Teledyne Tekmar 7000
HEADSPACE Autosampler
User Manual
14-4333-000_ Rev. B
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Copyright
© 2003 Teledyne Tekmar
All rights reserved. Reproduction, adaption, or translation without permission is prohibited, except as
allowed under copyright laws.
Printed in the U.S.A.
Updated Information
The information contained in this document is subject to change without notice.
Warranty
Teledyne Tekmar makes no warranty of any kind with regard to material, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. Tekmar should not be found
liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
Trademarks
The companies indicated own the following trademarks:
Teledyne Tekmar
4736 Socialville Foster Road
Mason, Ohio 45040
USA
www.tekmar.com
Toll Free: 800-543-4461
Sales/Support: 800-874-2004
Main: 513-229-7000
Fax: [phone]
Document:
HEADSPACE Autosampler
User Manual
Publication No. 14-4333-000_Rev. B
Tekmar.... Teledyne Tekmar
Date of Publication: June, 2003
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Warranty Information
Tekmar will repair or replace any Tekmar-manufactured product found to be defective in material or
workmanship throughout the warranty period; parts and labor, F.0.8 Point of Shipment. Please refer to
the original source of purchase to ascertain the duration of the warranty period.
This program specifically excludes equipment adjustmen~ repair, or parts replacement required
because of:
• acciden~ neglec~ misuse, failure of or improper electrical power, transportation, alteration,
vandalism, fire, weather conditions, or other casualty;
• causes other than ordinary use;
• attempted repair or service of equipment by other than Tekmar Service Engineers, without prior
approval of Tekmar;
• improper servicing of equipment by other than Tekmar Service Engineers.
This program specifically excludes the following parts: supply items and mechanical wear parts-such
as bearings, seals, traps, trap heaters, syringes, septa, glassware, fittings, frits, batteries, fuses, and
light bulbs.
Equipment parts which have been repaired or replaced under this program will be covered for the
remaining unexpired portion of the original program period.
Tekmar may require the customer to return equipment to a Tekmar-authorized service facility,
transportation prepaid.
Prior to placing a service reques~ the customer may be required to run diagnostic tests as determined
by T ekmar. If services are rendered for a malfunction caused by application contamination,
non-Tekmar devices, defective gases or samples, or if service efforts to isolate the cause of a
malfunction are increased as a result of the aforementioned, Tekmar will invoice the customer on a time
and material basis for such additional service.
Tekmar will accept no responsibility for repair or replacement of any equipment without a return
authorization number, issued by Tekmar in advance.
Tekmarwill only repair or replace the defective equipmen~ and accordingly Tekmarwill not be
responsible for, or accep~ consequential or special damages, labor costs, transportation, installation,
adjustmen~ or other expenses that may arise in connection with such equipment.
T ekmar may elect at its discretion to discharge its obligation to repair or replace such defective
equipment by accepting return of said equipment and refunding to the customer the original purchase
price thereof.
This program applies to Tekmar manufactured products purchased directly from Tekmar Company.
Instruments purchased through other sources may have other terms and conditions for an assistance
program. Please refer to the original source of purchase for warranty clarification.
Any questions regarding this policy and its application should be directed to the Tekmar Service
Department in Cincinnati, 800·874·2004 (in the U.S. and Canada), or 513·247-7000 (outside the U.S. and
Canada).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents
1 Introduction
1. 1 Overview of the Section................................................................ 1-1
1. 2 Scope of the Manual..................................................................... 1-1
1. 3 How the Manual is Organized...................................................... 1-1
1.4 Assumptions................................................................................ 1-2
1.5 Conventions Used in the Manual................................................. 1-2
1.6 Figures Used in the Manual......................................................... 1-3
1. 7 ProductDescription..................................................................... 1-5
1. 8 ProductApplications.................................................................... 1-7
2 Safety and Specifications
2.1 Overview ofthe Section................................................................ 2-1
2.2 Warnings...................................................................................... 2-1
2.3 Specifications............................................................................... 2-4
3 Description of Components
3.1 Overview ofthe Instrument Components..................................... 3-1
ProgramPanel/Keypad................................................................. 3-1
RearPanel Area........................................................................... 3-4
Plumbing Assembly/Pneumatic Controls...................................... 3-6
7050 Carrousel............................................................................ 3-8
PlatenArea.................................................................................. 3-9
Electronics Card Cage................................................................. 3-10
4 Installing the 7000fl050
4.1 Overview of the Section.............................................................. 4-1
4.2 PreliminaryProcedures................................................................ 4-1
Materials Needed for Installation................................................. 4-1
PowerRequirements................................................................... 4-3
Unpacking the Instrument...........................................................
