Sven MS-2080 User manual

www.sven.fi
OPERATION
MANUAL
2.1 Multimedia
Speaker System
MS-2080

ENG
2
2.1 Multimedia
Speaker System
Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2019. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The in-
formation in this Manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS...................................................................... 2
2. PACKAGE CONTENTS................................................................................ 3
3. SAFETY PRECAUTIONS.............................................................................. 3
4. TECHNICAL DESCRIPTION ......................................................................... 3
5. PREPARATION AND OPERATION .................................................................. 5
6. OPERATION MODES.................................................................................. 7
7. TROUBLESHOOTING ................................................................................. 9
8. TECHNICAL SPECIFICATIONS...................................................................... 9
1. BUYER RECOMMENDATIONS
• Unpack the device carefully. Make sure there are no accessories left in the box. Check up the de-
vice for damage; if the product was damaged during transportation, address the firm which carried
out the delivery; if the product functions incorrectly, address the dealer at once.
• Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or dis-
crepancy of numbers you forfeit the right for warranty repairs.
• Do not switch on the speaker system immediately after you bring it into a room from environ-
ment with negative temperature! After unpacking, the speaker system should be kept in conditions
of room temperature for at least 4 hours.
• Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.

ENG
3
MS-2080
Operation Manual
2. PACKAGE CONTENTS
• Subwoofer — 1 pc.
• Satellites — 2 pcs.
• Remote control (RC) — 1 pc.
• AAA type batteries — 2 pcs.
• Signal cable — 1 pc.
• Antenna wire — 1 pc.
• Satellite wall-mounting set — 2 pcs.
• Operation manual — 1 pc.
• Warranty card — 1 pc.
3. SAFETY PRECAUTIONS
Caution! High voltage inside! To avoid the risk of electric shock
do not open or touch elements inside.
• To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service
and repairs should be performed only by qualified specialists in an authorized service center. The list
of authorized service centers is available on www.sven.fi
• Do not allow the circuit of wires (including the grounded ones) between the speakers, on the power
amplifier or the ground, for it causes damage to the power amplifier output stage.
• Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.
• Do not put foreign objects inside the holes of the MSS.
• Protect the MSS from high humidity, water and dust.
• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
• Do not place any open flame sources on or close to MSS.
• Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When oper-
ating the MSS, do not put any devices on it, do not cover it with cloth or other objects preventing
it from cooling.
• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
MS-2080 2.1 Multimedia Speaker System (MSS) is designed to play music and sound games,
movies, etc. The MSS has a built-in power amplifier and audio cables allowing to connect it to
virtually any audio source (TV, PC, etc.) without using an additional power amplifier. The MSS has a
built-in FM radio, Bluetooth midule and audio player. Remote control is included.
Special features
• Built-in Bluetooth module
• Built-in audio player with storage media
• Built-in FM radio
• Digital LED display
• USB flash port and SD card slot
• Remote control
• MUTE, SLEEP and ST-BY modes
• Wall mountable satellites
• Wooden (MDF) cabinets of the subwoofer and satellites

ENG
4
2.1 Multimedia
Speaker System
Subwoofer control panels
aLED display
bST-BY/INPUT: standby mode on/off button (long
pressing);
switching of inputs and PC/AUX/FM/Player/Bluetooth
(pressed short)
cMENU: shift button of timbre control modes
d/AUTO: Play/Pause (pressed short in the
Player mode);
Start/Stop auto scan (pressed long in the
Radio mode)
e/СН-: previous track (pressed long in the
Player mode); previous station** (pressed long in
the Radio mode);
volume decrease (short pressing)
f/СН+: next track (pressed long in the Player
mode); next station** (pressed long in the Radio
mode);
volume increase (short pressing)
gU DISK: USB flash* contains МР3 and WAV audio
files
hSD/MMC CARD: SD/MMC cards* slot contains
МР3, WAV audio files
iON/OFF: on/off power switch
jPower cord
kFM ANT: FM input jack
lAUDIO INPUT: audio input jack
mAUDIO OUTPUT:audio output jack
Remote control
aDEL: delete selected FM station
bFM: Player mode
cTUNE+/-: manual scanning (Radio mode)
dCH-/ : previous track (pressed short in the Player
mode); previous station** (pressed short in the Radio
mode)
eAUX: AUX mode
fSW+/-: subwoofer volume level control
g0-9: numeric pad
hREPEAT: player operation mode
iRESET: return to default settings
jTRE-: treble level down
Fig. 1. Subwoofer control panel
Fig. 2. Side panel
Fig. 3. Subwoofer rear panel

