TECO TWS-TSO24HFEC User manual

Thank you for selecting a TECO quality Air Conditioner. To ensure satisfactory
operation for many years to come, this User’s Manual should be read carefully before
using your air conditioner. After reading, store it in a safe place. Please refer to this
manual for questions on use or in the event that any irregularities occur.
TWS-TSO24HFEC
This product is intended to be used to cool, heat or dehumidify the room air (excluding
laundry and bathrooms) to maintain conditions suitable for human comfort and must
be used for its intended purpose only.
Fixed Speed Split Systems

CONTENTS
FOREWORD
SAFETY PRECAUTIONS
OPERATING INSTRUCTIONS
CARE AND MAINTENANCE
TROUBLESHOOTING TIPS
Foreword....................................................................................................................... 2
Warning ..................................................................................................................................3
Caution ...................................................................................................................................4
Parts names ............................................................................................................................5
Operating temperature.............................................................................................................6
Manual operation ....................................................................................................................6
Care and maintenance ..........................................................................................................10
System code...........................................................................................................................12
The information contained in this material is provided by Teco Australia Pty Ltd in good faith. The
information supplied to our knowledge is correct; however is subject to change without notice, therefore
before relying on the material in any important matter, users should carefully evaluate its accuracy,
completeness and relevance for their purpose. It is not intended as a substitute for consulting the
relevant legislation or for obtaining appropriate professional advice relevant to your particular
circumstances. Teco Australia Pty Ltd cannot accept responsibility or liability for any loss, damage, cost
or expense you might incur as a result of the use of or reliance on information provided. It is not
intended to be, and should not be relied upon as the ultimate and/or complete source of information.
Images are for illustrative purposes only.
REMOTE CONTROLLER
Remote controller ....................................................................................................................7
Functions..................................................................................................................................7
Replacement of batteries .........................................................................................................9
Normal function of the air conditioner......................................................................................11
Troubleshooting guide.............................................................................................................13
REPAIR, SERVICE & WARRANTY............................................................................Back Cover
1

This air conditioner must be installed properly by qualified technicians in accordance with the
installation instructions provided with the unit.
The system must be installed in accordance with the current Australian and New Zealand
Refrigerant Handling Code of Practice.
Contact an authorised service technician for repair or maintenance of this unit.
Young children should be supervised to ensure that they do not play with the
air conditioner.
If the power cord is to be replaced, replacement work shall be performed by
Never insert fingers, pencils or any other object into the product to avoid accidents.
authorised personnel only.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they are supervised or instructed concerning use of the appliance by a
person responsible for their safety.
CAUTION
FOREWORD
This symbol stands for the items
should be forbidden.!This symbol stands for the items should be followed
The products in this manual may vary according to different models, some models have
a display panel and some models do not, the position and shape of the display panels
may vary.
Do not dispose this product as unsorted municipal waste.
Collection of such waste separately for special treatment
is necessary.
2

SAFETY PRECAUTIONS
To prevent injury to the user or other people and property damage, the following instructions
must be followed. Incorrect operation may cause harm or damage. The seriousness is
classified by the following indications:
This symbol indicates the possibility of death or serious injury.
WARNING
CAUTION This symbol indicates the possibility of injury or damage to property.
Connect with the power
properly.
Do not modify power cord
length or share the outlet
with other appliances
Always ensure effective
earthing.
Disconnect the power if
strange sounds, smell, or
smoke comes from it.
Ventilate room before operating air
conditioner if there is a gas leakage
from another appliance.
Otherwise, it may cause electric
shock or fire due to excess heat
generation.
It may cause electric shock
or fire due to heat generation.
No earthing may cause
electric shock.
It may cause fire and
electric shock.
It may cause explosion, fire and burns.
It may cause electric shock or fire
due to heat generation.
It may cause electric shock.
It may cause failure of
machine or electric shock.
It contains contaminants and
could make you sick.
It may cause fire and
electric shock.
It may cause electric shock
or fire.
This could damage your
health.
No installation may cause
fire and electric shock.
It may cause electric shock.
It may cause an explosion or fire.
It may cause failure and
electric shock.
Do not operate or stop the
unit by switching on or off
the power.
Do not operate with wet
hands or in damp
environment.
Do not allow water to run
into electric parts.
Do not drink water drained
from air conditioner.
Do not use the power cord
close to heating appliances.
Do not damage or use an
unspecified power cord.
Do not direct airflow at
room occupants only.
Always install circuit
breaker and a dedicated
power circuit.
Do not open the unit
during operation.
Do not use the power cord near
flammable gas or combustibles, such
as gasoline, benzene, thinner, etc.
Do not disassemble or
modify unit.
!
!!
!
!
WARNING
Use the correctly rated
breaker or fuse.
There is risk of fire or
electric shock.
!
3

