SwiftColor SCL-4000D Guide

SCL-4000D
Read this guide first.
Please read this guide before operating this product.
After you finish reading this guide, store it in a safe place for future reference.
SCL-4000P

The instruction manuals for this printer consist of the following.
START GUIDE(This Manual)
■ Please read before use of the
printer. This START GUIDE
contains precautions for safe
operation and instructions for
preparations necessary before
using this printer (such as
instructions on installing the
printer driver).
USER’S GUIDE
It is included in a Printer Software CD-ROM.
■ The USER’S GUIDE is in PDF
format. It contains specific
instructions on operation,
daily maintenance, and
troubleshooting.
- Adobe Reader must be installed
to view USER’S GUIDE. If Adobe
Reader is not installed in the
computer in use, download it from
the homepage of Adobe Systems
Incorporated and install it in the
computer.
About the Instruction Manuals
The CD-ROM supplied with the printer contains User’s Guide and the printer
driver. Please read this guide for instructions to install the printer driver.
About the Printer Software CD-ROM

2
Table of Contents
Before You Begin ...........................................................4
Conventions ........................................................................... 4
Illustrations and Sample Screens ........................................ 4
Trademarks ............................................................................ 4
Abbreviations ........................................................................ 5
Request to the Customer ...................................................... 5
Legal Notice ........................................................................... 5
Safety Warnings and Precautions .........................8
Check on the Bundled Items ......................................14
Before Using the Printer .............................................16
Printer Part Names and Functions .................................... 16
Front View ....................................................................................... 16
Rear View ....................................................................................... 17
Inside the Printer ............................................................................. 18
Roll Holder ...................................................................................... 19
Operation Panel .............................................................................. 20
Installing Software ......................................................22
Operating Environment ...................................................... 22
Installing the Printer Driver ................................................ 23

3
Table of Contents
Using the Printer Via a USB Cable ................................................. 23
Using the Printer Via a LAN Cable .................................................. 28
Import / Export Settings .................................................................. 35
Installing the User’s Guide ................................................. 41
Reading the User’s Guide ................................................... 43
Paper Loading Procedure ...........................................46
Specications ..............................................................50

4
Conventions
The following marks are used in this guide.
Warning Indicates a warning concerning operations that may lead to death or injury
to persons if not performed correctly. To use the machine safely, always pay
attention to these warnings.
Caution
Indicates a caution concerning operations that may lead to injury to persons
if not performed correctly. To use the machine safely, always pay attention to
these cautions.
Important Indicates operational requirements and restrictions. Be sure to read these
items carefully to operate the machine correctly, and avoid damage to the
machine or property.
Note Indicates a clarification of an operation, or contains additional explanations for
a procedure. Reading these notes is highly recommended.
Indicates an operation that must not be performed. Read these items carefully,
and make sure not to perform the described operations.
Illustrations and Sample Screens
The illustrations and the sample screens of the printer driver settings in this guide were created with
Swiftcolor SCL-4000D in Windows 7. The contents of these printer driver screens and instructions
are essentially the same as Windows Vista and Windows XP as well as those for Swiftcolor
SCL-4000P; however,explanations are provided when there are minor differences in screen content
or procedures.
Trademarks
● Microsoft, Windows and Windows Vista are trademarks of Microsoft Corporation in the
United States and/or other countries.
● Adobe and the Adobe logo are trademarks of Adobe Systems, Inc.
● Other brand and product names may be trademarks of their respective companies.
Before You Begin

5
Before You Begin
Abbreviations
Throughout this document the following abbreviations are used in text.
● Microsoft Windows 7 is abbreviated as “Windows 7”
● Microsoft Windows Vista is abbreviated as “Windows Vista”
● Microsoft Windows XP is abbreviated as “Windows XP”
● Microsoft Windows is abbreviated as “Windows”
Request to the Customer
● Copying this guide or any part of this guide without permission is strictly forbidden.
● The specifications for this printer as well as the software provided with the printer are subject
to change without prior notice.
● We have done our best to make this guide as complete and accurate as possible, and we
ask you to contact to the dealer where you purchased the printer if you find any omissions or
mistakes in this document.
● We can accept no responsibility for loss or damages resulting from the use of this printer or
its software; please accept this before you use the printer.
Legal Notice
■ Legal Limitations on the Usage of Your Product and the Use of
Images
● It is illegal to reproduce currency, bills, negotiable securities and other documents prohibited
by law. Reproduction of such items may be subject to criminal prosecution.
● It is illegal to reproduce legal certificates, licenses, and certain public and private documents
prohibited from reproduction by law. Reproduction of such items may be subject to criminal
prosecution.
● Please note that intellectual property protected by copyright may not be reproduced without
the express permission of the copyright holder except for personal or household use under
limited circumstances.

6
Before You Begin
■ Product Name
SCL-4000D
SCL-4000P
■ CE
This equipment conforms with the essential EMC requrements of EC Directive. We declare that this
product conforms with the EMC requirements of EC Directive at nominal mains input 230V, 50 Hz
although the rated input of the product is 100 to 240 V, 50/60 Hz. Use of shielded cable is necessary
to comply with the technical EMC requirements of EC Directive.
■ FCC (Federal Communications Commission)
FCC Part 15 Compliance
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause interference to
radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV engineer for help.
CAUTION: Changes or modications to this equipment not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.

8
Before using this printer, please read this section (“Safety Warnings and Precautions”) thoroughly.
Warnings to need and important matters are described here to prevent damages to the user and
other persons. Do not attempt to operate this printer in any way other than those mentioned in the
User’s Guide.
■ Location
Make sure that there is sufficient space around the printer.
548mm
594mm
600mm
Height at the Roll cover open
Upper unit open and Roll cover open (D)
765mm
Maintenance cartridge door open and
Roll cover open (W)
Setting space
Upper unit open and Roll cover open and Ink tank door open (D)
Safety Warnings and Precautions
