Teknion LEDGER PLUS Operating and maintenance instructions

Bullet Worksurface (PLSW), Pedestal Leg (PLSP), Worksurface Reinforcement
Channel (PLRC)
Part and Product Identification
0
Section:
Description: Page No:
Date:
Rev. No: 1
PEDESTAL LEG & REINFORCEMENT CHANNEL - SEMI-SUPPORTED WORKSURFACES
LEDGER PLUS
Sept 2019 1 of 5
TFF_404c
filing and storage Installation Guides
A - Semi Supported Bullet
Worksurface (PLSW) x1
B1 - Pedestal Leg Assembly
(N80-67019) x1
B2 - Casual Table Base Shell
(A15-8719) x1
B3 - Base Assembly
(N80-67003) x 1
B4 - 1/4-20 x 5/8", Machine
Screw Quad Thuss HD
(E01-0098) x12
B5 - Screw Flat HD Sock Cap
3/8-16 x1-1/2"
(E01-0643) x5
C - Worksurface Reinforcement
Channel (PLRC) xQty varies
D - #10 x 0.875" Screw, Quad
Pan Washer
(E07-0077) xQty varies.
B- Pedestal Leg (PLSP) x1
A
C
B

STEP 2: Using a Wrench, turn the Hex Bolt clockwise or counter-clockwise to raise or lower
the base to the appropriate height.
NOTE: Please refer to next page and Specification Drawing for the height of the Pedestal Leg.
STEP 1: Align Pedestal Leg Assembly, Casual Table Base shell and Base Assembly holes.
Secure in place with screws.
Section:
Description: Page No:
Date:
ASSEMBLE LEG ATTACH LEG TO WORKSURFACE
TFF_404c
2 of 5
Sept 2019
PEDESTAL LEG & REINFORCEMENT CHANNEL - SEMI-SUPPORTED WORKSURFACES
LEDGER PLUS
filing and storage Installation Guides
B3
B5
B2
B1
Hex Bolt
B
Wrench

STEP 4: Place Leg on Worksurface, align Worksurface and Leg Assembly holes. Secure in place
with screws.
STEP 3: Measure the height of the Pedestal and adjust the Pedestal Leg to the same height.
Section:
Description: Page No:
Date:
ASSSEMBLE LEG WITH PEDESTAL ATTACH LEG TO WORKSURFACE
TFF_404c
3 of 5
Sept 2019
PEDESTAL LEG & REINFORCEMENT CHANNEL - SEMI-SUPPORTED WORKSURFACES
LEDGER PLUS
filing and storage Installation Guides
Align
Pedestal
B
B4 A

Section:
Description: Page No:
Date:
WORKSURFACE REINFORCEMENT CHANNEL INSTALLATION
Sept 2019 4 of 5
TFF_404c
PEDESTAL LEG & REINFORCEMENT CHANNEL - SEMI-SUPPORTED WORKSURFACES
LEDGER PLUS
filing and storage Installation
Guides
STEP 5: Align Worksurface Reinforcement Channel and Worksurface holes. Secure Channel in place with screws.
D
C
ADIM L>=48
DIM >=40"
D/2
DIM <=36"
DIM L>=54 D/2
NOTE: Length of Reinforcement Channel is L-6"
NOTE: Length of Reinforcement Channel is L
(then rounded to Standard length)
BOTTOM VIEW

Section:
Description: Page No:
Date:
SECURE THE WORKSURFACE
Sept 2019 5 of 5
TFF_404c
PEDESTAL LEG & REINFORCEMENT CHANNEL - SEMI-SUPPORTED WORKSURFACES
LEDGER PLUS
filing and storage Installation
Guides
STEP 6: Assemble the Worksurface with the Pedestal.
NOTE: For complete Installation refer to Installation Guide TFF_403a.
Mounting Holes
Cabinet Top View
Bar Height Drawer Cabinet-Elevated
(PLDBE) used for demonstration
