Teledyne Lecroy T3DSO3000 User manual

T3DSO3000
Digital Storage Oscilloscope
User Manual

Copyright Information
© 2021 Teledyne LeCroy, Inc. All rights reserved.
Users are permitted to duplicate and distribute Teledyne LeCroy, Inc. documentation for
internal educational purposes only. Resale or unauthorized duplication of Teledyne LeCroy
publications is strictly prohibited.
Teledyne Test Tools is a trademark of Teledyne LeCroy, Inc., Inc. Other product or brand
names are trademarks or requested trademarks of their respective holders. Information in
this publication supersedes all earlier versions.
Specications are subject to change without notice.

Contents
1 Introduction .............................................................................................................. 1
2 General Safety Summary ......................................................................................... 2
2.1 Safety Terms and Symbols ..................................................................................3
2.2 Working Environment ..........................................................................................4
2.3 Cooling Requirements .........................................................................................6
2.4 AC Power ............................................................................................................6
2.5 Power and Ground Connections .........................................................................7
2.6 Calibration ...........................................................................................................8
2.7 Cleaning ..............................................................................................................8
2.8 Abnormal Conditions ...........................................................................................8
3 First Steps ................................................................................................................. 9
3.1 Delivery Checklist ................................................................................................9
3.2 Quality Assurance ...............................................................................................9
3.3 Maintenance Agreement ...................................................................................10
4 Getting Started ........................................................................................................ 10
4.1 Power on ............................................................................................................10
4.2 Shut down .........................................................................................................11
4.3 System Status ...................................................................................................11
5 Probe ....................................................................................................................... 12
6 Quick Start .............................................................................................................. 13
6.1 Front Panel Overview ........................................................................................13
6.2 Rear Panel Overview ........................................................................................14
6.3 Connecting to External Devices/Systems .........................................................15
6.3.1 Power Supply ............................................................................................ 15
6.3.2 LAN ........................................................................................................... 15
6.3.3 USB Peripherals ........................................................................................ 15
6.3.4 External Monitor ........................................................................................ 15
6.3.5 Auxiliary Output ......................................................................................... 16
6.3.6 Waveform Generator ................................................................................. 16
6.3.7 Probes ....................................................................................................... 16
6.3.8 Logic Probe ............................................................................................... 16
7 Touch Screen Display ............................................................................................ 17
7.1 Overview ...........................................................................................................17
7.2 Menu Bar ...........................................................................................................18
7.3 Grid Area ...........................................................................................................19

7.4 Channel Descriptor Box ......................................................................................20
7.5 Timebase and Trigger Descriptor Boxes .............................................................21
7.6 Dialog Box ...........................................................................................................25
7.7 Touch Gestures ...................................................................................................27
7.8 Mouse and Keyboard Operation .........................................................................28
7.9 Choosing the Language ......................................................................................28
8 Front Panel ................................................................................................................ 29
8.1 Overview .............................................................................................................29
8.2 Vertical Control ....................................................................................................30
8.3 Horizontal Control ................................................................................................30
8.4 Trigger Control .....................................................................................................31
8.5 Run/Stop Button ..................................................................................................32
8.6 Auto Setup Button ...............................................................................................32
8.7 Decode/Digital/Math/Ref Control .........................................................................33
8.8 Navigate Control ..................................................................................................34
8.9 Cursors Control ...................................................................................................34
8.10 Universal Knob ..................................................................................................35
8.11 Other Buttons .....................................................................................................35
9 Multiple Approaches to Recall Functions .............................................................. 36
9.1 Menu Bar .............................................................................................................36
9.2 Descriptor Box .....................................................................................................37
9.3 Shortcut Button on the Front Panel .....................................................................37
10 Quickly Capture the Signal .................................................................................... 38
11 Vertical Setup .......................................................................................................... 38
11.1 Turn on/o a Channel ........................................................................................38
11.2 Channel Setup ...................................................................................................39
12 Digital Channels ..................................................................................................... 45
12.1 Overview ...........................................................................................................45
12.2 Enable/Disable the Digital Channels .................................................................47
12.3 Digital Channel Setup ........................................................................................48
13 Horizontal and Acquisition Setup ......................................................................... 51
13.1 Timebase Setup ................................................................................................51
13.2 Acquisition Setup ...............................................................................................52
13.2.1 Overview ................................................................................................... 52
13.2.2 Acquisition ................................................................................................. 54
13.2.3 Roll Mode .................................................................................................. 57
13.2.4 Sequence .................................................................................................. 58
13.3 History ...............................................................................................................62
13.4 Zoom ..................................................................................................................65
14 Trigger ..................................................................................................................... 68
14.1 Overview ...........................................................................................................68

