Teeter Hang Ups DEX II Use and care manual

ASSEMBLYINSTRUCTIONS
USERMANUAL
DONOTDISCARD - KEEPFOR FUTUREREFERENCE

Carefully remove the individual parts from the carton. You should have all of the items listed below. If any items are missing
or damaged, contact your retailer or customer service directly (See Pg. 4 of the User Manual).
ASSEMBLY INSTRUCTIONS
Before you begin: These instructions will guide you in properly assembling the DEX IITM. Please review all the steps
before beginning assembly. Carefully adhere to theAssembly Instructions and User Manual to help ensure user security
andproductintegrity.
1. It is your responsibility to familiarize yourself with the proper use of the equipment and the inherent risks of inversion, such as
falling on your head or neck, pinching, entrapment or equipment failure.
2. This product is NOT designed for persons over 6’6” (198 cm) or 300 lbs (136 kg). Structural failure could occur or head/neck
may impact floor during inversion. Serious injury or death could result.
3. DO NOT use the equipment without a licensed physician’s approval and a review of the medical contraindications, as noted in
the User Manual.
4. Failure to assemble and/or use the equipment as directed may void the manufacturer’s warranty on this product and could
result in injury or death.
5. DO NOT use the DEX IITM until you have thoroughly and carefully read the User Manual, reviewed all other accompanying
documents, and inspected the equipment.
6. Choose a level surface for assembling and operating the DEX IITM.
7. Follow each step in sequence. Do not skip ahead.
8. Make sure that all fasteners are secure.
9. PRIOR TO USE, test and inspect the equipment. Make sure the Lap Pad rotates smoothly.
10. Replace defective components immediately and/or keep the equipment out of use until repair.
PRE-ASSEMBLY
ITEMS FORASSEMBLY ITEM#’s
Leg Support Assembly H1-2000
Leg Support Frame H1-2001
Leg Width Adjustment Knob H1-2016
Two (2) Rollers H1-2002
Two (2) Roller Caps H1-2003
Leg Support Shaft H1-2004
Two (2) Flat Washers (M8) H1-1414
Two (2) Hex Bolts (M8 x 25mm) H1-1415
Base Assembly H1-3008
Base Frame H1-2009
HeightAdjustment Knob H1-2018
Two (2) Legs H1-2010
Two (2) Base Feet D1-1012
Two (2) Leg Feet D1-1013
Four (4) Threaded Bolts (3/8-16) H1-2011
Four (4) Bolt Caps (3/8-16) H1-2012
Four (4) Flat Washers (3/8) H1-2013
Four (4) Lock Washers (3/8) H1-1301
H1-1412, H1-1304,
H1-1302, H1-2017
(may come pre-assembled to
the Lap Pad Assembly)
H1-2011, H1-2012,
H1-2013, H1-1301
H1-2014 H1-2015
!WARNING
DEX IITM Assembly Instructions LD-2000 Pg. 1
Lap Pad Assembly H1-2005
LapPadFrame H1-2006
LapPad D1-1005
Four (4) Screws H1-2007
Hex Bolt (3/8-16) H1-1412
Hex Nut (3/8-16) H1-1304
Two (2) Flat Washers (3/8) H1-1302
Two (2) Spacers H1-2017
Hardware
Two (2) Wrenches (13/14mm) H1-2014
Screwdriver H1-2015
some parts shown may not be in proportion to other parts
H1-2009
H1-2018
H1-2005
H1-2010
H1-2000
D1-1012
D1-1013
H1-1414, H1-1415
(may come pre-assembled to
the Leg Support Shaft)

