Teco Tws-tso25hvgt User manual

Cooling Only

TWS-TSO25CVGT

TWS-TSO50CVGT

TWS-TSO70CVGT

SPLIT-TYPE ROOM AIR CONDITIONER

Wireless Operation

Manual

Models:

Heat Pump

TWS-TSO25HVGT

TWS-TSO32HVGT

TWS-TSO50HVGT

TWS-TSO70HVGT

TWS-TSO80HVGT

IMPORTANT NOTE:

Thank you for selecting a TECO quality Air Conditioner.

Read this manual carefully before installing or operating

your new air conditioning unit. Make sure to save this

manual for future reference.

The design and specifications are subject to change

without prior notice for product improvement. Consult

with the sales agency or manufacturer for details.

CONTENTS

Smart Phone Environment and Wi-Fi Module ............................................1

Downloading and Installing the APP

.........................................................2

............................................................

..............................................................................

Activate APP - APP Settings

Activate APP - Activation Code and Privacy Agreement

Add Device

Air Conditioner Control - Main Control Screen

Air Conditioner Control - Mode

Air Conditioner Control - Fan Speed

Air Conditioner Control - Air Flow Control

Air Conditioner Control - ECO

Air Conditioner Control - Sleep

Air Conditioner Control - Timer (Off)

Air Conditioner Control - Timer (On)

Air Conditioner Control - Timer (Change / Disable / Delete)

Tips of the Device

News

Share the Device

Account and Help

Notice

Trouble Shooting ..............................................................................19

.....................................................

.............................................................................................7

............................................................................................ 16

............................................................................................19

..........................................................................

..............................................................................

..........................................................................

..............................................................4

...........................

....................................... 9

.......................................................

.............................................

.............................................................

............................................................. 12

..................................................... 13

..................................................... 14

....................... 15

Repairs, Services & Warranty ........................................................... 20

1. Minimum specifications on a Smart phone:

Android 5.0 version or higher

IOS 9.0 version or higher

2. Wireless Network Requirements of Wi-Fi module

2400 - 2483.5MHz

ISM band

Channel numbers

Smart Phone Environment and Wi-Fi Module

Standard IEEE 802.11 b IEEE 802.11 g IEEE 802.11 n

Operating frequency 2400 -2483.5MHz

ISM band

2400 -2483.5MHz

ISM band

Features

Data rate

Modulation

Sensitivity

Output Power

DQPSK,DBPSK

CCK,DSSS

BPSK,QPSK,16QAM

64QAM with OFDM

QPSK,BPSK,16QAM

64QAM with OFDM

13 channels

for wordwide

At most 150Mbps

At most 54Mbps

13 channels

for wordwide

At most 11Mbps

security

-76dBm for 11Mbps -65dBm for 54Mbps -64dBm at MCS7

(2.4GHz band/HT20)

-61dBm at MCS7

(2.4GHz band/HT40)

16 2dBm

for 11Mbps

14 2dBm

for 54Mbps

12 2dBm at MCS7

(2.4GHz band/HT20)

12 2dBm at MCS7

(2.4GHz band/HT40)

3. Where is the Wi-Fi module and The MAC address

Open the front panel, the Wi-Fi module is nearby the electric box cover or on the panel.

The MAC address is the ID of a Wi-Fi module, it's very important for after service, please don't remove or

destroy the MAC address label.

RESET

MAC

SN:

Reset button

Connecting cable

MAC address

Standard: WEP/WEPA/WPA2

encryption algorithm: WEP64/WEP128/TKIP/AES

Downloading and Installing the APP

1. Install the APP for Android Smart phone

Step1. Tap the Play Store icon on the Smart phone.

Step2. Type in the search window and search

the app.

Step3. Tap the INSTALL button.

Step4. Tap the ACCEPT button to install the APP..

Step5. When the app is finished installing, an OPEN

button is displayed on the screen. If you are

ready to use it ,tap OPEN to start it.

