Swann Al Fresco SH16310N User manual

v1.0
Patio Heaters Assembly
Photo Guide
Models: SH16310N, SH16320N, SH16330N
Please read in conjunction with the printed manual
that came with the product
Help line: 0333 220 6050
Patio_Heaters_Assy.indd 1 03/05/2019 11:35

2
1. Lower body
2. Upper body
3. Base
4. Base cover
5. Cord grip
6. Screws for joint boards
7. Screws & washers for base
8. Joint boards
9. Allen key
You will also need a cross head screw driver. Assembly is much
easier with two people and reduces the risk of damaging the
product.
SH16310N - COLUMN PATIO HEATER
1 2 3
4
56
7
89
Patio_Heaters_Assy.indd 2 03/05/2019 11:35

3
SH16310N - COLUMN PATIO HEATER
Thread the plug and
cable from the upper
body (2) through the
channel in the lower
body (1)
Make sure it goes all
the way through.
Slide the upper body
(2) on to the lower
body (1)
Patio_Heaters_Assy.indd 3 03/05/2019 11:35

4
SH16310N - COLUMN PATIO HEATER
Fit the joint boards
and secure with the
screws (6) using the
allen key provided (9)
Turn the unit upside
down (put some cloth
down to prevent
scratches).
Put the base (3)
inside the base cover
(4) and thread the
plug and cord through
the hole in the middle
Patio_Heaters_Assy.indd 4 03/05/2019 11:35

5
SH16310N - COLUMN PATIO HEATER
Fasten the base to
the main unit using
the screws & wash-
ers (7)
Fasten the cord grip
(5). Make sure the lip
faces upwards
Refer to the manual that came with the product for operation guide
Patio_Heaters_Assy.indd 5 03/05/2019 11:35

6
SH16320N - BAR TABLE PATIO HEATER
1. Main body
2. Base cover
3. Base
4. Table top
5. Foot bracket
6. Allen keys - 1 large + 1 small
7. Screws & washers for base
8. Long screws + steel tubes
9. Screws for table top
You will also need a cross head screw driver. Assembly is much
easier with two people and reduces the risk of damaging the
product.
1
2
3
4
5
6
7
8
9
Patio_Heaters_Assy.indd 6 03/05/2019 11:35

7
SH16320N - BAR TABLE PATIO HEATER
Turn the main body
(1) upside down (put a
cloth down to prevent
scratches)
Fit the base cover and
thread the plug and
cord through the hole
in the middle.
Fit the base inside the
base cover (2) and
align the holes ready
for the screws and
washers.
Patio_Heaters_Assy.indd 7 03/05/2019 11:35

8
SH16320N - BAR TABLE PATIO HEATER
Fit the screws and
washers. Leave them
slightly loose for the
moment. This allows
a little movement in
the base for the next
part...
Get someone to hold
the bar base (5) in
position.
Thread the long
screws though the
holes in to the steel
tubes (8) and into the
threaded holes on the
bar base.
Don’t fully tighten
them until all 3 are
fitted
Patio_Heaters_Assy.indd 8 03/05/2019 11:35

9
SH16320N - BAR TABLE PATIO HEATER
Once all 3 of the long
screws are fitted,
tighten them all (using
the larger allen key)
Finally tighten the
base screws as well
(small allen key)
Fit the cable to the
cable tie and fit the
castors
Patio_Heaters_Assy.indd 9 03/05/2019 11:35

10
SH16320N - BAR TABLE PATIO HEATER
Turn the unit the right
way up again & offer
up the table top.
The holes must line
up as shown. The
bump (2) must align
with the hole (1)
This MUST be a 2
person task or you
risk breaking the
table top.
1
2
Fit the screws to se-
cure the table top to
the main unit.
Refer to the manual that came with the product for operation guide
Patio_Heaters_Assy.indd 10 03/05/2019 11:35

11
SH16330N - PORTABLE PATIO HEATER
1. Main body
2. Base cover
3. Base
4. Cord grip & screws
5. Allen key
6. Deco board
7. Base screws & washers
You will also need a cross head screw driver. Assembly is much
easier with two people and reduces the risk of damaging the
product.
1
2
3
45
6
7
Patio_Heaters_Assy.indd 11 03/05/2019 11:35

12
Fit the deco boards
(6) as shown
SH16330N - PORTABLE PATIO HEATER
Put the base (3)
inside the base
cover (2) and thread
the plugs and cord
through the hole in
the middle.
Make sure the 2
mounting holes are
aligned.
Patio_Heaters_Assy.indd 12 03/05/2019 11:35

13
Fit the base assem-
bly to the main body
(1) and tighten the
screws and washers
(7) as shown.
SH16330N - PORTABLE PATIO HEATER
Fit the cord grip (4)
ensuring the lip faces
upward.
Refer to the manual that came with the product for operation guide
