding this manual or the product, please contact the manufacturer.
W RNING!
Compressed air!
ny contact with quickly escaping air or bursting
parts of the compressed air system can lead to
serious injuries or even death!
•Do not e ceed the ma imum permitted pressure range (see
sensors label).
•Only use pressure-tight installation material.
•Avoid that persons get hit by escaping air or bursting parts of the
instrument.
•The system must be pressureless during maintenance work.
W RNING!
Voltage used for supply!
ny contact with energized parts of the product
might lead to an electrical shock which can lead to
serious injuries or even death!
•Consider all regulations for electrical installations.
•The system must be disconnected from any power supply during
maintenance work.
•Any electrical work on the system is only allowed by authorized
qualified personal.
S430 5

1 Safety instructions
TTENTION!
Permitted operating parameters!
Observe the permitted operating parameters, any
operation exceeding this parameters can lead to
malfunctions and might lead to damage on the
instrument or the system.
•Do not e ceed the permitted operating parameters.
•Make sure that the product is operated in its permitted limitations.
•Do not e ceed or undercut the permitted storage and operating
temperature and pressure.
•The product should be maintained and calibrated frequently, at
least annually.
General safety instructions
•It is not allowed to use the product in e plosive areas.
•Please observe the national regulations before/during installation
and operation.
Remarks
•It is not allowed to disassemble the product.
•Always use a spanner to mount the product properly.
TTENTION!
Measurement values can be affected by malfunction!
The product must be installed properly and
frequently maintained. Otherwise it might lead to
wrong measurement values, which can lead to
wrong results.
•Always observe the direction of the flow when installing the
sensor. The flow direction is indicated on the housing.
•Do not e ceed the ma imum operating temperature at the sensor
tip.
•Avoid condensation on the sensor element because it will affect
the accuracy enormously.
6 S430

1 Safety instructions
Storage and transportation
•Make sure that the transportation temperature of the sensor
without the display is between -30°C ... +70°C and with the
display between -10 ... +60°C.
•For transportation it is recommended to use the packaging which
comes with the sensor.
•Please make sure that the storage temperature of the sensor is
between -10 ... +50°C.
•Avoid direct UV and solar radiation during storage.
•For the storage, the humidity must be <90% with no
condensation.
2 Registered trademarks
SUTO®
Registered trademark of SUTO iTEC
MODBUS®
Registered trademark of the Modbus Organization, Hopkinton, USA
HART®
Registered trademark of the HART Communication Foundation, Austin,
USA
PROFIBUS®
Registered trademark of the PROFIBUS User Organization, Karlsruhe,
Germany
Bluetooth® word mark and logos
Registered trademarks of Bluetooth SIG, Inc.
Android™, Google Play
Trademarks of Google LLC
S430 7

3 RF exposure information and statement
3 RF exposure information and statement
This equipment complies with FCC RF radiation e posure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance of 20 cm between the radiator and
your body.
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device might not cause harmful
interference, and (2) this device must accept any interference received,
including interference that might cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, might cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an e perienced radio/TV technician for help
•This device and its antenna(s) must not be co-located or operating
in conjunction with any other antenna or transmitter.
8 S430

4 Application
4 pplication
The S430 flow sensor is designed to measure the consumption of
compressed air and a variety of industrial gases in wet or high mass
flow/velocity applications. The sensor can even work in wet and dirty
gases such as the outlet of a compressor.
The S430 can measure the following parameters for compressed air or
gases:
Parameter Default unit
Velocity m/s
Volumetric flow m3/h
Pressure bar
Total consumption m3
Temperature °C
Remark: You can change units using the service App
S4C-FS or the optional sensor display.
The S430 flow sensor is mainly used in compressed air systems in the
industrial environment. The S430 is not designed for e plosive areas.
For the use in e plosive areas, please consult the manufacturer.
S430 9

5 Features
5 Features
•Flow and consumption measurement in wet or high mass flow or
velocity applications.
•Measurement at the compressor outlet.
•Bi-directional measurement available based on the advanced auto-
direction-detection technology.
•Insertion-type flow sensor, facilitating installation under pressure
through a ball valve.
•High-temperature applications up to 230°C.
•Tubes with diameters from 1.25” up to 10” through center
installation. Bigger diameters through non-center installation.
•No mechanical wear parts.
•All parts in contact with the medium are made of stainless steel.
•Various options for the signal output, such as analog and pulse,
Modbus RTU, Modbus TCP, or M-Bus.
•Optional Power over Ethernet (PoE) for the Modbus TCP output.
•Mobile service App S4C-FS for monitoring and configuring flow
sensors on mobile devices.
•Optional display for monitoring and configuring values directly on
the sensor.
10 S430

