Tektronix TDS1001B Installation and maintenance instructions

TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series
Digital Storage Oscilloscope
ZZZ
Declassification and Security Instructions
xx
www.tektronix.com
077-0445-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by
national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published
material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Table of Contents
Preface .............................................................................................................................................................. iii
Clear and Sanitize Procedures..................................... .................................................... .. .......................................... 1
Memory Devices............................................................................................................................................... 2
Data Export Devices........................................................................................................................................... 5
Troubleshooting..................................................................................................................................................... 7
How to Clear or Sanitize a Nonfunctional Instrument..................................................................................................... 7
TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series i

Table of Contents
ii TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series

Preface
If you have data security concerns, this document helps you to sanitize or remove memory devices from the listed products.
These products have data storage (memory) devices and data output devices (USB ports). These instructions tell you how
to clear or sanitize the memory devices, and also tell you how to declassify an instrument that is not functioning.
Instrument code and calibration settings reside in nonvolatile flash memory. Instrument setups and reference waveforms
mayalsobestoredinflash memory or on USB drives connected to the instrument.
If you have any questions, contact the Tektronix Technical Support Center at www.tektronix.com/support.
Reference The procedures in this document are written to meet the requirements specified in:
NISPOM, DoD 5220.22–M, Chapter 8
ISFO Process Manual for Certification & Accreditation of Classified Systems under NISPOM
Products The following Tektronix products are covered by this document:
TDS1000B Series. TDS1001B, TDS1002B, TDS1012B
TDS2000B Series. TDS2002B, TDS2004B, TDS2012B, TDS2014B, TDS2022B, TDS2024B
TDS1000C-EDU Series. TDS1001C-EDU, TDS1002C-EDU, TDS1012C-EDU
TDS2000C Series. TDS2001C, TDS2002C, TDS2004C, TDS2012C, TDS2014C, TDS2022C, TDS2024C
TPS2000B Series. TPS2012B, TPS2014B, TPS2024B
TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series iii

Preface
Related Documents The documents shown in the following table are available on the Tektronix Web site at www.tektronix.com/manuals.
Manual name Tektronix part number
TDS1000B and TDS2000B Series Digital Storage Oscilloscope Service Manual 071-1828-XX
TDS2000C and TDS1000C-EDU Series Digital Storage Oscilloscope Service Manual 077-0446-XX
TPS2000B Series Digital Storage Oscilloscope Service Manual 077-0447-XX
iv TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series

Preface
Terms The following terms may be used in this document:
Clear. This removes data on media/memory before reusing it in a secured area. All reusable memory is cleared to deny
access to previously stored information by standard means of access.
Erase. This is equivalent to clear.
Instrument Declassification. A term that refers to procedures that must be undertaken before an instrument can be
removed from a secure environment. Declassification procedures include memory sanitization and memory removal,
and sometimes both.
Media storage/data export. Any of several devices that are used to store or export data from the instrument, such as
aUSBport.
Nonvolatile memory. Data is retained when the instrument is powered off.
Power off. Some instruments have a “Standby” mode, in which power is still supplied to the instrument. For the purpose
of clearing data, putting the instrument in Standby mode does not qualify as powering off. For these products, you will
need to either push a rear-panel OFF switch or remove the power source from the instrument.
Remove. This is a physical means to clear the data by removing the memory device from the instrument. Instructions
are available in the product service manual.
Sanitize. This eradicates the data from media/memory so that the data cannot be recovered by other means or technology.
This is typically used when the device will be moved (temporarily or permanently) from a secured area to a nonsecured area.
Scrub. The user is able to directly retrieve the memory device contents.
User-modifiable. The user can write to the memory device during normal instrument operation, using the instrument
interface or remote control.
Volatile memory. Data is lost when the instrument is powered off.
TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series v

Preface
vi TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series

Clear and Sanitize Procedures
The following terms are used in the tables in this section:
Type of user info stored This column describes the type of user information that is stored in the device.
User data. Waveforms and other measurement data that represent signals that users connect to the instrument.
User settings. Instrument settings that the user can change.
Both. Both user data and user settings are stored in the device.
None. Neither user data nor user settings are stored in the device.
Method of modification This column indicates the method of modifying data:
Direct. Theusercanmodifythedata.
Indirect. The instrument system resources modify the data. The user cannot modify the data.
User accessible This column indicates whether the user can retrieve the device contents:
Ye s . The user can directly retrieve the memory device contents.
No. The user cannot retrieve the memory device contents.
To clear This column tells how to clear data from the media or memory device before reusing it in a secured area. All reusable
memory is cleared to deny access to previously stored information by standard means of access.
To sanitize This column tells how to eradicate the data from the media or memory device so that the data cannot be recovered by
other means or technology. This is typically used when the device will be moved (temporarily or permanently) from a
secured area to a nonsecured area.
TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series 1