4-3
Inspecting the Instrument............................................................ 4-3
Removing the Shipping Inserts.................................................... 4-4
Placing the 7000 at Your Workstation......................................... 4-4
4.3 Pneumatic Connections............................................................... 4-5
Venting the 7000 ....................................................................... 4-5
Choosing a Gas Supply................................................................ 4-6
Connecting the Pressurization Gas Supply.................................... 4-7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Connecting the Carrier Gas Supply............................................... 4-8
Connecting the Transfer Line....................................................... 4-15
4.4 ElectronicConnections................................................................ 4-36
Setting the DIP Switches............................................................. 4-38
Replacing the ROM..................................................................... 4-40
Installing Accessory Boards........................................................ 4-42
TekLink™Option....................................................................... 4-43
RS232 Interface Option.............................................................. 4-43
4.5 Installing the 7050 Carrousel....................................................... 4-44
4.6 Changing the Sample Loop and Sample Needle.......................... 4-46
4. 7 Leak Checking the System........................................................... 4-48
4.8 Checking the Vent........................................................................ 4-52
5 Setting Pneumatics
5.1 Overview ofthe Section.............................................................. 5-1
5.2 Pneumatic Controls and Gauges on the 7000.............................. 5-3
5.3 Principles of Operation- Column Carrier Flow............................ 5-5
5.4 Principles of Operation- Vial Needle Flow.................................. 5-6
5. 5 Principles of Operation -Static Vial Pressure.............................. 5-8
5.6 Setting Vial Pressurization.......................................................... 5-10
5. 7 Setting Standby Vial Needle Flow Rate....................................... 5-11
5. 8 Setting the Variable Injection Pressure Regulator........................ 5-11
6 Loading Vials and Inserts
6.1 Overview ofthe Section............................................................... 6-1
6.2 Preparing the 7000 for 9 ml and 12 ml Vials (with 7050)............. 6-1
6.3 Preparing the 7000 for 22 ml Vials (with 7050).............. .. ........... 6-4
6.4 Preparing the 7000 for 9 ml and 12 ml Vials (without 7050)...... 6-6
6.5 Preparing the 7000 for 22 ml Vials (without 7050)..................... 6-7
6.6 Preparing Vials for Sampling...................................................... 6-8
6.7 Loading Vials into the 7000 (without 7050)................................ 6-11
6.8 Loading Vials into the 7000 (with 7050)..................................... 6-13
6.9 Unloading Vials from the 7000 (without 7050)........................... 6-14
6.10 Unloading Vials from the 7000 (with 7050)................................ 6-15
7 The Microprocessor
7.1 TheMicroprocessor.................................................................... 7-1
7.2 ProgramPanel............................................................................ 7-2
ii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8 Setting Parameters
8.1 Overview ofthe Section............................................................. 8-1
8.2 ConstantHeat Time.................................................................... 8-1
8.3 Varying GC Cycle Times and GC Cycle Time Conflict Errors..... 8-4
8.4 Constant Heat
Time and Parallel Sample Introduction- Two
7000s and One GC..................................................................... 8-5
8.5 Reviewing Method Parameter Values......................................... 8-6
8.6 Setting New Method Parameter Values...................................... 8-8
Multiple Headspace Extraction................................................... 8-10
Programming Vial Sizes............................................................. 8-20
8.7 Copying Method Parameters...................................................... 8-21
8.8 Method Optimization Mode™ (MOM)...................................... 8-22
Tracking.................................................................................... 8-27
9 Developing Methods
9.1 Overview of the Section............................................................ 9-1
