teca AHP-250FF User manual

ProductInformationPacket
ModelAHP-250XE
SolidStateAirConditioner
Nema-4,ReversePolaritycapable,24VDC
Part#0-L095-5-000
Thankyouforyourpurchase.Informationhasbeenenclosedregardingthe
installation,specifications,andwiringofyoursolid-stateassembly.
Pleasereadandfollowallinstructionscarefullybeforeinstallation.Onlyqualified
techniciansshouldinstallthisequipment.
Ifyouhaveanyquestionsregardingyourequipment,pleasedonothesitateto
callusat773-342-4900,andwewillbehappytoassistyou.Weareopenfrom
8:00am-4:30pmCentralTime.
Includedinthispacketyouwillfind:
InstallationNotesforAirConditioners
ProductLiteratureandSpecifications
AssemblyDrawing#SK140313
WiringDrawing#SK140643
OptionalWiringDiagram#SK140644
InstallationDrawing#SK140314
WarrantyInformation

ImportantInstallationNotesforAir
Seal
Ambient
Air
Path
Enclosure
InternalAir
Path
MountingStyles:
Vertical(Side/Front/Back)Mounting:
CondensateRemovalSystem:
TopMounting:
Maintenance:
Cautions:
Notesoncondensation:
Both‘thrumount’and‘flushmount’unitscanbe
positionedinanyorientationandonanyenclosuresurface.Itisimportant
toconsiderinteriorairflowpatternswhendeterminingthemounting
location.Alsoofimportanceisanunrestrictedflowofambientairthru
thehotsideheatexchanger.Easeofaccessandinspectionmust
beconsideredforthoseapplicationsinparticularlysevere
environmentswhichmayrequireoccasionalmaintenance.
Verticalmountingreferstotheverticaldirectionofthecold
sideorinteriorfinsandisrecommendedforapplicationswith
highhumidity,poorandincompletecabinetsealsorany
conditionwhichmaycausethecoldsidefinstobemaintained
attemperaturesbelowthedewpointforlongperiodsoftime
allowingfortheformationofcondensation.Theverticalfin
directionprovidesadrippathwhereuponcondensationcanbe
collectedviaamoistureremovalsystem(standardonFHP-
units)oradrippanpositionedbelowthecoldsidefins.Drippansare
optionalforthrumountunits.
AllFHP-SeriesandAHP-1400airconditionerscontainabuilt-incondensateremovalsystem.Thecondensatekit
consistsofaantifungalspongewithacondensatewick.PVCtubingisalsoprovidedfordrainage.Drippansare
optionalforthrumountunitswhichmustbeevaluatedonanindividualbasis.Equationsdefiningarelationshipbetween
thecoldsidefinandenclosuretemperaturesareprovidedtoassistintheevaluation.
Thoughoftentheeasiestlocationtomountitisoftenthemostdifficulttoprotectfromcondensationinthisorientation
duetothefinorientation,gravityandanysusceptiblecomponentsbelow.Ifadrippanisemployedbytheenduseruse
cautiontoplacethepanfarenoughawayfromtheinternalfantominimizetherestrictionofairflow.Thepanshould
coverthefinendsaswellasthefanarea.Whenthereisachoice,theverticalorientationispreferredbymost
users.
Sincethetechnologyissolid-state,therearenofilters,compressors,orfluorocarbonstomaintain.Theonlymoving
partsarethefans.Itisrecommendedforharshordirtyenvironmentsthattheheatsinksbecleanedfromtimeto
time.ThiscanbeaccomplishedbydirectingcompressedairovertheexternalfinsoronNEMA4versionsbyhosing
theunitdown.Thiswillincreasetheoveralllifeandperformanceofthesystem.
Takecarewhenmountingnottodamagethesealbetweenthehotandcoldsidesinks.Donotattempttomountaunit
toawarpedsurfaceortrytomaketheunitsmountingsurfaceconformtoanunflatsurface.Donotpinchordamage
anyleadswhenmounting.Donotovertightenanyinstallationscrew,usereasonableforce.Alwaysmountwithany
condensatedraindown.Donotcompressthecoldsidebetweenthehotsideandanyothersurface.Donotobstruct
theairflowoneitherside.Whenmountingconsiderthenaturalairflowsoftheenclosure.Connectpoweronlyafterthe
installationiscomplete.
Condensationoccursat thecoldsidefinswhenthesurfacetemperaturegoesbelowthedewpoint.Toreduceor
removecondensate,considerthefollowing:
•RegulatetheFinTemperatureabovetheDewpoint.
•KeepEnclosureClosedandSealedfromOutsideHumidity.
•UseDesiccant(MoistureabsorbingGranules.)
•EmployCondensateRemovalSystem/DripPans.
Ifyouhaveanyquestionsregardingyourinstallation,Pleasefeelfreetocontactourtechnicaldepartmentforassistance
at773-342-4900.

