System air VEF 1 Manual

Document translated from English | 211934 · A006
Cupboard fans
VEF 1, VEF 2, VEF 4
GB Installation and Service ................................2
SV Installation och Service ..............................22
DE Betriebs- und Wartungsanleitung................42
NO Montasje og service...................................62

211877 | A006
GB
Installation and Service GB
© Copyright Systemair UAB
All rights reserved
E&OE
Systemair UAB reserves the rights to change their products without notice.
This also applies to products already ordered, as long as it does not affect the previously agreed specifications.
Systemair is not liable or bound by the warranty if these instructions are not adhered to during installation or service.

211877 | A006
Contents
1 Declaration of Conformity .................................5
2 Warnings.......................................................6
3 Product information .........................................6
3.1 General................................................6
3.2 Technical data .......................................6
3.2.1 Dimensions and weight ...............7
3.2.2 Duct connections........................8
3.2.3 Performance .............................8
3.2.4 Wiring diagram ..........................9
3.3 Transportation and storage..................... 10
4 Installation................................................... 10
4.1 Installing the fans ................................. 10
5 Commissioning ............................................. 12
6 Maintenance................................................ 13
6.1 Important ........................................... 13
6.2 Maintenance intervals ........................... 13
6.3 Cleaning the fan................................... 13
7 Troubleshooting............................................ 15
8 Accessories.................................................. 15
8.1 Controllers.......................................... 15
8.1.1 MTP 10/10K Proportional
speed controller....................... 15
8.1.2 MTP 20 3-Step
Controller ............................... 15
8.1.3 Humidity - Demand
control .................................. 16
8.1.4 CO2 - Demand control ............... 17
8.2 Cooker hoods ...................................... 17
8.2.1 251-14 EC .............................. 18
8.2.2 392–14 Slimline EC ................... 19

GB Declaration of Conformity | 5
1 Declaration of Conformity
Manufacturer
Systemair UAB
Linų st. 101
LT–20174 Ukmergė, LITHUANIA
Office: [phone] Fax: [phone]
www.systemair.com
hereby confirms that the following products:
VEF 1, VEF 2, VEF 4
(The declaration applies only to product in the condition it was delivered in and installed in the facility in accordance
with the included installation instructions. The insurance does not cover components that are added or actions carried
out subsequently on the product).
Comply with all applicable requirements in the following directives:
• Machinery Directive 2006/42/EC
• Low Voltage Directive 2014/35/EU
• EMC Directive 2014/30/EU
• Ecodesign Directive 2009/125/EC
The following regulations are applied in applicable parts:
1253/2014 Requirements for ventilation units
1254/2014 Energy labelling of residential ventilation units
327/2011 Requirements for fans above 125 W
The following harmonized standards are applied in applicable parts:
EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk reduction
EN 13857 Safety of machinery – Safety distances to prevent hazard zones being reached by upper or
lower limbs
EN 60 335-1 Household and similar electrical appliances – Safety Part 1: General requirements
EN 60 335-2-40 Safety of household and similar electrical appliances – Part 2-40: Particular requirements
for electrical heat pumps, air-conditioners and dehumidifiers
EN 62233 Measurement methods for electromagnetic fields of household appliances and similar
apparatus with regard to human exposure
EN 50 106:2007 Safety of household and similar appliances – Particular rules for routine tests referring to
appliances under the scope of EN 60 335-1 and EN 60967
EN 61000-6-2 Electromagnetic compatibility (EMC) – Part 6-2: Generic standards – Immunity for industrial
environments
EN 61000-6-3 Electromagnetic compatibility (EMC) – Part 6-3: Generic standards – Emission standards for
residential, commercial and light-industrial environments
Skinnskatteberg, 21–09–2017
Mats Sándor
Technical Director
211877 | A006

