INSTALLATION
INSTRUCTIONS
Ivy One-Piece Toilet
SM-1T112
www.swissmadison.com | 1-434-623-4766 | [email protected]om
Share your pictures for a feature!
using #SwissMadison
Swiss Madison

®

Prior to Installation:
If you have any questions or concerns please contact us:
Inspect toilet to ensure no damages have occurred while in shipping.
Observe all plumbing and building codes in accordance with your state and local requirements.
Remove old toilet.
Make sure mounting surface is CLEAN and LEVEL
1-434-623-4766
[email protected]om
General Recommendations: Read installation and maintenance instructions thoroughly before installing the toilet.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
—1 —

—2 —
Thank you for purchasing a Swiss Madison One-Piece Toilet.
We appreciate your business and know you will enjoy your toilet for many years to come.
If you have any questions or require assistance we would be happy to help,
please contact us at 1-434-6234766 or [email protected].
Thank you for your purchase
www.swissmadison.com
To learn more about our products, please visit:
Sincerely,
The Swiss Madison Team

ONE-PIECE TOILET ROUGH DIMENSIONS
—3 —
NOTE: Specialized tools may be necessary to install a Swiss Madison One-Piece Toilet, plumbing not included.
SUGGESTED TOOLS AND MATERIALS
One-Piece Toilet Wax Ring/ Gasket Bolts Side Cover Caps
Safety Glasses Wrench Level
Screwdriver
NOTE: Distance from wall to closest ange centerline must be listed as below.
Putty Knife Tape Measure
Hacksaw
Flexible Supply Tube
PARTS LIST
28.5”
15.5”
18.5”6.5”
14” 26.5” 14”
12”
6”

ONE-PIECE TOILET INSTALLATION INSTRUCTIONS
1. Read the complete instruction manual before beginning installation.
2. Conrm that your model will t in intended location and plumbing xtures are located where
legally required before beginning installation.
3. Not all drawings on this manual are drawn to scale. Please refer to the model chart.
4. Two people are recommended to install and move this product.
5. Product is FRAGILE! To avoid breakage and possible injury handle with care.
—4 —
NOTE: Drawings may not exactly dene contour of china.
The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison One-Piece Toilet.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
2. Rough-In the Toilet
Using the measurements on the previous page nd the toilets rough-in.
Measure the wall from behind the toilet to the middle of the closet bolt.
NOTE: Your rough-in measurement should be around 12”.
Rough-in
1. Remove Old Toilet
Close toilet supply valve and ush tank completely, use towel or sponge to remove excess water.
Disconnect and remove supply line, if you are replacing the valve shut o the main water supply rst.
Remove old mounting hardware, remove toilet and plug oor waste opening to prevent escaping gas.
Remove closet bolts from ange and clean away old wax, putty, etc. from base area.

—5 —
NOTE: Drawings may not exactly dene contour of china.
3. Install Closet Bolts
Install closet bolts to ange channel, turn 90° and slide into place 6”(152mm) apart and parallel to wall.
Closet Flange
Closet Bolts
A
4. Install Wax Seal
Invert toilet on oor (use cushion to prevent damage), and install wax ring evenly around waste ange (horn),
with tapered end of ring facing toilet. Apply a thing bead of sealant around toilet base.
Wax Ring
Sealant

—6 —
NOTE: Drawings may not exactly dene contour of china.
T
H
I
S
S
I
D
E
U
P
4. Position Toilet on Flange
Unplug oor waste opening and install toilet on closet ange so bolts project through mounting holes.
Loosely install retainer washers and nuts. Side of washers marked “THIS SIDE UP”must face up!
Closet Flange
Nut
Washer
Bolt
5. Install Toilet
Position toilet squarely to wall and, with a rocking motion, press bowl down fully on wax ring and ange.
Alternately tighten nuts until toilet is rmly sealed to oor.
NOTE: Do NOT over-tighten nuts as it might crack the ceramic!
Adhere bolt covers to toilet.
Smooth o the bead of sealant around the base. Remove excess sealant.
T
H
I
S
S
I
D
E
U
P
Closet Flange
Bolts

6. Install Toilet Seat
—7 —
NOTE: Drawings may not exactly dene contour of china.
Insert threaded rubber piece into
holes on top of toilet.
Place seat hardware over where you inserted the
threaded rubber pieces.
Place washer onto screw then thread screwthrough the seat hardware into the rubber piece.
Before you fully screw in hardware, be sure to test position by placing the seat on top and making
adjustments if needed.
Add cover caps over top of seat hardware. Pop on your quick-release seat.

Swiss Madison® products are made with quality materials and excellent craftsmanship to provide the
customers a long lasting product. In the case of any defects in materials or craftsmanship under regular
use were inspected in the rst year of purchase, Swiss Madison® will provide replacement parts at no
charge, or at its option, replace any product or part of the product that is deemed defective, under
normal installation, use, service and maintenance. This warranty applies only to the original purchaser.
Proof of purchase will be required in the case of a claim.
Swiss Madison® recommends the installations to be made by a licensed, professional plumber.
Swiss Madison® will not be held responsible for any damage or product failure due to improper
installation, misuse, or failure to use a licensed professional. Swiss Madison® is not responsible for any
removal or installation cost.
This One Year Limited Warranty will be voided if:
•The installation recommendations were not followed.
•The product has been moved from it’s initial place of installation.
•The product has been modied.
•The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accident or other damages.
Swiss Madison® makes no implication that products comply with any or all local building or plumbing
codes. It is the consumer’s responsibility to determine local code compliance. This warranty extends to
the original purchaser and rst consumer.
Swiss Madison® is not liable for any incidental, consequential or special damages associated with the
return, replacement, installation or use of your product. This includes freight costs, labor, travel time, lost
prot, home damages and other contingent liabilities and costs (including, without limitation, costs
associated with experts, investigations, analyses, attorneys and other professionals and services).
The Swiss Madison® warranty is a comprehensive and explicit limit of liability, and all items outside of it
are not addressable by or the responsibility of Swiss Madison®. Certain states have variances regarding
implied warranties and in those situations we remain fully compliant.
In the case of any questions or a claim contact us directly at 1-434-MADISON (623-4766).
WARNING: Content may contain sharp and other possibly harmful pieces and may cause hazard to
children and adults, Swiss Madison® is not responsible in any way for personal damage.
ONE YEAR LIMITED WARRANTY