ENG
5
MS-2080
Operation Manual
kVOL+/-: volume level control
lTRE+: treble level up
mCH+/ : next track (pressed short in the Player mode);
next station** (pressed short in the Radio mode)
n/AUTO: Play/Pause (pressed short in the Player mode);
start/stop auto scan (pressed long in the Radio mode)
oMUTE/DISP: sound on/off
pSLEEP: Sleep mode
q: MSS on/off button
rSAVE: Save selected FM station (Radio mode)
sBT: Bluetooth mode
tUSB/SD: Player mode
Battery Installation
• Open the battery compartment on the back of the remote control.
• Insert the included AAA batteries.
• Close the battery compartment.
Notes:
• Use the RC at an angle no more than 30° at a distance of no more
than 7 meters.
• If the remote control does not operate, check the batteries
or replace the discharged batteries with new ones.
• Remove the batteries from the RC if you don’t intend to use it
for a long time (more than one week).
5. PREPARATION AND OPERATION
Speaker placement
• Place the speakers symmetrically to the listener at least one meter
away. The subwoofer emits non-directional sound, therefore it can
be located in any place of the room where it sounds the best.
• Place MSS far away from monitors and TV sets, as insignificant
image distortion in these supersensitive devices is possible.
Fig. 4. Remote
control
* The storage device must be formatted as FAT, FAT32. Connection of external hard disks other
than USB flash drive is not recommended, otherwise it can cause the MSS damage.
** The feature is available if stations have been present in the memory.
b
c
c
d
e
g
a
f
h
n
l
k
j
o
m
i
+
-
+
-
0
q pr
s
t

ENG
6
2.1 Multimedia
Speaker System
Installation and operation
MS-2080 speaker system can be connected to virtually any audio devices: PCs, laptops, etc. (see
connection diagram in Fig. 5).
• Before making any connections, make sure the MSS is off and unplugged. And the ON/OFF
switch is in the OFF position. Then connect speakers to the subwoofer AUDIO OUTPUT m.
Observing the polarity connect the right speaker to the subwoofer AUDIO OUTPUT R with the
audio cable and the left speaker – to the AUDIO OUTPUT L (see connection diagram in Fig. 5).
• To connect the MSS to a PC, mobile device use 2RCA to mini-jack signal cable (included). Con-
nect the RCA jacks of the signal cable to the L and R jacks of the AUDIO INPUT
l , and the mini-
jack (
Ø 3.5 mm) of the signal cable – to the LINE OUT port of your PC sound card or to the audio
output mobile device, as shown in Fig. 5.
• Connect the subwoofer to the mains outlet with the power cord j .
• Turn on the MSS using button ST-BY b on the front panel or button q on the remote control.
• Select a desired signal source pressing short button b on the control panel or pressing buttons
b, e, s, t on the remote control.
• Adjust the master volume as desired with buttons VOL-, VOL+ e, f on the control panel or
pressing buttons VOL+/-
d, m on the remote control.
• Adjust the bass level using TRE+/-jbuttons on the remote control. The timbre level of the
system can be also adjusted using buttons e, fon the control panel preselecting this option
with MENU button c.
• Use SW+/- buttons fon the remote control to adjust the subwoofer volume level. The volume
level of the subwoofer can be also adjusted using buttons e, fon the control panel preselecting
this option with MENU button c.
•In order to have the high-fi gninetsilnehwnoitceridderiuqeraotannetnaehttceridnoitpecerytiled
the radio, first connect antenna to RADIO ANT jack k(see Fig. 5).
•When the MSS operation is over, mind to switch it off using ON/OFF switch (i, OFF position) and
unplug the power cord jfrom the socket.
Fig. 5. Connection diagram

ENG
7
MS-2080
Operation Manual
6. OPERATION MODES
Player Mode
• The system will enter the Player mode automatically when a carrier (USB flash or SD/MMC
card)* is connected to corresponding ports gor h, or press button bon the front panel of the
subwoofer or USB/SD button ton the remote control. The LED display awill show the selected
mode, then the number of the tracks found and a sequence number of the track played and then
the playback time elapsed. The playback will start automatically.
• To select a track, you can directly enter its number on the remote control using the numeric pad
buttons gor select it using buttons eand fon the front panel of the subwoofer. The display a
will show the track number for a short time and then the playback time elapsed.
• You can select the playback mode using REPEAT button hon the remote control (ONE – the
• playing track replay; RND – playback random tracks; ALL – playback all tracks available).
Bluetooth mode
• In order to transmit signal in this mode it is necessary by first to connect the device with a signal
source (see Fig. 6). For this purpose select the Bluetooth mode using button bon the front panel
of the subwoofer or BT button son the remote control. After 2-3 seconds the speaker system will
enter the search mode, BLU mode is shown on the display a«bt».
• It is necessary to select the search mode of devices with Bluetooth on a signal source (telephone,
notebook, smartphone, etc.) «MS-2080», message will be displayed on the screen which it should
be connected with**.
• The «bt» indicator lights continuously when connection is successful. If there is no any
connection, the lighting of the «bt» indicator is intermittent. In this case the system should be
switch over to the search mode once again (to turn off and turn on anew)***.
• It is possible to control the player of a signal source from the remote control or using the button
on the front panel of the subwoofer when connecting to a signal source.
• To force disconnect from BT signal source - press and hold the buttons AUTO con the front
panel of the subwoofer or button son the remote control.
FM Mode
• Use button b on the front panel of the subwoofer or FM button bon the remote control to enter
the FM mode. The display awill current adjustment frequency.
• Press long AUTO button don the front panel of the subwoofer or AUTO button non the remote
control short to auto scan and memorize the found stations.
• The second pressing of this button before the scanning is over will stop the auto scanning
process. The display ashows the frequency being scanned, when a radio station is being
memorized, the display shows its assigned sequence number for a short moment.
* The operation may be incorrect if a SD card of 512 Mb capacity or lower is used. If a USB flash
device of 8 Gb capacity or more is used, command processing time may be extended.
** You might have to enter “0000” code to connect some models of devices via Bluetooth.
*** If an item has been already registered in the device list of a source, then the second search
mode activation is not obligatory. Choose only the item name and the “connect” command on the
source.