6|Warnings GB
2 Warnings
The following admonitions will be presented in the different sections of the document:
Danger
Indicates a potentially or imminently hazardous situation which, if not avoided, could result in death or
serious injury.
Warning
Indicates a potentially hazardous situation that may result in minor or moderate injuries.
Caution
Indicates a risk of damaging the product or prevent optimal operation.
3 Product information
Caution
• Take precautions to prevent the back flow of exhaust gases from flues from other appliances installed in
the same room, which are fired by gas or other fuels.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
3.1 General
This installation manual concerns VEF 1, VEF 2, VEF 4 manufactured by Systemair UAB.
The cupboard fans are delivered with potentiometer, 0-10 V. The integrated potentiometer is factory preset to 10 V.
This value can be changed manually to obtain a different motor rpm/fan performance. An external potentiometer can
be connected if necessary. If so the internal potentiometer needs to be disconnected from the connection terminals.
This manual consists of basic information and recommendations concerning the design, installation, start-up and opera-
tion, to ensure a proper fail-free operation of the unit. The key to proper and safe operating of the unit is to read this
manual thoroughly, use the unit according to given guidelines and follow all safety requirements.
Cupboard fans are intended for transportation of air in air handling systems. The fans are meant for use in ducted sys-
tems and should always be duct connected on the inlet side. No moving parts shall be accessible after installation. Cup-
board fans are adapted to continuous operation.
Product and article number:
• VEF 1 — 88685
• VEF 2 — 88684
• VEF 4 — 88686
3.2 Technical data
Safe operating temperature is from -25 °C to +40 °C.
211877 | A006

GB Product information | 7
3.2.1 Dimensions and weight
Fig. 1 Dimensions of VEF 1 cupboard fan
The weight of VEF 1 cupboard fan is 6,25 kg.
Fig. 2 Dimensions of VEF 2 cupboard fan
The weight of VEF 2 cupboard fan is 6,25 kg.
Fig. 3 Dimensions of VEF 4 cupboard fan
The weight of VEF 4 cupboard fan is 6,335 kg.
211877 | A006

8| Product information GB
3.2.2 Duct connections
Exhaust air Extract air
3.2.3 Performance
3.2.3.1 VEF 1 performance curves
3.2.3.2 VEF 2 performance curves
211877 | A006

GB Product information | 9
3.2.3.3 VEF 4 performance curves
3.2.4 Wiring diagram
LSupply connection, power supply, phase, see nameplate for voltage range
NSupply connection, power supply, neutral conductor, see nameplate for voltage range
PE Ground connection
1Not used.
Tach output, open collector, 1 pulse per revolution, max = 10 mA, SELV
2 (-) Reference ground for control interface, SELV
30-10 V / PWM control input, Ri=100 kΩ, SELV
4 (+) Fixed voltage output 10 VDC +/-3 %, max. 10 mA, short-circuit-proof, power supply for ext. devices, SELV
BU Blue
BN Brown
BK Black
GND Ground
RD Red
YE Yellow
WH White
SC Signal cable
FC Fan cable
211877 | A006

10 | Installation GB
3.3 Transportation and storage
All fans are packaged at the factory to withstand normal transport handling. When handling the goods use suitable lift-
ing equipment in order to avoid damage to fans and personnel. Avoid blows and shock loads. Store the fans in a dry
place protected from weather and dirt until final installation.
Warning
• The unit is heavy. Be careful during transport and installation. Risk of injury through pinching. Use
protective clothing.
• Do not lift the fans by the connecting cable, connection box, motor bracket, impeller or inlet cone.
4 Installation
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Warning
• The units electrical connection to the mains supply must be preceded by an all pole circuit breaker with a
minimum 3 mm gap.
• Do not lift the fans by the connecting cable, connection box, motor bracket, impeller or inlet cone.
• The fans are not to be used in hazardous environments or connected to flue ducts.
• The appliance must be connected to a mains circuit breaker in the fixed installation.
Caution
• Make sure protection grid has been installed (EN ISO 13857), no moving parts shall be accessible after
installation.
• Do not remove, short-circuit or disconnect safety accessories (i.e. motor protection, safety grille).
4.1 Installing the fans
1 Install four mounting brackets (pos. 1) to dedicated
positions on the sides of fan housing. Use included
screws (pos. 2). This step can be skipped in case
mounting brackets will not be used for installation.
Stick the enclosed self adhesive anti-vibration rubbers
on the cupboard fan.
211877 | A006

