Swiss Madison SM-STS31 User manual

®
www.swissmadison.com | 1-434-623-4766 | [email protected]
INSTALLATION INSTRUCTIONS
Aqua Non-Electric Smart Toilet Seat Bidet
@SwissMadison
#WellMadeForever
®
well made for e v e r

—1 —
If you have any questions or concerns please contact us:
1-434-623-4766
[email protected]
PRIOR TO INSTALLATION:
· Inspect bidet to ensure no damages have occurred while in shipping.
· Observe all plumbing and building codes in accordance with your state and local requirements.
· All dimensions are nominal! Be sure to measure your toilet seat prior to installation.
· The step-by-step guidelines in the installation instructions are a general reference. Should there be
any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss
Madison products by hiring a licensed professional.
· Read installation and maintenance instructions thoroughly before installing. Be sure to use proper
tools and always wear proper personal safety accessories for your protection.
· Please use the new hose sets supplied with the product. Do not use other hose sets with the product.
· Open angle valve to clear any impurities in the pipe prior to installation.
· Water supply pressure must be 0.07-0.8 MPa.
INCLUDED PARTS:
SUGGESTED TOOLS & MATERIALS:
Pliers Screwdriver Bucket &
Rag
SMART SEAT BIDET INSTALLATION INSTRUCTIONS
Inlet Hose
with Filter
T-PipeSmart Seat
Bidet Adjustment Sheets
Fixing
Plate
Nuts &
Bolts Expansion Bolts

—2 —
SMART SEAT BIDET TECHNICAL SPECIFICATIONS
SKU
Backflow Prevention
Water Inlet
Wash Water Flow
Water Supply
Bidet Water Flow
Water Pressure Range
Check valve, vacuum breaker
Static pressure: 0.07 - 0.8 MPa, Dynamic pressure: above 0.03 MPa
Direct from water pipes
Side
0.09 gal/min - 0.48 gal/min
0.09 gal/min - 0.48 gal/min
SM-STS31
Water inlet on the left
Water inlet on the right Dismantlement
button
Bowl
Water inlet hose
Shutoff valve
T-pipe
Lever
Water tank
Water supply hose
Seat cover
Seat
Bidet nozzle
Wash nozzle

PRE-INSTALLATION
INSTALLATION
1. Remove Old Seat
· Remove old seat according to
manufacturer’s instructions.
2. Install Mounting Hardware
· Insert expansion bolts into ceramic holes.
—3 —
2. Insert into Fixing Plate
· Insert the connecting bolts in the holes of
adjustment sheets in the holes of the fixing plate
as shown.
1. Insert Connecting Bolts
· Insert the connecting bolts in the holes of
adjustment sheets as shown.
CAUTION:
· The water pressure limit is from 0.07 to 0.8 MPa, please use as instructed.
· The water shutoff valve should be near where the product can be installed and dismantled.
SMART SEAT BIDET INSTALLATION INSTRUCTIONS

—4 —
3. Install Installation Template
· Install the installation template on the toilet as shown.
4. Attach the Adaptable Panel
Installation A:
· Place the fixing plate over the expansion bolts, followed by the adjustment sheets then screws.
· Tighten screws with screwdriver.
Installation B:
· Place the fixing plate over ceramic holes, followed by the adjustment sheets then screws.
· Tighten nuts underneath screws.
NOTE: Keep the side labeled “FRONT” facing up.
A
B
SMART SEAT BIDET INSTALLATION INSTRUCTIONS

—5 —
6. Turn off Water
· Close the water valve and detach water pipe from the water tank.
· Connect the T-pipe to the water tank.
· Make sure that rubber sealing ring is inserted between the T-pipe and the water tank.
5. Remove Installation Template & Install Product
· Remove installation template.
· Keep the fix slots under the product aim at slots on the fixing plate. Push the product to the end as
shown below. Then complete installation.
SMART SEAT BIDET TECHNICAL SPECIFICATIONS
fix slots

—6 —
7. Connect Water Pipe to the T-Pipe
NOTE: Please remove the regulator cover and regulate o-ring under the following conditions:
a. When the water dynamic pressure is lower than 0.05 MPa.
b. When the nozzle cannot work normally and water is low.
· Take out regulator with pliers.
· Remove the regulator cover and regulate o-ring except the sealing o-ring.
· Insert the regulator component into the inlet pipe.
CAUTION: Must use the regulator cover and regulate o-ring when the water pressure is bigger than 0.1 MPa.
8. Connect Water Hose
· Press the filter and washer at the two ends of water hose into the threaded area, then connect the main
body and T-pipe with water hose.
· Turn on water and check for leaks.
WARNING:
Do not lift the product with the seat cover and seat open. This may cause mechanical trouble.
The water supply cannot be above 104°F or below 32°F.
Washer
Filter
SMART SEAT BIDET TECHNICAL SPECIFICATIONS
13
2
Regulator
Regulator
cover
Regulate
o-ring
Sealing
o-ring

—7 —
WASH
· Turn the lever clockwise form the vertical position.
· Nozzle for WASH moves forward and will start the function.
· The water volume changes with the turning of the lever.
BIDET
· Turn the lever counterclockwise form the vertical position.
· Nozzle for BIDET moves forward and will start the function.
· The water volume changes with the turning of the lever.
OFF & SELF-CLEANING
· Keep the lever at the 90° position when not in use.
· The wand cleans itself after each use. For additional flush clean of the wands, position the lever at
25° for a few seconds and then reposition back to 90°.
Low flow
High flow
Low flow
High flow
25˚
25˚
90˚
SMART SEAT BIDET FUNCTIONS

