Teknion HNBCCSMN User manual

Section:
Date: Aug 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Rev. 01
Page: 1 of 5
HABN_223d
1.1
1.2.2
1.2.1
2.1 2.2
Navigate End Screen Cover - Metal (HNBCCSMN), Navigate End of Run Screen (HNBTEF)

Section:
Date: Aug 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Rev. 01
Page: 2 of 5
HABN_223d
ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY.
1. Navigate End of Run Fabric Screen (HNBTEF) x1
1.1 NAVIGATE END OF RUN FABRIC SCREEN HNBTEF-X 1
1.2. FABRIC END SCREEN MOUNTING BRKT KIT, DOUBLE SIDED, HAB ( X06-0620) x1
1.2.1 END SCREEN BRKT ASSY, INNER, HAB N09-9090 2
1.2.2 END SCREEN BRKT, OUTER, HAB A16-7728 2
1.2.3 1/4-20X5/8" MACH SCR, BLACK, QUAD,TRUSS E01-0113 12
2. FABRIC END SCREEN MOUNTING BRKT KIT, DOUBLE SIDED, HAB (X06-0620) x1
2.1 TOP COVER FOR END SCREEN COVER, HNB A16-7441\72 1
2.2
INSIDE COVER FOR END SCREEN COVER, DOUBLE SIDED,
HNB
A16-7749\72 1
Part & Product Identification

Section: SCREENS & GABLES
Date: Aug 2019
height-adjustable bench
Installation Guides
Page: 3 of 5
HABN_223d
1.2.2
1.2.3
1.1
NOTE: Ensure the Screen is leveled.
1.2.3
1.2.1
ATTACH BRACKETS TO SCREEN
STEP 1: Attach Outer Brackets to Screen using Screws provided. STEP 2: Attach Inner Brackets to Frame using Screws provided.
ATTACH BRACKETS TO FRAME

Section:
Date: Aug 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Page: 4 of 5
HABN_223d
2.2
1.2.2
1.2.1 1.2.3
NOTE: If the screen is tilted forwards or
backwards, the slots in the Outer/Inner brackets
allow the screen to be rotated
NOTE: Support Bracket ships with
Cable Channel. For Cable Channel
installation procedures, please refer
to guide HABN_223a/223b
ATTACH SCREEN TO FRAME
STEP 3: Attach End Screen to Frame by first aligning Brackets, and then securing them using
Screws provided.
STEP 4: Slide Cable Channel Support Bracket into Inside Cover, making sure holes align.
Bring Inside Cover and Support Bracket together, and place them on the Frame Stretched
Bar
PLACE END COVER & BRACKET ON FRAME BAR

Section:
Date: Aug 2019
SCREENS & GABLES
height-adjustable bench
Installation Guides
Page: 5 of 5
HABN_223d
2.2
2.1
NOTE: Parts of the Frame are
hidden for Illustration purpose.
INSTALL END COVER
STEP 5: Secure Inside Cover in place using Support Bracket screws STEP 6: Place Top Cover on top of Inside Cover
PLACE TOP COVER IN POSITION