GB Installation | 11
2 Install the cupboard fan in your desired place. The
cupboard fan can be installed in any position and
place: floor, wall, ceiling.
Remove the cover of junction box (pos. 1) by turning
four locks in each corner from position 1 to 0.
Other installation options:
3Lead the power supply cable (pos. 1) through the hole
on the side of junction box. Connect wires to the ter-
minal block (pos. 2) according to wiring diagram
(3.2.4 Wiring diagram, page 9).
Fan speed can be increased or reduced by turning ro-
tating contact on the potentiometer (pos. 3) to differ-
ent position from 1 to 10.
• 1 — minimum speed
• 10 – maximum speed
4Place back the cover of junction box and lock it.
211877 | A006

12 |Commissioning GB
5 Commissioning
Danger
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Before initial operation, check the following:
• Electrical connection has been properly completed.
• Protective earth has been connected.
• Safety devices in place (protection grid).
• Leftover installation materials and foreign materials have been removed from the casing.
Testing the installation:
• Adjustment may be required in the electrical compartment during test (i.e. changing of the potentiometer), however
during operation the lid must be closed.
When putting into operation, check the following:
• Connection data corresponds to the specifications on the nameplate: Maximum voltage +6%, -10%, according to IEC
38. Rated current must not be exceeded with more than 5% at rated voltage.
• The direction of rotation should correspond to direction-of-rotation arrow (3 phase).
• Smoothness of motor operation, (no abnormal noises).
211877 | A006

GB Maintenance |13
6 Maintenance
6.1 Important
Danger
• Switch power off (all-pole circuit breaker) before servicing or maintenance, and make sure the impeller
has come to standstill.
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• Do not remove, short-circuit or disconnect safety accessories (i.e. motor protection, safety grille).
• Fan impeller has come to a complete standstill.
• Should the supply cable be damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard
• The unit is heavy. Be careful during transport and installation. Risk of injury through pinching. Use
protective clothing.
• Do not lift the fans by the connecting cable, connection box, motor bracket, impeller or inlet cone.
6.2 Maintenance intervals
The fan should be cleaned when necessary, at least once a year to avoid imbalance and unnecessary damage to the
bearings. The fan bearings are maintenance free and should only be replaced if damaged. Do not use a high-pressure
cleaner (steam jet) when cleaning the fan. Ensure that the fan impeller's balance weights are not moved or the fan im-
peller distorted. Listen for abnormal operating noise.
6.3 Cleaning the fan
Warning
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• Fan impeller has come to a complete standstill.
• The unit is heavy. Make sure that the motor bracket attach to the lock to prevent the motor to fall down
during maintenance.
Danger
• Make sure that the motor does not fall down.
Caution
• Beware of sharp edges during maintenance, use protective gloves. Risk of injury through pinching.
• The fans can have sharp edges and corners which may cause injuries. Be careful when opening the fans,
the motor assembled on the motor bracket is relatively heavy.
211877 | A006

14 |Maintenance GB
1 Remove four screws closest to each corner.
2 Carefully lift the cover. Clean the fan.
3 Place back the cover and secure it with previously re-
moved screws.
211877 | A006

GB Troubleshooting | 15
7 Troubleshooting
The following applies in case the fan has stopped:
• Try to restart the fan by cutting the power a couple of minutes.
• Ensure that the impeller is not locked. Disconnect the power supply, remove any obstacles. Check that the fan starts
after reconnecting the current. Should the fan not start please contact your place of purchase.
8 Accessories
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
8.1 Controllers
8.1.1 MTP 10/10K Proportional speed controller
Speed controller for the manual control of speed and airflow of Cupboard fans.
Component/product — Article number:
• MTP 10, 10K, Speed control — 32731
Fig. 4 Controller connection
Installation and connection
1. Remove the cover of junction box (pos. 1) by turning four locks in each corner from position 1 to 0.
2. Pull out potentiometer connected to sockets 2, 3 and 4 on the terminal block.
3. Connect + (4) on the accessory to socket 3 on the terminal block.
4. Connect – (5) on the accessory to socket 2 on the terminal block.
5. Connect Us marked wire to socket 4 on the terminal block.
6. Place back the cover of junction box and lock it.
Cupboard fans can be controlled with an external controller now.
8.1.2 MTP 20 3-Step Controller
A 3–step potentiometer for speed control with on and off function. The 10 V supply voltage is converted into three
steps to obtain a minimum, mid and maximum position. Position 1 and 2 can be adjusted to environment requirements.
Component/product — Article number:
• MTP 20, on/off, 3-step — 310220
211877 | A006

