Chapter 1 About this Guide
This installation guide for the SDE router contains information on how to correctly install this device in a working en-
vironment.
1.1 Supported devices
The information provided in this installation guide only applies to the SDE router.
1.2 Who should read this manual?
This manual should be read by the support personnel who need to configure, maintain and monitor the device.
1.3 When should this manual be read?
Read this guide as soon as you are ready to familiarize yourself with the device and its components.
This manual will help you understand your new device in greater depth.
1.4 What is included in this manual?
This installation guide contains the following information:
• Technical specifications.
• Power supply requirements.
• A description of the device LEDs and connectors.
• Troubleshooting.
1.5 What is not included in this manual?
This manual does not contain information relative to the device software or its configuration. For information on how
to configure this device, please see the relevant CLI manuals found on the Teldat website at this link: ht-
tp://www.teldat.com
1.6 How is the information organized?
Each chapter focuses on a specific part of the hardware and its components. All descriptive or technical specifica-
tions, and information on a component, can be found in the relevant chapter.
1.7 Technical support
Teldat S.A. offers a technical support service. Device software can be upgraded on a regular basis for maintenance
purposes and when new features are developed.
Contact information:
Web: http://www.teldat.com - Email: [email protected]
Tel.: [phone] - Fax: [phone]
Teldat S.A. 1 About this Guide
SDE 1

Chapter 2 Components and Power Supply
The following chapter provides detailed information on the chassis of the SDE router and its components. This in-
cludes information on:
• Components.
• Assembly.
• Power supply.
• Data connection.
2.1 Components
2.1.1 Front panel
The following figure shows the front panel.
Fig. 1: Front Panel
The front panel components are as follows:
Front panel components
Item Description
1 Left control panel. Holds the system health and system ID, status LED.
2 N/A
3 USB port.
4 VGA port. Allows you to connect a display device to the system.
5 Right control panel. Holds the power button, USB port, iDRAC Direct micro port,
and the iDRAC Direct status LED.
6 Drive slots. Allow you to install drives that are supported on your system.
7 Information tag. The Information Tag is a slide-out label panel that includes sys-
tem information (like the Service Tag, NIC, MAC address, etc.).
The following figure shows the left control panel view
2 Components and Power Supply Teldat S.A.
2 SDE

Fig. 2: Left control panel view
Left control panel
Item Description
1 Status LED indicators. They indicate the system's status.
2 System health and ID indicators. They indicate the system's health.
3 N/A
Status LED indicators
Icon Description Condition
Drive indicator The indicator turns solid amber if
there is a drive-related problem.
Temperature indicator The indicator turns solid amber if the
system experiences a thermal error
(for example, when the room temper-
ature is out of range or there is a fan
failure).
Electrical indicator The indicator turns solid amber if the
system experiences an electrical er-
ror (for example, when the voltage is
out of range, or a power supply unit
(PSU) or voltage regulator have
failed).
Memory indicator The indicator turns solid amber if a
memory error occurs.
PCIe indicator The indicator turns solid amber if a
PCIe card experiences an error.
System health and system indicator codes
Code Condition
Solid blue Indicates the system is on, healthy, and that the ID mode is not active. Press the
system health and system ID button to switch to system ID mode.
Blinking blue Indicates that the system ID mode is active. Press the system health and system
ID button to switch to system health mode.
Solid amber Indicates that the system is in fail-safe mode.
Teldat S.A. 2 Components and Power Supply
SDE 3

Blinking amber Indicates that the system is in trouble.
2.1.2 Rear panel
The following figure shows the rear panel.
Fig. 8: Rear panel
The following table provides information and a description of each component:
Rear panel components
Item Description
1 PCIe expansion card slot. The expansion slot(s) enable you to connect PCI Ex-
press expansion cards.
2 Power supply unit (2)
3 NIC SFP ports (4)
4 USB 3.0 port (2)
5 VGA port
6 Serial port
7 iDRAC9 dedicated network port
8 System status indicator cable port. Enables you to connect the status indicator
cable and check the system's status when the CMA is installed.
9 System identification button. The System Identification (ID) button is available on
the front and at the back. Press the button to identify a system in a rack by turning
on the system ID button. You can also use the system ID button to reset iDRAC
and to access BIOS using the step through mode.
2.2 Installation in a rack
The SDE device can be installed in a 19” rack.
2.2.1 Standalone
An SDE device can be placed as a standalone on a flat, stable surface. The adhesive rubber feet must be stuck to
the underside panel to prevent the router from sliding.
Make sure there is enough space around the router (for ventilation purposes) and check that the electricity cables
can reach it.
2.2.2 Wall mounting
The SDE cannot be wall.mounted.
2 Components and Power Supply Teldat S.A.
4 SDE

