Syris SYUR03N-U1 User manual

SYUR03N-U1
UHF TCP/IP fixed Reader
Manual
Version 01.02
2016/05/24

SYUR03N UHF TCP/IP fixed Reader Operation Manual
1
I. Features & Specification
Features:
Support for full 860 to 960 MHz UHF RFID carrier frequency range to accommodate worldwide
regulations
Compatible with EPC Class 1 Gen 2;ISO-18000-6C
Multi communication interface
IP65 splash resistant case
Provide protocol to develop.
Specifications:
Frequency
840~960MHz
Interface
Ethernet / Wi-Fi / RS485 / Wiegand
Wiegand
1 Wiegand output
RS485 baud rate
19,200 bits/sec (4,800~460,800)
Ethernet
10M/100M Ethernet Port
Wi-Fi
802.11 b/g/n
Indication
LED & Beeper (Extend 2W Speaker)
DI / DO
4 DI、4 RELAY
Protocols
EPC Class 1 Gen 2; ISO 18000-6C
Built-in antenna
8 dbi circularly polarized antenna
Read range
Up to 6 m (depends on tag’s antenna)
*Optional extend module
Xtive RFID module, 13.56MHz HF RFID module, Bluetooth module
Power Supply
9 ~28 VDC (12 VDC)
Power consumption
2W~4W
Dimensions (mm)
231 x 231 x70 mm
Operating temperature
-20°C to 60°C
Storage temperature
-40°C to 85°C
Sealing
IP65 splash resistant case

SYUR03N UHF TCP/IP fixed Reader Operation Manual
2
II. Wiring Diagram

SYUR03N UHF TCP/IP fixed Reader Operation Manual
3
III. Network Parameter Setting
1. Execute “NET_Discover_V0110.exe” and press to search SYUR03N product.
2. Factory default IP is “192.168.1.101”. User can check the MAC address from product sticker with IP to
confirm the device.

SYUR03N UHF TCP/IP fixed Reader Operation Manual
4
3. Double click IP (192.168.1.101) to open the web configure page(http://192.168.1.101)
Default login ID / Password : admin / admin

SYUR03N UHF TCP/IP fixed Reader Operation Manual
5
4. Default Net Mode is the same as the following. User can modify Net Mode and other parameters. If device
cannot communicate properly after setting, user can reset NET module via Micro USB.
Communication Parameter
Factory Default
Serial Configure
230400,8,n,1
Serial Framing Length
1050
Locale/Remote Port Number
5001

SYUR03N UHF TCP/IP fixed Reader Operation Manual
6
IV. Network Mode Switch
SYUR03N device support 4 network modes: Dual mode、ETH(Ethernet)、Wi-Fi AP、Wi-Fi client.
Default
Ethernet (DHCP) +Wi-Fi AP mode
ETH-SERIAL
Ethernet only (Factory Default)
WIFI(CLIENT)-SERIAL
Wi-Fi client mode
WIFI(AP)-SERIAL
Wi-Fi AP mode
1. ETH-SERIAL：Factory default is ETH-SERIAL. ( Standard TCP/IP Reader )
When user modify the IP and click on Apply button, device will reboot and apply the setting after 30 seconds.

SYUR03N UHF TCP/IP fixed Reader Operation Manual
7
2. Wi-Fi client mode：SYUR03N can be set to communicate via Wireless AP without Ethernet.
SSID:
Enter the SSID from AP you will connect to network.
Scan : User can scan AP in range of SYUR03N and select one to connect. But user cannot scan the AP
after changing default network mode (Ethernet only) to Wi-Fi (Client). SYUR03N need to power off / on to
enable the scan function.
Encrypt Type : Select Encrypt type for AP connection.
Password: Enter password for AP.
IP Type: DHCP is default mode. If user has to setup a static IP, please select Static.

SYUR03N UHF TCP/IP fixed Reader Operation Manual
8
3. Wi-Fi AP mode：Setup SYUR03N as AP (Wireless Access Point) for client device to communicate. This mode is
usually for setting device.
SSID: Setup device’s SSID.
Encrypt Type : Select Encrypt Type for the AP.
Password: Setting device’s Wi-Fi password.
IP address: Setting device’s Wi-Fi IP address.
Subnet Mask: Setting device’s Wi-Fi subnet mask.

SYUR03N UHF TCP/IP fixed Reader Operation Manual
9
4. Default mode：Ethernet (DHCP) +Wi-Fi AP mode.
It’s Dual-Mode ( Ethernet and Wi-Fi AP，but Ethernet only support DHCP.)
SSID: Setup device’s SSID.
Password: Setting device’s Wi-Fi password.

SYUR03N UHF TCP/IP fixed Reader Operation Manual
10
V. USB Connection
Setup SYUR03N parameter via micro USB.
1. Install USB driver ”CDC_USB_Driver_VCP_V1.4.0_Setup.exe”
2. System will generate a virtual COM port.
For example. Check port in device manager.(below picture is COM 3)
Micro USB

SYUR03N UHF TCP/IP fixed Reader Operation Manual
11
User also can update driver manually. The driver is saved in the folder that is same as following.
3. Get device Model information and serial number by using V7 Tools with correct COM port or TCP connection.
4. V7 Tools also provides Ethernet mode. User only needs to fill-in correct IP and Port and click
to setup.
2
3
4
1

SYUR03N UHF TCP/IP fixed Reader Operation Manual
12
VI. V7 Tools configuration
1. Common:
Get device serial number、device ID and firmware version.
Warm Start: Reboot device.
Initial: Restore device to factory default (It is NOT including network setting).
NET Initial (6 sec): Restore network parameter of device to default mode. User has to setup by referring the
following information after restore device to factory default.
Communication Parameter
Factory Default
Serial Configure
230400,8,n,1
Serial Framing Length
1050
Locale/Remote Port Number
5001

SYUR03N UHF TCP/IP fixed Reader Operation Manual
13
2. Reader
Set Interface: Setup reader’s communication interface. Default is “Wiegand & RS485”.
3. DI/DO
SYUR03 support 4 digital inputs and 4 relay outputs.
Click “auto test” to test DI/DO command.

SYUR03N UHF TCP/IP fixed Reader Operation Manual
14
4. UHF
Set ID block/byte: Select correct bank (EPC, TID or USER), address and length to setup SYUR03N auto read
data.
Auto read: Support read EPC, TID and USER block. (Only EPC is availible now.)
Length: Setup auto read data’s length.
Byte: Setup auto read data’s byte.
ID Reverse: Reverse read data.
Addr: Setup auto read data’s address.
Start: Setup auto read data’s address start byte.
Same: Same card time. Default is 50 (50 x 0.1=5 seconds)
Reader power: Setup UHF RFID power (-2~25 dbm) to control reader’s read range.
Frequency Range: Setup UHF frequency range for different RF regulation.
Country
Frequency range
US
902~928 MHz
TW
922~928 MHz
CN
920~925 MHz
CN2
840~845 MHz
EU
865~868 MHz
Write data to block: Test read/write EPC tag data in this area.

SYUR03N UHF TCP/IP fixed Reader Operation Manual
15
VII. SYUR03N Controller extend slave reader.
Extend slave reader via RS-485
1. Connect RS485 wire (4R+ to 4R+, 4R- to 4R-)

SYUR03N UHF TCP/IP fixed Reader Operation Manual
16
2. Select “READER” tab to setup interface to RS485.
3. Check controller and reader’s RS485 communication rate are the same (Default is 64 bits).
4. Select “86 Serial” tab to setup “Controller mode” and “RS485 Master Mode”.