16 |Accessories GB
Fig. 5 Controller connection
Installation and connection
1. Remove the cover of junction box (pos. 1) by turning four locks in each corner from position 1 to 0.
2. Pull out potentiometer connected to sockets 2, 3 and 4 on the terminal block.
3. This step can be skipped if power supply is already connected.
Lead the power supply cable through the hole on the side of junction box. Connect wires to the terminal block accord-
ing to wiring diagram.
4. Connect red wire (+10V) from the accessory to socket 4 on the terminal block.
5. Connect blue (GND) wire from the accessory to socket 2 on the terminal block.
6. Connect control input (1–10V) wire from the accessory to socket 3 on the terminal block.
7. Place back the cover of junction box and lock it.
Cupboard fans can be controlled with an external controller now.
8.1.3 Humidity - Demand control
The controller compares room humidity with an adjustable set point (SW1) and regulates a 0..10 V output signal applied
to a ventilator with a proportional algorithm in direct or reverse action based on jumper JP1 setting, significantly reduc-
ing energy consumption to maintaining indoor climate.
Component/product — Article number:
• EC-Basic-H humidity — 24807
Fig. 6 Controller connection
211877 | A006

GB Accessories |17
Installation and connection
1. Remove the cover of junction box (pos. 1) by turning four locks in each corner from position 1 to 0.
2. Pull out potentiometer connected to sockets 2, 3 and 4 on the terminal block.
3. Connect 0-10V (4) on the accessory to socket 3 on the terminal block.
4. Connect GND (5) on the accessory to the socket 2 on the terminal block.
5. Connect 230 V – Neutral (N) wire to the accessory and N socket on the terminal block (Blue wire).
6. Connect 230 V – Phase (L) wire to the accessory and L socket on the terminal block (brown wire).
7. Ground connection should be connected to the socket with ground symbol on the terminal block (yellow/green
wire).
8. Place back the cover of junction box and lock it.
VEF shall be controlled according to indoor humidity levels now.
8.1.4 CO2 - Demand control
The controller compares room CO2 with an adjustable set point (SW1) and regulates a 0..10 V output signal applied to a
ventilator with a proportional algorithm in direct or reverse action based on jumper JP1, setting significantly reducing
energy consumption to maintain indoor climate.
Component/product — Article number:
• EC-Basic-CO2 and temperature — 24808
Fig. 7 Controller connection
Installation and connection
1. Remove the cover of junction box (pos. 1) by turning four locks in each corner from position 1 to 0.
2. Pull out potentiometer connected to sockets 2, 3 and 4 on the terminal block.
3. Connect 0-10V (4) on the accessory to socket 3 on the terminal block.
4. Connect GND (5) on the accessory to the socket 2 on the terminal block.
5. Connect 230 V – Neutral (N) wire to the accessory and N socket on the terminal block (Blue wire).
6. Connect 230 V – Phase (L) wire to the accessory and L socket on the terminal block (brown wire).
7. Ground connection should be connected to the socket with ground symbol on the terminal block (yellow/green
wire).
8. Place back the cover of junction box and lock it.
VEF shall be controlled according to indoor CO2levels now.
8.2 Cooker hoods
These cooker hoods are designed with a possibility to connect them to ventilation units such as Cupboard fans.
211877 | A006

18 |Accessories GB
8.2.1 251-14 EC
This product will be available in the 4th quarter of 2018.
The cooker hood is ready internally wired and equipped with cables with special plugs for respectively mains supply
230 V~ and control signal to the ventilation unit (0-10 VDC).
Component/product — Article number:
• 251-14 EC Stainless Steel — 96803
• 251-14 EC White — 96804
Fig. 8 251–14 EC cooker hood connection
Position Description
1Junction box
2Cupboard fans
3 251-14 EC
4Power supply wires (230 V~)
5Control signal wires (10 VDC)
6Special plug (230 V~)
7Special plug (control signal 10 VDC)
Installation and connection
1. Remove the cover of junction box (pos. 1) by turning four locks in each corner from position 1 to 0.
2. Pull out potentiometer connected to sockets 2, 3 and 4 on the terminal block.
3. Remove a special plug (pos. 6) from a power supply cable of the cooker hood (pos. 3)
4. Connect 230 V~ neutral (N) wire to the accessory and N socket on the terminal block (blue wire).
5. Connect 230 V~ phase (L) wire to the accessory and L socket on the terminal block (brown wire).
6. Ground connection should be connected to the socket with ground symbol on the terminal block (yellow/green
wire).
7. Remove a special plug (pos. 7) from a control cable of the cooker hood (pos. 3)
8. Connect blue wire (N) from the accessory to socket 2 on the terminal block.
9. Protective earth wire (yellow/green) from the control cable should be connected to socket 2 on the terminal block.
10.Connect black wire (1–10V) from the accessory to socket 3 on the terminal block.
11.Connect brown wire (+10V) from the accessory to socket 4 on the terminal block.
211877 | A006