14.2 Trigger Setup ......................................................................................................69
14.3 Trigger Level .......................................................................................................71
14.4 Trigger Mode ......................................................................................................71
14.5 Trigger Type ........................................................................................................72
14.5.1 Overview .................................................................................................... 72
14.5.2 Edge Trigger ............................................................................................... 74
14.5.3 Slope Trigger .............................................................................................. 74
14.5.4 Pulse Trigger .............................................................................................. 77
14.5.5 Video Trigger .............................................................................................. 78
14.5.6 Window Trigger .......................................................................................... 83
14.5.7 Interval Trigger ........................................................................................... 86
14.5.8 Dropout Trigger .......................................................................................... 86
14.5.9 Runt Trigger ................................................................................................ 87
14.5.10 Pattern Trigger .......................................................................................... 88
14.5.11 Qualied Trigger ....................................................................................... 90
14.6 Trigger Source ....................................................................................................92
14.7 Holdo ................................................................................................................92
14.8 Trigger Coupling .................................................................................................94
14.9 Noise Reject .......................................................................................................95
14.10 Zone Trigger .....................................................................................................96
15 Serial Trigger and Decode .................................................................................... 102
15.1 Overview ..........................................................................................................102
15.2 I2C Trigger and Serial Decode .........................................................................104
15.2.1 I2C Signal Settings ................................................................................... 104
15.2.2 I2C Trigger ................................................................................................ 105
15.2.3 I2C Serial Decode .................................................................................... 109
15.3 SPI Trigger and Serial Decode ......................................................................... 112
15.3.1 SPI Signal Settings ....................................................................................112
15.3.2 SPI Trigger ................................................................................................115
15.3.3 SPI Serial Decode .....................................................................................117
15.4 UART Trigger and Serial Decode ..................................................................... 117
15.4.1 UART Signal Settings ................................................................................117
15.4.2 UART Trigger .............................................................................................118
15.4.3 UART Serial Decode .................................................................................119
15.5 CAN Trigger and Serial Decode .......................................................................120
15.5.1 CAN Signal Settings ................................................................................. 120
15.5.2 CAN Trigger .............................................................................................. 120
15.5.3 CAN Serial Decode .................................................................................. 121
15.6 LIN Trigger and Serial Decode ......................................................................... 123
15.6.1 LIN Signal Settings ................................................................................... 123
15.6.2 LIN Trigger ................................................................................................ 123
15.6.3 LIN Serial Decode .................................................................................... 124
15.7 FlexRay Trigger and Serial Decode .................................................................125

