Symmons Elm SLC5512PP Manual

Model Numbers
Lavatory Faucet
Operation & Maintenance Manual
SLC5512PP
• 4 inch centerset lavatory faucet with lever handles
• Commercial grade 1/4 turn ceramic disc valve
cartridge for drip free performance
• 1/2 inch IPS shanks
• Standard ow rate is 1.0 gpm (3.8 L/min)
• Optional lower ow rate restrictor available
• Polished chrome nish (standard)
Feature Highlights
SLC5512PP
Centerset Lavatory Faucet with A Push Pop Drain
Assembly
Dimensions
Note: Dimensions subject to change without notice.
Compliance
-ASME A112.18.1/CSA B125.1
-NSF/ANSI/CAN 61: Q<1, NSF/ANSI 372
-WaterSense 1.0 gpm
Elm®
WARNING: This product can expose you to chemicals
including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Warranty
Certied by
CSA Group

2
*Note: Append STN to part number for Satin Nickel
nish.
Replacement Parts
Item Description Part Number
A Handle Kit RL-021*
B Temperature Cartridge KN-114 Cartridge H
KN-113 Cartridge C
C
Aerator and Wrench(2.2)
Aerator and Wrench(1.5)
Aerator and Wrench(0.5)
LN-333-KIT
FLR-102-1.5-KIT
FLR-102-0.5
D Mounting Hardware RL-020
EPush Pop Drain Assem-
bly RL324*
Tools Required
Adjustable Wrench
Plumber Putty
Plumber Tape
(2) 1/2 in Supply Lines
Basin Wrench
Goggles
PLUMBER
PUTTY
Parts Breakdown
CA
D
B
E

3
Installation
2) Make connections to water lines.
Use 1/2" IPS faucet connections
(1)or use the supplied coupling
nuts (3) with 3/8" O.D. ball-nose
risers (2).Use wrenches to tighten
connections.
DO NOT overtighten.
1) Shut off water supplies. Re-
move old faucet. Place gasket
(1) on bottom of new faucet.
Place faucet through mounting
holes in sink. Secure faucet to
sink using mounting nuts (2)
provided.
If replacing an older faucet
ensure water supply is turned
OFF before removing, then
turn faucet control valve ON
to relieve water pressure.
DO NOT use pipe dope
or thread sealant on drain
assembly, or any plastic
threaded components.
4) Important: After installation is
completed, remove aerator. Turn
on water supply and allow both hot
and cold water to run for at least
one minute each. While water is
running, check for leaks. Replace
aerator.
3) Push Pop Install: Insert drain
body (L) into drain opening. From
below, Tighten locking nut (O)
with gasket (M) and washer (N)
to ange. Tighten tail nut (Y) with
washer (X) to secure tail pipe (Q).
DO NOT overtighten.
1
2
3
Plumbers Putty L
Q
X
N
Y
O
M
2
1
1
2
3

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2023 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3720 REV 0 ■ 021723
Maintenance
1) If faucet leaks from spout outlet
shut off water supplies and replace
cartridge (1).
Note: Install cartridge (1) correctly
for proper handle rotation.
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
Troubleshooting Chart
1