CAUTION
When the air filter is to be
removed, do not touch the
metal parts of the unit.
It may cause an injury.
Do not clean unit when
power is on as it may cause
fire and electric shock, it may
cause an injury.
Operation with windows
opened may cause wetting
of indoor and soaking of
household furniture.
When the unit is to be
cleaned, switch off, and turn
off the circuit breaker.
Stop operation and close
the window in storm or
hurricane.
Use caution when unpacking
and installing. Sharp edges
could cause injury.
Do not clean the air
conditioner with water.
Water may enter the unit and
degrade the insulation. It may
cause an electric shock.
This could injure the pet or
plant.
Do not put a pet or house
plant where it will be
exposed to direct air flow.
Ventilate the room well
when used together
with a stove, etc.
An oxygen shortage
may occur.
Do not use this air cond-
itioner to preserve preci-
sion devices, food, pets,
plants, and art objects.
It may cause deterioration
of quality, etc.
It may cause failure of
product or fire.
Do not use for
special purposes.
Turn off the main power
switch when not using
the unit for a long time.
If water enters the
unit, turn the unit off
and disconnect the
power, contact a
qualified service
technician.
!
!
!
!
!
It may cause failure of
appliance or accident.
Appearance may be
deteriorated due to change
of product color or
scratching of its surface.
Do not place obstacles
around air-inlets or inside
of air-outlet.
Do not use strong detergent
such as wax or thinner. Use
a soft cloth for cleaning.
If bracket is damaged, there
is concern of damage due to
falling of unit.
There is danger of fire or
electric shock.
Ensure that the installation bracket of
the outdoor appliance is not
damaged due to prolonged exposure.
Do not place heavy object on the
power cord and take care so that
the cord is not compressed.
Operation without filters
may cause failure.
Always insert the filters
securely. Clean filter
once every two weeks.
!
!
!
SAFETY PRECAUTIONS
4

Outdoor unit
Indoor unit
OPERATING INSTRUCTIONS
Front Panel
Louvre
Connecting Pipe
Connecting Cable
Stop Valve
Air Filter
Remote Holder
Remote Control
Display window
Run Indicator
Lights up during operation.
Timer Indicator
Lights up during Timer operation.
Temperature Indicator
Displays the temperature settings when the
air conditioner is operational.
Code Indicator
Displays system code.
(Please refer to page 12 for more info).
5
Parts names

Manual operation
Operating temperature
Mode
Temperature
Room temperature
Outdoor temperature
1. Optimum performance will be achieved within these operating temperatures. If air conditioner
is used outside of the above conditions, certain safety protection features might come into
operation and cause the unit to function abnormally.
2. If the air conditioner runs for a long time in cooling mode and the humidity is high (over
80%) , condensed water may drip out of the unit. Please sets the vertical air flow louver to its
maximum angle (vertically to the floor), and set HIGH fan mode.
NOTE:
Cooling operation Heating operation Drying operation
1. Open and lift the front panel up to an angle
until it remains fixed with a clicking sound.
For some models, please use suspension
bars to prop up the panel.
2. Locate the MANUAL CONTROL BUTTON
on the right hand side of the unit.
3. Press MANUAL CONTROL BUTTON once
to activate FORCED AUTO mode.
4. Press MANUAL CONTROL BUTTON again
to turn the unit off.
5. Close the panel firmly to its original position.
NOTE: The unit must be turned off before
operating the manual control button. If the
unit is operational, continue pressing the
manual control button until the unit is off.
17°C~32°C
0°C~30°C
10°C~32°C
Units are equipped with a switch to run emergency operation mode. It can be accessed by
opening the front panel. This switch is used for manual operation in case the remote controller
fails to work or maintenance necessary.
0°C~43°C 0°C~43°C
-7°C~30°C
Manual control
button
C A U T I O N: This switch is used for testing purposes only. Please do not use the function unless is absolutely
necessary. To restore the remote controller operation, use the remote controller directly.
6
OPERATING INSTRUCTIONS