9.2 Fundamentals ofHeadspace...................................................... 9-2
9.3 Injection Techniques................................................................. 9-4
9.4 Quantitation ofHeadspace........................................................ 9-8
9.5 Optimization ofHeadspace Sensitivity...................................... 9-10
9.6 Example Application Parameters.............................................. 9-24
10 Scheduling Methods/Aborting Runs
10. 1 Overview of the Section............................................................ 10-1
10.2 Scheduling Methods (7050 only).............................................. 10-1
10.3 Aborting Runs/Priority Sampling............................................... 10-5
10.4 Running an Unscheduled Automated Method............................ 10-6
11 7000 Sequence of Operation
11.1 Overview of the Section............................................................ 11-1
11.2 Sequence of Operation -Summary............................................ 11-2
11.3 Sequence of Operation- Flowchart........................................... 11-19
11.4 Valve Output Chart.................................................................. 11-20
12 Operating the 7000
12.1 Overview ofthe Section............................................................ 12-1
12.2 Steps Before Running a Method............................................... 12-2
12.3 Running SelfTests................................................................... 12-5
12.4 Aborting Runs/Priority Sampling.............................................. 12-8
12.5 Running an Unscheduled Automated Method............................ 12-9
iii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

13 Failure and Error Screens
13.1 Overview of the Section........................................................... 13-1
13 .2 Error: Vials in Platen................................................................ 13-1
13.3 Power Fail During Cycle- Kept Memory.................................. 13-3
13.4 Power Fail- Memory Lost- Reset Clock.................................. 13-4
13.5
Error- GC Cycle Time Conflict............................................... 13-6
13.6 Failure- Thermocouple Open................................................... 13-7
13.7 Failure -Setpoint Not Reached................................................. 13-8
13.8 Fatal Failure- Platen Motor...................................................... 13-9
13.9 Fatal Failure- Carrousel Motor................................................. 13-11
13.10 Fatal Failure- Vial Loader....................................................... 13-12
13.11 Fatal Failure -Sample Loader................................................... 13-13
13.12 Fatal Failure -Vial Loader ....................................................... 13-14
13.13 Fatal Failure- Mixer Sensor..................................................... 13-15
13.14 Fatal Failure- Carrousel Index................................................ 13-16
13.15 Fatal Failure- Platen (or Carrousel) Motor............................. 13-17
14 Routine Procedures and Maintenance
14.1 Overview ofthe Section............................................................ 14-1
14.2 Reviewing and Changing Instrument and Accessory
Configurations .........................................................................
14-1
14.3 Changing the Viewing Angle ofthe Screen.............................. 14-2
14.4 Reviewing and Resetting the Clock..........................................
14-3
14.5 Locking the Keypad................................................................. 14-4
14.6 Cleaning the 7000.................................................................... 14-6
14.7 Cleaningthe7050.................................................................... 14-6
15 Troubleshooting
15.1 Overview ofthe Section........................................................... 15-1
15.2 Viewing the Sensor Screen....................................................... 15-2
15.3 Using the Motor Test Mode Screen..........................................
15-3
15.4 VerifyingOutputs...................................................................... 15-4
15.5 Troubleshooting Flow Charts.................................................... 15-4
15.6 Expediting the Troubleshooting Process.................................... 15-18
16 Service and Replacement Parts
16.1 Contacting Tekmar Service........................................................ 16-1
16.2 Replacement Parts and Accessories............................................ 16-2
Diagrams
Index
iv
Glossary
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Essential
Instructions
Please read this
page before
proceeding!
