TEFAL RK705 User manual

EN
www.tefal.com
10-in-1 multicooker

15
6
7
9
2
3
4
17
14
13 11
12
15
16
10
8
4567
12 13 14 15
16
a
b
17
a
b
18 19
1 2 3b3a
MAX.
10cups
8 9 1110
10
cups
MAX.

15
6
7
9
2
3
4
17
14
13 11
12
15
16
10
8
4567
12 13 14 15
16
a
b
17
a
b
18 19
1 2 3b3a
MAX.
10cups
8 9 1110
10
cups
MAX.

13a
14a
14b
14c
14d
14e
14f
14g
14h
13b
13c
13d
13e
13f
CONTROL PANEL

1
EN
IMPORTANT SAFEGUARDS
SAFETY INSTRUCTIONS
Read these instructions for use carefully before
using your appliance for the first time and keep
them to hand for future reference.
• This appliance can be used by children aged
from 8 years and above if they have been
given supervision or instruction concerning
use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and
user maintenance shall not be made by children
unless they are older than 8 years and supervised.
Keep the appliance and its cord out of reach of
children aged less than 8 years.
• Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that
they do not play with the appliance.

2
• As this appliance is for household use only, it is
not intended for use in the following applications
and the guarantee will not apply for:
–Staff kitchen areas in shops, offices and other
working environments
–Farm houses
–By clients in hotels, motels and other residential
type environments
–Bed and breakfast type environments
• If your appliance is fitted with a removable
power cord: if the power cord is damaged, it must
be replaced by a special cord or unit available
from an authorised service centre.
• If your appliance is fitted with a fixed power
cord: if the power supply cord is damaged, it
must be replaced by the manufacturer, the
manufacturer’s after-sales service department
or similarly qualified person in order to avoid any
danger.
• The appliance must not be immersed in water or
any other liquid.
• Use a damp cloth or sponge with washing-
up liquid to clean the accessories and parts
in contact with foodstuff. Rinse with a damp
cloth or sponge. Drying accessories and parts in
contact with food with a dry cloth.
• If the symbol is marked on the appliance, this
symbol means “Caution: surfaces may become
hot during use”.

3
EN
• Caution: the surface of the heating element is
subject to residual heat after use.
• Caution: risk of injury due to improper use of the
appliance.
• Caution: if your appliance has a removable
power cord, do not spill liquid on the connector.
• Always unplug the appliance:
–immediately after use
–when moving it
–prior to any cleaning or maintenance
–if it fails to function correctly
• Burns can occur by touching the hot surface of
the appliance, the hot water, steam or the food.
• During cooking, the appliance gives out heat
and steam. Keep face and hands away.
• Do not get face and hands close to the steam
outlet. Do not obstruct the steam outlet.
• For any problems or queries please contact our
Customer Relations Team or consult our web site.
• This appliance is designed for domestic use
only. Any commercial use, inappropriate use
or failure to comply with the instructions, the
manufacturer accepts no responsibility and the
guarantee does not apply.
• The appliance can be used up to an altitude of
4000m.
• For your safety, this appliance complies with the safety regulations and directives
in effect at the time of manufacture (Low-voltage Directive, Electromagnetic
Compatibility, Food Contact Materials Regulations, Environment…).
• Check that the power supply voltage corresponds to that shown on the appliance
(alternating current).

4
• Given the diverse standards in effect, if the appliance is used in a country other
than that in which it is purchased, have it checked by an approved service centre.
Connecting to the power supply
• Do not use the appliance if:
–the appliance or the cord is damaged
–the appliance has fallen or shows visible damage or does not work properly
–In the event of the above, the appliance must be sent to an approved Service
Centre. Do not take the appliance apart yourself.
• Do not leave the cord hanging
• Always plug the appliance into an earthed socket.
• Do not use an extension lead. If you accept liability for doing so, only use an
extension lead which is in good condition, has an earthed plug and is suited to
the power of the appliance.
• Do not unplug the appliance by pulling on the cord.
Using
• Use a flat, stable, heat-resistant work surface away from any water splashes.
• Do not allow the base of the appliance to come into contact with water
• Never try to operate the appliance when the bowl is empty or without the bowl.
• Do not remove the bowl while the appliance is working.
• Do not put the appliance directly onto a hot surface, or any other source of heat
or flame, as it will cause a failure or danger.
• The bowl and the heating plate should be in direct contact. Any object or food
inserted between these two parts would interfere with the correct operation.
• Do not place the appliance near a heat source or in a hot oven, as serious
damage could result.
• Do not put any food or water into the appliance until the bowl is in place.
• Respect the levels indicated in the recipes.
• Should any part of your appliance catch fire, do not attempt to put it out with
water. To smother the flames use a damp tea towel.
• Any intervention should only be made by a service centre with original spare
parts.
Protect the environment
• Your appliance has been designed to run for many years. However, when
you decide to replace it, remember to think about how you can contribute to
protecting the environment.
• Before discarding your appliance you should remove the battery from the timer
and dispose of it at a local civic waste collection centre (according to model).
Environment protection first!
Your appliance contains valuable materials which can be recovered
or recycled.
Leave it at a local civic waste collection point.

