Tektronix WFM200BA User manual

xx
Safety Summary
Review the following safety precautions to avoid injury and
prevent damage to this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Retain product literature. Retain the original product
information for future reference.
To Avoid Fire or Personal Injury
Do not operate with suspected failures. If you suspect there
is damage to the battery, charger, or power supply, have it
inspected by qualified service personnel.
Recharge battery pack properly. Recharge the battery pack
only for the recommended charge cycle at the recommended
temperature.
Replace battery pack properly. Replace the battery pack only
with the specified type and rating.
Use proper battery charger. Use only the WFM2200 waveform
monitor or the WFM200BC battery charger to charge the
WFM200BA battery pack.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Safety Terms in This Manual
CAUTION. These statements identify conditions or practices
that could result in damage to the equipment or other
property.
Safety Symbols and Terms on the Product
DANGER indicates an injury hazard immediately accessible as
you read the marking.
WARNING indicates an injury hazard not immediately
accessible as you read the marking.
CAUTION indicates a hazard to property including the product.
Battery Recycling
This WFM200BA Lithium-Ion rechargeable battery pack must
be recycled or disposed of properly.
Lithium-Ion batteries are subject to disposal and recycling
regulations that vary by country and region. Always check
and follow your applicable regulations before disposing
of any battery. Contact Rechargeable Battery Recycling
Corporation (www.rbrc.org) for U.S.A. and Canada, or
your local battery recycling organization.
Many countries prohibit the disposal of waste electronic
equipment in standard waste receptacles.
Place only discharged batteries in a battery collection
container. Use electrical tape or other approved covering
over the battery connection points to prevent short circuits.
This symbol indicates that this product complies
with the applicable European Union requirements
according to Directives 2002/96/EC and 2006/66/EC
on waste electrical and electronic equipment
(WEEE) and batteries. For information about
recycling options, check the Support/Service section
of the Tektronix Web site (www.tektronix.com).
Lithium-Ion Battery Transportation
The capacity of the Lithium-Ion rechargeable battery pack in
this product is under 100 Wh. The lithium equivalent content
has been shown to meet the applicable requirements as defined
by the UN Manual of Tests and Criteria Part III Subsection 38.3.
Always check all applicable local, national, and
international regulations before transporting a Lithium-Ion
battery.
Transporting an end-of-life, damaged, or recalled battery
may, in certain cases, be specifically limited or prohibited.
The battery pack must be adequately protected against
short-circuit or damage during transport.
Description
The WFM200BA rechargeable battery pack is intended for use
only with the Tektronix WFM2200 SD/HD/3G SDI Waveform
Monitor & Generator. The battery pack consists of an array
of Lithium-Ion battery cells.
When the battery is installed, an internal circuit monitors the
charge on the battery and reports the condition to either the
WFM2200 waveform monitor or the WFM200BC External
Battery Charger.
When the battery is not installed, you can check the battery
charge level by pressing the Check button on the back of the
battery pack. LEDs illuminate to indicate the amount of charge
in increments of approximately 20%.
Battery Pack Installation
NOTE. For optimum performance, charge the battery pack
completely before using it for the first time or after prolonged
storage.
The battery can be installed, removed, or replaced while the
instrument is turned on and operating with the AC adapter.
1. On the rear panel of the instrument, remove the cover for
the battery compartment:
a. Lift up the battery cover ring.
b. Turn the battery cover ring ¼turn counterclockwise.
c. Lift away the battery cover.
2. Insert the WFM200BA battery pack into the battery
compartment as shown below.
3. Secure the battery pack tab as shown below.
4. Replace the battery compartment cover:
a. Insert the three tabs on the battery cover into the
chassis slots as shown below.
b. Close the battery cover and turn the battery cover ring
¼turn clockwise to secure the cover.
c. Press the battery cover ring down so that it latches
into place as shown below.
Battery Maintenance Guidelines
The WFM200BA Lithium-Ion rechargeable battery pack
requires routine maintenance and care in its use and handling.
