SPLIT-TYPE ROOM AIR CONDITIONER
Owner’s Manual
Models:
TWS-TSO26HFFT
TWS-TSO71HFFT
IMPORTANT NOTE:
Thank you for selecting a TECO quality Air
Conditioner. Read this manual carefully before
installing or operating your new air conditioning unit.
Make sure to save this manual for future reference.
The design and specifications are subject to change
without prior notice for product improvement. Consult
with the sales agency or manufacturer for details.

CONTENTS
....................................................................................................1
.................................................................................................................3
.........................................................................................................4
.................................................................................................5
........................................................................................................6
...............................................................................................9
SAFETY PRECAUTIONS
NAMES OF PARTS
INDOOR UNIT DISPLAY
EMERGENCY FUNCTION
REMOTE CONTROLLER
OPERATING INSTRUCTIONS
OPERATION RANGE
MAINTENANCE
TROUBLESHOOTING
.............................................................................................................15
....................................................................................................................16
..........................................................................................................17

SAFETY PRECAUTIONS
1
Read Safety Precautions Before Operation
WARNING
This symbol indicates the possibility
of personnel injury or loss of life.
CAUTION
This symbol indicates the possibility of
property damage or serious consequences.
WARNING
This appliance is not intended for use by persons(including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
WARNINGS FOR PRODUCT USE
• If an abnormal situation arises (like a burning smell), immediately turn off the unit and disconnect the
power. Call your dealer for instructions to avoid electric shock, fire or injury.
• Do not insert fingers, rods or other objects into the air inlet or outlet. This may cause injury, since
the fan may be rotating at high speeds.
• Do not use flammable sprays such as hair spray, lacquer or paint near the unit. This may cause fire
or combustion.
• Do not operate the air conditioner in places near or around combustible gases. Emitted gas may
collect around the unit and cause explosion.
• Do not operate your air conditioner in a wet room such as a bathroom or laundry room. Too much
exposure to water can cause electrical components to short circuit.
• Do not expose your body directly to cool air for a prolonged period of time.
• Do not allow children to play with the air conditioner. Children must be supervised around the unit at
all times.
• If the air conditioner is used together with burners or other heating devices, thoroughly ventilate the
room to avoid oxygen deficiency.
• In certain functional environments, such as kitchens, server rooms, etc., the use of specially
designed air-conditioning units is highly recommended.
CLEANING AND MAINTENANCE WARNINGS
• Turn off the device and disconnect the power before cleaning. Failure to do so can cause electrical
shock.
• Do not clean the air conditioner with excessive amounts of water.
• Do not clean the air conditioner with combustible cleaning agents. Combustible cleaning agents
can cause fire or deformation.

2
CAUTION
• Turn off the air conditioner and disconnect the power if you are not going to use it for a long time.
• Turn off and unplug the unit during storms.
• Make sure that water condensation can drain unhindered from the unit.
• Do not operate the air conditioner with wet hands. This may cause electric shock.
• Do not use device for any other purpose than its intended use.
• Do not climb onto or place objects on top of the outdoor unit.
• Do not allow the air conditioner to operate for long periods of time with doors or windows open, or
if the humidity is very high.
ELECTRICAL WARNINGS
• Only use the specified power cord. If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• Keep power plug clean. Remove any dust or grime that accumulates on or around the plug. Dirty
plugs can cause fire or electric shock.
• Do not pull power cord to unplug unit. Hold the plug firmly and pull it from the outlet. Pulling directly
on the cord can damage it, which can lead to fire or electric shock.
• Do not modify the length of the power supply cord or use an extension cord to power the unit.
• Do not share the electrical outlet with other appliances. Improper or insufficient power supply can
cause fire or electrical shock.
• The product must be properly grounded at the time of installation, or electrical shock may occur.
• For all electrical work, follow all local and national wiring standards, regulations, and the Installation
Manual. Connect cables tightly, and clamp them securely to prevent external forces from damaging
the terminal. Improper electrical connections can overheat and cause fire, and may also cause
shock. All electrical connections must be made according to the Electrical Connection Diagram
located on the panels of the indoor and outdoor units.
• All wiring must be properly arranged to ensure that the control board cover can close properly. If the
control board cover is not closed properly, it can lead to corrosion and cause the connection points
on the terminal to heat up, catch fire, or cause electrical shock.
• All wiring and disconnection must be incorporated in the fixed wiring in accordance with the wiring
rules.
Disposal Guidelines
This marking shown on the product or its literature, indicates that waste electrical and
eletrical equipment should not be mixed with general household waste.
•Young children should be supervised to ensure that they do not play with
the appliance and packaging.
•Packing (e.g. wraps, polystyrene etc.) can be dangerous for children. There
is a risk of suffocation. Keep packaging materials away from children.
•Contact your local authorities for correct method of disposal. Dispose of all
packaging in a responsible manner in accordance with local regulations.

