Symmons 0142-06-L/HDHSB-SS-TRM User manual

TUB/SHOWER/HAND SHOWER TRIM
MODEL: 0142-06-L/HDHSB-SS-TRM
INSTALLATION GUIDE
DIMENSIONS
REF.
77"
(1956mm)
REF.
32"
(813mm)
REF.
12"
(305mm)
7"
(178mm)
4-15/16"
(125mm)
Sq. 2-1/2"
(64mm)
3-1/2"
(89mm)
ROUGH-IN
2-3/8" ± 1/2"
(60mm ± 13mm)
FLOOR
Sq. 6-1/4"
(159mm)
PIPING AND
FITTINGS ARE
NOT SUPPLIED WALL SHOWN FOR
REFERENCE ONLY
3-1/8"
(79mm)
3-11/16"
(94mm)
Ø 2-1/2"
(64mm)
REF.
10"
(254mm)
Sq. 2-1/2"
(64mm)
Sq. 5"
(127mm)
3-3/8"
(86mm)
REF.
2"
(51mm)
1/2-14 NPT
5-1/4"
(133mm)
Note: Dimensions subject to change without notice.
FEATURE HIGHLIGHTS
Tub/Shower/Hand Shower Trim shall include metal lever handles, shower arm with decorative flange, hand shower
coupling with flange, in-line vacuum breaker and non-diverter tub spout.
Tub/Shower/Hand Shower Trim shall be metal construction plated in standard polished chrome finish.
WARRANTY
5 Years - for industrial/commercial installations.
Refer to symmons.com/warranty for complete warranty information.
COMPLIANCE
• ASME A112.18.1/CSA B125.1
• ASSE 1014 (in-line vacuum breaker for back flow protection)

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[e-mail] ■ZV-2625 REV 0 ■ 032218
INSTALLATION/PARTS BREAKDOWN
3
1
2
4
56
7
89
10
11
12
13
7
8
14
9
10
Item Description Part Number
1
2
Flange
Shower Arm 300SQ
3 Flange & Coupling T-375-KIT
4
5
6
Mounting Plate
Mounting Screws
Diverter Escutcheon
RTS-069
7
8
Dome Cover
Lock Nut T-19/20
9
10
Handle
Set Screw RTS-068
10 Set Screw TS-18A
11
12
13
Mounting Plate
Mounting Screws
Shower Escutcheon
RTS-065
14 Tub Spout 067
Tools Required
Adjustable Wrench
Allen Wrench:
Handle (3mm)
Phillips Head
Screwdriver
Plumber Tape
Silicone
Notes:
1) Apply a bead of silicone around the perimeter of all shower trim
installed flush to the finished wall (less mounting plates and
brackets). Leave opening on bottom of escutcheon for weep hole.
2) Apply plumber tape to threaded connections as necessary.
DO NOT use plumber tape on fittings with face seal washers or
o-rings.
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