Be sure to use the following guidelines to safely use the
WFM200BA Lithium-Ion batteries and achieve the maximum
battery life span.
Battery Pack Considerations
Do not leave a battery unused for an extended period of time,
either in the product or in storage. When a battery has been
unused for six months, check the charge status, and charge or
dispose of the battery as appropriate. See Charging the Battery
Pack and Battery Recycling.
The typical estimated life of a Lithium-Ion battery is about two
to three years, or 300 to 500 charge cycles, whichever occurs
first. One charge cycle is a period of use from fully charged, to
fully discharged, and fully recharged again. You should expect
a two to three year life expectancy for batteries that do not run
through complete charge cycles.
A rechargeable Lithium-Ion battery has a limited life and
will gradually lose its capacity to hold a charge. This loss of
capacity (aging) is irreversible. As the battery loses capacity,
the length of time it will power the product (run time) decreases.
ALith
ium-Ion battery continues to slowly discharge
(self-discharge) when not in use or while in storage. You need
to routinely check the charge status of the battery.
Use the WFM200BA battery pack only in WFM2200
waveform monitor. Use only WFM200BA battery packs in
your WFM2200 waveform monitor.
WFM200BA
Rechargeable Battery Pack
ZZZ
Instructions
x
*P075104101*
075-1041-01

Battery Pack Maintenance
Observe and note the run time that a new fully-charged
battery provides for powering your product. You can
use this new battery run time as a basis to compare run
times for older batteries. The run time of your battery
will vary depending on the product’s configuration and
the applications that you run.
The battery pack gives the best performance when operated
at normal room temperature, 20 °C ±5 °C (68 °F ±9 °F).
Routinely check the charge status of the battery.
Carefully monitor a battery that is approaching the end
of its estimated life.
Consider replacing the battery with a new one if the battery
run time drops below about 80% of the original run time,
or the battery charge time increases significantly.
Follow the storage requirements if you store or do not use
a battery for an extended period. If you do not follow the
storage requirements, and the battery will not power the
waveform monitor when installed, consider the battery
to be damaged. Do not connect power to the waveform
monitor during this time. Remove the battery pack from
the waveform monitor. Do not attempt to recharge or reuse
the battery. Replace it with a new battery.
Battery Pack Charging
The battery pack charges automatically when the waveform
monitor is connected to the external power supply. You can
also charge the battery pack with the Tektronix WFM200BC
External Battery Charger. Remove the battery pack from the
WFM200BC charger when charging is complete.
A Lithium-Ion battery pack will self-discharge during non-use.
To achieve the longest operating time, charge your battery
pack before use. If you plan to store battery packs, read
the instructions in the Battery Pack Storage section of this
document.
When the battery pack is in the WFM2200 waveform monitor,
the battery gauge ( ) on the waveform monitor display
indicates the approximate amount of charge.
To avoid automatic shutdown of the battery pack, only run
the waveform monitor on the battery pack when the gauge
on the waveform monitor is green or yellow.
Always verify the correct placement of the battery in the
WFM2200 waveform monitor or the WFM200BC battery
charger.
When the battery pack is installed in the waveform
monitor, it will automatically charge whenever the
supplied AC adapter is connected, whether the instrument
is On, Off, or in Standby mode.
Configuration Typical charging time
One fully discharged battery pack
charging in the WFM2200 waveform
monitor with the waveform monitor
turned on or off
5.5 hours
One or two fully discharged battery
packs charging in the WFM200BC
external battery charger
5.5 hours
CAUTION. To avoid damage to the battery pack, use only
the WFM2200 waveform monitor or the WFM200BC
battery charger to charge the battery pack. Do not connect
any other voltage source to the battery pack.
NOTE. For optimum performance, charge the battery pack
completely before using it for the first time or after prolonged
storage.
To discharge the battery pack completely, continue to run
the waveform monitor on the battery pack until automatic
shutdown occurs. After the instrument shuts down, either
recharge the battery pack promptly or remove it from the
instrument until you are ready to recharge the battery pack.
