What is Untethered 3
Why Lithium Iron Phosphate 4
Battery Management System 4
Product Map 5
Safety Instructions 6
Using Untethered Components 11
Untethered Battery and Chargers 11
Untethered Furniture Adapter 13
Untethered Mobile Power Post 16
Untethered Media Rover 18
Determining Battery Requirements 21
Planning with Low Usage 23
Planning with High Usage 24
Troubleshooting 25
FAQ 26

untethered | user guide
3
09.25.2023
what is untethered
Untethered is a exible workplace solution that gives teams the freedom to collaborate anywhere.
With the Untethered swappable battery system, you can localize power to your furniture, giving you
full control over where and how you work.
At the heart of this solution is the Untethered battery. e rechargeable lithium iron phosphate battery contains no nickel or cobalt,
which makes it near impossible to ignite in the event of mishandling. e battery also has a built-in electronic Battery Management
System, making it one of the safest and most ecient batteries on the market. With a 245Wh capacity, it can power an average laptop
with a power draw between 50-80W for 3-5 hours.
Charging is fast and easy with Untethered Mobile Charging Cart and Untethered Desktop Battery Charger. Charge up to 3 or 6
Untethered batteries simultaneously with a maximum charging time of 2-3 hours to full battery capacity. e Untethered Mobile
Charging Cart draws up to 250W at 120VAC per 3 charging bays. It can be plugged into a typical North American 120V wall outlet
without worrying about overage with a maximum of 12 batteries per single circuit.
Bring power with you in two ways: on its own with Untethered Mobile Power Post or mounted to movable furniture with Untethered
Furniture Adapter. Both Untethered Mobile Power Post and Untethered Furniture Adapter translate power from Untethered battery
into ready to use formats.
Swapping batteries is fast and easy. No need to wait for batteries to charge, just swap for a fresh one.

untethered | user guide
4
09.25.2023
why lithium iron phosphate
Lithium iron phosphate (LFP) batteries are a powerful and long-lasting energy solution for mobile and stationary power needs. With
exceptional safety and reliability, these batteries are ideal for a wide range of applications, from providing exible power in agile work
environments to being used as backup power systems. ey are a better option than lead-acid batteries for the environment because
they do not contain heavy metals or other toxic substances. Lithium iron phosphate batteries are also less likely to release toxic gasses
or ignite thanks to their chemistry, which further reduces their impact on the environment.
e primary benet of lithium iron phosphate batteries over other types of lithium-ion batteries is the cathode material. In extreme
temperatures, iron phosphate cathode is more stable and less reactive than the cobalt or nickel-based cathodes used in other lithium-ion
batteries. Iron phosphate cathode also produces a phosphorus-oxygen bond, a stronger molecular bond than the metal-oxygen bond in
other cathode materials. is bond hinders the release of oxygen and requires more energy and a higher on-set temperature for thermal
runaway. is makes lithium iron phosphate batteries safer (more stable when stored at full charge) and less prone to overheating or
catching re.
battery management system
Untethered's built-in Battery Management System (BMS) manages the charging and discharging of the battery, while continuously
monitoring its health to ensure safe and reliable operation. is system helps maximize the lifespan of the battery, allowing it to have
a long life cycle and an industry-leading 5year warranty.
Safety Features:
• Solid state sensors and state-of-the-art electronics keeps battery charging balanced throughout charge cycles, extending the life and
performance of the batteries over time
• Monitors rate of charge with built-in power surge protection
• Monitors temperature of individual cells in the battery pack to prevent overheating during operation and while charging
• Temperature controlled fan for high eciency

untethered | user guide
5
09.25.2023
untethered product map
Untethered Mobile Charging Cart,
ree Charging Bays
YUNMC03
Untethered Mobile Charging Cart,
Six Charging Bays
YUNMC06
Untethered Desktop Battery Charger
YUNDC
Untethered Battery
YUNBA
Untethered Expansion Training
Rectangular Flip-Top Table
YUNFT
Untethered Mobile Power Post
YUNMP
Untethered Navigate Table Base Only
(Counterbalance)
YUNAH
Untethered Media Rover
YUNMS

