Swissvoice ePure TAM User manual

Cordless analogue telephone (DECT)
WITH DIGITAL ANSWERING MACHINE
ePure TAM
User manual
Photo may differ from the actual product.

Welcome to Swissvoice
The ePure TAM is a cordless telephone designed for connection to an analog
telephone network. International DECT (GAP)-standard digital technology offers
excellent voice quality.
You can register up to 5 handsets to your base and make internal calls free of charge.
The ePure TAM comes with a built-in digital answer machine.
Please read these operating instructions carefully to familiarise yourself with and take
full advantage of the benefits of your new ePure TAM.
ePure TAM
ePure TAM

Contents
Keys 2
Display symbols 3
Range / Location 3
Battery advice 4
Insert the battery 4
Connecting the phone 5
Set date and time 5
Set language 5
Telephoning 6
Keypad lock 7
Redial 7
PBX operation 8
Paging – Locate mislaid handsets 8
Phonebook 8
Direct memory 9
Calls list 10
Extending the ePure TAM 10
Telephoning with several call partners 12
Personal settings 13
Advanced settings 13
Answer machine 15
Appendix 19
ePure TAM
ePure TAM 1

ePure TAM
2ePure TAM
Handset
1 Earpiece
2 Display
3 Redial key
4 Menu key
5 End call key / back to idle mode
6 Talk key
7 Key 1: Insert a space
8 Digit keys
9 Star key
In standby: Long press to activate/
deactivate the keypad lock.
10 Key 0: Press and hold for Internal
calls
11 Microphone
12 Loudspeaker (for ring signal and
hands-free)
13 Hash key
switches between lower and upper
case letters / switches off ringer /
press and hold when editing an entry:
insert a pause
14 Key R (long press key "9")
15 Control LED (flashes when you have
one or more missed calls, flashes
quickly with an incoming call)
16 Navigation key / set volume
Base
1 Paging key (on the bottom)
2/3 Adjust volume
4 Repeat message/return to previous
message
5 Start/stop playback
6 Skip to next message
7 Delete message during playback
8 Switch answer machine on/off
16
15
14
13
1
2
3
4
5
8
12
6
11
10
7
9
Keys
1
2 3 4 5 6 7 8

Display symbols
Steady on: batterie’s charge level.
Flashing: batteries have to be charged.
Date and time.
Call in progress.
Steady on : the caller’s list is open.
Flashing : new calls in the caller’s list.
The phonebook is open.
Scroll up/down in a list or a menu.
Confirmation.
Ringer off.
Handsfree active.
Alarm is set.
Steady on, when the handset is near the base. Flashes, if out of range or
not registered.
Steady on : the answer machine is activated
Flashing : you have new answer machine messages
Range / Location
To obtain the best possible range, we recommend positioning the telephone in a
location central to your sphere of activity. Avoid positioning the telephone in niches,
recesses and behind steel doors.
The maximum range between base station and handset is approximately 300 meters
outdoors. Depending on the surrounding conditions as well as spatial and structural
factors, the range may be smaller. Silent zones can occur due to the digital transmis-
sion in the frequency range used – even within the range, depending on the structural
environment. In this case the transmission quality may be reduced through the
increased incidence of short breaks in transmission. Normal call quality can be
restored if you move slightly out of the silent zone. If the range is exceeded, the call
will be disconnected unless you move back into range within ten seconds.
14/01 12:03
ePure TAM
ePure TAM 3

ePure TAM
4ePure TAM
Battery advice
Use only the original battery (Li-Ion 3.7 V / 550 mAh) as well as the original power sup-
ply (6.5 V DC 300mA, 7.5 V 200mA).
The handset operating times (standby 150 hours/active 10 hours) and charging times
apply only if the battery is charged to the defined minimum capacity.
Charging is electronically controlled to ensure optimal charging and care of battery in
different charge states. Full capacity is achieved only after several charging cycles.
Insert the battery
The battery compartment is situated in
the handset.
Open the handset cover.
Insert the battery in the battery compart-
ment.
Replace the handset cover.
Note:
Using other rechargeable battery or non-rechargeable battery/primary cells
can be dangerous and cause malfunctions or damage to the telephone. Do
not short-circuit the battery (danger). In particular, avoid inadvertent short-
circuits during storage and transport e.g. bunch of keys, metal panels or
similar objects, and make sure the battery do not come into contact with
greasy materials. When not in the handset, therefore, battery should be
stored only in insulating packaging. Ensure also that the contacts do not
touch greasy parts.
Rechargeable battery can become warm while recharging. This is a normal
occurrence and is not dangerous.
Make sure you install the battery pack and fit the cover the right way round:
- position the 3 metal contacts of the battery pack against the 3 blade
contacts,
- align the green dot on the handset with the one on the cover.
Green dots