NOTE. To prolong the life of the battery pack and to prevent
shutdown, do not operate or charge the battery pack at high
temperatures. For best results, allow the battery pack to cool to
room temperature before using or charging the battery pack.
Do not leave a battery pack discharged for extended periods.
See the Storing Battery Packs section for information on how to
properly store a battery pack.
The battery pack stops charging under the following conditions:
The battery pack is fully charged.
The internal temperature of the battery pack exceeds the
safe charging threshold.
A fault condition occurs.
The battery pack shuts down and disconnects itself from the
WFM2200 waveform monitor under the following conditions:
The battery pack is fully discharged.
The internal temperature of the battery pack exceeds the
safe discharging threshold.
A fault condition occurs.
Battery Pack Handling
Do not disassemble, crush, drop, or puncture the battery.
Do not short the external contacts on the battery.
Do not dispose of the battery in fire or water.
Do not expose the battery to temperatures above +60 °C
(+140 °F).
Seek medical advice if a battery or part of it has been
swallowed.
Do not put battery packs near heat or fire. Do not put in
sunlight.
Keep the battery pack clean and dry. Clean dirty
connectors with a dry, clean cloth.
Batteries contain hazardous chemicals that can cause burns
or explode. If exposure to chemicals occurs, clean with
soap and water and get medical aid. Repair the product
before use if the battery leaks.
Do not attempt to open, modify, reform or repair a battery
pack that appears to be malfunctioning, or which has been
physically damaged.
Keep the battery away from children and animals.
Avoid exposing the battery to excessive shock or vibration.
Do not use a damaged battery or charger.
If a battery pack has leaking fluids, do not touch any
fluids. Dispose of a leaking battery pack. See the
Battery Recycling section for information on disposal and
recycling.
In case of eye contact with fluid, do not rub eyes.
Immediately flush eyes thoroughly with water for at least
15 minutes, lifting upper and lower lids, until no evidence
of the fluid remains. Seek medical attention.
Battery Pack Storage
Store battery packs in a low-humidity environment free of
corrosive gases. Storing battery packs in high-humidity
environments, or outside the temperature range, can
cause oxidation on the metallic parts, increased leakage,
significant aging and premature failure.
Do not store battery packs near heat or fire. Do not store
in the sunlight.
Do not keep battery packs in a place where the terminals
can be shorted by metal objects (for example, coins, paper
clips, or pens).
Do not remove a battery pack from its original packaging
until required for use.
When possible remove the battery pack from the
equipment when not in use.
Charge the battery to approximately 50% of capacity at
least once every six months.
Remove the battery and store it separately from the
instrument. Refer to the WFM2200 User Manual for
instructions on removing and installing the battery.
For optimal battery life, store the battery at temperatures
between +5 °C and +25 °C (+41 °F and +77 °F). Higher
temperatures reduce the battery storage life.
Battery Pack Replacement
Use the instructions to remove and replace battery packs.
NOTE. Replace the Lithium-Ion battery pack only with a
WFM200BA battery pack.
See the Battery Recycling section for information on how to
properly dispose of a Lithium-Ion battery pack.
Specifications
Characteristic Description
Capacity, typical 6.14 Ah
Output, nominal 14.4 VDC
Charging temperature Installed in the WFM2200 waveform
monitor or WFM200BC battery charger:
10 °C to +40 °C (+50 °F to +104 °F);
varies per the WFM2200 heat
dissipation characteristics, the actual
limit may be lower
Operating temperature Installed in the WFM2200 waveform
monitor: 0 °C to +40 °C (+32 °F to
+104 °F)
Storage temperature -20 °C to +60 °C (-4 °F to +140 °F)
Weight Battery: 453.6 g (16.0 oz)
Battery (including packaging): 567 g
(20.0 oz)
Warranty Information
For warranty information, go to the www.tektronix.com Web
site, and search for “WFM200BA warranty”.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in
your area.
Copyright © Tektronix, Inc. All rights reserved. www.tektronix.com
