Swisscom Classic E104 User manual

Classic E104
Handset
User manual
561.865.7 dt/fr/it 12.99 PC-TE A31008-G3000-F001-1-2X19
3000Cla-IM1-2-en.bk Seite 1 Freitag, 14. Januar 2000 4:14 16

2
swisscom-classicE104, sc--en, A31008-G3000-F001-1-7619 3000ClaU.fm 14.01.00
Brief overview
Display keys
When icons are displayed above the 3 keys in the display,
the meaning of these icons is as follows:
The display is protected by a film. Please remove
protective film.
Charging
status
¤full
§empty
Redial
a number
Make
internal call
Ta l k k ey
– accept
call
– dial call
number
Keypad
protection
on/off:
hold down
Delete
characters
¤
Base station icon
–stationary: ready
for outgoing/inco-
ming calls
–flashing: no
base station
contact
Speed dialling
activate
Set key
– to save
– for settings
End call key
– end call
–on/off:
hold down
Recall key
– for systems
& select services
–insert pause:
hold down


Confirm
Scroll up
Scroll down
8
3000Cla-IM1-2-en.bk Seite 2 Freitag, 14. Januar 2000 4:14 16

3
swisscom-classicE104, sc--en, A31008-G3000-F001-1-7619 3000ClaU.fm 14.01.00
Quick reference guide
Function Key combination
Activate/deactivate
the handset Hold down ±for 1 second
Activate/deactivate
keypad protection Hold down wfor 1 second
Answer a call C
Make an external call OC
Redial a number 1or _C
Save a speed dial
number °-e.g. o`O
`±
Dial a speed dial
number -_ or e.g. C
Set the handset
volume °¯º`e.g. o`
Mute the microphone uMicrophone muted;
4Microphone on
Make an internal call ue.g. 
Call all handsets ux
Tr a n s f e r c a l l
(connect) ue.g. o±
Internal enquiry call ue.g. o;
Terminate enquiry call: 4
8
3000Cla-IM1-2-en.bk Seite 3 Freitag, 14. Januar 2000 4:14 16

4
swisscom-classicE104, sc--en, A31008-G3000-F001-1-7619 3000ClaU.fm 14.01.00
Safety precautions
• Never use ordinary (non-rechargeable) batteries. Only use
approved batteries of the same type (rechargeable), as
otherwise battery damage can result (dangerous), see ta-
ble page 7.
• The handset’s battery compartments feature the following
diagrams:
gInsert rechargeable batteries correctly in
accordance with polarity symbols.
hOperate battery type in accordance with these
operating instructions.
• Do not use strange charging devices, as this could dama-
ge the batteries.
• Batteries heat up during charging – this is a normal occur-
rence and is not dangerous.
• The handset can affect medical equipment.
• The handset can cause unpleasant humming in hearing
aids.
• Do not operate the handset in environments where there
is risk of explosion, such as a paint shop.
• Always include the operating instructions when passing
your handset onto third parties.
• The batteries and handset should be disposed of in an
environmentally-friendly manner.
Displays
Base station icon
¥Charging status icon
COff hook
(;7
External connection
,17
Internal connection
£Handset locked
1Pause
_Blank
JStar key x
Hash key w
PRecall key 4
1GJ Telephone PIN inpu
t
____ Keypad protection
Select from list
using °
Select from list
using 2
1to confirm the
selection
8
3000Cla-IM1-2-en.bk Seite 4 Freitag, 14. Januar 2000 4:14 16