ENG
8
2.1 Multimedia
Speaker System
• For manual scanning, use buttons TUNE-/+ c on the remote control (up/down the frequency
range). To save a selected frequency, press SAVE button ron the remote control, then using
buttons e, fon the front panel of the subwoofer or buttons d, mon the remote control select a
cell number to save and press the SAVE button once again. When saving, the display awill show
the message “Good”.
• If preset radio stations are available in the memory, you can switch from one to another by long
pressing buttons e, fon the front panel of the subwoofer or buttons d, mon the remote
control. You can also enter the frequency or the number of the preset station using numeric pad
buttons gon the remote control. The display awill show the station number for a short moment
and then its frequency. The radio will tune to the set frequency within 2-3 seconds.
AUX Mode
•Press button bon the front panel of the subwoofer or AUX button e on the remote control to
switch tothe AUX mode. The display awillshow «AUX» inscription.
ST-BY Mode
• To enter/exit «ST-BY» mode press and hold button ST-BY bfront panel of the subwoofer or
button qon the remote control. To exit «ST-BY» mode press ST-BY bon the front panel of the
subwoofer or button qon the remote control.
SLEEP Mode
• The SLEEP mode enables to switch over the device in the ST-BY mode after a lapse of time
chosen by a user. Press button pon the remote control to enter the SLEEP mode. To leave the
SLEEP mode, press button pon the remote control once again, while there is “0” character on
the display.
MUTE Mode
• To enter the MUTE mode, press button oon the remote control. To exit the MUTE mode, press
this button oonce again, or press volume button.
Note. Due to the constant development of the software, the actual MSS operation may
differ from described in this Manual. The most recent version of the Manual is available on
www.sven.fi.
Fig. 6. Bluetooth module connection diagram

ENG
9
MS-2080
Operation Manual
8. TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Output power (RMS), W:
subwoofer
satellites
70 (40 + 2 × 15)
40
2 × 15
Frequency response, Hz:
subwoofer
satellites
45 – 150
150 – 20 000
Speaker diameter, mm:
subwoofer
satellites
Ø 145
Ø 25 + Ø 70
Power supply, V/Hz ~230/50
Radius of operation, m up to10
Dimensions, mm:
subwoofer
satellites (one speаker)
250 × 340 × 290
105 × 200 × 100
Weight, kg 5.6
Notes. Technical specications given in this table are supplemental information and can-
not give occasion to claims. Technical specications and package contents are subject
to change without notice due to the improvement of SVEN production.
7. TROUBLESHOOTING
Problem Cause Solution
The MSS does not
turn on.
The MSS isn’t connected
to a mains outlet.
Check the connection.
The power switch is off. Turn on the switch.
No sound or the
sound is too quiet.
Volume level is set at
minimum value.
Adjust the volume control.
Improperly connected
audio source.
Connect the audio sources
correctly.
Distortion of sound. Large amplitude of the
input signal.
Turn down the source volume
and the MSS volume.
The remote control
is not working.
The batteries are
discharged.
Replace the batteries with new
ones.
If none of the above methods can solve the problem, please seek professional advice at your nearest
service center. Never attempt to repair the product yourself.

2.1 Multimedia
Speaker System
MS-2080
Model: MS-2080
Импортер в России: OOO «Регард», 105082,
г. Москва, ул. Фридриха Энгельса, д.75, стр.5.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 56, стр. 1. Условия гарантийного
обслуживания смотрите в гарантийном та-
лоне или на сайте www.sven.fi. Гарантий-
ный срок: 12 мес. Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176
Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Сканди-
навия Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat
Road, № 02-02, Singapore, 427447.
Produced under the control of Oy Sven Scan-
dinavia Ltd. 15, Kotolahdentie, Kotka, Finland,
48310. Made inChina.
® Registered Trademark
of Oy SVEN
Scandinavia Ltd. Finland.
9S0917
