MusicMan® * User Manual
Bluetooth In-Ear Headset & Charge BT–X25
USB car charger with integrated and removable Bluetooth
In-Ear earplug for handsfree calls
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares
that this device, to which this user manual belongs, complies with the essential
requirements of the standards referred to the Directive RED 2014/53/EU. The
Declaration of Conformity you find here: www.technaxx.de/ (in bar at the
bottom “Konformitätserklärung”). Before using the device the first time, read
the user manual carefully.
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
not used!
Turn OFF nearby Bluetooth devices to avoid signal interference!
WARNING: DO NOT TURN THE VOLUME TOO HIGH – HEARING LOSS
MIGHT BE THE RESULT!
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: sup[email protected]
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Warranty 2 years
Features
One mini silicone earphone with handsfree function via built-in
microphone Transfer of phone calls via Bluetooth & automatic call
acceptance Music playback via Bluetooth from mobil phone
Charger with 2 USB ports for the cigarette lighter socket (5V/2.1A
max; power input DC 12~24V) Charging of iPhone/iPod/iPad,
tablets, navigation systems & other devices 1-button operation
LED status indicator for connection & charging Over current and
over voltage protection

Technical Specification
Bluetooth In-Ear Headset (plug into one of your ears)
Bluetooth: V4.0, ~5m transmitting distance / Protocols: AVRCP, HFP,
A2DP / Frequency band 2.4GHz / Radiated transmission power max.
2.5mW
Built-in rechargeable 30mAh lithium polymer battery 3.7V
Charging ~1.5 hours / playing ~2.5 hours / standby ~30–40 hours
Material One silicone MONO earphone
Weight / Dimensions 7g / (L) 2.8 x (W) 2.2 x (H) 2.6cm
Car Charger (plug into a cigarette lighter socket of a vehicle)
Power input DC 12V~24V (cigarette lighter socket)
USB power output 1 5V / 1A (max. 1.1A)
USB power output 2 5V / 2.1A (max.2.1A)
Weight / Dimensions 35g / (L) 10.0 x (W) 3.2 x (H) 3.2cm
Package Contents: Bluetooth In-Ear Headset & Charge BT-X25, User
Manual
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution (use a clean drapery).
Avoid using rough, coarse-grained materials or
solvents/aggressive cleaner. Wipe the cleaned device
accurately. Distributor: Technaxx Deutschland GmbH
& Co.KG, Kruppstr. 105, 60388 Frankfurt a.M.,
Germany

Product view
①
Power on/off * Play/Pause * Handsfree
Press key 3 sec. to power on/off In-Ear Headset. To enter pairing
mode, keep pressing the key after In-Ear Headset is turned on.
Short press to receive or end calls, play or pause music. Press
key briefly 2x to dial last outgoing phone number. When In-Ear
Headset is under charging mode, take it from the charging adapter to
receive or reject a phone call.
②
In-Ear Headset LED indicator
Under pairing mode, RED and BLUE LED flashing
alternately.
The BLUE LED turns solid after successful pairing. In charging
mode, RED LED lights on. When it is fully charged, RED LED turns
off. When the vehicle starts, In-Ear Headset starts pairing
automatically. When the vehicle stops, In-Ear Headset turns off
automatically within 5 minutes if it is not paired with another device.
③
Microphone ④ One silicone MONO earphone

⑤
USB charging connectors: (1) 5V / 1A & (2) 5V / 2.1A
⑥
Cathode connector ⑦ Anode connector
Charging
Before first use, fully load the battery of the BT-X25 by plugging the
device into the included car charger. The built-in magnet holds the
In-Ear Headset in place. The RED LED shines bright while charging.
When the In-Ear Headset is fully charged, the RED LED turns off.
Bluetooth pairing
Turn on the BT-X25 by pressing the ①On/Off button. BLUE and
RED indicator are slowly flashing alternately. To enter Bluetooth
pairing mode, keep pressing the button after the BT-X25 is turned on.
The Bluetooth pairing mode is shown by the quickly flashing BLUE
and RED LED.
If the In-Ear Headset fails to connect and search the device
name ”Technaxx BT-X25” on your Bluetooth device. After pairing
successfully, the BLUE LED lights solid. When the In-Ear Headset is
connected with your Smartphone and there is an incoming call, you
can press the ①On/Off button once to receive calls. To end the
calls press the ①On/Off button again.

Hint
When the vehicle is running and you have previously connected the
BT-X25 with your mobile phone, it will start automatically the
pairing process with your mobile phone. When the BT-X25 is not
paired to a device within 5 minutes, it automatically turns off.
Operation
Connect the included car charger with lighter connector of the
vehicle, it charges the In-Ear Headset. In the meantime, connect the
USB charging cable with one of the two USB charging connectors
⑤to get other devices charged, such as Smartphone, tablet PC,
headphone or speaker etc.
Warnings
Make sure that voltage of device to be charged is lower than 5V.
Otherwise it may destroy the device. Do not remove any cover to
avoid the risk of an electric shock or other damages. Do not
attempt to disassemble the device, it may result in short-circuit or
even damage. Do not drop or shake the device, it may break
internal circuit boards or mechanics. Keep the device in dry and
ventilated environment. Avoid high humidity and high temperature.
Do not install the device near any heat source, such as radiators, or
other equipment that produces heat. Do not expose this unit to
rain or moisture to reduce the risk of fire or electrical shock. The
device should not be exposed to dripping or splashing. Do not place
any objects filled with liquids shall be placed on or near by the
device. Keep the device away from little children.
