OPERATOR’S MANUAL
55mm Coil Nailer
FCN55V
Air tool operator manual_FCN55V.indd 1Air tool operator manual_FCN55V.indd 1 20/10/2020 15:3620/10/2020 15:36

2
IMPORTANT
Please make certain that the person who is to use
this equipment carefully reads and understands these
instructions before starting operations.
WICHTIG
Bitte stellen Sie sicher, dass die Person, die mit
diesem Gerät arbeiten wird die Anleitungen vor
Gebrauch sorgfältig durchliest und versteht.
IMPORTANT :
Veuillez vous assurer que l’utilisateur de cet
équipement a lu et compris les consignes de
manipulation avant de mettre en marche l’appareil.
IMPORTANTE
Por favor, asegúrese que la persona que va a usar
este equipo lea detenidamente y conozca estas
instrucciones antes de usarlo.
IMPORTANTE
Accertarsi che l’utente abbia letto e compreso
queste istruzioni prima di procedere all’utilizzo
dell’apparecchio.
Air tool operator manual_FCN55V.indd 2Air tool operator manual_FCN55V.indd 2 20/10/2020 15:3620/10/2020 15:36

FASTENING TOOLS FOR THE PROFESSIONAL
3
FASTENING TOOLS FOR THE PROFESSIONAL
3
1 3
6
4
8
7
NAILER
NAGLER
CLOUEUSE
CLAVADORA
CHIODATRICE
OILER
ÖLER
GRAISSEUR
LUBRICADOR
LUBRIFICATORE
FILTER
FILTER
FILTRE
FILTRO
FILTRO
AIR SUPPLY
LUFTZUFUHR
ALIMENTATION EN AIR
SUMINISTRO DE AIRE
ALIMENTAZIONE ARIA
REGULATOR
REGLER
RÉGULATEUR
REGULADOR
REGOLATORE
AIR HOSE
LUFTSCHLAUCH
TUYAU D’AIR
MANGUERA DE AIRE
TUBO DELL’ARIA
QUICK CONNECTOR
SCHNELLVERBINDER
RACCORD RAPIDE
CONECTOR RÁPIDO
CONNETTORE RAPIDO
2
5
FIG. A
FIG. B - CONNECTING A TOOL TO THE AIR SUPPLY
Air tool operator manual_FCN55V.indd 3Air tool operator manual_FCN55V.indd 3 20/10/2020 15:3620/10/2020 15:36

4
FIG. C - LOADING THE FASTENERS
1
2
3
Air tool operator manual_FCN55V.indd 4Air tool operator manual_FCN55V.indd 4 20/10/2020 15:3620/10/2020 15:36

5
FASTENING TOOLS FOR THE PROFESSIONAL
FIG. C - LOADING THE FASTENERS - CONTINUED
4
5
6
FIG. D -
ADJUSTING
THE DEPTH
FIG. F - AIR DEFLECTOR
FIG. E -
FIRING
MODES
Air tool operator manual_FCN55V.indd 5Air tool operator manual_FCN55V.indd 5 20/10/2020 15:3620/10/2020 15:36