2.3 Power source
The SDE is powered by means of two internal AC/DC sources. The SDE has two power inputs and two power sup-
plies that operate simultaneously. It can operate each one individually or both at the same time. If SDE is powered by
the two power supplies and one of them fails, the other one acts as a backup.
Warning
The equipment must be used with the power supply provided by the manufacturer.
Workplace Conditions. Main Characteristics
• Avoid humid and/or dusty locations.
• Avoid prolonged exposure to sunlight and other heat sources. The device should not be placed amongst papers,
magazines or other elements that could hinder natural air circulation.
• The device should not be placed close to strong electromagnetic fields, e.g., by speakers, motors, etc.
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.
2.4 Connecting the data
The SDE has the following data connections.
2.4.1 SFP ports
The SDE incorporates 4 10Gbit SFP ports.
Fig. 9: SFP ports (with connected transceivers)
All OSDx interfaces are bridged by default. The system tries to obtain the IP address via DHCP. If no IP address is
obtained, 192.168.1.1 will act as default.
The SSH server is enabled in SDE. Default credentials are:
user: admin
password: admin
2.4.2 Connecting for configuration
To access the SDE device via the local console, a monitor and a keyboard can be connected to it (using the VGA
and USB ports, respectively)
Default credentials are:
user: admin
password: admin
2.5 Factory reset
To perform a factory reset and restore the default configuration, follow these steps:
(a) Enter SDE's local console.
(b) Type the following command: factory-reset now
Teldat S.A. 2 Components and Power Supply
SDE 5

2.5.1 Default configuration
The default configuration of the SDE device is as follows:
set interfaces bridge br0 address dhcp
set interfaces bridge br0 dhcp client fallback 192.168.1.1/24
set interfaces ethernet eth0 bridge-group bridge br0
set interfaces ethernet eth1 bridge-group bridge br0
set interfaces ethernet eth2 bridge-group bridge br0
set interfaces ethernet eth3 bridge-group bridge br0
set service cnm role router
set service cnm url discover.cloudnetmanager.com
set service dns resolver dhcp
set service dns resolver name-server 8.8.8.8
set service ssh
set system login user admin authentication encrypted-password
'$6$GSjsCj8gHLv$/VcqU6FLi6CT2Oxn0MJQ2C2tqnRDrYKNF8HIYWJp68nvXvPdFccDsT04.WtigUONbKYrgKg8d6rEs8PjljMkH0'
set system ntp server address pool.ntp.org
2 Components and Power Supply Teldat S.A.
6 SDE

Chapter 3 Compliance
3.1 Manufacturer information
Brand Dell
Manufacturer Dell Technologies
Country US
Contact www.dell.com/support/home.
3.2 Safety warnings
            
         
         !" #$%&'( (
)%* $ %&+           , -  ./ 0
1            
           -&)!0  
        -   0     
          
 ,       ! )     ,
  2        
+  (  3     1 .  
!4)            .   
 2 15 ' 6/789.:8//;
3.3 WEEE information
The crossed-out wheelie bin symbol indicates that the device must be disposed of
separately from normal domestic waste at an appropriate waste disposal facility at
the end of its useful service life.
3.4 REACH
In compliance with the REACH Candidate List, the delivered product and product packaging do not contain chemical
substances above a concentration limit of 0.1% weight by weight (w/w). This declaration will be updated whenever
any changes occur or other chemical substances are added to the REACH Candidate List. Information is currently
provided to consumers upon request.
Teldat S.A. 3 Compliance
SDE 7

3.5 EC declaration of conformity
English (EN) Hereby, Teldat S.A. declares that the radio equipment type SDE is in compliance
with:
Directive 2014/30/EU (EMC)
Directive 2014/35/EU (LVD)
Directive 2009/125/EC (ErP)
Directive 2011/65/EU (RoHS)
of the European Parliament and of the Council.
The full text of the EU declaration of conformity and additional product documentation is available at the following
website: http://www.teldat.com
This equipment complies with CE procedures and marking.
3.6 Laser product
Use only trained and qualified personnel to install or replace this device
Chose SFP+ transceivers that meet the following regulations
• Class 1
• IEC/EN60825-1:2007 2nd Edition or later, European standard
• FCC 21 CFR Chapter 1, Subchapter J (in accordance with FDA and CDRH re-
quirements)
• Application of CE marking in accordance with the 2014/30/EU EMC Directive
and the 2014/35/EU Low Voltage Directives
• UL and/or CSA registered component for North America
• 47 CFR Part 15, Class A
3 Compliance Teldat S.A.
8 SDE