"Intelligent AC"

needs access to

Device & app history

Photos/Media/Files

Camera

Wi-Fi connection

information

Device ID & call

information

Google Play

Intelligent AC

ON/OFF Fan Speed Precision

Air Flow

Eco Sleep

Mode

Timer

lntelligent AC

Device list News Share Me

2.8 10K+

117 reviews Downloads Everyone

lntelligent AC

ACSmart

Tools

xxxff

Device list

INSTALL

aaa

Cool

lntelligent AC

ACSmart

Tools

UNINSTALL OPEN

Rate this app

Tell others what you think

Write a review

Developer contact

Website

Downloading and Installing the APP

2. Install the APP for iPhone (IOS system)

Step1. Tap the "APP Store"icon on the iPhone.

Step2. Type "intelligent ac" in the search window and

search the app.

Step3. Tap the button to download and install

the APP.

Step4. When the app is finished installing, an OPEN

button is displayed on the screen. If you are

ready to use it ,tap OPEN to start it.""

App Store

5.0 4+

1 Rating Age

lntelligent AC

ACSmart

xxxff

Device list

aaa

Cool

What's New

Version 1.0.1

Version History

1mo ago

Preview

5.0 4+

1 Rating Age

lntelligent AC

ACSmart

xxxff

Device list

aaa

Cool

What's New

Version 1.0.1

Version History

1mo ago

Preview

OPEN

Activate APP - APP Settings

1. Launch the APP by tapping the Intelligent AC icon on your smart phone.

Intelligent AC

2. Once get the permissions, on the next Select Area Of Use screen,

please carefully select one of the area and tap Confirm.

Make sure that the product you use is

the same as the local area you choose.

Otherwise the product may not work

properly

Confirm

Device List

Select Area Of Use

Confirm

Mainland China(China Server)

European Region(European server)

Other Region(American server)

For users in mainland China only, users in Hong

Kong, Macau, and Taiwan in China should use

Other Areas

Recommended GDPR to include users in

countries and regions.

Users in other areas please select this area.

Select Area Of Use

Confirm

Mainland China(China Server)

For users in mainland China only, users in Hong

Kong, Macau, and Taiwan in China should use

Other Areas

European Region(European server)

Recommended GDPR to include users in

countries and regions.

Other Region(American server)

Users in other areas please select this area.

3.Tap Allow to get permissions of access to camera

and storage on the next permissions screen.

Direct access to camera to take photos or

videos

Intelligent AC requires access to following

permission: Camera. Allow?

Configure permissions from Phone Manager>

Permissions manager.

Never ask again after denying permission

Deny Allow

Access photos, media, and files on your device

Intelligent AC requires access to following

permission: Storage. Allow?

Configure permissions from Phone Manager>

Permissions manager.

Never ask again after denying permission

Deny Allow

Note: if you tap Deny, the app will disable and prompt Please enable the permission in settings"".

You can enable the permission in your mobile setting.

Activate APP - Activation Code and Privacy Agreement

4. On the next activation screen, to active the APP, you

can scan the activate QR code directly or choose

Manual input and input the activation code .

Scan QR code

Mainland China

Activate Manual input

Activate QR code and activation code

Note Without the QR code or activation code,

you can't active the APP and using it,

please keep them safe.

Input activation code

Cancel Activate

5. Please tap Allow on the next Access to location screen after activation .

Scan the QR code or Manual Input

Privacy Agreement

1. Scope:

(a). This App automatically receives and records your

browser and phone information when you use the

network service provided by this App or access web

pages in this App, including but not limited to your IP

address, browser type, language, date and time, OS and

hardware information and web page requests

information, etc.;

(b). User s personal data legally collected from

business partners;You understand and agree the

following information are not applicable for this privacy

policy:

(c). Keywords input for searching service provided by

this platform;

This App respects and protects personal privacy for all

users. This App will use and disclose your personal

information according to the regulations specified in

this privacy policy for provision of more accurate and

personalized service for you. However, this App will

treat these information with highest prudence and

attentions. This App will not disclose these information

to public or third parties without your prior permission,

unless otherwise specified This privacy policy might

be timely updated for this App.

Your consent to this App s service agreement will be

considered that you fully agreed to all contents in this

of this App service agreement.

Disagree

Agree

Access this device's location

Intelligent AC requires access to following

permission: Your location. Allow?

Configure permissions from Phone Manager>

Permissions manager.