ePure TAM
ePure TAM 5
Connecting the phone
• Before you can start using your telephone you must plug in the telephone
connector cable and the mains cable.
• When the phone is delivered, the battery is not yet charged.
• To charge the battery, insert the handset in the base station. The battery will take
around 6 hours to fully charge (initial charge).
Set date and time
• Press , select Clock/Alarm with the navigation key π/†and press OK.
• Select
Date&Time and press OK.
• Enter date and press OK.
• Enter the time and press OK.
Set language
• The language of the display texts can be changed in the menu:
Personal set/Language
Mains power socketTelephone line socket

Telephoning
• Dial the desired number using the keypad.
• Press the Talk key .
End the call
Press the End call key.
Accepting a call
• Incoming calls are signalled by a ring tone and a quick flashing of the control LED
on the handset.
• Press the Talk key and conduct your conversation.
End the call
Press the End call key.
Handsfree operation
You can use the handsfree function to conduct calls without holding the handset in
your hand and allow others present in the room to take part in the call.
Activating handsfree before a call:
1. Press . The display shows . Press again . You can hear the
ringing signal over the handset loudspeaker.
2. Press to deactivate handsfree speaking.
Activating handsfree during a call:
Press . To deactivate handsfree speaking, press again .
Switch ringer off
Press and hold the key for approx. 3 seconds to switch the ringer off.
The display shows .
Press the key again for approx. 3 seconds to reactivate the ringer.
Calls cannot be made if the battery is almost discharged or the handset is
out of range of the base station.
ePure TAM
6ePure TAM

Set speaker/loudspeaker volume
You can adjust the speaker/loudspeaker volume during a conversation.
Set the desired volume using the navigation key π/†.
Switch handset off
• Press and hold the End call key (approx. 5 sec).
• Press and hold again the End call key to reactivate the handset.
Set alarm
• Press , select Clock/Alarm using the navigation key π/†and press
OK.
• Select
Set alarm using the navigation key π/†and press OK.
• Select the desired alarm function (e.g. On once), enter the alarm time and press
OK.
Set alarm tone
• Press , select Clock/Alarm using the navigation key π/†and press
OK.
• Select
Alarm tone using the navigation key π/†and press OK.
• Select the desired alarm melody and press OK.
The activated alarm is displayed in standby mode by .
The alarm sounds for 60 seconds or can be deactivated immediately by pressing
any key.
Keypad lock
Activate keypad lock
• Press approx. 3 sec. All keys are locked.
Deactivate keypad lock
• Press approx. 3 sec.
Redial
The Redial list contains up to 10 entries.
• Press and select the desired entry using the navigation key π/†.
ePure TAM
ePure TAM 7

• Press the Talk key.
Edit redial list
• Open the Redial list, press OK.
You have the following options:
- Save Number – Add number to the phonebook.
- Delete entry – Delete the entry.
- Delete All – Delete the entire redial list.
PBX operation
Your telephone is designed for use in the analogue telephone network and can be
operated on a PBX that supports DTMF dialling and flash signalling. To enter the R key
(e.g. needed to establish a connection) press and hold key 9.
You can adjust the flash/recall time for key R (see chapter "Advanced settings").
Paging – Locate mislaid handsets
All registered handsets ring for one minute, when the Paging key on the base is
pressed. To stop the ring press the End call key on the handset or the Paging key on
the base.
Phonebook
You can store up to 100 names and numbers in the phonebook on each handset.
Digits / Characters
Different characters are printed on each key. The entries in the phonebook are sorted
alphabetically.
Key #When entering text: Press and hold key to change from upper case to
lower case letters (ABC/abc).
When entering numbers: Press and hold key to insert a pause inside a
phone number (“P” appears).
Key 1Insert a space.
ePure TAM
8ePure TAM

