352SH, 352SH-3
Dia™Showerhead Series
Operation & Maintenance Manual
Model Numbers Specifications
352SH Dia 3" 1 Mode Showerhead
352SH-3 Dia 3" 3 Mode Showerhead
3" 1 mode showerhead (352SH) and 3" 3 mode
showerhead (352SH-3) inlcude standard 2.5 gpm
(9.5 L/min) ow restrictor. Components made from metal
and plastic materials plated in standard polished chrome
nish.
Modifications Compliance
-1.5 1.5 gpm (5.7 L/min) flow restrictor
-2.0 2.0 gpm (7.6 L/min) flow restrictor
-STN Satin nickel finish
Note: Append appropriate -sufx to model number.
-ASME A112.18.1/CSA B125.1
-WaterSense (1.5 & 2.0 gpm)
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Dimensions
AA
B
B
D
D
C
C
352SH
352SH-3
Note: Dimensions are subject to change without notice.
Measurements
A 4 1/4”, 108 mm
B 4 1/8”, 105 mm
C 4 3/4”, 121 mm
D 4 1/2”, 114 mm
Required for Installation
Teon Tape
Certied by
IAPMO R&T
c

2Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3013 REV 0 01/15/2014
1) Install showerhead to shower arm (not included) turn-
ing clockwise to tighten.
1) Turn showerhead to desired mode of operation.
352SH, 352SH-3
Dia™Showerhead Series
Operation & Maintenance Manual
Installation Operation
1
2
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then
quickly rinse with water.
Showerhead is leaking from shower
arm when valve is in “on” position.
Coupling connecting showerhead
to shower arm is cracked or washer
inside coupling is worn.
Inspect coupling and washer
and replace showerhead if
necessary.