TECA 1-888-TECA-USA (832-2872) www.teca-usa.com
AHP-250 Air Conditioner
Air Cooled 12 VDC, 24 VDC
Through Mounted 129 BTU/HR
Nema-12, 4, 4X
FEATURES
• Compact (only 6” X 4.75” X 6.6”)
• Mounts and operates in any orientation:
horizontal, vertical, etc.
• Low vibration and noise
• No moving parts except fans
• Environmentally safe
• No compressor, fluorocarbons or filters
• Heat via reverse polarity
• Virtually maintenance-free operation
• Weight 4.4 LBS.
Operating Ambient -40/+70 °C
Operating Enclosure -10/+60 °C
OPERATING TEMPERATURES
INCLUDES
• Mounting gasket
• Mounting hardware
• Power input leads
Cooling (Traditional) 129 BTU/HR
Cooling (Din 3168) 38 WATTS
Cooling COP (at L35 L35) 0.53
PERFORMANCE RATINGS
OPTIONS
• Temperature Control TC-6F DC for cool only
• Temperature Control TC-3F DC for heat/cool
• Adaptable for TC-3400
• Stainless steel exterior housing
CONFIGURATIONS
MODEL PART NUMBER NOTES HEAT VOLTAGE CURRENT ENVIRONMENT
Watts VDC AMPS
AHP-250FF 0-L094-1-000 Industrial Fans 100 12 6 NEMA-12, IP 52
AHP-250FF 0-L095-1-000 Industrial Fans 100 24 3 NEMA-12, IP 52
AHP-250XE 0-L094-5-000 Sealed Hot Side Fan 100 12 6 NEMA-4, IP 56
AHP-250XE 0-L095-5-000 Sealed Hot Side Fan 100 24 3 NEMA-4, IP 56
AHP-250X 0-L094-3-000 Mil. Grade Hot Side Fan 100 12 6 NEMA-4X, IP 56
AHP-250X 0-L095-3-000 Mil. Grade Hot Side Fan 100 24 3 NEMA-4X, IP 56
Heat function via reverse polarity (controller dependent)
AC.qxp 4/22/2014 3:09 PM Page 78

www.teca-eu.com 1-888-TECA-USA (832-2872) TECA
PERFORMANCE CURVE
Equation of Line: y=⌬T(°C) x=Capacity (Watts)
Ambient Temp 35°C 50°C
Enclosure Air y=1.35x-51 y=1.34x-52
Cold Sink y=1.15x-51.7 y=1.13x-52.6
AHP-250
Air Conditioner - Air Cooled
MOUNTING STYLE
Through Mounted
ENVIRONMENTS SERVED
NEMA-12 IP 52
NEMA-4,4X IP 56
RATING (TRADITIONAL)
129 BTU/hr @ 0 °F ⌬T
162 BTU/hr @ +20 °F ⌬T
RATING (DIN 3168)
38 Watts L35 L35
28 Watts L35 L50
DIMENSIONS
Air Flow Pattern
AC.qxp 4/22/2014 3:09 PM Page 79

LIMITEDWARRANTY
Intheeventadefectinmaterialorworkmanshipisdiscoveredinanyof
TECA’sproductswithinoneyearafterthedatetheyaredeliveredtoBuyer,
:(a)TECAisnotifiedofthedefectinwritingbycertifiedmailwithin14
daysofthedateofdiscovery;(b)TECAmaytheneither,atitssolediscretion,
inspecttheproductatBuyer’slocation,orrequirethattheproductbemade
availableatBuyer’sexpenseatTECA’spremisesforTECA’sinspectionwithin
14daysofthedateofnotification;and(c)theproductsaredefectiveandthe
defectsresultfromfaultymaterialsand/orworkmanshipandnotinanyway
fromaccident,misuse,misapplication,mishandling,modification,oralteration
bytheBuyerortheshipper,TECAshall,atitssoleoption,repairor
exchangedefectiveproductsfreeofchargetoBuyer,orcredittobuyerthe
priceofthedefectiveproducts.ALLOTHERWARRANTIES,EXPRESSOR
IMPLIED,AREEXCLUDED,INCLUDINGBUTNOTLIMITEDTOTHE
IMPLIEDWARRANTIESOFMERCHANTABILITYANDFITNESSFORA
PARTICULARPURPOSE.INNOEVENTSHALLTECABELIABLEFOR
ANYCLAIMBASEDUPONBREACHOFEXPRESSORIMPLIED
WARRANTYORANYOTHERDAMAGESWHETHERSPECIAL,INDIRECT,
INCIDENTAL,CONSEQUENTIAL,LOSTPROFITS,BUSINESS
INTERRUPTION,ORLOSSOFBUSINESSORCUSTOMER
RELATIONSHIPS.
Inordertoreturnmerchandiseforanyreason(repair,replacement,orcredit)
areturnauthorizationnumbermustbeissuedbyTECA.Newmerchandise
maynotbereturnedforcreditbeyond60daysfromshipment.Chargesfor
incidentalorotherdamagesmayalsobemade.Allreturnedgoodsmustbe
sentfreightprepaid.Arestockingchargeof15%willapply.Onspecial
equipmentandcustommodifiedequipmentorders,additionalincremental
cancellationchargesmaybemade.
andif
then
RETURNEDGOODS,RESTOCKINGCHARGES