ePure TAM
ePure TAM 9
Add new entries in the phonebook
• Press , select Phonebook and press OK.
• Select
New entry and press OK.
• Enter the desired name and press the navigation key π/†for further input
options.
• Press OK to save the entry.
Edit phonebook
• Press , select Phonebook and press OK.
• Select
View entry and press OK.
• Select the desired entry using the navigation key π/†or enter the first letter of
the name.
• Press the Talk key to call the number.
In the phonebook menu you have the following options:
- New entry
- View entry
- Delete all
- Direct mem
- Call a programmed direct memory number.
- PB Transfer – Copy phonebook to another handset (appears only if you have
more than one handset registered
Direct memory
Phone numbers from the phone book can be assigned to numerical keys 1 to 9.
Programming direct memory keys
• Press , select Phonebook and press OK.
• Select
Direct mem and press OK.
• Select the desired memory key and press OK twice.
• Select
Add and press OK.
• Select the desired entry from the phonebook using the navigation key π/†and
press OK.
Calling a direct memory number
To call a direct memory number, press the corresponding key for approx. 3 seconds.
The programed number is called.

Calls list
The control LED on the side of the handset flashes when you have one or more
missed calls. The calls list can contain up to 50 entries.
Call a number from the calls lists
• Open the calls list by pressing the navigation key π.
• Select the desired entry using the navigation key π/†.
• Press the Talk key to call the number.
or
• press OK and select a function from the list.
Edit calls list
• Open the calls list.
You have the following options:
- Edit entry
- Save Number
– Store number in the phonebook.
- Delete entry – Delete single entries.
- Delete All – Delete all entries.
Extending the ePure TAM
The delivered handset is already registered on to base station. In standby the internal
number of the handset is displayed.
You can register up to 5 handsets to your base station.
If you register your ePure TAM handset with a "third party" base station or a "third
party" handset on your ePure TAM base station (GAP), you may not be able to use
some functions or only to a limited extent.
If the caller's number is suppressed, only Withhold is displayed. The call is
not entered in the call list.
To use this function, the caller's number must be transmitted (CLIP). Contact
your network operator for further information.
ePure TAM
10 ePure TAM

Register new handsets
Registering an additional handset with the main base station (the base station you
have connected to the telephone network):
1. Before registering an additional handset, you first need to unregister it from its
original base station:
• Press , select
Advanced set and press OK.
• Select
Unregister and press OK.
• The ePure TAM may now ask for the PIN. If so, enter the PIN (default 0000) and
press OK.
• Press OK again to confirm.
Your handset is now no longer registered with any base station.
2. Preparing the main base station (base you have connected to the telephone
network) for registering additional handsets:
• On the base station you want to use as the main base station, press and hold down
the Paging key for around 10 seconds (the Paging key is on the underside of the
base station).
3. Registering an additional handset:
• Press , select
Advanced set and press OK.
• Select
Registration and press OK.
• Select
Regist Base and press OK.
•
Base1234 is displayed on the handset. Select the main base station (default 1).
• After a few seconds you will be asked to enter the PIN.
• Enter the PIN (default 0000) and press OK.
• If registration is successful you will hear the dialling tone when you press the Talk
key , and after one minute the handset will go to standby mode.
Repeat this procedure for every additional handset.
If the registration is not successful:
• Move closer to the base station. During registration the distance between handset
and base must be less than 1 m.
• Interrupt power supply of base and handset (disconnect power adapter/remove
battery).
• Repeat the registration procedure.
ePure TAM
ePure TAM 11
MAIN MENU
ADVANCED SET
ADVANCED SET
REGISTRATION
REGISTRATION
REGIST. BASE
UNREGISTERED
Base station connected to the telephone network
Move to "REGIST. BASE"
with navigation key and
confirm with
BASE 1 2 3 4
HANDSET X
01/01 00:00
Press
If registration is successful
you will hear the dialling
tone when you press ,
and see handset number on
the display. Repeat this
procedure for every additio-
nal handset.
PIN ?
Press and hold down
the Paging key for at
least 10 seconds
After a few seconds you
will be asked to enter the
PIN. Enter PIN (default
0000) and press
Move to "ADVANCED SET"
with navigation key and
confirm with
Select the main base station
(default 1) by pressing the
"1" on your handset
Move to "REGISTRATION"
with navigation key and
confirm with
2
3
1
4
56
78
1
2
3
4
5
6
7
8

