Taylor 9523 User manual

Care and Precautions
1.Always read instructions thoroughly to ensure that you have the full benefit of all the unit's features.
2. Use extreme caution when operating the laser. DO NOT look directly into the laser or point the laser toward
anyone’s eyes. Permanent eye damage may result. Use extreme caution while operating the laser. Keep out of reach
of all children.
3. DO NOT immerse unit in water, as doing so will cause damage to internal components and void the warranty. If
you spill liquid on it, dry it immediately with a soft, lint-free cloth. The unit is not dishwasher safe. Damage will void
warranty.
4. DO NOT clean the unit with an abrasive or corrosive material. This may scratch the plastic parts and corrode the
electronic circuits.
5. DO NOT subject the units to excessive force, shock, dust, temperature or humidity.This may result in malfunction,
shorter electronic life span, damaged battery and distorted parts.
6. DO NOT operate or store the unit in high temperature or humidity conditions. The heat or moisture may interfere
with the unit’s internal components. Store the unit at temperatures between -4~149°F (–20 to +65°C).
7. DO NOT tamper with the unit's internal components. Doing so will invalidate the warranty on the unit and may
cause damage. The unit contains no user-serviceable parts.
8. This unit operates on 2 AAAbatteries. Do not dispose of this product or batteries in fire, as batteries inside this
product may explode or leak.
9. Due to continuous product improvements, illustrations may differ from the actual product.
1 Year Limited Warranty
Taylor® warrants this product to be free from defects in material or workmanship for one (1) year for the original
purchaser from date of original purchase. It does not cover damages or wear resulting from accident, misuse, abuse,
commercial use, or unauthorized adjustment and/or repair.
If service is required, do not return to distributor. For service, call between 7:30 AM and 4:30 PM, Mountain Standard
Time, Monday through Friday.To assist us in serving you, please have the model number and date of purchase
available. Should this item require service (or replacement at our option) while under warranty, please pack the item
carefully and return it prepaid, along with receipt showing date of purchase and a note explaining reason for return
to:
Taylor Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001 USA
Customer Service Phone: [phone]
Customer Service Fax: [phone]
www.taylorusa.com
There are no express warranties except as listed above. This warranty gives you specific legal rights, and you may
have other rights which vary from state to state.
©2011 Taylor Precision Products and its affiliated companies, all rights reserved. Taylor® and Leading the Way in
Accuracy® are registered trademarks of Taylor Precision Products and its affiliated companies. All rights reserved.
Made to our exact specifications in China.
9523 8.11
Model 9523
Instruction Manual

Taylor® 9523ThermometerInstructions
Thank you for purchasing a Taylor® non-contact infrared thermometer. Please read this instruction manual carefully
before use. Keep these instructions handy for future reference.
Please remember to keep the unit away from children and do not use it for safety related applications.
Instructions
FEATURES:
oF or oC switchable Press the “°C/°F” key to switch between oF and oC temperature scales.
Backlight LCD Backlight: always on while the unit is on.
Laser
To enable the laser, press the “ ” button while the unit is on. The “ ” icon appears on the
LCD, indicating the laser is active. The laser sight will then operate when the Measurement
button is pressed. To disable the laser, press the “ ” button while the unit is on.
AutoOff The unit will automatically turn off after 15 seconds of non-use to conserve battery power.
Scan/Hold
When the Measurement button is pressed, the unit will scan for surface temperatures and
update the reading on the LCD screen. When the Measurement button is released, the screen
will hold the last reading. The maximum temperature reading appears in the bottom of the
screen. (The maximum temperature reading will reset after each use.)
EMC/RFI
Readings may be affected if the unit is operated within a radio frequency electromagnetic field strength of
approximately 3 volts per meter, but the performance of the instrument will not be permanently affected.
CAUTION
1. WHEN THE DEVICE IS IN USE, DO NOT LOOK DIRECTLY INTO THE LASER BEAM, OR POINT THE LASER
TOWARDS ANYONE ELSE’S EYES, AS PERMANENT EYE DAMAGE MAYRESULT.