Tekrnar designs, manufactures, and tests its products to meet many
national and international standards. Because the 7000 Headspace
Autosampler/7050 Carrousel is a sophisticated technical product, you
must properly install, use, and maintain the instrument to ensure that
they continue to operate within their normal specifications. Also, you
must adhere to and integrate the following instructions into your safety
program when installing, using, and maintaining these Tekrnar products.
Failure to follow the proper instructions may invalidate the warranty.
• Read all instructions prior to installing, operating, and servicing the
product. Follow all warnings, cautions, and instructions marked on
and supplied with the product and in this manual. If you do not
understand any
of the instructions, contact your Tekrnar representa-
tive for clarification.
• Educateyour personnel in the proper installation, operation, and
maintenance
of the product -- only qualified personnel should install,
operate, update, program, and maintain the product.
• Install your equipment as specified in the installation section of this
manual and according to applicable local and national codes.
Connect all products to the proper electrical and pressure sources.
• When replacement parts are required, ensure that qualified indi-
viduals use replacement parts specified by Tekrnar. Unauthorized
parts and procedures can affect the product's performance and
jeopardize safety. Using look-alike substitutions may result in fire,
electrical hazards,
or improper operation.
• Ensure that all equipment doors are closed and protective covers are
in place -- except when maintenance is being performed
by qualified
persons -- to prevent electrical shock and personal injury.
v
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1.1 Overview of the
Section
1.2 Scope of the
Manual
1.3 How the Manual
is Organized
700Dn050 Instruction Manual
Introduction 1
This section of the 7000/7050 User Manual explains the manual and its
organization. It also lists the figures used throughout the document and
includes a description
of the 7000/7050 and a summary of its applications.
This manual describes the
TekmarTM 7000 Headspace Autosampler and
7050 Carrousel and tells you how to:
• Install the instrument
• Set optimum pneumatics
• Develop methods
• Schedule methods
• Load vials
• Operate the instrumentfrom startup to shutdown
• Perform routine maintenance and troubleshooting procedures
• Order replacement parts and service support
The manual is organized into 19 main sections.
Section
Topics
Section 1- Introduction is an overview of the manual organization. It
describes the autosampler, its operation and applications.
Section 2- Safety Information and Specifications warns of possible safety
hazards and lists product specifications.
Section 3- Description of Components briefly describes major
components of the instrument.
Section 4- Installing the 7000/7050 includes such procedures as
unpacking, pneumatic/electronic connections, leak checking.
Section 5- Setting Pneumatics explains how to determine static vial
pressure, set flow rates, and other related topics.
Section 6-
Loading Vials and Inserts tells you how to prepare and load
vials into the 7050 carrousel or the 7000 platen.
Section 7- The Microprocessor explains the program panel and keypad.
Section 8- Setting Parameters tells you how to run self tests, review,
change, and copy parameter values, and perform other tasks.
Section 9- Developing Methods explains the steps - and your options -
in developing methods for the 7000/7050.
1-1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1 Introduction
1.4 Assumptions
1.5 Conventions Used
in the Manual
& DANGER
& WARNING
& CAUTION
Note:
1-2
Section
Topics
Section 10-
Scheduling Methods/Aborting Runs discusses scheduling
methods, and unscheduled automated runs.
Section 11 -
Sequence of Operation describes the 7000 program steps.
Section 12-
Operating the 7000 has step-by-step instructions for
running the instrument
Section 13-
Failure and Error Screens describes the errors you may
encounter when operating the instrument.
Section 14-
Routine Procedures and Maintenance covers cleaning,
instrument adjustments, and leak checking.
Section 15-
Troubleshooting lists potential problems and solutions.
Section 16-
Service and Replacement Parts tells you how to contact
T ekmar for service support and replacement parts.
Section 17-
Diagrams includes wiring and flow diagrams.
Section 18-
Index is a listing of key topics and their location.
Section 19-
Glossary provides a definition of technical terms.
