Taylor Made®
Towable Tubes
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-006236
Table of Contents
Introduction ............................................ 1
Safety ................................................... 2
Resources Required ................................... 3
Ination and Assembly ................................ 3
Taylor Made Accessories .............................. 4
Taylor Made Tow Booster .............................. 4
Maintenance ............................................ 4
Notes .................................................... 4
Taylor Made®
Towable Tubes
Installation and
Owner’s Manual
(For Aftermarket Applications)
Taylor MadeTaylor Made®® Towable Tubes and Accessories Towable Tubes and Accessories
LetterLetter Part #Part # DescriptionDescription
A2021136 877 Wild Wave 2 person tube PL2101
B2021136 878 Wild Wave 3 person tube PL2102
C2021136 879 Chaos 3 person tube PL2103
D2021136880 Chaos 4 person tube PL2104
E2021136881 Nebula Round Tube PL2105
F2021136882 Shock Wave Tube PL2106
G2021136883 Tidal Wave 2 person tube PL2107
H2021136884 Tidal Wave 3 person tube PL2108
I2021136885 Taylor Made Tow Booster PL2109
N/A 2021150 644 Taylor Made Tow Rope 2K PL2111
N/A 2021150 643 Taylor Made Tow Rope 4K PL2112
Introduction
The Taylor Made Towable Tubes are constructed of the
finest materials and assembled to rigid specifications.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
A
C
E
G
B
D
F
H
I

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.28.22
Taylor Made®
Towable Tubes
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-006236
Safety
Read and fully understand all instructions before operating
this product. Adhere to all safety labels. To reduce the risk
of injury or death, follow these guidelines:
• Carefully read this manual and follow the instructions.
• Do not use in shallow water or near shore, docks, pilings,
swimmers, other watercraft, or any other obstacles.
• Use only on water.
• Never attempt land or dock starts. This will increase your
risk of injury or death.
• Always wear a properly fitted life jacket (PFD) approved
by your country’s agency, USCG Type III, ISO, etc.
• The faster you ski or ride, the greater your risk of injury.
• Never make sharp turns that may cause a slingshot effect
on the skier/rider’s speed.
• Skier/Rider should be towed at an appropriate speed for
their ability level.
• Only use your tube with a responsible watercraft operator
who knows how to operate a watercraft properly.
• Take all reasonable precautions in the use and operation
of your tube and boat.
• Teach anyone using your tube how to attach it to the
rope, how to ride it, and how to maintain it.
• Use a single tube for not more than one rider and no
more than two riders for a double tube. Do not exceed
the manufacturer’s recommended number of riders for
your particular tube.
• If the tube is designed for more than one person, take
extra precaution to avoid colliding with one another.
• The stress on the rope is different from the stress on the
tube, and will vary with the weight of the passengers,
design, and surface area of the tube.
• Never strap or attach anyone to the tube or cover.
Never put your feet or hands through the strapping of the
towing system or handles. Never wedge your hands or
feet under the cover or between the cover and the tube.
TOWABLE WARNING - USE OF THIS PRODUCT
AND PARTICIPATION IN THE SPORT INVOLVES
INHERENT RISK OF INJURY OR DEATH.
• Do not use at speeds that exceed skills of the rider.
Boat speed should never exceed 20 mph for adults and
15 mph for children.
• This product should never be used by children except
under adult supervision.
• This is not a personal flotation device.
• Always wear a U.S. Coast Guard approved Type III
(PFD) Life Jacket.
• Never place wrists or feet through handles or towing
harness. Ensure tow rope is clear of all body parts
prior to or during use.
• Rider should keep feet out of the water.
• Watercraft driver is responsible for the ride since the
tube cannot be controlled by the rider. Always have a
person other than the driver as an observer.
• Watercraft driver should avoid excessive speed or
sharp turns which might cause the tube to flip over
abruptly resulting in serious injury to the rider.
• Do not tow in shallow water or near shore, docks,
pilings, swimmers or other boats.
• Do not exceed the manufacturers recommended
number of riders for your particular tube.
• Use a tow rope of at least 1500 lbs. average tensile
strength for pulling a single person, 2375 lbs. average
tensile strength for pulling two people, 3350 lbs.
average tensile strength for pulling three people and
4100 lbs. tensile strength for pulling four people on an
inflatable tube. The tow rope should be at least 50 feet
in length but do not exceed 65 feet.
• Do not operate watercraft or ride under the influence
of alcohol or drugs.