5
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000ClaIVZ.fm 13.01.00
Contents
Brief overview ................................................................... 2
Display keys......................................................................2
Quick reference guide ...................................................... 3
Safety precautions............................................................ 4
Displays.............................................................................. 4
Preparing the handset...................................................... 6
Inserting the batteries.......................................................6
Charging the batteries ......................................................7
Attaching the belt clip .......................................................8
Activating/deactivating the handset ..................................8
Activating/deactivating keypad protection ........................8
Assignment the handset .................................................. 9
Making calls .................................................................... 10
Making an external call ...................................................10
Making an internal call ....................................................10
Answering a call..............................................................10
Transferring a call, enquiry call........................................11
Redial ............................................................................... 11
Speed dialling ................................................................. 12
Saving/changing/deleting call numbers...........................12
Speed dialling..................................................................12
Deleting the speed dial list .............................................13
Network access support ................................................ 13
Security............................................................................ 14
Changing the telephone PIN ...........................................14
Activating direct station selection ...................................14
Activating the handset lock.............................................15
Deactivating the handset lock/direct station selection....15
Settings............................................................................ 16
Ringer volume.................................................................16
Ring tones.......................................................................16
Handset volume..............................................................16
Activating/deactivating beeps .........................................17
Activating/deactivating base station display....................17
Activating/deactivating auto talk .....................................18
Resetting the factory settings.........................................18
Changing the base station ..............................................19
Appendixl ........................................................................ 20
Warranty/repair/maintenance/approval ...........................20
3000Cla-IM1-2-en.bk Seite 5 Freitag, 14. Januar 2000 4:14 16

6
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Preparing the handset
Contents of the package
Handset, 2 batteries, belt clip, user manual.
Inserting the batteries
• Insert the batteries, ensuring correct polarity – see figu-
re on left.
• Insert the battery cover approx. 3 mm into the battery
compartment and slide it upwards until it clicks into pla-
ce.
•To o p e n the battery cover, press the grooved area on the
cover and slide downwards.
• Never use ordinary (non-rechargeable) batteries.
Only use approved batteries of the same type
(rechargeable), as otherwise battery damage can
result (dangerous), see table page 7.
• The handset’s battery compartments feature the
following diagrams:
gInsert rechargeable batteries correctly in
accordance with polarity symbols.
hOperate battery type in accordance with
these operating instructions.
• Do not use strange charging devices, as this
could damage the batteries.
• Please dispose of old, defective batteries in an
environmentally friendly manner in accordance
with the relevant legislation.
+
+
–
–
3000Cla-IM1-2-en.bk Seite 6 Freitag, 14. Januar 2000 4:14 16

7
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Charging the batteries
The batteries supplied are not charged.
To charge the batteries, insert the handset in the base sta-
tion or charging unit (accessory) – you will hear the confirma-
tion beep. The charging status icon flashes on the handset
display to indicate that a charging operation is in progress:
Approved batteries:
Always replace both batteries and only use batteries of the
same type/from the same manufacturer.
§Batteries empty ¥Batteries 2/3charged
¦Batteries 1/3charged ¤Batteries full
– We recommend initially charging the batteries for at least
16 hours without interruption – irrespective of the
charging status icon.
– Charging is controlled electronically. This ensures opti-
mum charging and prolongs battery life.
It is recommended that you discharge the batteries at re-
gular intervals.
– The batteries heat up during charging.
– The battery charging status is only displayed correctly
after uninterrupted charging/discharging. You should
therefore avoid opening the battery compartment unne-
cessarily.
Nickel-cadmium (NiCd) Nickel-metal-hydride (NiMH)
Sanyo N-3U (700 mAh) Sanyo H-3 U (1500 mAh)
GP GP60AAKC (600 mAh) GP GP130 AA HC (1300 mAh)
Varta 751RS (700 mAh) GP GP150 AA HC (1500 mAh)
Mobile Power 700 (700 mAh) Varta VH 1101 or Phone Power
(1100 mAh)
Panasonic 60 DT (600 mAh) Panasonic HHR-110 AA (1100 mAh)
Friwo NiMH (1400 mAh)
Toshiba TH-1200 AARE (1200 mAh)
3000Cla-IM1-2-en.bk Seite 7 Freitag, 14. Januar 2000 4:14 16