Telephoning with several call partners
During a call you can make a second internal call (enquiry call), switch between call
partners (brokering) or simultaneously converse (3-way conference call) without the
need for two telephone lines.
Internal conversation / Internal call
• Long press key 0and enter the desired internal party. If only two handsets are
registered, long press key 0will automatically call the other handset.
If you receive an external call while you are on the phone to an internal call partner,
you will hear an incoming call alert. End the internal call by pressing the End call key.
Press the Talk key. You are connected to the external party.
Call transfer to another handset
You are conducting an external call and you want to transfer it to another handset.
• Long press Key 0.
• Enter the desired number.
• When the internal party responds press the End call key to transfer the call to the
other party.
Brokering / Conference
You are conducting an external call.
• Call another internal party (see above).
• The internal party answers.
• Long press key 0to start a conference call. If one of the handsets presses the End
call key, the other handset will be connected to the external call.
ePure TAM
12 ePure TAM

ePure TAM
ePure TAM 13
Personal settings
• Press , select Personal set and press OK.
• Select a function from the list using the navigation key π/†and press OK.
-Handset tone
- Ring volume
- Ring melody
- Group melody
- Key tone
- Every time a key is pressed, a brief beep is heard.
-Handset name - To better distinguish between handsets, you can give each
handset a name.
-Auto pick-up - Just pick up the handset from the base to answer a call (without
pressing any key).
-Auto hang-up - Just hang up the handset to end a call.
-Language
-Room monitor
- You need two handset to use this function. Place one of the
handsets in the room you wish to monitor. Enable the function at that handset.
You can then establish a connection to this handset from a second handset and
monitor the room acoustically. Dialling the internal phone number of the handset
placed in the room starts room monitoring. Room monitoring is stopped again by
either putting the phone down or pressing the Talk key.
Advanced settings
• Press , select Advanced set and press OK.
• Select a function from the list using the navigation key π/†and press OK.
-Recall Time – Select the recall time (flash time) for the analogue network
functionalities in your country.
-Dial Mode – Tone: Normal dialling procedure on analog lines. Pulse: May be
required for connecting older telephone systems. Please refer to the relevant
documentation.
-Call barring – Use this function to bar certain phone numbers from being
dialled. The call barring numbers must be entered separately for each handset.
You can specify up to 4 numbers each comprising up to 4 digits. All phone
numbers whose first digits match the specified numbers will be barred. To access
the menu, enter the PIN code (0000 on delivery). Select the sub-menu
Number
and enter the numbers to be blocked (max. 4). Then select the sub-menu Call
barring
and activate the function.
-Baby call – Use this function to store a set phone number that will be dialled
automatically when any key (except the End call key) is pressed. To access the

menu, enter the PIN code (0000 on delivery). Select the sub-menu Number and
enter the desired call number. Then select the sub-menu
Mode and activate the
function.
Baby call on is displayed.
To deactivate the baby call:
Press the End call key .
Baby call on off? is displayed. Press OK.
-Registration - Register accessory handsets to the base station.
-
Select base - If a handset is registered to multiple bases, select the base you
want to use.
-
Regist. base - You can register up to 4 bases. To register an accessory base,
enter the number of the base (e.g. BASE 2) and press OK. You may be
prompted to enter the PIN code of the base you want to register. The handset
searches the base and then displays the corresponding base number. Repeat
the procedure for every accessory base.
The handset is automatically connected to the last registered base.
-Unregister – Select the handset you want to deregister.
-PIN – You can modify the PIN code (0000 on delivery).
-Reset unit
-Prefix
- Detect digit
- If the first digits of a number you are calling are identical to
the digits stored, they will be suppressed.
- Prefix num. - The prefix number can be 5 digits long. The stored digits are
added in front of the phone number when dialling (with a dialling pause).
-Intrusion - Enabling this function allows you to link in handsets to the call made
with another handset.
-ECO Mode – When ECO Mode is set to ON, the handset’s power transmission is
regulated and a radiation reduction is achieved when it is near the base station.
-Zero Emit - Multi handset ECO Mode = Fulleco, ECO mode for all handsets
registered to the base.
ePure TAM
14 ePure TAM

Answer machine
Your ePure TAM features an integrated digital answer machine with a max. recording
capacity of 30 minutes. You can operate your answer machine from the base and from
any handset registered to the base. On delivery an outgoing message for each mode
(
Answer & Rec and Answer only ) is pre-recorded. The answer machine is ready to
use.
Activate/deactivate the answer machine (from the base)
Press key on the base station to switch the answer machine on or off.
The LED under key
- lights up when the answer machine is activated
- doesn’t light up when the answer machine is deactivated
- flashes when you have new message(s) on the answer machine
Operating the answer machine (from the base)
If you have new messages, the LED under key is flashing.
The messages are played back beginning with the most recent.
• Press to start playback.
• During playback the following options are available:
Key Function
Activate/deactivate answer machine
Repeat message/return to previous message
Skip to next message
Start/end playback
Delete message during playback
/ Adjust volume
Delete all old messages (from the base)
Impossible during playback. Press and hold key to delete all old messages.
Activate/deactivate the answer machine (from the handset)
• Press , select Answ Machine and press OK.
• Select
Answ On/Off and press OK.
ePure TAM
ePure TAM 15