LAMP button
Enable/disable indoor screen display
button
REMOTE CONTROLLER
Remote controller
7
1. ON/OFF button: This button is used to start or close operation of the machine.
2. MODE button: This button is used to change the operation mode: AUTO, COOL, DRY, HEAT or FAN.
3. + button: This button is used to increase the temperatures.
4. - button: This button is used to decrease the temperatures.
5. AIR FLOW button: This button is used to select the left or right air flow direction, when press the in flap will swing
or fix. (It just works on three-dimensional air-flow model).
Functions

REMOTE CONTROLLER
Functions
6. SWING button: This button is used to change the flap mode: natural flow, swing or fixed wind.
(It would be automatically set at fixed wind direction in DRY mode).
7. FAN SPEED button:
This button is used to set air rate you want. Low (display indicates ), Med (display indicates ),
Hi (display indicates ), Auto (display indicator flashing).
(It would be automatically set at low speed and unadjustable in DRY mode).
8. TIMER button: This button is used to set the ON or OFF timer
.
Set OFF timer: Set the time for the unit to turn off automatically.
• When the air conditioner is operating, press the TIMER button and the air conditioner will enter the
timed switch-off mode.
• Continually press the TIMER button to set the timer from 1 to 24 hours to switch off the air
conditioner. (The time indication sequence as follow: 1 - 2 - .... - 24 - cancel (no indication) - 1- 2 - ....
• After the desired time is set for the timed switch-off, the digits shown on the display screen will
decrease by 1 for every elapsed hour. The displayed digits indicate the remaining time prior to the
timed switch-off.
Set ON timer: Set the time for the unit to turn on automatically.
• When the air conditioner is in standby mode, press the TIMER button and the air conditioner will
enter the timed switch-on mode.
• Continually press the TIMER button to set the timer from 1 to 24 hours to switch off the air
conditioner. (The time indication sequence as follow: 1 - 2 - .... - 24 - cancel (no indication) - 1- 2 - ....
• After the desired time is set for the timed switch-on, the digits shown on the display screen will
decrease by 1 for every elapsed hour. The displayed digits indicate the remaining time prior to the
timed switch-on.
Press the TIMER button again after display 24 to delete the timed mode.
9. TURBO button: This button turn on or off the TURBO operation which increase the air rate to HIGH. (Only
in COOL or HEAT mode).
10. SLEEP button: This button is to set or cancel sleep function. When set the sleep function the room
temperature will be raised gradually by around 2°C higher than the setting under cooling mode after few
hours or dropped gradually around 5°C lower than the setting under heating mode when in sleep function
is selected. The fan speed will switch to LOW automatically, but can be change by press FAN SPEED
button.
11. CLEAN button: Only effective when the remote control is off. Press CLEAN button when remote if off will
switch on the unit with temperature set at 25°C cooling mode and high fan speed for 6 minutes.
12. LAMP button: This button to turn on or off display screen on the indoor unit.
13. HOLD button: Press HOLD button to lock or unlock remote control keyboard.
14. FOLLOW ME button:
Push this button to initiate the Follow Me function, the remote display actual temperature at its location.
The remote control will send this signal to the air conditioner every 3 minutes interval until the Follow Me
button is pressed again. The air conditioner will cancel the Follow Me feature automatically if it does not
receive the signal within any 7 minutes interval.
8