5
EN
DESCRIPTION
BEFORE THE FIRST USE
1 Steam basket
2 Graduation marks for water
3 Removable ceramic bowl
4 Measuring cup
5 Rice spoon
6 Soup spoon
7 Lid
8 Removable inner steam shield
9 Micro pressure valve
10 Lid opening button
11 Handle
12 Rice spoon support
13 Control panel
a “KEEP WARM/CANCEL”
b “CRUST/FRY”
c “–”
d “START”
e “MENU”
f “+”
g “DELAYED START”
14 Function indicators
a “RICE/CEREAL” function
b “RISOTTO” function
c “REHEAT” function
d “MILK PORRIDGE” function
e “STEW” function
f “STEAM/SOUP” function
g “YOGURT” function
h “BAKING/DESSERT”
function
15 Housing
16 Heating element
17 Power cord
Unpack the appliance
• Remove the appliance from the packaging and unpack all the accessories
and printed documents.
• Open the lid by pushing the opening button located on the housing –
fig.1.
Read the instructions and carefully follow them.
Clean the appliance
• Remove the bowl – fig.2, the steam shield and the pressure valve –
fig.3a and 3b (see “Cleaning and Maintenance” section for detailed
instructions on removal).
• Clean the bowl, the valve and the steam shield with a sponge and
washing up liquid.
• Wipe the outside of the appliance and the lid with a damp cloth.
• Dry off carefully.
• Put all the parts back in their original position. Install the steam shield in
the correct position on the top of machine. Then, put the steam shield
behind the 2 ribs and push it onto the lid until it’s fixed. Install the
detachable cord into the socket on the cooker base.
• Insert the spoon support on the base of the appliance – fig.4.

6
THE APPLIANCE
PREPARATION BEFORE RICE COOKING
• This multicooker is equipped with 10 multi-functions: Rice/Cereal,
Risotto, Reheat, Milk Porridge, Stew, Steam/Soup, Yogurt, Baking/
Dessert, Crust/Fry, Keep Warm, plus Adjustable Timer and Delayed Start.
• When the power cord is installed into the power outlet and into the
socket on the cooker base, it will make a long “Beep” sound, the digital
screen and indicator lights will flash once, then the digital screen will
display “--”. It indicates the appliance has entered the standby mode
and is ready for function selection.
• At the end of the cooking period, the appliance will automatically switch
over to keep warm which will last up to 24 hours.
• Do not clean the bowl or the body of the appliance in the dishwasher.
• Do not touch the heating element when the product is connected or
after cooking.
• Do not carry the product when in use or just after cooking.
Measuring the ingredients - Max capacity of the bowl
• The graduated markings on the inside of the bowl are given in litres and
cups, these are used for measuring the amount of water when cooking rice.
• The plastic measuring cup provided with your appliance is for measuring
rice and not water. 1 level measuring cup of rice weighs about 160 g.
• Users may reduce or increase the water quantity according to the type
of rice and their preference for firm or soft texture rice.
• Fluctuations in the household mains supply, can cause voltage variations
when operating the product, this may result in slight spill over of rice and
water on the higher capacity settings, and is a normal phenomenon.
• The maximum quantity of water + rice should not exceed the highest
mark inside the bowl.
Never add ingredients or water higher than the highest level mark.
When cooking rice
Note: Always add the rice first, not the water, otherwise you will have
too much liquid which may cause overflows during use.
• Before cooking, measure the rice with the measuring cup and rinse it
very well.
• Put the rinsed rice into the bowl and distribute evenly around the whole
surface of the bowl. Fill it with water to the corresponding CUP mark
printed on the inside of the bowl (see cooking guide).