8
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Handset operating time/charging time:
Attaching the belt clip
Press the belt clip against the back of the handset until the
side protrusions click into place in the holes provided.
Activating/deactivating the handset
±Press the end call key for 1 second.
Activating/deactivating keypad protection
When keypad protection is activated, the keypad buttons are
ineffective.
Calls can be accepted with the talk key C.
wHold key down for more than
1 second to activate/deactivate keypad pro-
tection.
Capacity
(mAh)
Standby time
(hours)
Ta l k t i m e
(hours)
Charging
time
(hours)
700 up to 100 over 10 approx. 5
1100 up to 160 over 15 approx. 9
1500 up to 220 over 20 approx. 12
The handset automatically activates as soon as you insert
the batteries and place it in the base station/charging unit.
3000Cla-IM1-2-en.bk Seite 8 Freitag, 14. Januar 2000 4:14 16

9
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Assigning the handset
You must assign your handset at the base station before you
can start to make calls.
Step 1
• First prepare the base station for registration:
Step 2
• You now have one minute to enter the following at the
handset:
°uxPress the keys shown.
¯` Enter the base station number, e.g. ¯(sta-
tion 1-4) and confirm.
System PIN
`
Enter the base station’s system PIN and con-
firm (factory setting: 0000) – the unassigned
call numbers appear after a few seconds.
e.g. oEnter the desired call number – the statio-
nary base icon is displayed.
Your handset is ready for operation!
Pronto/
Classic/Top
Base station preparation
210, E104,
E401, E304
Hold down the base station key for approx.
10 seconds until you hear signal tones.
E314 ISDN In the base station menu select registration
option and confirm.
Cordless Press the display (LED) –
flashing during registration.
– Please refer to the relevant operating instructions (step 1)
to register at other base stations.
– You can register your handset at
up to 4 different base stations, see above.
3000Cla-IM1-2-en.bk Seite 9 Freitag, 14. Januar 2000 4:14 16

10
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Making calls
Making an external call
OEnter the call number.
If necessary, correct it with the delete key
v.
CPress the talk key to start the dial operation.
Ending a call:
Press the end call key ±.
Making an internal call
uPress the INT key – the actual internal call
number is displayed.
OEnter the internal call number.
Press xto call all handsets.
Ending a call:
Press the end call key ±.
Answering a call
CPress the talk key.
or
Lremove the handset from the base station/
charging unit if the auto talk feature is activa-
ted.
–Youcan
cancel the dial operation with the end call key
±.
–Youcaninsertapause with the recall key 4(hold it
down).
– You can opt to not save entries, e.g. when checking an
account: press the keys °x, all characters entered af-
terwards are not saved for number redial.
3000Cla-IM1-2-en.bk Seite 10 Freitag, 14. Januar 2000 4:14 16

11
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Transferring a call, enquiry call
The base stations Pronto 210, To p E 3 01,
Classic E104 and
To p E 3 0 4 allow you to transfer an external call to another
handset or to conduct an internal enquiry call.
uPress the INT key.
ODial the internal call number.
When the user answers:
•transfer the call: press the end call key ±.
•enquiry call: press the recall key 4to revert to the cal-
ler on hold.
Redial
Redialling a number
You can access the last five call numbers dialled.
1Display call numbers.
_Select a call number.
If necessary, confirm the number with `
and correct it with the delete key v.
CPress the talk key to start the redial opera-
tion.
Deleting redial numbers
All five redial numbers are deleted.
°Press the set key.
¯t`Initiate the setting.
Te l . P I N `Enter the telephone PIN and confirm
(factory setting: 0000).
o`± Delete the redial list.
3000Cla-IM1-2-en.bk Seite 11 Freitag, 14. Januar 2000 4:14 16

12
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Speed dialling
The speed dialling function allows you to dial up to 10 call
numbers at the push of a button.
Saving/changing/deleting call numbers
°-Press the set key followed by the speed dial
key.
e.g. ¯Enter the speed dial number (memory loca-
tion, digit 0to 9) or press _to scroll.
`Confirm the number.
OEnter a new call number or delete/change an
existing call number with v.
`± Save the number.
Speed dialling
2Display the call numbers.
e.g. ¯Enter the speed dial number (0to 9) or
press _to scroll.
If necessary, confirm the number with `
and dial further digits for the extension num-
ber.
CPress the talk key to start the dial operation.
Saving a call number from the redial list
°2Press the set key followed by the speed dial
key.
e.g. ` Enter the speed dial number (digit 0to 9) or
press _to scroll and confirm.
_Select the call number (scroll) – the other
redial numbers are displayed.
`± Save the call number.
3000Cla-IM1-2-en.bk Seite 12 Freitag, 14. Januar 2000 4:14 16