REMOTE CONTROLLER
Replacement of batteries
9

CARE AND MAINTENANCE
CareandMaintenance
Beforemainatenance
CAUTIONS
Aclothdampenedwithcoldwatermaybeused
ontheindoorunitifitisverydirty.Thenwipeit
withadrycloth.
Donotuseachemicallytreatedclothordusterto
cleantheunit.
Donotusebenzine,thinner,polishingpowder,or
similarsolventsforcleaning.Thesemaycause
theplasticsurfacetocrackordeform.
Neverusewaterhotterthan40C/104Ftoclean
thefrontpanel,itcouldcausedeformationof
discoloration.
Turnthesystemoffbeforecleaning.Toclean,wipewith
asoft,drycloth.Donotusebleachorabrasives.
NOTE:Powersupplymustbedisconnectdbefore
cleaningtheindoorunit.
1.Lifttheindoorunitpaneluptoanangleuntilit
stopswithaclickingsound.Forsomemodels,
pleaseusesuspensionbarstopropupthepanel.
2.Takeholdofthehandleoftheairfilterandliftit
upslightlytotakeitoutfromthefilterholder,
thenpullitdownwards.
3.RemovetheAIRFILTERfromtheindoorunit.
CleantheAIRFILTERoncetwoweeks.
CleantheAIRFILTERwithavacuum cleaner
orwater,thendryitupincoolplace.
Cleaning the unit
wipetheunit withasoft dryclothonly. Iftheunit is
verydirty, wipeitwithaclothsoaked inwarmwater.
Cleaning the airfilter
Acloggedairfilterreducesthecoolingefficiency of
thisunit. Pleasecleanthefilteronce every2weeks.
Filter Tabs
•Do not touch the metal parts of the unit when removing the filter. Injuries can occur when
handling sharp metal edges.
•Do not use water to clean inside the air conditioner. Exposure to water can destroy the
insulation, leading to possible electric shock.
•When cleaning the unit, first make sure that the power and circuit breaker are turned off.
•Do not wash air filter with hot water at more than 40°C /104°F. Shake off moisture
completely and dry it in the shade. Do not expose it directly to the sun, it may shrink.
Caution
10

The following events may occur during normal operation.
1.
Compressor protection
The compressor can't restart for 3-4 minutes after it stops.
Anti-cold air (Cooling and heating models only)
The unit is designed not to blow cold air on HEAT mode, when the indoor heat exchanger is in
one of the following three situations and the set temperature has not been reached.
A) When heating has just started.
B) Defrosting.
C) Low temperature heating.
The indoor or outdoor fan stop running when defrosting (Cooling and heating models only).
Defrosting (Cooling and heating models only)
Frost may be generated on the outdoor unit during heat cycle when outdoor temperature is low
and humidity is high resulting in lower heating efficiency of the air conditioner.
During this condition air conditioner will stop heating operation and start defrosting automatically.
The time to defrost may vary from 4 to 10 minutes according to the outdoor temperature and
the amount of frost built up on the outdoor unit.
2.
A white mist may generate due to a large temperature difference between air inlet and air outlet
on COOL mode in an indoor environment that has a high relative humidity.
A white mist may generate due to moisture generated from defrosting process when the air
conditioner restarts in HEAT mode operation after defrosting.
3.
You may hear a low hissing sound when the compressor is running or has just stopped running.
It is the sound of the refrigerant flowing or coming to a stop.
You can also hear a low "squeak" sound when the compressor is running or has just stopped
running. This is caused by heat expansion and cold contraction of the plastic parts in the unit
when the temperature is changing.
A noise may be heard due to louver restoring to its original position when power is turned on.
4.
5.
Protection of the air conditioner.
A white mist coming out from the indoor unit
Low noise of the air conditioner
6.
Dust is blown out from the indoor unit.
This is a normal condition when the air conditioner has not been used for a long time or during first
use of the unit.
A peculiar smell comes out from the indoor unit.
This is caused by the indoor unit giving off smells permeated from building material, from furniture,
or smoke.
The air conditioner turns to FAN only mode from COOL or HEAT (For cooling and
heating models only) mode.
When indoor temperature reaches the temperature setting on air conditioner, the compressor will
stop automatically, and the air conditioner turns to FAN only mode. The compressor will start again
when the indoor temperature rises on COOL mode or falls on HEAT mode (For cooling and heating
models only) to the set point.
Normal function of the air conditioner
11
TROUBLESHOOTING TIPS