2. USE EXTREME CAUTION WHEN OPERATING THE LASER.
3. NEVER POINT THE DEVICE TOWARDS ANYONE’S EYES.
4. KEEP OUT OF REACH OF ALL CHILDREN.
STORAGE & CLEANING
The sensor lens is the most delicate part of the thermometer. The lens should be kept clean at all times. Take care
when cleaning the lens, using only a soft cloth or cotton swab with water or medical alcohol, and allow the lens to
fully dry before using the unit. Do not submerge any part of the thermometer. The thermometer should be stored at
room temperature between -4~140°F (–20 to +60°C).
LOW BATTERY INDICATIOR:
When the ‘Low Battery’ icon indicates the battery is low, the batteries should be replaced immediately with 2
AAAbatteries. Please note: It is important to turn the instrument off before replacing the batteries, otherwise the
thermometer may malfunction. Dispose of used batteries properly and keep away from children. Always
replace both batteries at the same time; do not combine old and new batteries. Do not mix Alkaline, carbon-zinc
(standard) or Nickel-Cadmium (rechargeable) batteries. Remove the batteries if the unit will not be used for a
long period of time.
SPECIFICATIONS
Measurement Range -49 to +752oF (-45 to +400oC)
Operating Range 32 to 122°F (0 to 50°C)
Accuracy (-49 to +32°F / -45 to 0°C range) +/- 1.8oF+ (.10 x (reading-32))°F
+/- 1°C + (.10 x reading)°C
Accuracy (+32 to +149°F / 0 to +65°C range) +/- 1.8°F (+/-1°C)
Accuracy (above +149°F / +65°C range) +/- 1.5% of reading
Emissivity 0.95 fixed
Resolution (-9.9~199.9°C) 0.1°F / 0.1°C
Response Time (90%) 0.5 second
Distance:Spot 6:1
Battery Life Approximately 16 hours
Dimensions 7.35×1.72×3.37 inches (186.8 x 43.6 x 85.7 mm)
Weight 0.37 lb (169 g) including batteries (2 AAA)
1. Simply aim the thermometer at the target with the Infrared Lens and press the
Measurement button to display the surface temperature.
2. The Distance:Spot is 6:1. Please make sure the target area is within the field
of view.

Taylor® 9523ThermometerInstructions
Thank you for purchasing a Taylor® non-contact infrared thermometer. Please read this instruction manual carefully
before use. Keep these instructions handy for future reference.
Please remember to keep the unit away from children and do not use it for safety related applications.
Instructions
FEATURES:
oF or oC switchable Press the “°C/°F” key to switch between oF and oC temperature scales.
Backlight LCD Backlight: always on while the unit is on.
Laser
To enable the laser, press the “ ” button while the unit is on. The “ ” icon appears on the
LCD, indicating the laser is active. The laser sight will then operate when the Measurement
button is pressed. To disable the laser, press the “ ” button while the unit is on.
AutoOff The unit will automatically turn off after 15 seconds of non-use to conserve battery power.
Scan/Hold
When the Measurement button is pressed, the unit will scan for surface temperatures and
update the reading on the LCD screen. When the Measurement button is released, the screen
will hold the last reading. The maximum temperature reading appears in the bottom of the
screen. (The maximum temperature reading will reset after each use.)
EMC/RFI
Readings may be affected if the unit is operated within a radio frequency electromagnetic field strength of
approximately 3 volts per meter, but the performance of the instrument will not be permanently affected.
CAUTION
1. WHEN THE DEVICE IS IN USE, DO NOT LOOK DIRECTLY INTO THE LASER BEAM, OR POINT THE LASER
TOWARDS ANYONE ELSE’S EYES, AS PERMANENT EYE DAMAGE MAYRESULT.
2. USE EXTREME CAUTION WHEN OPERATING THE LASER.
3. NEVER POINT THE DEVICE TOWARDS ANYONE’S EYES.
4. KEEP OUT OF REACH OF ALL CHILDREN.
STORAGE & CLEANING
The sensor lens is the most delicate part of the thermometer. The lens should be kept clean at all times. Take care
when cleaning the lens, using only a soft cloth or cotton swab with water or medical alcohol, and allow the lens to
fully dry before using the unit. Do not submerge any part of the thermometer. The thermometer should be stored at
room temperature between -4~140°F (–20 to +60°C).