6
EN 55mm Coil Nailer FCN55V
Congratulations!
On the purchase of your Tacwise power tool. Your tool will perform
to your satisfaction for a long time if handled in accordance with our
Safety and Operating instructions.
Save this manual for future reference
Technical Data
Characteristic Value
Minimum operating air pressure 70psi
Maximum operating air pressure 120psi
Nail length range 25mm (1") - 57mm (2 1/4")
Nail size 2.1-2.5 Flat & Conical Nails
Magazine capacity 300-350pcs
Air inlet 1/4" NPT
Air consumption 0.62 CFM @ 90psi
Weight 2.4kgs (5.3lbs)
Vibration emission level* 2.6m/s2
* The declared vibration emission level represents the main applications
of the tool. However if the tool is used for different applications, with
different accessories or poorly maintained, the vibration emission may
differ. This may significantly increase exposure level over the total
working period.
CE –Declaration of Conformity
55mm Coil Nailer FCN55V
Tacwise declares that this power tool has been designed in compliance
with the Regulations and Standards of the
European Directives.
Quality Department, Tacwise Group Plc – UK
WARNING! Before Use Carefully Read And Understand
All Instructions.
Failure to do so could result in fire and/or serious personal injury. For
any queries relating to safety matters on this power tool, please email
[email protected].
Unpacking
• Carefully remove the tool and accessories from the box.
• Inspect the tool carefully to make sure no breakage or damage
occurred during transit.
• If any parts are damaged or missing, please email
[email protected] for assistance. Do not operate this tool until
the missing or damaged parts are replaced. Failure to do so could
result in a personal injury.
• Whilst every effort has been made to ensure accuracy of information
contained within this manual, the Tacwise policy is one of
continuous improvement to our products and as such
we reserve the right to change the product specification without
prior notice.
General Safety Instructions
Important. Tacwise recommends that this power tool should not
be modified or used for any application other than that for which it
was designed. Any such alteration or modification is misuse and could
result in a hazardous condition leading to a personal injury. If you are
unsure of its relative applications do not hesitate to contact us and we
will advise you.
Work Area
• Keep your work area clean and well lit. Cluttered benches and
dark areas invite accidents.
• Keep children and pets away. All visitors should be kept a safe
distance from work area.
• Secure work. Use clamps or a vice to hold work. This frees both
hands to operate the power tool.
Safety Warnings & Cautions
• Never use oxygen combustible gases, bottled gases or high
pressure compressed gas as a power source for this tool.
The tool may explode and cause serious injury.
• Outdoor extension cords. When air compressor is used outdoors,
use only rounded jacket extension cords intended for outside
use. See manufacturer’s manual for the AWG required for the
compressor’s amperage draw.
• Pay attention to air hose and their connections. Don’t trip over
hoses. Make sure all connections are tight.
• Use the correct air connector. The connector on the tool must
not hold pressure when the air supply is disconnected. If the
wrong fitting is used, the tool can be charged with air after being
disconnected and still be able to drive a fastener.
• When connecting the air. The tool may possibly fire the fasteners
as soon as you plug it in to the air hose. Therefore, remove all the
fasteners before connecting to the air.
• Do not depress the trigger when loading.
• If the fasteners are jammed. Disconnect the tool from the air and
remove the jammed fasteners.
• Stay alert. Always watch what you are doing and use common
sense. Do not operate a power tool when you are tired or under the
influence of medication, alcohol or drugs.
• Wear proper clothing. Do not wear loose clothing or jewellery that
can catch in moving parts. Non-slip footwear is recommended.
Contain long hair and roll long sleeves above
the elbow.
• Do not over reach or use on unstable surfaces. Keep proper
footing and balance at all times.
• Use safety equipment. Dust mask, non-skid safety shoes, hard
hat, or hearing protection must be used for appropriate conditions.
Wear CE approved safety goggles at all times. Normal spectacles
only have impact resistant lenses; they are NOT safety glasses.
• DO NOT use on hard surfaces such as rock, concrete, masonry,
bricks or steel. Personal injury or damage to the power tool
could result.
• Stored power tools. When not in use, all power tools should be
stored in a dry, locked cupboard, out of the reach of children and
other untrained persons.
• Recommended accessories. Use only accessories that are
recommended by the manufacturer for your model. Accessories that
may be suitable for one tool may create a risk of injury when used
on another tool.
• Beware of hidden danger. Always make sure there is no danger of
hitting any hidden power cables, water or gas pipes.
• Always assume that the tool is loaded with fasteners. Handling
the tool without care could result in an unexpected firing of
fasteners and lead to personal injury.
• Do not activate the power tool unless it is in contact with the
work piece. Serious injury can result if you depress the
safety lock pin on nose/contact trip with your fingers, or by improper
operation.
• Never point any power tool at yourself or at any other person.
While working, hold the tool in such a way that no injuries can be
caused to the head or to the body in the event of possible recoil.
• Do not drive fasteners on top of other fasteners.
Air tool operator manual_FCN55V.indd 6Air tool operator manual_FCN55V.indd 6 20/10/2020 15:3620/10/2020 15:36

