Teknion Navigate Power Pole Mid HNBEPP M Operating and maintenance instructions

Navigate Power Pole - Mid (HNBEPP_M), Navigate Power Pole Single Sided - Mid (HNBEPP_S), Navigate Ceiling
Feed (HNBECF) & Navigate Chicago Ceiling Feed (HNBECF)
Section: Page No:
Date:
Rev. No: 02
ELECTRICS
May 2022 1 of 9
HABN_322b
height-adjustable bench Installation Guides
NOTE: HNBEPP_M is
shown as an example.
A
B5G
B3
B1
B2
B4
B5F
B5A

Part and Product Identification
Section: Page No:
Date:
Rev. No: 02
ELECTRICS
May 2022 2 of 9
HABN_322b
height-adjustable bench Installation Guides
A - Ceiling Feed OR Chicago
Ceiling Feed
(HNBECF or HNBECFCH) x1
OR
OR
OR
B - Power Pole Mid - Standard (HNBEPP_M) OR Power Pole Mid Single-Sided (HNBEPP_S) x1
B5 - Hardware Kit For Navigate Height Adjustable Bench Power Pole (X01-4349) x1
B1 - Upper Pole Body
(AEA21-0200-ECPQ72) x1
B2 - Lower Pole Body
(AEA21-0200-09) x1
B3 - Upper Pole Cover
(AEA23-E014-ECPQ72) x1
B4 - Lower Pole Cover
(AEA23-E014-10) x1
B5A - HAB Mid Mounting Bracket
OR HNB SS Power Pole Bracket
(MPA15-E786 OR MPA16-E064) x1
B5B - 1/4-20 5/8" Long Screw OR SHCS
1/4-20 X 1"
(FS1/4-20-5/8RPM) x6 OR
(FS1/4-20x1AC) x1
B5C -Thumb Screw Knob (SS only)
(FMKNOB 3/4) x1
B5D -#8-5/8" Quad Drive
(FS8-5/8RRB) x6
B5F -Bracket to Extend Height of Pole
(MPA15-E152) x1
B5G -Ceiling Plate
(MPA15-2666) x2
B5I -4 Prong Tee Nut
(FN8-32x7/16T4) x2
B5H -#8-32 x3/4 QD RD HD Screw
(FS8-32X3/4QRZ) x2
B5J -Snap Cap
(FM315-902) x2
B5E - Plastic Wire Tip/Cap
(PCAPLUG8) x4

STEP 2a: After installing Mid-Gable, attach and align Lower Power Pole to Connecting Bracket
as shown
STEP 1a: Install Connecting Bracket to the Underside of the Stretch Bar
Section: Page No:
Date:
CONNECT BRACKET ASSEMBLY (STANDARD) ATTACH LOWER EXTRUSION (STANDARD)
HABN_322b
3 of 9
May 2022
ELECTRICS
height-adjustable bench Installation Guides
B5B
B5A
B2
NOTE: Install Connection
Bracket then proceed Mid-
Gable Installation
NOTE: Cable Channels
hidden for illustration
NOTE: Cable Channels
hidden for illustration

STEP 2b: After installing Mid-Gable, attach and align Lower Power Pole to Connecting
Bracket as shown
STEP 1b: Install Mounting Bracket on the Frame Link. Secure it by fastening the Thumb Screw
Section: Page No:
Date:
MOUNT CONNECTING BRACKET (SINGLE SIDED) ATTACH LOWER EXTRUSION (SINGLE SIDED)
HABN_322b
4 of 9
May 2022
ELECTRICS
height-adjustable bench Installation Guides
B2
B5A
B5B
B5C

STEP 4: Mark Power Pole position on the cieling using Plum Bob line. Cut 3-1/2" x3-1/2"
opening. Measure Distance from top of the Lower Power Pole Extrusion to the Ceiling. Add
approx. 3" to that dimension and cut Power pole Cover to that measurement.
STEP 3: Fasten Bracket to Lower Power Pole Body
Section: Page No:
Date:
SECURE BOTTOM EXTRUSION CEILING CUT OUT
HABN_322b
5 of 9
May 2022
ELECTRICS
height-adjustable bench Installation Guides
B5D
3-1/2"
3-1/2"
Power Pole Length = distance +3"
NOTE: Frame Legs hidden
for illustration

STEP 6: Drop Ceiling Feed cable down through ceiling Cut-out down along the Power Pole
Slide junction box Inside the Power Pole Extrusion
STEP 5: Insert Upper Power Pole Extrusion inside Ceiling Cut-Out (Uncut edge down).
Drop Power Pole Upper Extrusion on the Top of Lower Extrusion and Connect them
together using Connection Plate and Screws with Caps on other side of pole from Screws
Section: Page No:
Date:
INSTALL UPPER EXTRUSION CEILING FEED ASSEMBLY
HABN_322b
6 of 9
May 2022
ELECTRICS
height-adjustable bench Installation Guides
NOTE: Cable Channel
hidden for illustration
B1
B5F
B5E
B5D

Section: Page No:
Date:
CABLE MANAGEMENT
May 2022 7 of 9
HABN_322b
ELECTRICS
height-adjustable bench Installation Guides
STEP 7: Open Mid-Gable Top Cover and Connect Ceiling Feed to fish Cable thru underside of Cable Channel
NOTE: Cable Channel
hidden for illustration Cable Channel

STEP 9: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole
Extrusion
STEP 8: Tuck cable and attach Power Pole Covers by engaging them into Lower Extrusion
Section: Page No:
Date:
ATTACH LOWER COVER ATTACH UPPER COVER
HABN_322b
8 of 9
May 2022
ELECTRICS
height-adjustable bench Installation Guides
NOTE: Cable Channel, Leg, and
Cable hidden for illustration
B4
B3

STEP 11: Push T-nuts inside holes from the Top of the ceiling tile. Wrap cover plates around
the Power Pole and fasten using hardware provided.
STEP 10: Attach Ceiling Plates to Power Pole under the Ceiling. Drill holes for T-nuts using
Ceiling Plates as a template to determine location.
Section: Page No:
Date:
ATTACH CEILING PLATE THEN DRILL HOLES SECURE PLATES
HABN_322b
9 of 9
May 2022
ELECTRICS
height-adjustable bench Installation Guides
B5I
B5J
B5H
B5G
WARNING:Don't connect to power source
until installation is complete. All wire
connections must be performed by a licensed
electrician in accordance with applicable codes
and regulations. Not following these instructions
could result in damge and /or injury.
