Symmons H321-V User manual

Model Numbers Feature Highlights
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
1 Mode Hand Shower Unit
Installation Guide
H321-V
Options/Modifications
Compliance
☐H321-V 1 Mode Hand Shower Unit • 1 mode hand shower
• 2-3/4" diameter hand shower head
• Dual checks for backow protection
• 30" slide bar with cradle for hand shower mounting
• 60" exible metal hose
• Standard 2.5 gpm (9.5 L/min) ow restrictor
• Shall be metal and nonmetallic construction, plated in
standard polished chrome nish
Note: Append appropriate -sufx to model number.
☐-1.5 1.5 gpm (5.7 L/min) flow restrictor
☐-2.0 2.0 gpm (7.6 L/min) flow restrictor
☐-STN Satin Nickel finish
- ASME A112.18.1/CSA B125.1
CG
Dimensions
Measurements
A Ø 1-1/2", 38 mm
B 2-1/8", 54 mm
C 28-9/16", 725 mm
D(2x) Hole Size:
Ø 1/4", 6 mm
E 3", 76 mm
F
Male 1/2-14 NPT tting must
be recessed 1/4" (6 mm)
from nished wall
Note: Dimensions subject to change without notice.
FLOORFLOOR
EE
B
C
A
FF
D

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2020 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-2574 REV D ■021419
Tools Required
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
FG
AB
C
D
A
B
C
H
E
Replacement Parts
Item Description Part Number
A
B
C
(2x) Cap
(2x) Screw
(2x) Tile Anchor RA-003
D30" Bar
48" Bar
RA-005
RA-006
E Hand Shower EF-100
F 60" Hose EF-02976
G Wall Elbow EF-105
H Slide Assembly RA-004
Replacement Parts
Item Description Part Number
A
B
C
D
(2x) Cap
(2x) Screw
(2x) Bar End
(2x) Tile Anchor
RA-013
E30" Bar
48" Bar
RA-010
RA-011
F Hand Shower EF-100
G
60" Hose EF-02976
H
Wall Elbow EF-105I
Slide Assembly RA-012
AB
D
E
F
G
HI
C
FOR SYSTEMS PURCHASED AFTER SEPTEMBER 1ST, 2018 FOR SYSTEMS PURCHASED BEFORE SEPTEMBER 1ST, 2018
Notes:
1) Apply a bead of silicone around the perimeter of all shower trim installed ush to the nished wall.
2) Apply plumber tape to all threaded connections.
Parts Breakdown
Adjustable Wrench Drill Phillips Head Screwdriver Plumber Tape Silicone