15.7.1 FlexRay Signal Settings .......................................................................... 125
15.7.2 FlexRay Trigger ....................................................................................... 126
15.7.3 FlexRay Serial Decode ............................................................................ 127
15.8 CAN FD Trigger and Serial Decode ................................................................129
15.8.1 CAN FD Signal Settings .......................................................................... 129
15.8.2 CAN FD Trigger ....................................................................................... 129
15.8.3 CAN FD Serial Decode ........................................................................... 131
15.9 I2S Trigger and Serial Decode ........................................................................133
15.9.1 I2S Signal Settings .................................................................................. 133
15.9.2 I2S Trigger ............................................................................................... 134
15.9.3 I2S Serial Decode ................................................................................... 136
15.10 MIL-STD-1553B Trigger and Serial Decode ..................................................136
15.10.1 MIL-STD-1553B Signal Settings ........................................................... 137
15.10.2 MIL-STD-1553B Serial Decode ............................................................. 137
15.11 SENT Trigger and Serial Decode ..................................................................138
15.11.1 SENT Signal Settings ............................................................................. 138
15.11.2 SENT Trigger ......................................................................................... 139
15.11.3 SENT Serial Decode .............................................................................. 143
15.12 Manchester Serial Decode ............................................................................145
15.12.1 Manchester Signal Settings ................................................................... 145
15.12.2 Manchester Serial Decode .................................................................... 147
16 Cursors .................................................................................................................. 148
16.1 Overview .........................................................................................................148
16.2 Select and Move Cursors ................................................................................155
17 Measurement ........................................................................................................ 158
17.1 Overview .........................................................................................................158
17.2 Set Parameters ...............................................................................................161
17.3 Type of Measurement ......................................................................................163
17.3.1 Vertical Measurement .............................................................................. 163
17.3.2 Horizontal Measurement ......................................................................... 166
17.3.3 Miscellaneous Measurements ................................................................. 168
17.3.4 Delay Measurement ................................................................................ 169
17.4 Trend ...............................................................................................................171
17.5 Display Mode ...................................................................................................172
17.6 Measurement Statistics ...................................................................................173
17.7 Statistics Histogram .........................................................................................174
17.8 Simple Measurements .....................................................................................175
17.9 Gate .................................................................................................................175
18 Math ....................................................................................................................... 177
18.1 Overview ......................................................................................................... 177
18.2 Arithmetic .........................................................................................................178
18.3 Algebra ............................................................................................................179

18.3.1 Dierential ............................................................................................... 179
18.3.2 Integral .................................................................................................... 181
18.3.3 Square Root ............................................................................................ 182
18.4 Frequency Analysis .........................................................................................183
18.5 Formula Editor .................................................................................................194
19 Reference .............................................................................................................. 195
20 Search ................................................................................................................... 196
21 Navigate ................................................................................................................ 199
22 Mask Test .............................................................................................................. 206
22.1 Overview .........................................................................................................206
22.2 Mask Setup .....................................................................................................208
22.2.1 Create Mask ............................................................................................ 208
22.2.2 Mask Editor ............................................................................................. 210
22.3 Pass/Fail Rule ............................................................................................ 212
22.4 Operation .........................................................................................................213
23 DVM ....................................................................................................................... 214
23.1 Overview .........................................................................................................214
23.2 Mode ...............................................................................................................215
23.3 Diagrams .........................................................................................................216
24 Counter .................................................................................................................. 220
24.1 Overview .........................................................................................................220
24.2 Mode ...............................................................................................................221
26 Histogram .............................................................................................................. 224
26.1 Overview .........................................................................................................224
26.2 Region Setting .................................................................................................227
26 Power Analysis ..................................................................................................... 229
26.1 Overview .........................................................................................................229
26.2 Power Quality ..................................................................................................230
26.3 Current Harmonics ..........................................................................................232
26.4 Inrush Current .................................................................................................234
26.5 Switching Loss ................................................................................................236
26.6 Slew Rate ........................................................................................................239
26.7 Modulation .......................................................................................................239
26.8 Output Ripple .................................................................................................. 240
26.9 Turn on/Turn o ...............................................................................................241
26.10 Transient Response ......................................................................................244
26.11 PSRR .............................................................................................................246
26.12 Power Eciency ............................................................................................247
27 Bode Plot ............................................................................................................... 248
27.1 Overview .........................................................................................................248
27.2 Conguration ...................................................................................................249