6 Technical data
6 Technical data
6.1 General data
FCC ID: 2ASK2-SUTO-004
Parameters Flow selectable: Volumetric flow, working
condition flow, dry air flow,
Free Air Delivery (FAD),
mass flow
Consumption
Velocity (working condition)
Medium temperature
Medium pressure
Selectable units Volumetric Flow: m3/h, m3/min, l/min, l/s,
cfm
Mass flow: kg/h, kg/min, kg/s, t/h, lb/h
Consumption: m3, ft3, t, lb, l, kg
Velocity: m/s, ft/min
Temperature: °C, °F
Pressure: bar, psi, kPa, MPa
Reference conditions Selectable by users. Default e -factory
settings:
compressed air: ISO1217 20°C, 1000 hPa
other gas: DIN1343 0°C, 1013.25 hPa
Principle of measurement Differential pressure with Pitot tube
Sensor Differential pressure sensor
Measuring medium Air, gas (non corrosive gas)
Operating temperature -40 … +230°C probe tube
-30 … +70°C housing
0 … +50°C display (Optional)
-10 ... +40°C PoE (Optional)
Turndown ratio 1:10 (min/ma flow ratio)
Operating pressure 0 ... 1.6 MPa
Housing material PC + ABS
S430 11

6 Technical data
Material of the probe tube,
sensor head and the
screwing
Stainless steel 1.4404
Protection class IP65
Dimensions See dimensional drawing on page 15.
Display (optional) 2.4” colour graphics display with keypad
(optional)
Tube diameter 1.25” to 10” (greater diameters on request)
Screwing thread G 3/4” (ISO 228/1)
Weight 1.12 kg
6.2 Electrical data
Power supply 24 VDC, 150 mA
48 VDC, 100 mA (PoE)
6.3 Output signals
nalogue output Signal: 4 ... 20 mA
Scaling: 0 to ma imum volume flow /
velocity
Accuracy: 0.06 mA
Pulse output 1 pulse per consumption unit
Isolated switch: ma . 30 VDC / 200 mA
Pulse length: 30 … 120 ms depending on
the flow rate
Modbus output
(default setting)
See section 10.3 on page 41.
M-Bus output
(default setting)
See section 10.4 on page 43.
12 S430

6 Technical data
6.4 ccuracy
ccuracy* Flow: ±(1.5% of reading+0.3% full scale)
Pressure: 0.5% full scale
Temperature: 0.5°C
Stated accuracy at Ambient/process temperature 23°C ± 3°C
Ambient/process humidity <90%
Process pressure at 0.6 MPa
* The specified accuracy is valid only within the minimum and ma imum
flows that are indicated in section 14.1 on page 45.
S430 13

6 Technical data
The minimum flow rate depends on the medium pressure and the cut-
off setting. Below chart shows the relationship at 20 sm/s cut-off and
at 30 sm/s cut-off. The cut-off e factory is to 20 sm/s.
14 S430

7 Dimensional dra ing
7 Dimensional drawing
S430 15

8 Installation
8 Installation
Before you install the sensor, make sure that all components listed
below are included in your package.
Qty Description Item No.
1 S430 sensor S695 4300 or S695 4302
1 Sealing ring NA
1 Alignment key NA
2 Depending on orders:
M12 plug or M12 cable
Plug: C219 0059
Cable: A553 0104/A553 0105/A553 0146
1 Instruction manual NA
1 Calibration certificate NA
8.1 Installation requirements
To install the sensor, a ball valve and a nozzle are needed with the
following the requirements:
•The inner thread must be G 3/4”.
•The diameter of the nozzle must be ≥ 18 mm. Otherwise the shaft
can not be inserted in.
16 S430

8 Installation
8.2 Installation considerations
To achieve and maintain the accuracy stated in the technical data, the
sensor must be inserted in a straight pipe section with unhindered flow
characteristics.
8.2.1 Inlet and outlet sections
Unhindered flow characteristics are achieved if the section in front of the
sensor (inlet) and behind the sensor (outlet) are sufficiently long,
absolutely straight, and free of obstructions such as edges, seams,
curves, and so on.
Make sure that enough space e ists at your site for an adequate
installation as described in this manual.
TTENTION!
The wrong measurement might occur if the sensor is
not installed correctly.
•Pay careful attention to the design of the inlet and outlet sections.
Obstructions can cause counter-flow turbulence as well as
turbulence in the direction of the flow.
•The sensor is for indoor use only! At an outdoor installation, the
sensor must be protected from solar radiation and rain.
Remark: If there is any combination of the following situations, the
longest straight inlet section must be maintained.
S430 17

8 Installation
•E pansion •Reduction
•90° Bend •2×90° Bend
•Three dimensional Bend •T-piece
18 S430

8 Installation
•Shut-off valve •Filter or similar (unknown
objects)
8.2.2 Insertion angles
Insertion into a horizontal pipe
As shown in the left figure, the
angle to the horizontal level must
be >10°. A horizontal installation
is NOT permitted.
Please install the sensor only in
the recommended area.
S430 19

8 Installation
Insertion into a vertical pipe
As shown in the left figure, S430
can be installed in a vertical pipe
when the following two conditions
are met:
•The flow direction is from bottom
to top.
•The sensor is installed with a
horizontal angle of at least 10-
degree. (Recommended angle:
20-degree).
TTENTION: Do not install the
sensor in vertical pipes where the
flow is from top to bottom.
8.3 Calculating the insertion depth
Generally, you must insert the sensor tip in the center of the pipe with
the help of the sensor shaft that has a scale engraved. To determine the
right position, calculate the insertion depth as described below.
20 S430