Clear and Sanitize Procedures
Memory Devices
The following tables list the volatile and nonvolatile memory devices in the standard instrument and listed options:
Table1: Volatilememorydevices
Type and min.
size Function
Type of user
information
stored
Backed up
by battery
Method of
modification
Data input
method Location
User
accessible To clear To sanitize
SDRAM,
512K X 32
Acquisition memory
for holding
and processing
waveforms, and
processor system
RAM.
Both user data and
user settings
No Indirect Firmware
operations,
user input
Main
Acquisition
board
No Remove power from
the instrument for at
least 20 seconds.
Remove power from
the instrument for at
least 20 seconds.
SRAM, 128K X 8 Shared memory
between the
acquisition system
and the USB
processor.
Both user data and
user settings
No Indirect Firmware
operations
Main
Acquisition
board. TDS
models only.
No Remove power from
the instrument for at
least 20 seconds.
Remove power from
the instrument for at
least 20 seconds.
Real-time clock,
which contains
battery backed-up
memory
Holds date/time data None Yes Indirect User input Main
Acquisition
board.
No Remove the battery
from the board.
Remove the battery
from the board.
USB 2.0 OTG
host/peripheral
controller, 8K X 16
RAM
Contains USB
controller program
and data memory.
None No Indirect Firmware
operations
Main
Acquisition
board. TDS
models only.
No Remove power from
the instrument for at
least 20 seconds.
Remove power from
the instrument for at
least 20 seconds.
SRAM, 64K X16 Data memory for the
USB processor.
None No Indirect Firmware
operations
Main
Acquisition
board. TDS
models only.
No Remove power from
the instrument for at
least 20 seconds.
Remove power from
the instrument for at
least 20 seconds.
2 TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series

Clear and Sanitize Procedures
Table 2: Nonvolatile memory devices
Type and
minimum
size Function
Type of user
information
stored
Method of
modification Data input method Location
User
Accessible To clear To sanitize
FLASH,
8M X 8,
4M X 16
Holds instrument
firmware, current
setup, saved setups,
saved reference
waveforms, hard
copy image files, and
calibration constants.
Both user data and
user settings
Indirect Factory configurations,
firmware operations,
user input, and USB disk
upgrade
Main
Acquisition
board
No See the Clear Flash
Procedure that
follows this table.
See the Clear Flash
Procedure that follows
this table.
EEPROM,
SERIAL, 1M
Program memory for
the USB processor.
None Indirect Factory configurations,
USB disk upgrade
Main
Acquisition
board. TDS
models only.
No Not applicable,
does not contain
user data or
settings. Cleaning
would disable
instrument
functionality.
Not applicable, does
not contain user
data or settings.
Sanitizing would disable
instrument functionality.
Clear Flash Procedure This procedure does not erase or change factory calibration constants.
1. Push the front panel DEFAULT SETUP button to recall the default setup.
2. Push the front panel SAVE/RECALL button.
3. Push the Action option (side bezel) button until Save Setup is selected.
4. Push the Save To option button until Setup is selected.
5. Push the Setup option button until 1 is selected.
6. Push the Save option button to overwrite setup 1 with the default setup.
7. Push the Setup and Save option buttons again to overwrite the next setup with the default setup. Repeat this step until
setup 1 is selected again.
8. Push the front panel CH 1 MENU button, and then push the Coupling option button until Ground is selected.
9. Push the front panel SAVE/RECALL button.
TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series 3

Clear and Sanitize Procedures
10. Push the Action option button until Save Waveform is selected. Push the Save To option button until Ref is selected.
Push the Source option button until CH1 is selected.
11. Push the To option button until RefA is selected. Push the Save option button to overwrite reference waveform RefA
with the null waveform.
12. Push the To and the Save option buttons again to overwrite the next reference waveform with the null waveform.
Repeat this step until reference RefA is selected again.
13. For TDS oscilloscopes, insert a USB flash drive into the USB Flash Drive port on the front of the oscilloscope. For
TPS oscilloscopes, insert a compact flash card into the Compact Flash slot on the front of the oscilloscope.
14. Push the front panel UTILITY button.
15. Push the Options option button.
16. Push the Printer Setup option button.
17. Push the PRINT Button option until Saves Image To File is selected.
18. For TDS oscilloscopes, push the File Format option button until JPG is selected. For TPS oscilloscopes, select
BMP instead of JPG.
19. Remove any probes from the BNC front panel connectors.
20. Push the front panel PRINT button to overwrite the hard copy image file with an image that does not contain any
useful information.
21. Power off the oscilloscope, and then power on the oscilloscope to complete the process.
4 TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series

Clear and Sanitize Procedures
Data Export Devices
The following table lists the data export devices in the standard instrument and listed options:
Table 3: Data export devices
Type and min
size Function
Method of
modification Data input method Location Process to disable
USB host port Supports removable USB flash drive.
User storage of reference waveforms,
screen images, and instrument setups.
Directly Save Front panel Files can be deleted or overwritten on the oscilloscope or
a PC; USB flash drive can be removed and destroyed
The USB host port cannot be disabled
USB device port Supports remote control and data transfer
to a PC
Directly Remote control via
USBTMC
Rear panel The USB device port cannot be disabled
Compact flash
card
User storage of reference waveforms,
screen images, and instrument setups.
Directly By system resources Front panel The Compact Flash port cannot be disabled.
TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series 5

Clear and Sanitize Procedures
6 TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series

Troubleshooting
How to Clear or Sanitize a Nonfunctional Instrument
If your instrument is not functioning and you need to clear or sanitize it, proceed as follows:
Acquisition Board Remove the Acquisition board and return the product to Tektronix. A new Acquisition board will be installed, and the
instrument will be repaired and adjusted as necessary.
For removal instructions, refer to your product service manual. (See page iv, Related Documents.)
After removal of the Acquisition board, refer to your company's internal policies regarding handling or disposal of the
board.
Compact Flash Card (TPS
oscilloscopes only)
Remove the compact flash card and return the instrument to Tektronix for repair.
After removal of the compact flash card, refer to your company's internal policies regarding handling or disposal of the
compact flash card.
USB Flash Drive (TDS
oscilloscopes only)
Remove the USB flash drive and return the instrument to Tektronix for repair.
After removal of the USB flash drive, refer to your company's internal policies regarding handling or disposal of the
flash drive.
Charges Replacement of any missing hardware will be charged according to the rate at the time of replacement.
TDS1000B/TDS2000B, TDS1000C-EDU/TDS2000C, and TPS2000B Series 7