7.
8.
10. Lightning or a wireless telephone
9.
Lightning or a wireless telephone operating nearby may cause the unit to malfunction.
Disconnect the unit’s power and then reconnect the unit’s power again. Push the on / off button
on the remote to restart operation.
Dripping water may generate on the surface of the indoor unit when cooling in a high
relatively humidity (relative humidity higher than 80%). Adjust the horizontal louver to
the maximum air outlet position and select HIGH fan speed.
Heating mode (For cooling and heating models only)
The air conditioner draws in heat from the outdoor unit and releases it via the indoor unit
during heating operation. When the outdoor temperature falls, heat drawn in by the air
conditioner decreases accordingly. At the same time, heat loading of the air conditioner
increases due to larger difference between indoor and outdoor temperature. If a
comfortable temperature can't be achieved by the air conditioner, we suggest you use a
supplementary heating device.
Auto-restart function
Power failure during operation will stop the unit completely.
For the unit without Auto-restart feature, when the power restores, the OPERATION indicator
on the indoor unit starts flashing. To restart the operation, push the ON/OFF button on the
remote controller. For the unit with Auto-restart feature, when the power restores, the unit
restarts automatically with all the previous settings preserved by the memory function.
TROUBLESHOOTING TIPS
System Code
If following system code appear on the indoor display. Please wait for about 10 minutes,
system may be recovered automatically, if not, disconnect the power and then connect it in
again. If the problem still exists, disconnect the power and contact the nearest customer
service center.
SYSTEM CODE Description
dF or Heating icon flash
Fan motor picture not running
E2
E3
E7
E1
E6
Defrost indication
Anti cold wind
Room temperature sensor error
Coil temperature sensor error
External feedback error
Outdoor tube temperature
sensor error
EEPROM Communication error
12

Malfunctions
Unit does not
start
Unit not cooling
or heating
(Cooling/ heating
models only)
room very well
while air flowing
out from the air
conditioner
Cause
Power cut
Unit may have become Unplugged.
Fuse may have blown.
Battery in Remote controller may
have been exhausted.
The time you have set with timer
is incorrect.
Wait for power to be restored.
Check that plug is securely in wall
receptacle.
Replace the fuse.
Replace the battery.
Wait or cancel timer setting.
Set temperature correctly. For
detailed method please refer to
"Using remote control" section.
Clean the air filter.
Close the doors or windows.
Clear obstructions away first, then
restart the unit.
Wait.
Inappropriate temperature
setting.
Air filter is blocked.
Doors or Windows are open.
Air inlet or outlet of indoor or
outdoor unit has been blocked.
Compressor 3 minutes
protection has been activated.
If the trouble has not been corrected, please contact a local dealer or the nearest customer
service center. Be sure to inform them of the detailed malfunctions and unit model number.
Notes: Do not attempt to repair the unit yourself.
Always consult an authorized service provider.
What should be done?
Troubleshooting guide
Fuse blows frequently or circuit breaker trips
frequently .
Other objects or water fall into the air conditioner.
Terrible odors are smelled or abnormal sounds
are heard.
Trouble
OPERATION (RUN) indicator or other
indicators continue flashing.
If one of the following code appears on the
display area : dF, E1,E2,E3.....
The unit may stop operation or
continue to run in a safety condition
(depending on models). Waiting for
about 10 minutes, the fault may be
recovered automatically, if not,
disconnect the power and then
connect it in again. If the problem
still exists, disconnect the power and
contact the nearest customer service
center.
Stop the air conditioner immediately,
disconnect the power and contact the
nearest customer service center.
TROUBLESHOOTING TIPS
13

Did you know?
TECO Australia’s product range also includes:
Top Load Clothes Washers
Front Load Clothes Washers
Twin Tub Clothes Washers
Auto Sensing Condenser and Vented Clothes Dryers
Refrigerators
Chest and Vertical Freezers
Bar Fridges
Dehumidiers
Televisions
Air Curtains and Air Conditioners
Visit www.teco.com.au for our full range.

REPAIRS, SERVICE & WARRANTY
It is hazardous for anyone installing, removing, altering, repairing, servicing
or testing of this appliance.
Only an Authorised Service Person can carry out servicing or repairs to
this appliance.
IF SERVICE IS REQUIRED:
If you have a problem, and the problem persists after you have made the
checks mentioned in this manual, contact:
TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST)
For warranty details please visit www.teco.com.au
Service Email: [email protected]
Spare Parts: [email protected]

www.teco.com.au
IBG-v4