untethered | user guide
6
09.25.2023
safety instructions
untethered battery
Read before operating the unit to prevent personal injury or damage to the unit.
Untethered Battery DTG-P1-NA-1XP-S0: Swappable Battery Pack has been tested and certied to meet or exceed the requirements within
UN ST/SG/AC.10/11/Rev 6. Manual of Tests and Criteria, Part III sub section 38.3 and IEC 62133:2012.
e guidelines provided below have been evaluated as "Means of Operator Protection (MOOP)".
1. To reduce the risk of re or electric shock, DO NOT OPEN battery. ere are no user-serviceable parts inside.
2. For service or repair, contact your Dealer to initiate return process.
3. For indoor use only.
4. Keep the unit away from moisture and water.
5. Secure the unit in a location where children are not likely to be present.
CAUTIONS:
• e battery does not have an ON/OFF switch. Remove the Untethered battery from Untethered Furniture Adapter or Untethered
Mobile Power Post when not in use as it will drain 0.5A from the battery even if no load is connected.
• When the voltage of the Untethered battery connected to the Untethered Furniture Adapter falls below 11.5V, its output will
switch OFF.
• During the battery swapping process, there will be a temporary interruption in the power output. As a result, the device(s) being
powered may turn o or switch to its internally stored battery power. It is recommended to have spare batteries charged and ready
to replace the depleted battery to minimize any potential downtime.

untethered | user guide
7
09.25.2023
safety instructions
untethered furniture adapter
Read before operating the unit to prevent personal injury or damage to the unit.
e guidelines provided below have been evaluated as "Means of Operator Protection (MOOP)".
1. To reduce the risk of re or electric shock, DO NOT OPEN Furniture Adapter. ere are no user-serviceable parts inside.
2. For service or repair, contact your Dealer to initiate return process.
3. For indoor use only.
4. To reduce the risk of electric shock, remove battery from furniture adapter before attempting any maintenance or cleaning.
5. Place the furniture adapter in an area with unobstructed air ow . DO NOT block or obstruct vent openings.
6. Keep the unit away from moisture and water.
7. Secure the unit in a location where children are not likely to be present.
8. e maximum power output from the Furniture Adapter cannot exceed 120W.
CAUTIONS:
• e battery does not have an ON/OFF switch. Remove the Untethered battery from Untethered Furniture Adapter or Untethered
Mobile Power Post when not in use as it will drain 0.5A from the battery even if no load is connected.
• When the voltage of the Untethered battery connected to the Untethered Furniture Adapter falls below 11.5V, its output will
switch OFF.
Overload and short circuit
• If the load exceeds 120W, the output voltage will gradually decrease; however, the system will NOT shut down. Disconnect all
devices to reset Furniture Adapter. e unit will turn back on once the devices are removed.
• In the event of a catastrophic electrical short, the system may not be able to reset and will need to be serviced. Contact your dealer
to initiate return/replacement process.
Over temperature due to fan failure or due to lack of cool replacement air
• e unit will shut down if temperature exceeds 105°C.
• e unit will reset automatically on cooling.
Cooling
• e Furniture Adapter has a temperature controlled fan for cooling.
• e fan will start once the temperature inside the unit exceeds 70°C / 158°F.
• In the event of a fan malfunction or insucient cool air circulation, the temperature of the unit will steadily increase. If it reaches
or exceeds 105°C/221°F, the AC output will shut down automatically as a safety measure. Once the unit cools down to an
acceptable level, the AC output will resume functioning.
• Place the unit in a cool, well ventilated space that has adequate cool replacement air.

untethered | user guide
8
09.25.2023
safety instructions
untethered mobile power post
Read before operating the unit to prevent personal injury or damage to the unit.
e guidelines provided below have been evaluated as "Means of Operator Protection (MOOP)".
1. To reduce the risk of re or electric shock, DO NOT OPEN Mobile Power Post. ere are no user-serviceable parts inside.
2. For service or repair, contact your Dealer to initiate return process.
3. For indoor use only
4. To reduce the risk of electric shock, remove battery from Mobile Power Post before attempting any maintenance or cleaning
5. Place the furniture adapter in an area with unobstructed air ow . DO NOT block or obstruct vent openings.
6. Keep the unit away from moisture and water
7. Secure the unit in a location where children are not likely to be present.
8. e maximum power output from the Mobile Power Post cannot exceed 120W.
CAUTIONS:
• e battery does not have an ON/OFF switch. Remove the Untethered battery from Untethered Furniture Adapter or Untethered
Mobile Power Post when not in use as it will drain 0.5A from the battery even if no load is connected.
• When the voltage of the Untethered battery connected to the Untethered Furniture Adapter falls below 11.5V, its output will
switch OFF.
Overload and short circuit
• If the load exceeds 120W, the output voltage will gradually decrease; however, the system will NOT shut down. Disconnect all
devices to reset Mobile Power Post. e unit will turn back on once the devices are removed.
• In the event of a catastrophic electrical short, the system may not be able to reset and will need to be serviced. Contact your dealer
to initiate return/replacement process.
Over temperature due to fan failure or due to lack of cool replacement air
• e unit will shut down if temperature exceeds 105°C.
• e unit will reset automatically on cooling.
Cooling
• e Mobile Power Post has a temperature controlled fan for cooling
• e fan will start once the temperature inside the unit exceeds 70°C / 158°F
• In the event of a fan malfunction or insucient cool air circulation, the temperature of the unit will steadily increase. If it reaches
or exceeds 105°C/221°F, the AC output will shut down automatically as a safety measure. Once the unit cools down to an
acceptable level, the AC output will resume functioning
• Place the unit in a cool, well ventilated space that has adequate cool replacement air