GB Accessories |19
12.Place back the cover of junction box and lock it.
Cupboard fans can be controlled with a cooker hood now.
8.2.1.1 Fan speed configuration
Fig. 1 H1 — minimum speed voltage, H2 — normal
speed voltage
It is possible to adjust the minimum and normal fan speed
by internal potentiometers located next to the lamp. Max-
imum speed is not adjustable and always 10 V.
The potentiometers are adjusted by means of a screw
driver.
Turning the potentiometer results in different control vol-
tages to the fans. To get an idea of the airflow corre-
sponding to each voltage output see 3.2.3 Performance.
Fan performance diagrams show performance curves for
extract air.
Speed setting Voltage range
Minimum speed (1) 1,5-5 V
Normal speed (2) 2-8 V
Maximum speed (3) 10 V (not possible to
change)
8.2.2 392–14 Slimline EC
This product will be available in the 4th quarter of 2018.
The cooker hood is internally wired and equipped with a cable for a control signal to the ventilation unit (0-10 VDC) and
power cable.
Component/product — Article number:
• 392-14 EC Slimline White — 96805
Fig. 9 392–14 Slimline EC connection
Installation and connection
1. Remove the cover of junction box (pos. 1) by turning four locks in each corner from position 1 to 0.
2. Pull out potentiometer connected to sockets 2, 3 and 4 on the terminal block.
3. Connect 230 V~ neutral (N) wire to the N socket on the terminal block (blue wire).
4. Connect 230 V~ phase (L) wire to the L socket on the terminal block (brown wire).
211877 | A006

20 |Accessories GB
5. Ground connection should be connected to the socket with ground symbol on the terminal block (yellow/green
wire).
6. Protective earth wire (green) from the control cable should be connected to socket 2 on the terminal block.
7. Connect yellow wire (1–10V) from the accessory to socket 3 on the terminal block.
8. Connect brown wire (+10V) from the accessory to socket 4 on the terminal block.
9. Place back the cover of junction box and lock it.
Cupboard fans can be controlled with a cooker hood now.
8.2.2.1 Control description and fan speed configuration
392–14 Slimline EC cooker hood control panel has 5 buttons:
Turn on/off the
cooker hood lights.
Open/close damper
Damper
automatically closes
after 60 min.
The fan of the unit
works at minimum
speed (1,5 V).
Voltage can be
adjusted from 1,5 V
to 5 V.
The fan of the unit
works at medium
speed (2 V)
Voltage can be
adjusted from 2 V to
8 V.
The fan of the unit
works at maximum
speed (10 V)
Voltage cannot be
adjusted.
The fan
automatically turns
off after 60 min.
Voltage is adjusted by pressing the damper button and fan speed button at the same time. Each fan speed button press
increases voltage to the fan. After reaching the maximum allowed voltage for selected fan speed, voltage value resets
to default value.
Voltage value for each step is displayed bellow.
Table 1 Fan speed configurations
Fan speed 1 Fan speed 2
Combination Voltage, V Combination Voltage, V
Default value 1,5 Default value 2
+ x 1 2+ x 1 2,5
+ x 2 2,5 + x 2 3
+ x 3 3+ x 3 3,5
+ x 4 3,5 + x 4 4
+ x 5 4+ x 5 4,5
+ x 6 4,5 + x 6 5
+ x 7 5+ x 7 5,5
+ x 8 1,5 + x 8 6
+ x 9 6,7
+ x 10 7
+ x 11 7,5
+ x 12 8
+ x 13 2
211877 | A006