27.2.1 Connection .............................................................................................. 249
27.2.2 Sweep ..................................................................................................... 250
27.3 Display .............................................................................................................253
27.4 Data Analysis ...................................................................................................255
28 Display ................................................................................................................... 258
29 Arbitrary Waveform Generator ............................................................................ 265
29.1 Overview .........................................................................................................265
29.2 Output ..............................................................................................................266
29.3 Wave Type .......................................................................................................267
29.4 Other Setting ...................................................................................................269
29.5 System ............................................................................................................271
30 Save/Recall ........................................................................................................... 273
30.1 Save Type ........................................................................................................273
30.2 Internal save and Recall ..................................................................................276
30.3 External save and Recall .................................................................................277
30.3.1 File Manager ........................................................................................... 278
30.3.2 External save and Recall Instance .......................................................... 280
31 System Setting ..................................................................................................... 284
31.1 System Status .................................................................................................284
31.2 Sound ..............................................................................................................284
31.3 Upgrade Software ...........................................................................................285
31.4 Language ........................................................................................................287
31.5 Screen Saver ...................................................................................................287
31.6 I/O Setting .......................................................................................................288
31.6.1 LAN ......................................................................................................... 288
31.6.2 Clock Source ........................................................................................... 289
31.6.3 VNC Port ................................................................................................. 289
31.7 Date/Time ........................................................................................................290
31.8 Reference Position Setting ..............................................................................290
31.9 Perform Self-Test .............................................................................................294
31.10 Do Self Cal ....................................................................................................297
31.11 Default ...........................................................................................................298
31.12 Power on Line ...............................................................................................298
31.13 Debug ............................................................................................................298
32 Remote Control ..................................................................................................... 299
32.1 Web Browser ...................................................................................................299
32.2 Other Connectivity ...........................................................................................300
33 Troubleshooting ................................................................................................... 301
34 Contact Teledyne LeCroy .................................................................................... 304
35 Certications ......................................................................................................... 305

1 User Manual
1. Introduction
Teledyne Test Tools T3DSO3000 series Digital Storage Oscilloscopes are available in
bandwidths of 1 GHz, 500 MHz and 350 MHz. All models include a maximum sample
rate of 5 GSa/s, maximum record length of 250 Mpts, and display up to 4 analog
channels + 16 digital channels mixed signal analysis capability.
The T3DSO3000 series employs the latest technology which features a maximum
waveform capture rate of up to 110,000 wfm/s (normal mode, up to 500,000 wfm/s in
Sequence mode) and a 256-level intensity grading display function plus a color
temperature display mode. It also employs an innovative digital trigger system with high
sensitivity and low jitter. The trigger system supports multiple powerful triggering modes
including serial bus triggering. History waveform recording, Sequence acquisition,
Search and Navigate functions allow for extended waveform records to be captured,
stored, and analyzed. An impressive array of measurement and math capabilities, a
25 MHz arbitrary waveform generator, and serial decoding are all features of the
T3DSO3000.
The large 10.1’’ display capacitive touch screen supports multi-touch gestures. With the
addition of a user-friendly one-button design for the most commonly used functions, the
T3DSO3000 provides the user with an enhanced operating eciency.
Key Features
• Waveform capture rates of up to 110,000 wfm/s (normal mode), and 500,000 wfm/s
(sequence mode)
• Supports 256-level intensity grading and color temperature display modes
• Record length up to 250 Mpts
• Digital trigger system