13
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Deleting the speed dial list
All call numbers saved are deleted!
°Press the set key.
¯t`Activate the function.
Te l . P I N `Enter the telephone PIN and confirm
(factory setting: 0000).
¯`±Delete the speed dial list.
Network access support
• Using the speed dial key
– Save the call number as the speed dial number "0" see
„Speed dialling” page 12
Hold down the speed dial key -to display the call
number saved as speed dial number "0".
2Hold down the speed dial key – the prefix is
displayed.
OC Enter the user’s call number and press the
talk key to dial the "complete" number.
• By "linking" the speed dial list
You can save prefix codes as speed dial numbers:
2_` Display the prefix code and confirm.
e.g.
2_` Display the user’s call number in the speed
dial list and confirm or enter it manually.
CPress the talk key to dial the complete num-
ber.
3000Cla-IM1-2-en.bk Seite 13 Freitag, 14. Januar 2000 4:14 16

14
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Security
Changing the telephone PIN
Important functions/settings are protected by the handset’s
telephone PIN (Personal Identification Number).
°Press the set key.
¯o`Activate the function.
Te l . P I N `Enter the current telephone PIN and
confirm (factory setting: 0000).
2x new
tel. PIN
Enter the new telephone PIN (4 digits)
twice.
`± Save the new telephone PIN.
Activating direct station selection
This function is not available in all countries!
When direct station selection (DSS) is active, every key-
stroke triggers a call to the DSS number saved. This
function is used to call for help or raise an alarm.
Saving/changing/deleting a DSS number:
°Press the set key.
¯¯`Select the function.
Te l . P I N `Enter the telephone PIN and confirm
(factory settings: 0000).
o`Press the keys shown.
OEnter or change the DSS number or press
vto delete it.
`Save the DSS number – direct station selec-
tion is activated.
Do not forget your telephone PIN! Forgotten PINs can
only be reset by Swisscom for a fee!
The telephone lock is activated if you press `when the _
(empty) icon is displayed.
3000Cla-IM1-2-en.bk Seite 14 Freitag, 14. Januar 2000 4:14 16

15
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Activating the handset lock
All functions with the exception of emergency call are una-
vailable when the telephone is locked. You can still be rea-
ched, however. Simply press the talk key Cto accept a
call.
°Press the set key.
¯¯`Select the function.
Te l . P I N `Enter the telephone PIN and confirm
(factory setting: 0000).
¯`Activate the telephone lock.
Deactivating the handset lock/direct station
selection
°Press the set key.
¯¯`Activate the function.
Te l . P I N `Enter the telephone PIN and confirm
(factory setting: 0000).
º`± Deactivate direct station selection/telephone
lock.
You can dial all base station emergency numbers.
3000Cla-IM1-2-en.bk Seite 15 Freitag, 14. Januar 2000 4:14 16

16
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Settings
Ringer volume
You can choose between 5 volumes and the "crescendo"
ring (increasing volume).
°qActivate the function – you will hear the rin-
ger.
e.g. pChange the ringer volume (level 1 to 5,
crescendo = 6).
`Save the setting.
Ring tones
You can choose between 10 ring tones.
°~Activate the function – you will hear the rin-
ger.
e.g. Select the ring tones (0 to 9).
`Save the setting.
Handset volume
You can set the handset volume to any of 3 levels (even
during a call).
°Press the set key.
¯º`Activate the function.
e.g. oChange the volume (1, 2 or 3).
`± Save the setting.
q
~
3000Cla-IM1-2-en.bk Seite 16 Freitag, 14. Januar 2000 4:14 16