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.28.22
Taylor Made®
Towable Tubes
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-006236
Resources Required
• If applicable, a low-pressure, high volume inflater such
as a 12 volt inflater, foot or hand pump, or a local gas
station air hose.
Inflation and Assembly
1. If applicable, begin by inserting the tube into its cover
and aligning it as well as possible.
2. When there are multiple air chambers inflate the smaller
push-in valve(s) first and the large, screw-in (Boston) valve last.
Fig.1
Fig.2
Fig.3
A
A
A
• Never attempt jumps or dangerous tricks with your tube.
If more than one tube is being towed, avoid collisions
with other tubes.
• Scout the area before use to avoid any debris or
obstacles that might present a safety hazard.
• Be in good physical condition and be cautious in your use
of this or any other towable tube.
• Check the rope and connector for frays, cuts, sharp
edges, knots, or wear before each use. Discard rope if
any such condition exists or if rope appears to be worn.
Such conditions may lead to breaks.
• Do not use tow rope with elastic or bungee material to pull
skiers or riders. Such an addition can break or stretch which
may lead to injury of users or boat occupants.
• Rope is subject to deterioration when exposed to direct
sunlight. The life of the product will be extended when
stored away from sunlight.
• The tow rope should be replaced when signs of
deterioration appear, indicated by the existence of
discoloration, wearing, fraying or raveling.
• Do not add hardware or attachments that are not
otherwise supplied by the manufacturer.
3. Locate the valve (Fig.1A) on the main tube, under the
valve cover on the nylon cover.
4. To inflate your tube, use any high volume, low-pressure
inflator. Some of the Taylor Made Towable Tubes come
with large Boston valves that may be filled using either
the pumps referred to above or your local gas stations air
hose. When included, it can be found under the top cap
of the large screw-in valve. Inflate until it is firm and the
cover is wrinkle-free and taut. Close the valve completely.
Close the valve cover by aligning and pressing the hook
and loop fastener (Fig.2A) together.
5. A towable tube comes with either a “Quick Connect”
hook (Fig.3A) fitting a webbing strap or a section of rope
at the towing end of the tube. These are for connecting
your towline. Be sure the line is connected securely.
Check it regularly between rides to avoid the dangers
of a sudden disconnect.

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.28.22
Taylor Made®
Towable Tubes
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-006236
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a
revised version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
Maintenance
After use, clean debris from your tube by wiping it off or
spraying it with fresh water. This is especially important
if it has been used in salt water, or in an area where there
has been exposure to oil or gasoline.
Never use harsh detergents to clean the tube. If you need
more than water, use dish-washing detergent or a similarly
mild cleansing agent.
Dry your tube and store it DEFLATED, in a cool, dry area.
Storage in a very cold area could result in cracking of the
vinyl tubes.
Taylor Made Accessories
Part #Part # Product NameProduct Name Capacity / DescriptionCapacity / Description Key FeaturesKey Features
2021136885 Taylor Made Tow
Booster PL2109
Tow Capacity - For towables that have up to a 4 rider
maximum capacity, Adjustable Line Lengths - 50’,
55’, 60’.Heavy-Gauge PVC bladder
Keeps the rope from dragging in
the water to enhance the tube’s
performance on turns and slides
2021150 644 Taylor Made Tow
Rope 2K PL2111
Tow Rope, Max. Total Rider Weight - 340 lbs or 2
riders, Line Length - 60’ Average Break Strength - 2,375 lbs
2021150 643 Taylor Made Tow
Rope 4K PL2112
Tow Rope, Max. Total Rider Weight - 680 lbs or 4
riders, Line Length - 60’ Average Break Strength - 4,100 lbs
Taylor Made Tow Booster
The Taylor Made Tow Booster (Fig.4B) keeps the tow rope
out of the water while towing, reducing drag, rope spray,
and submarining. It also lowers stress on tubes & covers,
allowing your towables to last. Attach the green rope
(Fig.4A) to a fitting of ski eyelet on the center of the stern
and attach the orange rope (Fig.4C) to the towable tube.
Notes
Fig.4
A
C
B