DEX IITM Assembly Instructions LD-2000 Pg. 2
ASSEMBLY INSTRUCTIONS
ASSEMBLY
Figure 3
Figure 3A
Chrome
Shaft
STEP THREE
Secure the Lap Pad Assembly (H1-2005) to the Chrome Shaft of
the Base Frame Assembly
•RemovetheHexNut(H1-1304), Flat Washers (H1-1302)and
Spacers(H1-2017)fromtheHexBolt(H1-1412).Keep this
hardwarenearby.
•With the Traction Handles facing the rear of the Base Frame
Assembly, place the Lap PadAssembly over the Chrome Shaft in
the Base Frame and align the holes. (See Figure 3)
•Thread the Hex Bolt through a Flat Washer and Spacer. Make
sure the small end of the Spacer faces away from the head end
of the Hex Bolt.
•Insert the Hex Bolt with Flat Washer and Spacer through the
holes, securing the Lap PadAssembly to the Chrome Shaft.
ThreadtheremainingSpacerwiththesmallendfacingthe
Chrome Shaft and tighten with the Flat Washer and Hex Nut.
(SeeFigure3Aforclose-upview)
•Make sure the fasteners are securely tightened and the Lap Pad
rotates smoothly.
STEP ONE
Assemble the Feet (D1-1012, D1-1013) onto the Base Frame (H1-2009)
and the Legs (H1-2010)
•Slide the Base Frame Feet (D1-1012) on to the Base Frame. (See
Figure1A)
•Slide the Leg Feet onto the end of the Legs with the cane handle.
(SeeFigure1B)
•Push firmly on all four feet to ensure they are fully mounted.
Leg Housings
Traction
Handles
(Rear)
(Front)
STEP TWO
Attach the Legs (H1-2010) to the Base Frame (H1-2009)
•With the cane handles facing upward, insert the Legs into
the Leg Housings of the Base Frame until the two holes in
the Leg Housing align with the holes at the top of each
Leg.(SeeFigure2)
•Insert a Threaded Bolt (H1-2011) from the inside of the
Leg Housing through the holes on each column. Finish
on the outside of the Base Frame using the Flat Washer
(H1-2013), Lock Washer (H1-1301) and Bolt Cap
(H1-2012) and tighten with Wrenches (H1-2014).
Figure 2
Figure 1A
Figure 1B

DEX IITM Assembly Instructions LD-2000 Pg. 3
STEP FIVE
Testing the Assembly
PRIOR TO USE:
• Test the Lap Pad for smooth and steady rotation.
• Ensure that all fasteners are secure.
The assembly of the DEX II •decompression & extensionTM is now complete! Please remember:
• Read the User Manual and accompanying materials thoroughly before using the DEX IITM. Improper
use could result in serious injury or death.
• Please complete and mail the warranty card.
STEP FOUR
Attach the Leg Support Assembly (H1-2000) to the Lap Pad
Assembly (H1-2005)
•You may need to remove the Hex Bolts (H1-1415) and Flat
Washers(H1-1414)fromtheLeg Support Shaft(H1-2004).
•Slide the Leg Support Shaft into thereceivingend oftheLap Pad
Assembly. (See Figure 4) Lining up the two holes, insert the Flat
Washers and Hex Bolts. Secure with wrench.
Figure 4
ASSEMBLY INSTRUCTIONS

USER MANUAL
IMPORTANT SAFETY INSTRUCTIONS
It is your responsibility to familiarize yourself with the proper use of the equipment and the inherent risks of
inversion, such as falling on your head or neck, pinching, entrapment or equipment failure. FAILURE TO
FOLLOW INSTRUCTIONS OR HEED WARNINGS COULD RESULT IN SERIOUS INJURY OR DEATH.
Restrictions on Use
•DO NOT use the equipment without a licensed physician's approval. Carefully review the following list of
medical contraindications for inversion with your licensed physician: (This is not an exhaustive list, it is
intended only for reference)
· Middle ear infection · Conjunctivitis · Recent stroke or transient ischemic attack
· Extreme obesity · High blood pressure · Bone weakness (osteoporosis)
· Pregnancy · Hypertension · Recent or unhealed fractures
· Hiatal hernia · Heart or circulatory disorders · Medullary pins
· Ventral hernia · Spinal injury · Surgically implanted orthopedic supports
· Glaucoma · Cerebral sclerosis · Acutely swollen joints
· Retinal detachment · Use of anticoagulants (including high doses of aspirin)
•DO NOT use if you are over 6'6" (198 cm) or 300 lbs. (136 kg). Structural failure could occur or head/neck
may impact the floor during inversion.
•DO NOT modify the equipment or use accessory attachments that are not recommended by the
manufacturer. Utilize the equipment for its intended purpose only.
• This product is not intended for use in public facilities.
Precautions Before Using
•DO NOT use the DEX IITM until you have thoroughly and carefully read the User Manual, reviewed all other
accompanying documents, and inspected the equipment.
•NEVER allow children to use the equipment unsupervised.
•DO NOT operate equipment while under the influence of drugs, alcohol, or medication that may cause
drowsiness or disorientation.
•ALWAYS inspect the equipment prior to use. Make sure that all fasteners are secure and that the
equipment is located on a level surface.
•ALWAYS replace defective components immediately and do not use until repaired.
•ALWAYS make sure the equipment is properly adjusted to the correct user settings prior to each use.
• Refer to additional warning notices posted on the equipment.
Precautions During Use
•DO NOT use aggressive movements, or use weights, elastic bands or any other exercise or stretching
device while on the DEX IITM.
•ALWAYS keep hands and fingers away from moving parts to avoid injury. DO NOT drop or insert objects
into any opening.
• First time users should use a spotter until comfortable with the operation of the equipment.
WARNING
!
Leg Rollers
Leg Width
Adjustment
Knob
Lap Pad
Chrome Shaft
Corner Feet
Height Adjustment
Handle
Height
Adjustment
Knob
Cane Shaped
Handles
Locking Pin
Traction Handles
DEX IITM User Manual LD-2000 Pg. 1