—8 —
OUTER CLEANING INSTRUCTIONS:
· Use a smooth or cloth with diluted kitchen detergent to clean the product. Do not use the following:
hydrogen chloride detergent, paint thinner, benzene, abrasive paper, polishing agent, fragrance or
insecticide etc.
CLEANING THE NOZZLE:
· Pull out the nozzle gently and use a smooth sponge, cloth or toothbrush with kitchen detergent to
clean the nozzle.
CLEANING THE FILTER & REGULATOR:
If the water flow is less than usual:
1. Clean the filter for both sides. Make sure to disconnect the water supply hose during cleaning.
2. Clean the regulator o-ring.
REMOVAL:
· To remove, close the lid, push the dismantlement button and pull out the product according to the
arrows shown below.
Filter
Braided hoses
Regulator
Dismantlement
SMART SEAT BIDET MAINTENANCE

—9 —
LEVER REPLACEMENT:
· As per figure A, rotate the lever to the highest
wash volume. As per figure B, remove the old lever
along the axis direction.
· As per figure C, insert the new lever rib into the
corresponding control valve slot. The installation is
completed with a *click* sound.
NOZZLE REPLACEMENT:
· As per figure A, pull out the tube and do not
release then remove the old nozzle along the axis
direction. As per figure B, insert the new nozzle into
the tube along the corresponding slot. The nozzle
replacement is completed.
REGULATOR REPLACEMENT:
· Rotate the lever in the working position, remove
the regulator from the inlet tube with pliers.
· Press the new regulator into the bottom of the
inlet tube. The regulator replacement is completed.
· Rotate the lever back to non-working position.
WATER HOSE LEAKING SOLUTION:
· If water leaks from the two ends of water hose,
re-tighten the nuts to avoid water leaking, making a
quarter-turn at a time to avoid damaging the fitting.
ABCAB
nozzle
Regulator
SMART SEAT BIDET MAINTENANCE

—10 —
SMART SEAT BIDET TROUBLESHOOTING
CAUTION:
Do not disassemble, repair or remodel the unit.
If you have any questions or concerns please contact us:
1-434-623-4766
[email protected]
Status Cause Solution
Water is too
low during
WASH/BIDET
1. Low water pressure of the unit.
2. Low water pressure of the water supply.
1. During WASH/BIDET, turn the lever fast to
the biggest volume.
2. When water supply pressure is lower than
0.07 MPa, contact local department for
water pressure question.
No water
comes out
during WASH/
BIDET
1. Water shut-off valve is turned off.
2. Filter net of T-shaped connector is stuck.
3. Filter net of water inlet hose is stuck.
4. Nozzle head is stuck.
5. External water pressure is low.
1. Turn on the water shut-off valve.
4. Take off and clean the nozzle head.
5. Increase external water pressure.
Water
dropping from
bowl when
using the unit
1. External water pressure is too big.
1. The maximum water pressure of the
unit is 0.8 MPa. If water supply pressure
is higher than that, please contact local
department for water pressure question.
2. Clean the filter net of T-pipe.
3. Clean the filter net of the water inlet hose.

1-434-MADISON
(623-4766)
www.swissmadison.com
ONE YEAR LIMITED WARRANTY
Swiss Madison® products are made with quality materials and excellent craftsmanship to provide our
customers with beautiful, durable, long-lasting products. Should there be any defects in materials or
craftsmanship under regular use that are discovered within the first year of installation, Swiss Madison®
will provide replacement parts at no charge, or at its discretion, replace any product or part of the product
that is deemed defective, under normal installation, use, service or maintenance. This warranty applies
only to the original purchaser. Proof of purchase will be required in the instance of a claim.
Swiss Madison®recommends all installations of Swiss Madison® products to be conducted by a
licensed, professional plumber or contractor. Swiss Madison®will not be held responsible for any
damage or product failure due to improper installation, misuse, or failure to utilize a licensed professional
for installation. Swiss Madison® is not responsible for any installation or removal costs.
This One Year Limited Warranty Will Be Voided If:
• The installation recommendations were not followed by the installer
• The product has been moved from its initial place of installation
• The product has in any way been modified from its packaged state
• The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accidents, or other damages, etc.
Swiss Madison®makes no implication that its products comply with any local building or plumbing
codes. It is the consumer’s responsibility and obligation to determine local code compliance prior to and
during installation. This warranty extends only to the original purchaser and first consumer.
Swiss Madison®is not responsible for any special, incidental or consequential damages associated with
the installation, replacement, return or use of the original purchaser’s product. This includes, but is not
limited to: freight costs, labor, travel time, lost profit, home damages and other contingent liabilities and
costs (including, without limitation, costs associated with ‘professionals’ or ‘experts’, investigations,
audits, analyses, attorneys and any other professional/hired services).
The Swiss Madison®warranty is a comprehensive and explicit limit of liability. All items not disclosed
within the warranty are not addressable within the responsibility of Swiss Madison®. Certain states have
variances regarding implied warranties; in those situations, we remain fully compliant.
If you have any questions or concerns, please contact us directly at
1-434-MADISON (623-4766)
WARNING: Contents of your order may contain sharp and possibly other harmful pieces and may
cause hazard to children and adults. Swiss Madison®is not responsible in any way for personal
damages.
®
well made for e v e r