17
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Activating/deactivating beeps
•Confirmation beeps – function code 13 (both beeps)
– Confirmation beep (1 beep) when you conclude a
function and replace the unit in the charging unit
– Error beep (4 short beeps) when you make an incorrect
entry
•Key beep – function code 14
– every keystroke is confirmed
•Battery warning beep – function code 15
– when the battery is empty
°Press the set key.
e.g.
¯p` For example, enter function code 14 and
confirm.
e.g. ºFor example, deactivate the key beep.
Deactivate = 0; activate = 1
You can also activate the battery warning
beep for call status only = enter o.
`± Save the entry.
Activating/deactivating base station display
The current base station is displayed when the handset is
idle.
°Press the set key.
¯~`Activate the function.
e.g. ¯For example, activate the display.
Activate = 1; deactivate = 0
`± Save the setting.
3000Cla-IM1-2-en.bk Seite 17 Freitag, 14. Januar 2000 4:14 16

18
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Activating/deactivating auto talk
When this function is active, you can answer a call by remo-
ving the handset from the base station or charging unit.
°Press the set key.
¯s`Activate the function.
e.g. ºEnter ºto deactivate auto talk.
Enter ¯to activate auto talk.
`± Save the setting.
Resetting the factory settings
This setting does not delete the telephone PIN. Base sta-
tion registrations are maintained.
Factory settings:
°Press the set key.
¯t`Activate the function.
Te l . P I N `Enter the telephone PIN and confirm
(factory default: 0000).
º`± Reset settings to factory default.
Speed dial numbers, redial, DSS number deleted
Handset volume, ringer melody 1
Ringer volume 5
Key beep, battery warning beep, confirma-
tion beeps, auto talk
on
Base station display off
3000Cla-IM1-2-en.bk Seite 18 Freitag, 14. Januar 2000 4:14 16

19
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Changing the base station
Prerequisite: the handset is registered with more than one
base station.
You can choose one of the following settings:
• Set the handset to automatically select (factory setting)
the best base (factory setting).
• Set the handset to priority base station – the handset
searches for other base stations if this is not found within
30 seconds.
• Set the handset to a fixed base station.
°uPress the set key followed by the INT key.
e.g. ¯¯ For example, set base 1 as the priority base.
For automatic selection: enter º.
For priority base: enter the base number
twice.
For fixed base: enter the base number
once.
`± Save the setting and terminate the function.
3000Cla-IM1-2-en.bk Seite 19 Freitag, 14. Januar 2000 4:14 16

20
swisscom-classicE104, sc-en, A31008-G3000-F001-1-7619 3000Cla.fm 14.01.00
Appendix
Warranty/repair/maintenance/approval
Warranty
Swisscom offers a two-year warranty for this device from
the date of purchase.
For a repair under warranty, the warranty card must be com-
pleted, stamped by the dealer and returned with the faulty
terminal.
The warranty does not cover damage caused by incorrect
use, wear and tear or third-party access. The warranty does
not cover consumables or defects which only have a minor
effect on the value or operability of the terminal.
In the event of malfunction, please contact the dealer.
Repair/maintenance
Leased terminals
If your telephone does not work properly, contact the faults
service (telephone number 175).
Repairs1) and fault removal are performed free of charge.
Purchased terminals
Repairs are performed free of charge within the warranty
period in accordance with warranty specifications1). For
repair, the terminal must be returned to the dealer.
If the faults service is used (even during the warranty
period), you will be charged a fee for travel and time. Out-
side the warranty period, material costs are invoiced in addi-
tion to this.
Battery
Batteries are considered as consumables and as such are
not covered by the warranty. Defective batteries are not
replaced free of charge. The applies to both leased and
purchased terminals.
1) excluding damage to consumables (cables, labels,
batteries, etc.) and caused by incorrect use (if the
terminal is dropped, leakages, etc.).
3000Cla-IM1-2-en.bk Seite 20 Freitag, 14. Januar 2000 4:14 16