User Manual 2
2. General Safety Summary
Read the following precautions carefully to avoid any personal injuries, or damage to the
instrument or products connected to it. Use the instrument only as specied.
Only use the power cord supplied for the instrument.
Ground the instrument. The instrument is grounded through the ground conductor of the
power cord. To avoid electric shock, always ensure that the instrument is grounded
correctly before connecting its input or output terminals.
Connect the signal wire correctly. To avoid damage, observe input polarity and
maximum voltage/current ratings at all times.
Observe all terminal ratings and signson the instrument to avoid re or electric shock.
Before connecting to the instrument, read the manual to understand the input/output
ratings.
Do not operate with suspected failures. If you suspect that the instrument is damaged,
contact the Teledyne LeCroy service department immediately.
Do not operate in wet/damp conditions. Keep the surface of the instrument clean and
dry.
Do not operate in an explosive atmosphere.
Avoid touching exposed circuits or wires. Do not touch exposed contacts or
components when the power is on.
Do not operate without covers. Do not operate the instrument with covers or panels
removed.
Use only the fuse specied for the instrument.
Use proper over voltage protection.
Use anti-static protection. Operate in an anti-static protected area. Ground
measurement cable conductors before connecting to the instrument to discharge any
static electricity before connecting the cables to the instrument.
Observe ventilation requirements. Ensure good ventilation by checking the
instrument’s vent and fan regularly, to prevent overheating.

3 User Manual
This chapter contains information and warnings that must be followed to keep the
instrument operating under the appropriate safety conditions. In addition to the
safety precautions specied in this section, you must also follow recognized safety
procedures.
2.1 Safety Terms and Symbols
When the following symbols or terms appear on the front or rear panel of the
instrument or in this manual, they indicate special care in terms of safety.
This symbol is used where caution is required. Refer to the
accompanying information or documents in order to protect against
personal injury or damage to the instrument.
This symbol warns of a potential risk of shock hazard.
This symbol is used to denote the measurement ground connection.
This symbol is used to denote a safety ground connection.
This symbol shows that the switch is an On/Standby switch. When it
is pressed, the scope’s state switches between Operation and
Standby. This switch does not disconnect the device's power supply.
To completely power o the scope, the power cord must be
unplugged from the AC socket after the oscilloscope is in the
standby state.
This symbol is used to represent alternating current, or “AC”.
CAUTION The “CAUTION” symbol indicates a potential hazard. It calls
attention to a procedure, practice or condition which may be

User Manual 4
dangerous if not followed. Do not proceed until its conditions are fully
understood and met.
WARNING The “WARNING” symbol indicates a potential hazard. It calls
attention to a procedure, practice or condition which, if not followed,
could possibly cause bodily injury or death. If a WARNING is
indicated, do not proceed until the safety conditions are fully
understood and met.
WARNING: Do not operate the oscilloscope in an explosive
atmosphere or wet and damp conditions.
2.2 Working Environment
This instrument is intended for indoor use and should be operated in a clean, dry
environment with an ambient temperature range of 10 °C - 40 °C.
Note:Direct sunlight, radiators, and other heat sources should be taken into account
when assessing the ambient temperature.
The design of the instrument has been veried to conform to EN 61010-1 safety
standard per the following limits:
�Installation (overvoltage) Category: II (Mains Supply Connector) & I
(Measuring Terminals)
�Degree of Pollution: II
�Degree of Protection: I

5 User Manual
Note:
Installation (Overvoltage) Category II refers to the local distribution level, which is
applicable to equipment connected to the mains supply (AC power source).
Installation (Overvoltage) Category I refers to signal level, which is applicable to
equipment measuring terminals that are connected to source circuits in which
measures are taken to limit transient voltages to an appropriately low level.
Degree of Pollution II refers to a working environment which is dry and non-
conductive pollution occurs. Occasional temporary conductivity caused by
condensation is expected.
Degree of Protection I refers to grounded equipment, in which protection against
electric shock is achieved by basic insulation and by means of a connection to the
protective ground conductor in the building wiring.
Terminal ratings:
CAUTION: Protect the display touch screen of the scope from
excessive impact.
CAUTION: Do not exceed the maximum specied front panel terminal
(CH1, CH2, CH3, CH4, EXT) voltage levels. Refer to Terminal ratings
above for more details.
CAUTION: Do not connect or disconnect probes or test leads while they
are connected to a voltage source.
T3DSO3xx4 CH1-4 T3DSO31004 CH1-4 EXT
50Ω coupling ≥ 5Vrms ≥ 5Vrms ≥ 5Vrms
1MΩ coupling 400 Vpk max. 400 Vpk max. 50 Vpk max.
20 dB/decade from 50
kHz to 5 MHz
15 dB/decade from 10 kHz
to 1.6 MHz
20 dB/decade from 500
kHz to 5 MHz
10Vpkmaxabove5MHz 10Vpkmaxabove1.6MHz 5Vpkmaxabove5MHz