LOW BATTERY INDICATIOR:
When the ‘Low Battery’ icon indicates the battery is low, the batteries should be replaced immediately with 2
AAAbatteries. Please note: It is important to turn the instrument off before replacing the batteries, otherwise the
thermometer may malfunction. Dispose of used batteries properly and keep away from children. Always
replace both batteries at the same time; do not combine old and new batteries. Do not mix Alkaline, carbon-zinc
(standard) or Nickel-Cadmium (rechargeable) batteries. Remove the batteries if the unit will not be used for a
long period of time.
SPECIFICATIONS
Measurement Range -49 to +752oF (-45 to +400oC)
Operating Range 32 to 122°F (0 to 50°C)
Accuracy (-49 to +32°F / -45 to 0°C range) +/- 1.8oF+ (.10 x (reading-32))°F
+/- 1°C + (.10 x reading)°C
Accuracy (+32 to +149°F / 0 to +65°C range) +/- 1.8°F (+/-1°C)
Accuracy (above +149°F / +65°C range) +/- 1.5% of reading
Emissivity 0.95 fixed
Resolution (-9.9~199.9°C) 0.1°F / 0.1°C
Response Time (90%) 0.5 second
Distance:Spot 6:1
Battery Life Approximately 16 hours
Dimensions 7.35×1.72×3.37 inches (186.8 x 43.6 x 85.7 mm)
Weight 0.37 lb (169 g) including batteries (2 AAA)
1. Simply aim the thermometer at the target with the Infrared Lens and press the
Measurement button to display the surface temperature.
2. The Distance:Spot is 6:1. Please make sure the target area is within the field
of view.

Care and Precautions
1.Always read instructions thoroughly to ensure that you have the full benefit of all the unit's features.
2. Use extreme caution when operating the laser. DO NOT look directly into the laser or point the laser toward
anyone’s eyes. Permanent eye damage may result. Use extreme caution while operating the laser. Keep out of reach
of all children.
3. DO NOT immerse unit in water, as doing so will cause damage to internal components and void the warranty. If
you spill liquid on it, dry it immediately with a soft, lint-free cloth. The unit is not dishwasher safe. Damage will void
warranty.
4. DO NOT clean the unit with an abrasive or corrosive material. This may scratch the plastic parts and corrode the
electronic circuits.
5. DO NOT subject the units to excessive force, shock, dust, temperature or humidity.This may result in malfunction,
shorter electronic life span, damaged battery and distorted parts.
6. DO NOT operate or store the unit in high temperature or humidity conditions. The heat or moisture may interfere
with the unit’s internal components. Store the unit at temperatures between -4~149°F (–20 to +65°C).
7. DO NOT tamper with the unit's internal components. Doing so will invalidate the warranty on the unit and may
cause damage. The unit contains no user-serviceable parts.
8. This unit operates on 2 AAAbatteries. Do not dispose of this product or batteries in fire, as batteries inside this
product may explode or leak.
9. Due to continuous product improvements, illustrations may differ from the actual product.
1 Year Limited Warranty
Taylor® warrants this product to be free from defects in material or workmanship for one (1) year for the original
purchaser from date of original purchase. It does not cover damages or wear resulting from accident, misuse, abuse,
commercial use, or unauthorized adjustment and/or repair.
If service is required, do not return to distributor. For service, call between 7:30 AM and 4:30 PM, Mountain Standard
Time, Monday through Friday.To assist us in serving you, please have the model number and date of purchase
available. Should this item require service (or replacement at our option) while under warranty, please pack the item
carefully and return it prepaid, along with receipt showing date of purchase and a note explaining reason for return
to:
Taylor Precision Products
2220 Entrada Del Sol, Suite A
Las Cruces, New Mexico 88001 USA
Customer Service Phone: [phone]
Customer Service Fax: [phone]
www.taylorusa.com
There are no express warranties except as listed above. This warranty gives you specific legal rights, and you may
have other rights which vary from state to state.
©2011 Taylor Precision Products and its affiliated companies, all rights reserved. Taylor® and Leading the Way in
Accuracy® are registered trademarks of Taylor Precision Products and its affiliated companies. All rights reserved.
Made to our exact specifications in China.
9523 8.11
Model 9523
Instruction Manual