HOW TO INVERT
PRIOR TO USE
Step One
• Inspect the equipment before each use. Make sure that the Lap Pad rotates smoothly to the inverted
position (approximately 90 degrees) and back and that all fasteners are secure.
Step Two
• The DEX IITM features two adjustment settings that allow you to properly adjust the equipment for your
body type. Make sure the equipment is properly adjusted every time you use the equipment by
A) adjusting the height of the Lap Pad, and B) adjusting the width between the Leg Rollers and Lap Pad:
A. Adjust the height of the Lap Pad:
i. Loosen the Height Adjustment Knob by rotating it several turns
counterclockwise.
ii. Pull the locking pin for the Chrome Shaft while lifting or lowering the
Lap Pad by the Height Adjustment Handle on the back of the Lap Pad.
iii. Select a height setting so that your hips are at the same height as the
top edge of the Lap Pad.
iv. Release the Locking Pin so that it engages fully into one of the height
settings. Tighten the Height Adjustment Knob by rotating clockwise.
v. Make sure the Locking Pin is fully engaged and the Height Adjustment
Knob is tightened prior to use. Failure to do so could result in serious
injury!
B. Adjust the width between the Leg Rollers and Lap Pad:
i. Loosen the Leg Width Adjustment Knob by rotating it several turns
counterclockwise.
ii. Pull out on the Leg Width Adjustment Knob and slide the Leg Rollers in or
out depending on your leg width and comfort.
iii. Release the Leg Width Adjustment Knob so that it engages fully into one
of the hole settings. Tighten the Leg Width Adjustment Knob by rotating clockwise.
iv. Make sure the Leg Width Adjustment Knob is fully engaged and tightened prior to use.
Failure to do so could result in serious injury!
USER MANUAL
The DEX IITM operates strictly under user control - that is, you are able to rotate the unit as slow or as fast as
you desire. You will need to use the strength of your arms to lower your body down and to return upright. If you
are unsure about your ability to operate the equipment properly, always have a spotter nearby or discontinue
the use of the equipment. Step One
•Step onto the cross bar of the Base Frame with thighs between the
Leg Rollers and Lap Pad.
•Determine whether the width between the Leg Rollers and Lap Pad is
comfortable. Adjust if necessary.
•Determine whether the Lap Pad is at the correct height. Your hips
should be the same height as the top edge of the Lap Pad. Adjust if
necessary.
DEX IITM User Manual LD-2000 Pg. 2
A.Adjust Height
B. Adjust Leg Width
Step One
User stands inside
the Leg Rollers -
hips should align
with the top edge
of the Lap Pad

Step Two
• To begin inversion, bend one knee and slowly lean forward to grab
hold of the Cane Shaped Handles.
• While holding the Cane Shaped Handles, continue to slowly lean
forward and rotate the Lap Pad while lifting and bending the other leg.
Step Three
•Continue rotation until the Lap Pad reaches the stop position. Your
body weight will be supported by your thighs.
•Keep both knees bent around the Leg Rollers. Allow your hands to
dangle on the floor or place them folded behind your head.
It is important to maintain bent knees to help support your body while
inverted. Failure to do so could result in serious injury or death!
USER MANUAL
WHILE INVERTED
RELAX. BREATHE. STRETCH. DECOMPRESS. MOVE. EXERCISE. Here are some tips to achieve
maximum benefits when using the DEX IITM:
• For maximum decompression, breathe deeply and relax the muscles in the lower back and shoulders.
• Movement is recommended to encourage relaxation, stimulation of circulation and lymph flow.
• It is important to listen to your own body. Everyone is unique and your own body will tell you when
you’vehad enough.
• You may want to increase your duration of use over a period of time. However, inversion is NOT a no
pain, no gain activity.Always listen to your body’s response to inversion and ascend if you feel anxiety,
discomfort, dizziness or pain.
• For a more active workout program consisting of stretching and exercise, see page 4.
To return to an upright position, reverse the procedure explained above:
• Use the Cane Shaped Handles to gradually walk yourself upright,
rotating the Lap Pad and straightening your legs until standing at the
start position.
RETURNING TO THE UPRIGHT POSITION
HOW TO INVERT cont...
DEX IITM User Manual LD-2000 Pg. 3
Step Two
User bends one
knee, leans
forward and
reaches for
the Cane
Shaped
Handles
Step Three
User rotates the
Lap Pad, inverting
in the 90/90
position
Return
Upright:
User
pushes on
the Cane
Shaped
Handles
and
straightens
legs

