Symmons Symmetrix S-23 Series Quick guide

Installation
Caution: Be sure to turn off hot and cold water supplies before
installing or servicing faucet.
Step 1 If installing model with hose and spray, install hose
guide into hole in sink (normally the far right hole on four
hole sink). From underneath sink place washer then nut over
hose guide and secure to sink. Insert hose through hose guide
and up through middle hole from le in sink. Loosely install
the anchor bar (KN-23), spacer (KN-26) and nut (L-36) on the
mounting bolts and place gasket on base of faucet. From above
sink attach hose securely to nipple on base of faucet.
Step 2 Align faucet to sink by matching underside arrow
and word “FRONT” on base plate (KN-33) with front of sink.
Without straightening copper supplies insert through center
hole of sink and anchor bar/spacer/nut assemblies through
holes in sink. Secure faucet to sink by tightening nuts from
underside. (If sink surface is uneven use putty or sealant to
make proper seal under base.)
Step 3 Carefully straighten copper supplies to avoid kinking
tubing. Connect hot supply to le tube and cold supply to right
tube using appropriate connectors.
Step 4 It is very important to thoroughly ush the supply
lines to prevent foreign matter, i.e. copper chips, sand, stones,
etc. from damaging the sealing surfaces of cartridge. Remove
aerator and turn valve handle on to full cold position, open cold
supply. Without closing, turn handle to full hot and open hot
supply. Let water run in hot only and cold only positions long
enough to ush supply lines thoroughly. If equipped with a hose
and spray, direct spray head into sink and activate spray. Shut
o faucet and replace aerator. Check for leaks.
Step 5 e handle limit stop can be set to limit handle turn
to the hot position. e limit mechanism is factory set to allow
full handle travel. To adjust the limit stop, turn handle to the
full hot position and li handle to open faucet approximately
half way to obtain a smooth ow for correct initial temperature
measurement.
Step 6 If when faucet is on and in full hot position and water
is too hot, remove plug button (KN-157), loosen set screw
(L-22) and remove handle (KN-3RB or KN-3BRB), li limit
stop ring using a small at head screw driver and rotate counter
clockwise to lower temperature. If water is not hot enough,
rotate clockwise (See Figure 1 on reverse side). Aer correct
temperature is achieved, reattach handle, reversing procedure
above.
Cartridge Replacement (KN-4)
Step 1 Remove plug button (KN-157), loosen set screw (L-22)
and remove handle (KN-3RB or KN-3BRB).
Step 2 Engage tabs in cartridge wrench (LN-34) with slots in
compression ring (KN-2) and use screwdriver in wrench holes or
pliers on wrench and turn counter clockwise until compression
ring engages with cap (KN-1). Continue turning counter
clockwise so that cap/ring assembly is removed from the body
(KN-11).
Step 3 Remove cartridge and three ring seal (KN-4).
Step 4 Install new cartridge while taking care to maintain
position of the three ring seal at the base of the cartridge. Match
posts in base of cartridge with alignment holes in adapter plate
during assembly.
Step 5 Reassemble faucet in reverse fashion. Thread cap onto
body firmly by hand. Do not use a wrench which may damage
the finish. Tighten compression ring (KN-2) finger tight using
the wrench (LN-34) then 1/4 to 1/2 turn further. Set hot water
limit stop in accordance with installation step 6 above.
Diverter replacement (KN-169)
1. Follow cartridge replacement steps 1 through 5 above.
2. Remove retaining ring (K-44) with 3/8” hex key wrench.
3. Remove diverter (K-43) and o-ring (K-46).
4. Grease diverter o-ring and install into body.
5. Press diverter into o-ring and body.
6. Replace retaining ring.
Kitchen Faucet S-23 Series
Installation and Service Instructions
Symmetrix™
10-1/8"
257mm
7-1/2"
191mm
8"
203mm
7-1/4"
184mm
6"
152mm
6-1/4"
159mm
1/2"- 13mm
with spacer
1-1/4"- 32mm
without spacer
spacer
optional 1/2-14
NPT tting
5 1/4
133mm
8-3/4"
222mm
10-7/8"
276mm
1/4-20" UNC
Dimensions Symmetrix Kitchen Faucet, S-23
Note: Dimensions subject to change without notice.

KN-1
KN-2
KN-4
KN-20
KN-11 ASSY
KN-11A ASSY
L-42
KN-19A
KN-30
KN-30A
L-35
KN-33
KN-212
KN-118
KN-23
KN-26
L-36
K-41/42
LN-15
LN-16
LN-100
L-22
KN-157
KN-3BRB
LN-135
optional IPS
connections shown
KN-3RB
K-41/42* Hand spray and holder
K-43 Diverter valve
K-44 Retainer ring
K-46 O-ring
KN-1* Valve cap
KN-2 Compression ring
KN-3RB* Solid Handle
KN-3BRB* Loop Handle
KN-4 Cartridge
KN-11 ASSY Supply body assembly
with diverter
KN-11A ASSY Supply body assembly
without diverter
KN-19A Spacer
KN-20 O-ring (2)
KN-23 Anchor bar (2)
KN-26 Mounting spacer (2)
KN-30* Escutcheon
KN-30A* Escutcheon with hand spray hole
KN-33 Base plate
KN-118 Gasket
KN-157 Plug button
KN-169 Diverter assembly
KN-212 Screw (3)
L-22 Set screw
L-35 Carriage bolt (2)
L-36 Mounting nut (2)
L-42 Nut (2)
LN-15* Aerator (Faucet with hand spray)
LN-16* Aerator (Faucet without hand spray)
LN-34 Cartridge wrench (not shown)
LN-100 Aerator (vandal resistant)
LN-135 6” lever handle with
red/blue indicators
* Note: When ordering parts for products with an
optional decorative nish, append appropriate three
letter nish sufx code to part numbers marked with
an asterisk (*).
K-44
K-43
K-46
KN-20 Diverter assembly
KN-169
6 inch lever handle
Loop handle
Lever handle
Repair
use only
3/8"
Parts Assembly Symmetrix Kitchen Faucet, S-23 Series
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184
Phone: [phone] ■Fax: [phone]
Website: www.symmons.com ■Email: [email protected]
©2007-2014 Symmons Industries, Inc. Printed in U.S.A. ■ZV-330 ■110514