The manual assumes that you are familiar with gas chromatography
technology and somewhat familiar with static headspace technology.
To help you locate and interpret information more easily, the manual
uses certain typefaces and symbols with specific meanings, including:
This symbol alerts you to a situation where incorrect operation
of the
7000 could result in electrical shock or other serious hazard and
cause severe and permanent personal injury as well as damage to your
equipment.
This symbol points out a situation where incorrect operation could result
in personal injury and equipment damage.
This symbol indicates that incorrect operation could lead to equipment
damage.
The "notes" throughout the text point outvery useful information.
7000H050 Instruction Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1.6 Figures Used in
the Manual
70oonoso Instruction Manual
The following figures are included in the manual:
Figure# Description
1-1
7000 Headspace Autosampler w/ 7050 Carrousel
3-1
7000/7050 Components
3-2
7000 Keypad
3-3
7000/7050 Rear View
3-4 Valve Oven and Plumbing Assembly
3-5 Valve Oven
3-6 Pneumatic Controls
3-7 7050 Carrousel
3-8
Platen Area
3-9
Electronics Card Cage
4-1
Location of Platen Shipping Inserts
4-2
Typical Pressurization Gas Connection
4-3
Carrier Gas Connection
4-4
Flow Element Location
4-5 Carrier Gas Connection
4-6
GC-Supplied Carrier Gas Connections
4-7
Septum Needle Adapter
4-8
Low Volume Injector Assembly
4-9
Cryofocusing Module
4-10
VIPR Connections
4-11
VIPR Connections
4-12
VIPR Back View
4-13
VIPR Front View
4-14
7000 Interface Board
4-15
DIP Switch Settings
4-16
ZIF Socket/ROM Chip Orientation
4-17
7050 Carrousel Installation
4-18
Valve Oven Area
5-1 7000 Flow Diagram
5-2
Pneumatic Controls and Gauges
5-3
7000 Pneumatic Controls
5-4 Valve Configuration of the 7000 in Standby Mode
5-5
Vial Needle Flow Rate and Vial Pressure
5-6 7000 Flow in Vial Pressurization Mode
6-1 Carrousel Collar Location
6-2
Platen Chambers
6-3 Properly Sealed Vial
6-4 Undercrimped Vial
Introduction 1
Page#
1-6
3-1
3-3
3-5
3-6
3-7
3-7
3-8
3-9
3-11
4-4
4-7
4-9
4-10
4-12
4-14
4-22
4-28
4-31
4-34
4-35
4-35
4-35
4-37
4-39
4-41
4-45
4-46
5-2
5-3
5-4
5-6
5-7
5-9
6-1, 6-4
6-2
6-8
6-8
continued
1-3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1 Introduction
Figure# I Description I Page#
6-5
Overcrimped Vial
6-9
6-6
Hand Crimper and Vial
6-10
7-1
7000 Keypad 7-2
7-2
7000 Numbered Keypad
7-3
9-1
Full Evaporation Technique
9-5
9-2
Parameter Optimization Kit 9-7
9-3
Equilibration Curve
9-12
9-4
Non-Equilibrating Sample
9-12
9-5
Parameter Worksheet
9-21
11-1
7000 Flow Diagram
11-2
11-2
7000 Screen and Flow in Standby Mode
11-4
11-3
7000 Screen and Flow in Sample Equilibrate Mode
11-7
11-4
Equilibration Curve
11-8
11-5
Non-Equilibrating Sample
11-8
11-6 Screens and Flow in Mixing Mode
11-9
11-7
Screen and Flow in Stabilize Mode
11-10
11-8
Screen and Flow in Pressurize Mode
11-11
11-9
Screen and Flow in Pressure Equilibrate Time Mode
11-12
11-10
Screen and Flow in Loop Fill Mode
11-13
11-11
Screen and Flow in Loop Equilibrate Time Mode
11-14
11-12 Flow in Inject Mode
11-17
11-13
Screen and Flow in Re-Equil Mode
11-18
17-1
7000 Sampling Sequence
17-1
17-2
7000 Wiring Diagram Page 1
17-2
17-3
7000 Wiring Diagram Page 2
17-3
17-4
7000 Flow Diagram
17-4
17-5
7000 Valve Plumbing Assembly Page 1
17-5
17-6
7000 Valve Plumbing Assembly Page 2
17-6
1-4 700017050 Instruction Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1.7 Product
Description
7ooonoso Instruction Manual
Introduction 1
The Tekmar™ 7000 Headspace Autosampler is a microprocessor-
controll~d automatic sampler that is designed to improve sensitivity/
precision in gas chromatographic
or Gel spectrometry analysis of volatile
compounds in a wide range
of samples.