untethered | user guide
9
09.25.2023
safety instructions
untethered desktop charger
Read before operating the unit to prevent personal injury or damage to the unit.
MPower Battery Charger in Untethered Desktop Charger is TÜV Rheinland listed as a Recognized Component conforming to CAN/
CSA-C22.2 No. 60601-1:14. Complies with FCC Part 15(A).
1. Untethered Battery is the only compatible battery to charge using this product.
2. To reduce the risk of re or electric shock, DO NOT OPEN Desktop Charger. ere are no user-serviceable parts inside.
3. For service or repair, contact your Dealer to initiate return process.
4. For indoor use only.
5. To reduce risk of damage to electric plug and cord, pull by plug rather than cord when disconnecting the unit.
6. An extension cord should not be used.
7. Keep the unit away from moisture and water.
8. Secure the unit in a location where children are not likely to be present.
CAUTIONS:
• e unit has no ON/OFF switch. It will switch ON automatically after plugging in AC power.
• e unit only outputs when Untethered Batteries with the corresponding pin connector engage with the pins in the charging bay.

untethered | user guide
10
09.25.2023
safety instructions
untethered mobile charging cart
Read before operating the unit to prevent personal injury or damage to the unit.
MPower Battery Charger in Untethered Mobile Charging Cart is TÜV Rheinland listed as a Recognized Component conforming to CAN/
CSA-C22.2 No. 60601-1:14. Complies with FCC Part 15(A).
1. Untethered Battery is the only compatible battery to charge using this product.
2. To reduce the risk of re or electric shock, DO NOT OPEN Mobile Charging Cart. ere are no user-serviceable parts inside.
3. For service or repair, contact your Dealer to initiate return process.
4. For indoor use only.
5. To reduce risk of damage to electric plug and cord, pull by plug rather than cord when disconnecting the unit.
6. An extension cord should not be used.
7. Keep the unit away from moisture and water.
8. Secure the unit in a location where children are not likely to be present.
CAUTIONS:
• e unit has no ON/OFF switch. It will switch ON automatically after plugging in AC power.
• e unit only outputs when Untethered Batteries with the corresponding pin connector engage with the pins in the charging bay.
• Avoid outdoor placement. e unit is not water-resistant.

untethered | user guide
11
09.25.2023
Ergonomic Top Handle
Push Button for Battery Life Indicator
Battery Life Indicator
State of Charge Indicator
Alignment Slots
3
4
5
3
4
5
2
1
1
2
100%
80%
60%
40%
20%
push button for battery life indicator
untethered battery and chargers
state of charge indicator
Green light:
Battery Fully Charged
Amber light:
Battery Charging
Battery will make a chirping sound
when charge level drops below 5%.
To check the battery for available
power, briey press the soft
rectangular push button near the
top of the battery. e number of
LED bars indicate the amount of
charge remaining in the battery.