Appendix A Technical Information
A.1 Troubleshooting
The following table can help you solve problems when installing the device. If you cannot solve the issue, contact
your dealer for more information.
Symptom Solution
Drive error · Check the System Event Log to determine if there is a drive-related error.
· Run the appropriate Online Diagnostics test. Restart the system and run embed-
ded diagnostics (ePSA).
· If drives are configured in a RAID array, restart the system and enter the host ad-
apter configuration utility program.
Temperature error Make sure none of the following conditions are present:
· A cooling fan has been removed or has failed.
· A system cover, air shroud, memory module blank, or back filler bracket has
been removed.
· The room temperature is too high.
· The external airflow is obstructed.
Electrical error. Check the System Event Log or system messages to identify the error. If it is due
to a problem with the PSU, check the LED on the PSU. Reset the PSU.
Memory error Check the System Event Log or system messages to locate the memory that is
failing. Reset the memory module.
PCIe error. Restart the system. Update any required drivers for the PCIe card. Reinstall the
card.
A.2 Updating the software
The SDE software can be updated to newer versions. Please contact your dealer for information on new releases.
For further information, please see manual: “Teldat Dm945-I_Provisioning SDWAN devices" (chapter 5) .
A.3 Technical specifications
A.3.1 Hardware architecture
MODELS SDE-20K SDE-22K SDE-24K
PROCESSORS Intel Xeon Silver 4210
2.2G, 10C/20T, 9.6GT/s,
13.75M Cache, Turbo, HT
(85W) DDR4-2400
2xIntel® Xeon® Gold 6230
2.1G, 20C/40T, 10.4GT/s,
27.5M Cache, Turbo, HT
(125W) DDR4-2933
2xIntel® Xeon® Gold 6254
3.1G, 18C/36T, 10.4GT/s,
24.75M Cache, Turbo, HT
(200W) DDR4-2933
MEMORY 3x8GB RDIMM, 2666MT/s,
Single Rank
6x8GB RDIMM, 2666MT/s,
Single Rank
6x8GB RDIMM, 2666MT/s,
Single Rank
STORAGE UNIT 2 x 600GB 10K RPM SAS
12Gbps 512n 2.5in Hot-
plug Hard Drive (RAID 1)
2 x 600GB 10K RPM SAS
12Gbps 512n 2.5in Hot-
plug Hard Drive (RAID 1)
2 x 600GB 10K RPM SAS
12Gbps 512n 2.5in Hot-
plug Hard Drive (RAID 1)
CONSUMPTION 2x495W 2x495W 2x750W
Teldat S.A. Technical Information
SDE 9

A.3.2 NIC
Intel X710 Quad Port 10GbE SFP+, rNDC
Connections Quad SFP+ cages for:
• SFP+SRfiber-optic transceivers
• SFP+LRfiber-optic transceivers
• SFP+RJ45 transceivers
• SFP+Direct Attach cables
Network Standard Physical Lay-
er Interface
IEEE 802.3:
10GBASE-SR
10GBASE-LR
10GBASE-T
SFF-8431:
10GSFP+ DAC (Direct Attach Copper)
A.3.3 Power supply
INPUT VOLTAGE 100–240 V AC, auto-ranging
Heat dissipation (maximum) 2891 BTU/hr
INPUT FREQUENCY 50/60 Hz
MAXIMUM POWER 750 W
A.3.4 Dimensions and weight
TYPE Desktop / chassis for a 1 U high rack mounting enclosure.
LENGTH x WIDTH x HEIGHT 808 x 482 x 42.8 mm.
WEIGHT 21.9 kg.
A.3.5 Environmental specifications
TEMPERATURE NORMAL OPERATION: 10°C to 35°C, with no direct sunlight hitting the equip-
ment.
RELATIVE HUMIDITY 10% to 80%, with a maximum dew point of 29°C.
Technical Information Teldat S.A.
10 SDE