FASTENING TOOLS FOR THE PROFESSIONAL
7
• Do not use this tool to fasten electric cables. This tool is not
designed for the installation of electric cabling and may damage
electric cables which could lead to injury by electric shock or
fire hazards.
Features (Fig. A)
1. Firing Mode Selector
2. Trigger
3. Quick Release Plug (Euro Fitting)
4. Magazine Drum
5. Depth Adjustment Wheel
6. Magazine Release Latch
7. Nose Piece
8. Air Deflector
Set up
Your air tool is fully assembled when you receive it. Before using it,
attach the air line and desired air system accessories. See Fig. B for the
recommended accessories and connection order. Be sure the air hose
is de-pressurised when installing or removing adaptors to the air line.
Connecting The Tool to an Air Supply (Fig. B)
• Determine if the tool needs oil and, if necessary, place two drops of
oil in the air plug as shown in Fig. B. If you are using an automatic
in-line oiler, check and add oil if necessary.
• Turn the compressor on and set the regulator to the proper pressure
for the size and type of fastener being used.
• Connect the tool to the air supply.
Loading the Tool (Fig. C)
• Squeeze latch to open nail door, then rotate magazine door so it
is fully open.
NOTE: THE MAGAZINE PLATFORM MUST BE SET FOR THE LENGTH
OF NAIL TO BE USED. NAILS WILL NOT FEED SMOOTHLY IF THE
PLATFORM IS NOT CORRECTLY ADJUSTED.
• The magazine contains an adjustable nail platform on which the
nail coil rest. The nail platform can be moved up and down across
various settings. To change nail platform height, screw centre post
until correct height is met.
• Place the coil of nails over the post of the platform in the magazine.
• Uncoil enough nails to reach the nose of the tool.
• Insert the first nail into the nose and the second nail between the
two rails of the feed pawl.
NOTE: Be careful not to deform the coil of nails during the loading
process. Otherwise, the nail guide door will not close and the nails
might not feed consistently.
• First close magazine cover, then close latch door. Make sure the
door latch is completely engaged.
Adjusting the Depth (Fig. D)
The driving depth of the fasteners can be set with the depth adjustment
wheel (5).
• Fasteners are not driven in deep enough: To increase the driving
depth, turn depth adjustment wheel to the left.
or
• Fasteners are driven in too deeply: To reduce the driving depth,
turn the depth adjustment wheel to the right.
• Test the new driving depth on a test workpiece. Repeat steps above
as required.
Operating the Tool
Test the driving depth in a sample piece of wood before using. See
section ADJUSTING THE DEPTH.
• Connect the tool to the air supply. Make sure the air pressure is in
correct range denoted in section of TECHNICAL DATA.
• Load fasteners as directed in the section called LOADING THE TOOL.
• Hold the body and press the drive guide to work surface, be sure
the tool is straight and then gently depress the trigger to drive
the fastener.
• Lift the tool off the work surface.
Firing Modes (Fig. E)
The tool has two driving modes:
Sequential fire:
• Choose the correct mode before firing by rotating the FIRING MODE
SELECTOR SWITCH (Fig. E).
• Put the nose on the working surface, lightly push the tool toward the
working surface until the safety bracket is depressed, then, depress
the trigger to drive the fasteners. Whilst maintaining contact with
the working surface, the tool will drive a fastener each time the
trigger is depressed.
Contact trip (Bump fire):
• Choose the correct mode before firing by rotating the FIRING MODE
SELECTOR SWITCH (Fig.E).
• First, depress the trigger, then, repeatedly impact the safety
bracket, the tool can repeatedly drive the fasteners. The tool will
drive one fastener when the safety bracket is impacted once.
NOTE: The air deflector (Fig. F) is directional and can be rotated through
360°.
Removing a Jammed Fastener
NOTE: You must remove any jammed fasteners before using the tool
any further. If you continue to try and fire a fastener while the tool is
jammed, you could cause damage to the mechanism.
• Disconnect tool from the compressed air system
• Remove any unused fasteners from the magazine, this should clear
the jammed fastener(s).
• If any fasteners remain stuck in the nose piece, place tool upside
down on a solid surface. Put a punch or small screwdriver into the
firing nozzle and carefully tap to release the jammed fastener.
• Close the nose plate and lock the latch before reconnecting to the
air system.
• Following the removal of a jammed fastener, always carefully test
the tool function before proceeding with any work. If fasteners
become jammed in the nose piece frequently, have the tool serviced
by a Tacwise Engineer or appointed service agent.
Regular Maintenance
• Frequent, but not excessive, lubrication is required for best
performance. Oil added through the airline connection will lubricate
internal parts. An automatic airline oiler is recommended but oil
may be added manually before every operation or after about 1 hour
of continuous use. Only a few drops of oil at a time are necessary.
Too much oil will collect inside the tool and be blown out during
the exhaust cycle. ONLY USE PNEUMATIC TOOL OIL. Do not use
detergent oil or additives, as these lubricants will cause accelerated
wear to the seal in the tool.
• Use a small amount of oil on all moving surface and pivots.
• Dirt and water in the air supply are major causes of pneumatic tool
wear. Use a filter/oiler for better performance and longer life. The
filter must have adequate flow capacity for the specific application.
Consult the manufacturer’s instructions for proper maintenance of
your filter.
• Keep tools clean for better and safer performance. Use
non-flammable cleaning solutions (CAUTION: Such solutions may
damage O-ring and other tool parts) only if necessary - DO NOT
SOAK.
FASTENING TOOLS FOR THE PROFESSIONAL
Air tool operator manual_FCN55V.indd 7Air tool operator manual_FCN55V.indd 7 20/10/2020 15:3620/10/2020 15:36