Never ask again after denying permission

Deny Allow

6. Welcome screen and Privacy Agreement screen will POP up ,

please check the privacy carefully and tap Agree.

Teco

1. For the new installation of APP, the login screen will appear after Privacy agreement.

Fora new login, it will appear after launching and welcome screen.

2. If you don t have any account please tap Register.

3. Tap country calling code of you phone number like +61 .

4. Slide the screen or find the country of your mobile phone number located.

Tap the country like Australia +61.

5. Input your mobile phone number and create a password

(Password must including 6~20 characters and numbers)

6. Tap Get verification code and a message with verification code will be

received on your smart phone.

7. Input the verification code within 59s.

8. Tap Complete when done.

Mainland China

No account? Register

Remember Password Forget Password

Enter your phone number

Enter password

Intelligent AC

< Choose Country

Afghanistan +93

Albania +355

Algeria +213

Andorra +376

Anguilla +1264

Antigua and Barbuda +1268

Argentina +54

< Mobile Register< Mobile Register

Verification code is sent to your phone

040*******

1234

Complete

38s

[Intelligent AC verification code]

you are now using SMS to obtain

Intelligent AC authentication code,

verification code is 1234

Message sample

You mobile phone number will only be used in

account system, and will not reveal your personal

information.

< Mobile Register

one number

Set the password

You mobile phone number will only be used in

account system, and will not reveal your personal

information.

< Mobile Register

********

++61 040*******

Get verification code

Tap it to display

or hidden the

password

1. If you forget the password to login please tap Forget Password.

2. Input your mobile phone number and create a new password

(Must including 6~20 characters and numbers).

3. Tap Get verification code.

4. Input the verification code( included in the message received on your smart phone) within 59s.

5. Tap Complete to finish the registration.

Mainland China

No account? Register

Remember Password Forget Password

Enter your phone number

Enter password

Intelligent AC

You mobile phone number will only be used in

account system, and will not reveal your personal

information.

+61

You mobile phone number will only be used in

account system, and will not reveal your personal

information.

< Retrieve Password

040*******

********

Get verification code

< Mobile Register

Set the password

Verification code is sent to your phone

040*******

8179

Complete

38s

< Retrieve Password

1. Input your mobile phone number and password.

2.Tap Login.

Mainland China

No account? Register

Remember Password Forget Password

040*******

******

Intelligent AC

Add Device

1. Click + in the upper right corner of the Device list screen ,then tap Add Device.

2. Power on the indoor unit(Launching the Air conditioner is not required ) and follow up the

instruction on 1/5 screen or press restart button of the Wi-Fi module to restart the Wi-Fi

module. Tap next on 1/5 screen.

3.Input the Wi-Fi name and password, the same as your smart-phone connected, tap Connect.

4. You can see the percent rate of connecting process,

5. When finished the configuration it will get into 4/5 and 5/5 screen automatically.

6. Input the name of this device and tap Complete on 5/5 screen.

The device will be listed on the Device list screen when done.

at the same time

PP","SA","AP" shining in turn on the indoor display.

"PP" means "searching the router"

"SA" means "connected to the router"

"AP" means "connected to the server"

No device, click + in the upper right

corner to add

Device list News Share Me

Device list +

Add Device

Sharing Device

Press "DISPLAY" or "ECO" button on

the remote controller 6 times within

8 seconds until the buzzing is heard

and "CF" is shown on the display.

Press "GEN" button on the remote

controller 9 times within 8 seconds

until the buzzing is heard and "CF" is

shown on the display.

< Add Device

1/5

This device does not support some 5G WiFi

Connect

< Add Device

2/5

Enter your WiFi password

Configuring network

Adding

< Add Device

3/5

Try to make your router, mobile phone

and device near each other. Device name

Complete

< Add Device

5/5

Please input name

Configure successfully

The device is being added,

please wait patiently

Adding

< Add Device

4/5

Try to make your router, mobile phone

and device near each other.

Air Conditioner Control - Main Control Sceen

Device list News Share Me

Device list +

Sample1

Tap the name of one device, it will get into the main control screen of the device.