Dependinguponyourcurrentfitness levelandgoals,youmaywanttotry advancedinversionexercisesonthe DEXIITM. Proper
form is key for effective stretching and strengthening, and that is why it is essential that you are familiar in mounting,
dismountingandstretchinginthe90/90 position before attempting thefollowingexercises.
Limit all activities to smooth movements. Aggressive exercises that involve a lot of body movement could cause the
DEX IITM to tip over resulting in serious injury or death.
Traction Stretch - Push
• Hangfullyinvertedandrelax.
• Gently push against the Traction Handles located at the side of the Lap Pad.
Alternative: Traction Stretch - Pull
• Hangfullyinvertedandrelax.
• Placeyourelbowsunderthe Cane ShapedHandlesandgentlypush against the
Handles.
Helpful Hints: Stretch, hold 10 seconds and release, repeating several times to
achievethedesiredstretch. Relaxandbreathe deeply.
BackExtensions
• Hangfullyinvertedwith handscrossedonyourchest or folded behindyourhead.
• Tightenglutesandbackand lift torso upslowlyintoextension.Make sure to keep
abdominal muscles engaged to support spine while extended.
• While the DEX IITM is designed to reduce the chance of hyperextension, it is
important that you perform this exercise in a slow and controlled manner. DO
NOTusebodymomentum for theextensionorextendpast parallel withthefloor.
Alternative: Back Extensions - Rotation
• Slightly rotate your torso when extending to work the back extensors and external
obliqueabdominalmuscles.
Helpful Hints: Extend, hold and release, repeating as desired to meet your
workout goals.
Abdominal Crunches
• Hangfullyinvertedwith hands crossedonyourchestorfolded behind yourhead.
• Contract your abdominal muscles, crunching inward toward the support posts.
Alternative: Abdominal Crunch - Rotation
• Slightly rotate your torso when crunching to work the rectus abdominus and
externaloblique muscles.
Helpful Hints: Contract, hold and release, repeating as desired to meet your
workout goals.
Forinformationaboutthe5-yearwarrantyorifyouhaveanyproblemsassemblingtheDEXII™or
questionsaboutitsuse,pleasecontactCustomerServiceattheappropriatelocationbelow:
TeeterHangUpsisatrademarkofInversion
International,Ltd.andlicensedtoSTLInternational,
Inc.Specificationssubjecttochangewithoutnotice.
©COPYRIGHT2007,InversionInternational,Ltd.
InternationalLawProhibitsAnyCopying, 05/07-1
USA & Canada:
STL International, Inc.
9902 162nd St. Ct. E.
Puyallup, WA 98375
(Phone) 800-847-0143
(Fax) 800-847-0188
(email) [email protected]
(web) www.STLIntl.com
International:
Inversion International, Ltd.
PO Box: AP 59245
New Providence Island, Bahamas
(Phone) [phone]
(Fax) [phone]
(email) [email protected]
(web) www.InversionInternational.com
EXERCISING ON THE DEX IITM
USER MANUAL
Europe:
Teeter, Ltd.
Cygnet House, Sydenham Road
Croydon, Surrey CR0 2EE, UK
(Phone) [phone]
(Fax) [phone]
(email) [e-mail]
(web) www.TeeterLtd.com
Traction Stretch - Push
Users can obtain a
more aggressive
stretch and greater
joint decompression
Back Extensions
Users can strengthen their
lower back, glutes and
hamstrings
Crunches
Users can achieve a
great workout for their
abs and obliques
DEX IITM User Manual LD-2000 Pg. 4