The 7000 is built upon the "static" headspace (as compared to the "dy-
namic" purge and trap) sampling technique. The 7000 removes volatile
compounds from a non-volatile matrix and injects them into the gas chro-
matograph in vapor form.
Ingeneral terms, the instrument works like this:
• The sealed vial, containing the sample, is lowered into the
electrically-heated sample platen. The platen can hold and heat up to
12 vials simultaneously.
• During the heating time, the volatile compounds in the sample
partition into the vial's atmosphere, known as the "headspace."
• When the platen has reached the temperature setpoint -- and the rate
of analytes going into the gas phase is equal to the rate of analytes
returning -- the system reaches a state
of equilibrium.
• The vial is pressurized with gas to a setvalue.
• The gas in the sample vial exits through the sample loop to the
atmosphere, as the loop is filled with sample vapor.
• At equilibrium, the 7000 extracts the compounds (in vapor form)
from the headspace
of the vial, then injects them through the sample
transfer line into the gas chromatograph for analysis. During injection,
there is precise control
of sampling pressure, volume, and tempera-
ture, which greatly increases quantitation -- and therefore reliability --
of the sampling run.
With the Tekmar™ 7050 Carrousel installed, the 7000 can automatically
control the sample sequencing
of up to 50 vials. These samples can be
programmed to run under "Constant Heat Time™", a feature that provides
equal thermal exposure to each sample. Constant HeatTime reduces
overall analysis time and increases the number
of samples that can be run,
improving lab productivity.
The 7000's screen displays menus that allow you to choose from various
options for scheduling and editing methods, setting parameters,
testing internal components, etc.
continued
1-5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1 Introduction
1-6
The optional TekLink™software/hardware package connects the 7000
to a PC and allows for complete remote control of the GC, data collec-
tion system, and the 7000. TekLink operates with Microsoft®
Windows™.
Additional standard features such as Method Optimization Mode™
allowyou to easily increment the optimal time, temperature, and mix
power settings for a given sampling run.
The 7000's "valve and loop" sampling design offers increased precision
and reproducibility
of injection volume. The exclusive PV rr Injector™
in the 7000 valve oven ensures precise control of injection pressure,
volume
and temperature.
Carryover is kept to a minimum because the 7000 automatically
performs a carrier-gas sweep to clean all sample lines between injec-
tions. Sample loops are interchangeable; the 7000 can accommodate
stainless steel, E-Form,
or Polar option sample loops in various sizes.
Flow elements are also interchangeable, giving you four different
ranges from one flow controller and the ability to set the optimal flow
rate best suited to your specific column type and size.
Controls/Gauges
Program Panel Keypad
Base Unit
7050 Carrousel
Figure 1-1 Tekmarm 7000 Headspace Autosampler
with 7050 Carrousel
700Dn050 Instruction Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1.8 Product
Applications
7000fi050 Instruction Manual
Introduction 1
The Tekmar™ 7000 Headspace Autosampler/7050 Carrousel system retains
sensitivity and precision in the analysis
of volatile components.
The 7000's primary applications are:
• Environmental screening of soils, water, and solid wastes
The 7000 is ideal for screening and direct analysis of priority
pollutants and
BTEX samples.
