S-4504-TRM
Canterbury™Tub/Hand Shower Trim
Operation & Maintenance Manual
Model Number Specifications
S-4504-TRM Tub/Hand Shower Trim Tub/hand shower trim with lever handle and secondary
integral diverter handle includes wall connection, cradle
for hand shower mounting, non-diverter tub spout (069),
in-line vacuum breaker, exible metal hose and 3 mode
hand shower (442W) with 2.5 gpm (9.5 L/min) ow
restrictor. Components made from metal and plastic
materials plated in standard polished chrome nish.
Modifications Warranty
-1.5 1.5 gpm (5.7 L/min) flow restrictor
-2.0 2.0 gpm (7.6 L/min) flow restrictor
-442HSB 30" slide bar in place of wall cradle on
hand shower units
-STN Satin nickel finish
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Note: Append appropriate -sufx to model number.

2
Dimensions
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3075 REV 0 06/16/2014
Measurements
A 2 1/8", 54 mm
B
Male 1/2" NPT thread must
be recessed 1/4" from
nished wall
C 6", 152 mm right or left
D 3 1/2", 89 mm
E 7 1/2", 191 mm
F Ø 2 5/8", 67 mm
G 32", 813 mm
H 12", 305 mm
I 3", 76 mm
J 3", 76 mm
K 1/2", 13 mm
L 1/2" NPT
M(Rough-in)
2 3/8" ± 1/2", 60 mm ± 13 mm
N 7 1/4", 184 mm
Notes:
1) All dimensions measured from nominal rough-in (see M as reference).
2) Dimensions are subject to change without notice.
LL
K
K
AA
G
G
H
H
B
B
I
I
J
J
M
M
N
N
Floor
Floor
F
F
EE
C
C
D
D

3
Parts Breakdown
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3075 REV 0 06/16/2014
Replacement Parts
Item Description Part Number
A
Q
Vacuum Breaker and
Hose EF-104
B Wall Elbow EF-105
C
D
E
Wall Cradle
Cradle Mounting Screws
Cradle Mounting Plate
EF-106
F
G
H
I
Plug Button
Star Washer
Handle
Set Screw
T-226
J
K
Lock Nut
Dome Cover T-19/20-PL
L
M
Mounting Screws
Shower Escutcheon T-225B
N Hand Shower 442W
O Diverter Handle T-30C
P Tub Spout 069
Notes:
1) Append -STN to part number for Satin nickel nish.
2) Append -1.5 or -2.0 to hand shower for low ow.
Required for Installation
Adjustable wrench
Phillips head screwdriver
Allen wrench, 3/16"
Teon Tape
O
D
C
E
A
B
L
K
P
Q
M
G
I
J
F
H
N

4
Installation
Note:
For valve body installation, please
see valve body installation guide.
1) Install secondary integral
diverter (O) into shower
escutcheon (M).
2) I nstall shower escutcheon (M) to
shower valve. Secure with two
screws (L).
3) Install dome cover (K) to valve and
secure with lock nut (J).
4) Install handle (H) to valve and
secure with screw (I) and star
washer (G). Attach plug
button (F) to handle.
Note: Handle should be facing the
6 o'clock position.
5) Install tub spout (P) to pipe
tting. Turn clockwise to secure.
6) Install wall elbow (B) to stub out
pipe. Turn clockwise to tighten.
7) Place cradle mounting plate (E) in
position, mark and drill 1/8" pilot
holes into stud.
Option: Place cradle mounting
plate (E) in position, mark and drill
3/16" holes into wall. Install anchors.
8) Remove cover of hand shower
cradle (C) . Install cradle and
mounting plate (E) . Secure with
three screws (D) . Replace cover
on hand shower cradle.
O
M
1
2
L
M
1
2
B
1
3
2
E
1
2
3
G
H
F
I
1
2
P
4
3
E
D
C
2
1
1
2
E
1
2
K
J
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3075 REV 0 06/16/2014

5
9) Attach large end of hand shower
hose (Q) to hand shower head (N).
Attach small end of hand shower
hose (Q) and gasket to in-line
vacuum breaker (A). Connect
in-line vacuum breaker to wall
elbow (B). Turn clockwise to
tighten.
1) Turn shower handle counter-
clockwise approximately 1/4 turn
to put valve in cold position.
2) Turn shower handle counter-
clockwise approximately 1/2 turn
to put valve in warm position.
3) Turn shower handle counter-
clockwise approximately 3/4 turn
to put valve in hot position.
1) Turn diverter left for tub spout
operation.
2) Turn diverter right for hand
shower operation.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3075 REV 0 06/16/2014
3
1
4
2
Q
N
B
Q
A
Installation Temperature Control Diverter Control
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then
quickly rinse with water.