User Manual 6
2.3 Cooling Requirements
This instrument relies on the forced air cooling with internal fans and ventilation
openings. Care must be taken to avoid restricting the airow around the apertures
(fan holes) at each side of the scope. To ensure adequate ventilation it is required
to leave a 15 cm (6 inch) minimum gap around the sides of the instrument.
CAUTION: Do not block the ventilation holes located on both sides of
the scope.
CAUTION: Do not allow any foreign matter to enter the scope through
the ventilation holes, etc.
2.4 AC Power
The instrument operates with a single-phase, 100 to 240 Vrms (+/-10%) AC power
at 50/60 Hz (+/-5%), or single-phase 100 - 120 Vrms (+/-10%) AC power at 400Hz
(+/-5%).
No manual voltage selection is required because the instrument will automatically
adapt to the line voltage.
Depending on the type and number of options and accessories (probes, PC
port plug-in, etc.), the instrument can consume up to 100 W of power.
Note: The instrument will automatically adapt to the AC line input within the
following ranges:
Voltage Range: 90 - 264 Vrms 90 - 132 Vrms
Frequency Range: 47 - 63 Hz 380 - 420 Hz

7 User Manual
2.5 Power and ground connections
The instrument includes a grounded power cord with a molded three terminal
polarized plug and a standard IEC320 (Type C13) connector for making the line
voltage and safety ground connection. The AC inlet ground terminal is connected
directly to the frame of the instrument. For adequate protection against electrical
shock hazard, the power cord plug must be fully inserted into a mating AC outlet
containing a safety ground contact. Use only the power cord specied for this
instrument and certied for the country of use.
Warning: Electrical Shock Hazard!
Any interruption of the protective conductor inside or outside of the
scope, or disconnection of the safety ground terminal creates a
hazardous situation.
Intentional interruption is prohibited.
The position of the oscilloscope should allow easy access to the socket. To ensure
the oscilloscope is completely powered o, unplug the instrument power cord from
the AC socket.
The power cord should be unplugged from the AC outlet if the scope is not to be
used for an extended period of time.
CAUTION: The outer shells of the front panel terminals (CH1, CH2,
CH3, CH4, EXT) are connected to the instrument’s chassis and
therefore to the safety ground.

User Manual 8
2.6 Calibration
The recommended calibration interval is one year. Calibration should be only
performed by qualied personnel.
2.7 Cleaning
Only clean the exterior of the instrument using a damp, soft cloth. Do not use
chemicals or abrasive elements. Under no circumstances allow moisture to
penetrate the instrument. To avoid electrical shock, unplug the power cord from the
AC outlet before cleaning.
Warning: Electrical Shock Hazard!
No operator serviceable parts inside. Do not remove covers.
Refer servicing to qualied personnel
2.8 Abnormal Conditions
Only operate the instrument for the purposes specied by the manufacturer. Do not
operate the scope if there is any visible sign of damage or has been subjected to
severe transport stresses.
If you suspect the scope’s protection has been impaired, disconnect the power cord
and secure the instrument against any unintended operation.
Proper use of the instrument depends on careful reading of all instruction and
labels.
Warning: Any use of the scope in a manner not specied by the
manufacturer may impair the instrument’s safety protection. This
instrument should not be directly connected to human subjects or
used for patient monitoring.