• Blood alcohol and forensic medicine
The 7000 ensures accurate identification and quantitation of
levels of ethanol, acetone, and other toxins in blood and
other biological samples.
• Monomers in polymers and residuals in food packaging
materials
Residuals in packing materials such as ethane, propane, and
propylene can
be easily and accurately quantitated.
• Residual solvents in pharamaceutical tablets and capsules
The 7000/GC process allows for routine monitoring of volatile
organic impurities in bulk pharmaceuticals and excipients.
• Flavors in foods and beverages
Flavor profiling determines the composition and taste of fruit,
wine, spices, coffee, soda, cheese, beer, and other foods and
beverages.
The static headspace technique around which the 7000 is designed
improves sensitivity
of the lighter compounds including HCN, S0
2,
butadiene, as compared to analysis of these compounds by liquid injection.
Static headspace technology is also ideal for semi-volatile organics such as
pyridine, di- and tri-chlorobenzenes, etc.
Through precise positioning and control of the heating process (as well as
through proper insulation), the 7000 maintains accuracy in sample tempera-
ture within 0.1
oc between samples.
Several
of the features built into the 7000, including Method Optimization
Mode™, Optimix™ Equilibration, Multiple Headspace Extraction, Re-
Equilibration, Constant Heat Time, and Full Evaporation Technique, also
help ensure optimal analytical results. All
of these features are discussed in
more detail in later sections
of this instruction manual.
If you have questions about the 7000/7050 as it relates to your particular
application, please call Tekmar at [phone] to speak with an
Applications Chemist.
1-7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2.1 Overview of
the Section
2.2 Warnings
7000!7050 Instruction Manual
Safety Information & Specifications 2
The first three pages of this section describe safety and operation issues
to be aware
of before operating the 7000/7050. The last part of Section 2
covers instrument specifications.
~ DANGER
Never connect a flammable gas (such as hydrogen) to
the pressurize bulkhead fitting on the rear of the 7000.
Venting ofthis gas in the Standby mode creates an
explosion or fire hazard.
~WARNING ~
Electrical shock hazard inside this instrument.
Unplug power cord before servicing.
~WARNING -·
It is recommended that safety glasses be worn at all
times when operating the 7000. Heated sample vials are
under pressure during normal operations. An inadvertent
over-pressurization
could cause a vial to burst.
~WARNING d.
This instrument contains heating elements. Touching
any heated zone during operation could cause a burn.
(The system's heaters will come on anytime their
setpoints
are above ambient temperature.) When
operating the 7000, keep all instrument panels fastened.
~ WARNING
The dust cover shipped with the 7050 (50-Position
Carrousel) must be installed before operating the
system. The cover protects the carrousel and also
protects the operator by providing a safety shield in
the event that an overpressurized vial would burst.
2-1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2 Safety Information & Specifications
2-2
£ WARNING
Be alert for environmental, shock, or other hazards in the
event that a vial would break inside the instrument. Before
cleaning up, unplug the instrument and determine the
nature of the sample that has spilled. Use extreme caution
and apply the appropriate clean-up measures.
£ WARNING d.
Always use the insert removal tool (Tekmar p/n
14-4365-027) when removing inserts from the platen. The
inserts are at the same temperature as the platen heater
and may cause a burn if handled improperly.
£ WARNING
Use extreme care when handling hot vials, particularly when
unloading vials from the 7000withoutthe 7050. Improper
handling of the hot vials may cause a burn.
£ WARNING __}
~
When the 7050 carrousel is indexing, do not place hands
between the carrousel and the valve oven area.
£ WARNING
Do not over-pressurize or over-heat samples during
operation. Extreme static pressure build-up in a vial due
to excess pressure levels or heat settings could cause a
vial toburst.
£ WARNING
When accessing the valve oven area, be certain that the
valve is cool before opening the cover.
7000fl050 Instruction Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