NAMES OF PARTS
No. Description
1
2
Front panel
Air filter
3
Terminal block cover
4
Emergency button
5
6
LED Display
Signal receiver
7
Airflow direction louver
8
Deflectors
9
10
Note: the above figures are only intended to be a
simple diagram of the appliance and may not
correspond to the appearance of the units that
have been purchased.
No. Description
13 Air outlet grille
Terminal block cover
14
Gas valve
15
Liquid valve
16
Indoor unit rating label
17
Outdoor unit rating label
13
15
16
17
INDOOR UNIT
3
OUTDOOR UNIT
14
11
INDOOR UNIT
OUTDOOR UNIT
10
Remote controller
Mode
Fan
Eco
TempSwing
Timer
Display
Sleep
MuteTurboIFeel

INDOOR UNIT DISPLAY
The shape and position of switches and indicators may be different according to the model, but their
function is the same.
4
No.
Led Function
1
2
3Temperature display / Error code
(1) Lights up during Timer operation when
the air conditioner is operational
(2) Displays the malfunction code when
fault occurs.
SLEEP mode
Lights up during Timer operation.
SLEEP
TIMER

EMERGENCY FUNCTION
5
The shape and position of the emergency button
may be different according to the model, but their
function is the same.
The emergency button in some models could be on
the right part of the unit under the front panel.
Open and lift the front panel up to an angleto reach the
emergency button.
1. One press of the emergency button(one beep) will
lead to the forced COOLING operation
2. Two press of the emergency button within 3 sec
(two beeps) will lead to the forced HEATING
operation.
3. To switch off the unit , you just need to press the
button again (a single long beep) .
4. After 30 minutes in forced operation , the air
conditioner will automatically start working in 23
cooling mode, auto fan speed.
If the remote controller fails to work or maintenance
necessary, proceed as follows:
EMERGENCY FUNCTION
The indoor fan speed during capacity and or efficiency test should be "quick cool" or "quick heat"
which can be activated by pressing "TURBO" button of remote controller

REMOTE CONTROLLER
6
The shape and position of buttons and indicators may vary according to
the model, but their function is the same.
The outlooking and some function of remote control may vary according
to the model.
The unit confirms the correct reception of each press button with a beep.
To select the mode of operation
To LED displayswitch on/off the
To activate or deactivate of the movement of the
deflectors.
To activate the function SLEEP
In cooling mode,press this button ,the temperature
will increase 2 on the base of setting temperature
In heating mode, press this button, the temperature
will decrease 2 on the base of setting temperature
Press this button to activate / deactivate the Super
function which enables the unit to reach the preset
temperature in the shortest time.
In COOL mode, the unit will give the maximum
cooling temperature with 16 ,high fan speed.
In HEAT mode, the unit will give the maximum heating
temperature with 31 ,high fan speed.
Press it to decrease temperature / time setting.
Press it to increase temperature / time setting.
Press it to start or stop operation.
Press it to set auto-off timer.
To select the fan speed of auto/low/mid/high
No.
8
10
12
6
7
9
MODE
SWING
DISPLAY
SLEEP
ECO
TURBO
11
1
(TEMP DN)
(TEMP UP)
2
3
4
ON/OFF
FAN
5TIMER
Button Function
To activate the function of Mute.
MUTE
8
3
6
7
9
10
5
12
4
1
2
11
13To activate the I Feel function.
I FEEL
13