Back to the Device List screen

Decrease temperature

Power on/off

Selected Functions indicator

ON/OFF

Sample1

Cool

Fan Speed Swing Flow

Eco Sleep

Mode

Timer

Turbo

Tips

Name of the device

Current mode

Increasing temperature

Different background for different mode:

Cool/Heat/Dry/Fan/Auto

Function Buttons

Air Conditioner Control - Mode

1. Tap the Mode button.

2. There are 5 modes on the Mode screen, tap one button to set the Air conditioner working mode.

3. Tap the X button to back to the main control screen.

4. The mode and background will change on the screen.

Back

Sample1

Cool

Cool Dry Fan

Heat

Auto

Mode X

Note: please read the details of each mode

in the user manual to control more comfortable.

Air Conditioner Control - Fan Speed

1.Tap the Fan speed button.

2.Choose your desired fan speed and tap it.

3.Tap the X button to back the main control screen.

4.The selected fan speed indicator will appear on the screen.

Back

Sample1

Cool

Fan Speed X

Mode Fan Speed

Cool

Fan

Dry

Heat

Auto

All speeds

Midhigh AutoLow

Note:

Fan Speed can t be adjusted on Dry mode .

ON/OFF

Sample1

Cool

Fan Speed Swing Flow

Eco Sleep

Mode

Timer

Turbo

Left-Right Flow

ON/OFF

Sample1

Cool

Fan Speed Swing Flow

Eco Sleep

Mode

Timer

Turbo

Left-Right Flow

Air Conditioner Control - Air Flow Control

1. dĂƉƚŚĞWƌĞĐŝƐŝŽŶŝƌ&ůŽǁďƵƚƚŽŶŽƌ^ǁŝŶŐ&ůŽǁďƵƚƚŽŶ

2. ŚŽŽƐĞǇŽƵƌĚĞƐŝƌĞĚĂŝƌĨůŽǁĂŶĚƚĂƉŝƚ

3. dĂƉƚŚĞyďƵƚƚŽŶƚŽďĂĐŬƚŽƚŚĞŵĂŝŶĐŽŶƚƌŽůƐĐƌĞĞŶ

4. dŚĞƐĞůĞĐƚĞĚĂŝƌĨůŽǁŝŶĚŝĐĂƚŽƌǁŝůůĂƉƉĞĂƌŽŶƚŚĞƐĐƌĞĞŶ

ϭϭ

KEK&&

Sample1

Cool

&ĂŶ^ƉĞĞĚ ^ǁŝŶŐ&ůŽǁ

ĐŽ ^ůĞĞƉ

DŽĚĞ

dŝŵĞƌ

dƵƌďŽ

>ĞĨƚͲZŝŐŚƚ&ůŽǁ

ĂĐŬ

Sample1

Cool

^ǁŝŶŐ&ůŽǁ y

hƉͲŽǁŶ >ĞĨƚͲZŝŐŚƚ

Note: For some models without auto Left-Right wind, If you active it, you will hear a beep,but no any actions.