9 User Manual
3 First steps
3.1 Delivery Checklist
First, verify that all items listed below have been delivered. If you note any omissions
or damage, please contact your nearest Teledyne LeCroy customer service center
or distributor as soon as possible. If you fail to contact us immediately in case of
omission or damage, we will not be responsible for replacement.
• 1 Oscilloscope
• 4 Passive probes
• 1 AC power cord rated for the local region
• 1 Quick Start Guide
• 1 Certicate of Calibration
• 1 Declaration of Conformity
• 1 USB cable
3.2 Quality Assurance
The oscilloscope has a 3-year warranty (1-year warranty for probe attachments)
from the date of shipment, during normal use and operation. Teledyne LeCroy can
repair or replace any product that is returned to the authorized service center during
the warranty period. We must rst examine the product to make sure that the defect
is caused by the process or material, not by abuse, negligence, accident, abnormal
conditions or operation.
Teledyne LeCroy shall not be responsible for any defect, damage, or failure caused
by any of the following:
i) Attempted repairs or installations by personnel other than Teledyne LeCroy.
ii) Connection to incompatible devices/incorrect connection.
iii) For any damage or malfunction caused by the use of non-Teledyne LeCroy
supplies. Furthermore, Teledyne LeCroy shall not be obligated to service a
product that has been modied. Spare, replacement parts, and repairs have
a 90-day warranty.

The oscilloscope's rmware has been thoroughly tested and is presumed to be
functional. Nevertheless, it is supplied without warranty of any kind covering detailed
performance. Products not made by Teledyne LeCroy are covered solely by the
warranty of the original equipment manufacturer.
3.3 Maintenance Agreement
We provide various services on the basis of maintenance agreements. We oer
extended warranties as well as installation, training, enhancement and on-site
maintenance and other services through specialized supplementary support
agreements. For details, please consult your local Teledyne LeCroy customer
service center or distributor.
4 Getting Started
4.1 Power on
T3DSO3000 provides two ways to power it on:
1. Power on Line
When the “Power on Line” option is enabled, once the oscilloscope is connected
to the AC power supply through the power cord, the oscilloscope boots
automatically. This is useful in automated or remote applications where physical
access to the instrument is dicult/impossible.
Steps for enabling the “Power on Line” function:
Utility＞Power On Line
2. Power on manually
When the "Power on Line” option is disabled, the power button on the front
panel is the only control for the power state of the oscilloscope.
User Manual 10

11 User Manual
4.2 Shut down
Press the power button to turn o the oscilloscope. Or follow the steps below:
Utility＞Shutdown
Note:
The Power button does not disconnect the oscilloscope from the AC power supply.
The only way to fully power down the instrument is to unplug the AC power cord from
the outlet. The power cord should be unplugged from the AC outlet if the scope is
not to be used for an extended period of time.
4.3 System Status
Follow the steps below to examine the software and hardware versions of the
oscilloscope.
Utility＞System Setting＞System Status
See the section “System Status” for details.

User Manual 12
5 Probe
The T3DSO3000 series oscilloscope package includes passive probes as
standard accessories. Please visit www.teledynelecroy.com for technical data and
information on the full range of probes available.
Probe Compensation
When a probe is used for the rst time, you should compensate it to match the
input channel of the oscilloscope. Non-compensated or poorly compensated
probe may increase measurement inaccuracy or error. The probe compensation
procedures are as follows:
1. Connect the coaxial cable interface (BNC connector) of passive probe to
any channel of the oscilloscope.
2. Connect the probe to the “Compensation Signal
Output Terminal” (Cal) on the front of the
oscilloscope. Connect the ground alligator clip of
the probe to the “Ground Terminal” under the
compensation signal output terminal.
3. Press the Auto Setup button.
4. Check the waveform displayed and compare it with the examples below:
5. Use a non-metallic screwdriver to adjust the low-frequency compensation
adjustment point on the probe until the waveform displayed matches the
“Perfectly compensated” example.
Under
Compensated
Perfectly
Compensated
Over
Compensated