REMOTE CONTROLLER
Remote controller DISPLAY
Meaning of symbols on the liquid crystal display
7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
COOLING indicator
DEHUMIDIFYING indicator
FAN ONLY OPERATION indicator
HEATING indicator
SIGNAL RECEPTION indicator
TIMER OFF indicator
TIMER ON indicator
AUTO FAN indicator
LOW FAN SPEED indicator
MIDDLE FAN SPEED indicator
HIGH FAN SPEED indicator
SLEEP indicator
15
TUBRO indicator
16
17 HEALTHY indicator
18 ECO indicator
Meaning
No. Symbols
CLOCK indicator
1
2
3
4
5
6
7
8
9
10
11
12
13
14
FEEL mode indicator
COOLING indicator
DEHUMIDIFYING indicator
FAN ONLY OPERATION indicator
HEATING indicator
SIGNAL RECEPTION indicator
TIMER OFF indicator
TIMER ON indicator
AUTO FAN indicator
LOW FAN SPEED indicator
MIDDLE FAN SPEED indicator
HIGH FAN SPEED indicator
SLEEP indicator
SWING Up-Down indicator
15
TUBRO indicator
16
17 HEALTHY indicator
18 ECO indicator
Meaning
No. Symbols
CLOCK indicator
SWING Left-Right indicator
19

8
REMOTE CONTROLLER
Signal
receptor
+
+
+
Replacement of Batteries
Remove the battery cover plate from the rear of the remote controller,
by sliding it in the direction of the arrow.
Install the batteries according the direction (+and -)shown on the Remote
Controller.
Reinstall the battery cover by sliding it into place.
Use 2 LRO 3 AAA (1.5V) batteries . Do not use rechargeable
batteries . Replace the old batteries with new ones of the same
type when the display is no longer legible.
Do not dispose batteries as unsorted municipal waste. Collection
of such waste separately for special treatment is necessary.
NOTE:if you adjust the remote controller in cooling mode,
it will not be possible to activate the heating function in units with
heating pump . you need to take out the batteries and repeat the
procedure described above.
1. Direct the remote controller toward the Air conditioner.
2. Check that there are no objects between the remote control
and the Signal receptor in the indoor unit.
3. Never leave the remote controller exposed to the rays of the sun.
4. Keep the remote controller at a distance of at least 1m from the
television or other electrical appliances.
Recommendations for locating and using the remote controller holder (if present)
The remote controller be kept in a wall-mounted holder
Refer to picture 2:
When you insert the batteries for the first time in the remote
controller or if you change them, you need to program the remote
controller of only cooling or cooling and heating.
When you insert the batteries, the symbols ( ) and
( ) start fashing. If you push whatever button when
the symbol ( ) is displayed, the remote controller is
adjusted in only cooling mode . If you push whatever button when
the symbol ( ) is displayed , the remote controller is
adjusted in Cooling and heating mode.
COOL
HEAT
COOL
HEAT
Refer to picture 1:
i. When you open the battery cover, you can see a DIP switch on
the cover back.l
Ii. NOTE:After adjusting the function, you need to take
out the batteries and repeat the procedure described above.
DIP switch on position Function
The remote controller is adjusted in degree celsius
The remote controller is adjusted in only cooling mode
The remote controller is adjusted in cooling and heating mode
The remote controller is adjusted in degree fahrenheit.
Cool
Heat
C
F
Remote controller holder
Mode
Fan
Eco
TempSwing
Timer
Display
Sleep
MildewTurbo Health
Mode
Fan
Eco
TempSwing
Timer
Display
Sleep
Mildew TurboHealth
Mode
Fan
Eco
Temp Swing
Timer
Display
Sleep
Mute Turbo IFeel