Air Conditioner Control - ECO

1. &ŽƌĐŽĨƵŶĐƚŝŽŶũƵƐƚƚĂƉƚŚĞďƵƚƚŽŶƚŽĂĐƚŝǀĂƚĞƚŚĞĨƵŶĐƚŝŽŶƚŚĞďƵƚƚŽŶǁŝůůďĞůŝŐŚƚŝŶŐ ĂŶĚ

ƚŚĞŝŶĚŝĐĂƚŽƌǁŝůůĂƉƉĞĂƌŽŶƚŚĞƐĐƌĞĞŶ

2. dĂƉĂŐĂŝŶƚŽĚŝƐĂďůĞƚŚĞĨƵŶĐƚŝŽŶ

3. dĞŵƉĞƌĂƚƵƌĞĐŽŶƚƌŽůůĞĚĨŽƌƐŽŵĞĂŝƌĐŽŶĚŝƚŝŽŶĞƌŵŽĚĞů

/ŶŽŽůŝŶŐŵŽĚĞƚŚĞŶĞǁƐĞƚƚŝŶŐƚĞŵƉĞƌĂƚƵƌĞǁŝůů Ϯϲ 

/ŶŚĞĂƚŝŶŐŵŽĚĞƚŚĞŶĞǁƐĞƚƚŝŶŐƚĞŵƉĞƌĂƚƵƌĞǁŝůů Ϯϱ 

KEK&&

Sample1

Cool

&ĂŶ^ƉĞĞĚ ^ǁŝŶŐ&ůŽǁ

ĐŽ ^ůĞĞƉ

DŽĚĞ

dŝŵĞƌ

dƵƌďŽ

Mode ECO enabled

Cool

Fan

Dry

Heat

Auto

zĞƐ

KŝƐĚŝƐĂďůĞĚŽŶ&ĂŶƌǇƵƚŽŵŽĚĞ

Note:

ECO is disabled on Turbo/Sleep mode too

for some air conditioner model.

ECO

Low

Air Conditioner Control - Sleep

1. Tap the Sleep button.

2. Choose your desired sleep mode and tap it.

3. Tap the X button to back to the main control screen.

4. The selected sleep mode indicator will appear on the screen.

ON/OFF

Sample1

Cool

Fan Speed Swing Flow

Eco Sleep

Mode

Timer

Turbo

Mode Sleep enabled

Cool

Fan

Dry

Heat

Auto

Yes

Note:

Sleep is disabled on Turbo/Sleep mode too

for some air conditioner model..

Sleep

Low

Sleep is disabled on Fan/ Dry/Auto mode .

Back

Sample1

Cool

Sleep X

Child

The aged

Standard

Air Conditioner Control - Timer (Off)

1. Tap the Timer button.

2. Tap + in the upper right corner of the Timer main screen.

3. Choose the Time/Repeat/Switch OFF then tap Save.

4. The timer(off) will appear on the Timer main screen.

Sample1

Cool

< Timer

No Timer

< Timer

19 27

20 28

22 30

23 31

Save

21 : 29

Repeat Monday....>

Switch OFF>

Once

Monday

Tuesday

Wednesday

Thursday

Friday

Saturday

Sunday

Cancel Repeat Confirm

Slide up or down

to select time

Tap repeat > then tap your desired

repeat days or Once, then tap

Confirm your selection. < Timer

21:29

OFF, Weekday

Cancel Switch Confirm

OFF

Tap Switch > then slide the

screen to choose ON

and Confirm.

ON/OFF Fan Speed Swing Flow

Eco Sleep

Mode

Timer

Turbo

Air Conditioner Control - Timer (On)

1. Tap the Timer button.

2. Tap + in the upper right corner of the Timer main screen.

3. Set the Time/Repeat Date/Switch(ON)/Temperature/Mode/Fan speed/Air Flow as your desired

and then tap Save.

4. The timer will appear on the Timer main screen.

Sample1

Cool

< Timer

14 17

15 18

17 20

18 21

Save

16 : 19

Repeat Monday....>

Switch ON>

Temperature25 >

Mode Cool>

Fan Speed Mid>

Swing Swing>

Slide up or down

to select time

Once

Monday

Tuesday

Wednesday

Thursday

Friday

Saturday

Sunday

Cancel Repeat Confirm

Tap repeat > then tap your desired

repeat days or Once, then tap

Confirm your selection. < Timer

Cancel Switch Confirm

OFF

Tap Switch > then slide the

screen to choose ON

and Confirm.

16:19

ON,Cool,Mid,Up-Down Swing 25 ,M...

< Timer

21:29

OFF, Weekday

Tap Temperature/Mode/Fan Speed/

Air Flow > one by one then set as your

desired as mentioned on the previous

chapter and tap Confirm the setting.

04:30

OFF

21:29

OFF, Weekday

04:30

OFF

ON/OFF Fan Speed Swing Flow

Eco Sleep

Mode

Timer

Turbo

Air Conditioner Control - Timer (Change /Disable /Delete)

1. Change the Timer setting:

Tap anywhere of the timer list bar except the switch bar to get into the Timer setting

screen, change the setting and then tap save.

2.Enable or Disable the Timer:

Tap the left of the switch to disable the Timer.

Tap the right of the switch to enable the Timer.

3.Delete the Timer:

Slide the list bar of the Timer from right to left until Delete button appear, then tap delete.

< Timer
