Symmons 0142-02-L/HD-SS-TRM User manual

TUB/SHOWER TRIM
MODEL: 0142-02-L/HD-SS-TRM
INSTALLATION GUIDE
DIMENSIONS
REF.
77"
(1956mm)
REF.
32"
(813mm)
REF.
12"
(305mm)
7"
(178mm)
4-15/16"
(125mm)
Sq. 2-1/2"
(64mm)
3-1/2"
(89mm)
ROUGH-IN
2-3/8" ± 1/2"
(60mm ± 13mm)
FLOOR
Sq. 6-1/4"
(159mm)
PIPING AND
FITTINGS ARE
NOT SUPPLIED WALL SHOWN FOR
REFERENCE ONLY
3-1/8"
(79mm)
3-11/16"
(94mm)
Ø 2-1/2"
(64mm)
1/2-14 NPT
5-5/8"
(143mm)
Note: Dimensions subject to change without notice.
FEATURE HIGHLIGHTS
Tub/Shower Trim shall include metal lever handle, shower arm with decorative flange and diverter tub spout.
Tub/Shower Trim shall be metal construction plated in standard polished chrome finish.
WARRANTY
5 Years - for industrial/commercial installations.
Refer to symmons.com/warranty for complete warranty information.
COMPLIANCE
• ASME A112.18.1/CSA B125.1

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[e-mail] ■ZV-2627 REV 0 ■ 040218
INSTALLATION/PARTS BREAKDOWN
1
2
3
4
5
6
7
10
8
9
Item Description Part Number
1
2
Flange
Shower Arm 300SQ
3
4
5
Mounting Plate
Mounting Screws
Shower Escutcheon
RTS-065
6
7
Dome Cover
Lock Nut T-19/20
8
9
Handle
Set Screw RTS-068
9 Set Screw TS-18A
10 Tub Spout 352TS
Tools Required
Adjustable Wrench
Allen Wrench:
Handle (3mm)
Phillips Head
Screwdriver
Plumber Tape
Silicone
Notes:
1) Apply a bead of silicone around the perimeter of all shower trim
installed flush to the finished wall (less mounting plates and
brackets). Leave opening on bottom of escutcheon for weep hole.
2) Apply plumber tape to threaded connections as necessary.
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