untethered | user guide
12
09.25.2023
1
Verify that either your Desktop
Charger or Mobile Charging Cart
is securely connected to the wall
power outlet.
2
Grasp the battery rmly using the
handle located at the top. Gently
and gradually, lower the battery into
the charging bay.
4
Once the battery is inserted into
the charging bay, the LED status
light on the battery will illuminate
in an amber hue. is will persist
for a brief period. Subsequently, the
Battery Life Indicator will begin
to emit a pulsating light pattern.
is display will cycle through a
sequence where the number of lit
LEDs will rotate between 1 to 5 in
a continuous manner.
3
Make sure the slots on each side
of the Battery align with the metal
guides in the battery cradle. is
creates a secure connection between
the metal contacts on the bottom of
the Battery and the connector pins
at the base of the cradle.
5
Upon complete charge of the battery,
all ve LEDs on the Battery Life
Indicator will remain consistently
illuminated, indicating that the
battery is fully charged.
charging untethered battery
Untethered Batteries can be charged with Untethered Mobile Charging Cart or Untethered Desktop Charger.
USE CAUTION!
Lowering the battery too hastily into the battery
cradle can damage the connector pins at the base.
Always handle the battery gently and carefully
when inserting it into the Charger.
IMPORTANT: Read Safety Instructions before operation.

untethered | user guide
13
09.25.2023
powering electrical accessories on
untethered tables
Untethered Expansion Training Rectangular
Flip-Top Table
Untethered Furniture Adapter
(specied separately)
Untethered Battery (specied separately)
3
2
1
1
2
3
Untethered Navigate Table Base Only
(Counterbalance)
Height-Adjustable Worksurface for Navigate
(WBH/WJH) (specied separately)
Untethered Furniture Adapter
(specied separately)
Untethered Battery (specied separately)
Power Qube (YEPQ) (specied separately)
3
4
5
2
1
1
4
2
3
5
untethered expansion training rectangular flip-top table
untethered navigate table base only (counterbalance)
Untethered batteries can serve as the energy source for electrical accessories such as the Power Qube, Power Station, and Port Port.
ese accessories can be seamlessly installed on any Untethered Table by connecting them to the Untethered Furniture Adapter.
e Untethered Furniture Adapter is an integral part of this setup, hosting an inverter within its design. e inverter convert the Direct
Current (DC) that is provided by the Untethered battery into Alternating Current (AC) in a format that is compatible with standard
North American plug congurations.

untethered | user guide
14
09.25.2023
e maximum output of the Furniture Adapter is 120W. To avoid overloading the
system, electrical congurations with no more than 2 AC outlets, 1 USB-A and
1USB-C are recommended.
connecting electrical accessories to untethered furniture adapter
1
Remove mesh cover from
Untethered Furniture Adapter.
2
Plug electrical accessory into
the AC outlet located on top of
the inverter. Carefully guide the
accessory’s cable and secure it to
the wire clip inside the Untethered
Furniture Adapter.
3
Reattach the mesh cover to the
adapter, ensuring the accessory cable
is guided through the designated
opening on the mesh cover.
Do not connect any combination of electrical
accessories or devices that collectively exceed a
power rating of 120W. Exceeding this limit will
result in a blown fuse and potential damage to
equipment.
CQAMP
Routes Power Port
2 AC
YEPQ
Power Cube
1 AC, 2 USB
YEPQ
Power Cube
2 AC
YEPQ
Power Cube
2 AC, 4 USB
YEPQ
Power Cube
3 AC, 2 USB
CQAMP
Routes Power Port
3 AC
IMPORTANT: Read Safety Instructions before operation.

untethered | user guide
15
09.25.2023
powering electrical accessories on untethered tables through the
untethered furniture adapter
1
Conrm the charge status of the
Untethered Battery by pressing
the button for the Battery Life
Indicator.
2
Conrm that the combined power
requirement of the devices you
intend to use does not exceed 120W.
4
Make sure the slots on each side
of the Battery align with the metal
guides in the battery cradle. is
creates a secure connection between
the metal contacts on the bottom
of the Battery and the connector
pins at the base of the cradle.
e Battery Life Indicator will
illuminate when the Battery has
been correctly engaged.
3
Grasp the battery rmly using the
handle located at the top. Gently
and gradually, lower the Untethered
Battery into the battery cradle at the
front of the Furniture Adapter.
5
Return Untethered Battery to either
Untethered Desktop Charger or
Untethered Mobile Charging Cart
at the end of the day or when power
is no longer needed.
USE CAUTION!
Lowering the Untethered Battery too hastily
into the battery cradle can damage the
connector pins at the base. Always handle the
Battery gently and carefully when inserting it
into the Furniture Adapter.
e Untethered Battery doesn’t have an ON/OFF switch. For optimal performance and to prolong its lifespan, detach it
from the Furniture Adapter when it’s not in use, even if no devices are connected. is simple step can help ensure your
battery remains in great condition for an extended period.
IMPORTANT: Read Safety Instructions before operation.