• Select On or Off using the navigation keys π/†and press OK.
is displayed when the answer machine is switched on.
• You must now select the desired operating mode and record a personal outgoing
message:
Record a personal outgoing message
• Press , select Answ Machine and press OK.
• Select
Answer Mode and press OK.
• Select
Answer & Rec (the caller can leave a message) or Answer only (the caller
cannot leave a message) and press OK.
• Select
Personalized and press OK.
• Select
Record mess and press OK.
• Speak your outgoing message into the handset microphone. Your personal
outgoing messages can be 1 minute long (max.).
• Press OK to end recording. The recorded personal outgoing message is played
back.
Operating the answer machine (from the handset)
If you have new messages on your answer machine the symbol flashes. The
messages are played back beginning with the most recent and over the handset loud-
speaker (the handset loudspeaker activates automatically).
• Press , select
Answ Machine and press OK.
• Select
Play and press OK.
• Press the End call key to end playback.
During playback:
• Press OK to open the
Options menu.
The following options are available:
•
Repeat – repeat the message
•
Next message – skip to next message
•
Prev message – return to previous message
- To restore the standard outgoing message, select Answer & Rec or Answer
only
followed by Predefined and press OK.
- To listen to an outgoing message, select
Answer & Rec or Answer only
followed by Play and press OK. The outgoing message is played back.
- To delete a personal outgoing message, select
Answer & Rec or Answer
only
followed by Delete and press OK.
ePure TAM
16 ePure TAM

• Delete – delete a message during playback
•
Save number – save the number in the phonebook
Press the navigation key π/†, to adjust the playback volume.
Delete all old messages (from the handset)
• Press , select Answ Machine and press OK.
• Select
Delete all and press OK.
• To delete all messages confirm the security question with OK.
Record memo
You can leave a message behind for other internal users by recording a memo.
• Press , select
Answ Machine and press OK.
• Select
Record Memo and press OK.
•
Recording is displayed.
• Speak your memo into the handset microphone.
• Press OK to end recording. The memo is stored the same way as an incoming
message.
Answer machine settings
• Press , select Answ Machine and press OK.
• Select
Answ Setting and press OK.
• Select the desired function by pressing the navigation key π/†and press OK.
-Ring Delay – Select the desired delay or Toll saver . If you set the delay to
Toll Saver, your answer machine will answer after 2 rings if you have new
messages. If you do not have new messages it will not answer until 6 rings. This
enables you to save costs by hanging up before you are connected.
-
Remote Acc. – Switch remote access on or off
-
HS Screening – When the answer machine is on and the function activated, you
can listen to the messages being recorded over the handset loudspeaker
-
TAM language – Select the default outgoing message language.
ePure TAM
ePure TAM 17

Memory full
The recording capacity of your answer machine is 30 minutes (including outgoing
messages).
If the memory is full,
Memory full appears on the handset display. No more messages
can be recorded. The answer machine switches to Answer only mode automatically.
You must delete old messages.
Remote access
You can remote access your answer machine from any external telephone with DTMF
or multifrequency dialling function. Dial your number and enter your PIN code (0000 on
delivery). The remote access PIN code is identical with the PIN code of your
telephone.
Activating/deactivating remote access
To be able to remote access your answer machine you musst first activate the function.
• Press , select
Answ Machine/Answ Setting/Remote Acc. and press OK.
• Select
Activated or Deactivated and press OK.
Remote operation from an external telephone
You can remote access your answer machine from any telephone with DTMF or
multifrequency dialling function.
• Dial your number.
• Press when you hear your outgoing message. The outgoing message is
interrupted. Press #.
• Enter your PIN code (0000 on delivery). If the PIN is correct you will hear a
confirmation tone.
• You can now perform a number of functions by entering the relevant digits (see the
following table):
Key Function
1 Return to previous message
2 Play all messages
3 Skip to next message
6 Delete message during playback
7 Switch answer machine on
8 Stop playback
9 Switch answer machine off
ePure TAM
18 ePure TAM