88
PROBLEM CAUSE OF PROBLEM SOLUTION
Air leaking at trigger area 1. O-ring in trigger valve is damaged.
2. Trigger valve head is damaged.
3. Trigger valve stem, seal or O-ring
is damaged.
1. Check and replace O-ring.
2. Check and replace trigger valve head.
3. Check and replace trigger valve stem,
seal or O-ring.
Air leaking between body and front plate Damaged piston O-ring or bumper Check and replace O-ring or bumper
Air leaking between body and cylinder cap 1. Screw loose.
2. Damaged seal.
1. Tighten screws.
2. Check and replace seal.
Blade driving fastener too deeply 1. Worn bumper.
2. Air pressure is too high.
1. Replace bumper.
2. Adjust the air pressure.
Runs slowly or has power loss 1. Insufficient oil.
2. Insufficient air supply.
3. Broken spring in cylinder cap.
4. Exhaust port in cylinder cap is blocked.
1. Lubricate as instructed.
2. Check air supply.
3. Replace spring.
4. Replace damaged internal parts.
Tool skips a fastener 1. Worn bumper or damaged spring (53).
2. Dirt in front plate.
3. Inadequate airflow to tool.
4. Worn or dry O-ring on piston.
5. Damaged O-ring on trigger valve.
6. Cylinder cap seal leaking.
1. Replace bumper or pusher spring.
2. Clean drive channel of front plate.
3. Check hose and compressor fittings.
4. Replace O-ring or lubricate.
5. Replace O-ring.
6. Replace seal.
Fasteners are jammed 1. Joint guider is worn.
2. Fasteners are wrong size or damaged.
3. Magazine or front plate screws are loose.
4. Blade in piston assembly is damaged.
1. Replace joint guider.
2. Use the recommended and undamaged
fasteners.
3. Tighten screws.
4. Replace piston assembly.
Tool will not drive down tight 1. Worn blade in piston assembly.
2. Lack of power.
3. Slow cycling and loss of power.
1. Replace piston assembly.
2. Adjust to adequate air pressure.
3. Check cylinder cap spring for broken
coils or reduced length. Check if exhaust
port of cylinder cap is restricted.
Trouble Shooting
Stop using the tool immediately if any of the following problems occur. Serious personal injury could occur. Any repairs or replacements must be
completed by a qualified person or an authorised service centre only.
Air tool operator manual_FCN55V.indd 8Air tool operator manual_FCN55V.indd 8 20/10/2020 15:3620/10/2020 15:36

9
FASTENING TOOLS FOR THE PROFESSIONAL
9
FASTENING TOOLS FOR THE PROFESSIONAL
Air tool operator manual_FCN55V.indd 9Air tool operator manual_FCN55V.indd 9 20/10/2020 15:3620/10/2020 15:36

10
Air tool operator manual_FCN55V.indd 10Air tool operator manual_FCN55V.indd 10 20/10/2020 15:3620/10/2020 15:36

11
FASTENING TOOLS FOR THE PROFESSIONAL
Air tool operator manual_FCN55V.indd 11Air tool operator manual_FCN55V.indd 11 20/10/2020 15:3620/10/2020 15:36

Tacwise Group Plc, England. www.tacwise.com 10/20
FASTENING TOOLS FOR THE PROFESSIONAL
Air tool operator manual_FCN55V.indd 28Air tool operator manual_FCN55V.indd 28 20/10/2020 15:3620/10/2020 15:36