untethered | user guide
16
09.25.2023
Untethered Mobile Power Post
Untethered Battery (specied separately)
Battery Cradle
2
2
1
1
untethered mobile power post
e Mobile Power Post provides portable, convenient, on-the-go charging for laptops, mobile devices and more. It has one power
outlet, one USB-A and one USB-C port.
3
3

untethered | user guide
17
09.25.2023
4
Make sure the slots on each side
of the Battery align with the metal
guides in the battery cradle to create
a secure connection between the
metal contacts on the bottom of the
Battery and the connector pins at the
base of the cradle. e Battery Life
Indicator will illuminate when the
Battery has been correctly engaged.
6
Return Untethered Battery to either
Untethered Desktop Charger or
Untethered Mobile Charging Cart
at the end of the day or when power
is no longer needed.
3
Grasp the battery rmly using the
handle located at the top. Gently
and gradually, lower the battery into
the battery cradle at the front of the
Mobile Power Post.
5
Connect your devices to the AC
Outlets and/or USB ports at the top
of the Mobile Power Post.
USB-A
Output
USB-C
Output
USB-A only 5W –
USB-C only – 20W
USB-A + USB-C 5W 15W
1
Conrm the charge status of the
Untethered Battery by pressing
the button for the Battery Life
Indicator.
2
Conrm that the combined power
requirement of the devices you
intend to use does not exceed 120W.
powering electrical accessories with the untethered mobile power post
e Untethered Battery doesn’t have an ON/OFF switch. For optimal performance and to prolong its lifespan, detach it
from the Mobile Power Post when it’s not in use, even if no devices are connected. is simple step can help ensure your
battery remains in great condition for an extended period.
IMPORTANT: Read Safety Instructions before operation.

untethered | user guide
18
09.25.2023
Untethered Media Rover
Untethered Furniture Adapter (specied separately)
Untethered Battery (specied separately)
3
32
2
1
1
untethered media rover
e Untethered Media Rover creates an interactive digital experience between present and remote workers. Powered by Untethered
batteries, it can be moved around freely without being conned by wall power access.

untethered | user guide
19
09.25.2023
Refer to Routes Media Rover
Installation Guide TRO_412 for
instructions on how to attach
Monitor to Untethered Media Rover.
 
4
Reattach the mesh cover to the
adapter, ensuring the accessory cable
is guided through the designated
opening on the mesh cover.
3
Connect power plug of Monitor
into the AC outlet located on top
of the inverter. Carefully guide the
accessory's cable and secure it to
the wire clip inside the Untethered
Furniture Adapter.
1
Conrm that the power requirement
of the monitor you intend to use
does not exceed 120W.
2
Remove mesh cover from
Untethered Furniture Adapter.
connecting the monitor to the untethered furniture adapter
IMPORTANT:
Do not connect any combination of monitor and/or
devices that collectively exceed a power rating of 120W.
Exceeding this limit will result in a blown fuse and
potential damage to equipment.
IMPORTANT: Read Safety Instructions before operation.

untethered | user guide
20
09.25.2023
powering the untethered media rover
1
Conrm the charge status of the
Untethered Battery by pressing
the button for the Battery Life
Indicator.
2
Grasp the battery rmly using the
handle located at the top. Gently
and gradually, lower the Untethered
Battery into the battery cradle at the
front of the Furniture Adapter.
4
Return Untethered Battery to either
Untethered Desktop Charger or
Untethered Mobile Charging Cart
at the end of the day or when power
is no longer needed.
3
Make sure the slots on each side
of the Battery align with the metal
guides in the battery cradle. is
creates a secure connection between
the metal contacts on the bottom
of the Battery and the connector
pins at the base of the cradle.
e Battery Life Indicator will
illuminate when the Battery has
been correctly engaged.
e Untethered Battery doesn’t have an ON/OFF switch. For optimal performance and to prolong its lifespan, detach it
from the Furniture Adapter when it’s not in use, even if no devices are connected. is simple step can help ensure your
battery remains in great condition for an extended period.
USE CAUTION!
Lowering the Untethered Battery too hastily into the
battery cradle can damage the connector pins at the
base. Always handle the Battery gently and carefully
when inserting it into the Furniture Adapter.
IMPORTANT: Read Safety Instructions before operation.
